Mitsubishi Electric GOT1000 GT14 User manual

GT14 User,s Manual

A - 1
SAFETY PRECAUTIONS
(Always read these precautions before using this equipment.)
Before using this product, please read this manual and the relevant manuals introduced in this manual
carefully and pay full attention to safety to handle the product correctly.
The precautions given in this manual are concerned with this product.
In this manual, the safety precautions are ranked as "WARNING" and "CAUTION".
Note that the caution level may lead to a serious accident according to the circumstances.
Always follow the instructions of both levels because they are important to personal safety.
Please save this manual to make it accessible when required and always forward it to the end user.
[DESIGN PRECAUTIONS]
WARNING
●Some failures of the GOT, communication unit or cable may keep the outputs on or off.
Some failures of a touch panel may cause malfunction of the input objects such as a touch switch.
An external monitoring circuit should be provided to check for output signals which may lead to a
serious accident.
Not doing so can cause an accident due to false output or malfunction.
●If a communication fault (including cable disconnection) occurs during monitoring on the GOT,
communication between the GOT and PLC CPU is suspended and the GOT becomes inoperative.
A system where the GOT is used should be configured to perform any significant operation to the
system by using the switches of a device other than the GOT on the assumption that a GOT
communication fault will occur.
Not doing so can cause an accident due to false output or malfunction.
●Do not use the GOT as the warning device that may cause a serious accident.
An independent and redundant hardware or mechanical interlock is required to configure the device
that displays and outputs serious warning.
Failure to observe this instruction may result in an accident due to incorrect output or malfunction.
●Incorrect operation of the touch switch(s) may lead to a serious accident if the GOT backlight is gone
out.
When the GOT backlight goes out, the POWER LED blinks (green/orange) and the display section
dims, while the input of the touch switch(s) remains active.
This may confuse an operator in thinking that the GOT is in "screensaver" mode, who then tries to
release the GOT from this mode by touching the display section, which may cause a touch switch to
operate.
Note that the following occurs on the GOT when the backlight goes out.
• The POWER LED flickers (green/orange) and the monitor screen appears blank.
WARNING Indicates that incorrect handling may cause hazardous conditions,
resulting in death or severe injury.
CAUTION Indicates that incorrect handling may cause hazardous conditions,
resulting in medium or slight personal injury or physical damage.

A - 2
[DESIGN PRECAUTIONS]
WARNING
●The display section is an analog-resistive type touch panel.
If you touch the display section simultaneously in 2 points or more, the switch that is located around
the center of the touched point, if any, may operate.
Do not touch the display section in 2 points or more simultaneously.
Doing so may cause an accident due to incorrect output or malfunction.
●When programs or parameters of the controller (such as a PLC) that is monitored by the GOT are
changed, be sure to reset the GOT or shut off the power of the GOT at the same time.
Not doing so can cause an accident due to false output or malfunction.
●To maintain the security (confidentiality, integrity, and availability) of the GOT and the system against
unauthorized access, DoS*1 attacks, computer viruses, and other cyberattacks from unreliable
networks and devices via network, take appropriate measures such as firewalls, virtual private
networks (VPNs), and antivirus solutions.
Mitsubishi Electric shall have no responsibility or liability for any problems involving GOT trouble and
system trouble by unauthorized access, DoS attacks, computer viruses, and other cyberattacks.
*1 DoS: A denial-of-service (DoS) attack disrupts services by overloading systems or exploiting
vulnerabilities, resulting in a denial-of-service (DoS) state.
CAUTION
●Do not bundle the control and communication cables with main-circuit, power or other wiring.
Run the above cables separately from such wiring and keep them a minimum of 100mm apart.
Not doing so noise can cause a malfunction.
●Do not press the GOT display section with a pointed material as a pen or driver.
Doing so can result in a damage or failure of the display section.
●When the GOT is connected to the Ethernet network, the available IP address is restricted according
to the system configuration.
• When multiple GOTs are connected to the Ethernet network:
Do not set the IP address (192.168.0.18) for the GOTs and the controllers in the network.
• When a single GOT is connected to the Ethernet network:
Do not set the IP address (192.168.0.18) for the controllers except the GOT in the network.
Doing so can cause the IP address duplication. The duplication can negatively affect the
communication of the device with the IP address (192.168.0.18).
The operation at the IP address duplication depends on the devices and the system.
●Turn on the controllers and the network devices to be ready for communication before they
communicate with GOT.
Failure to do so can cause a communication error on the GOT.

A - 3
[MOUNTING PRECAUTIONS]
WARNING
●Be sure to shut off all phases of the external power supply used by the system before mounting or
removing the GOT to/from the panel.
Not switching the power off in all phases can cause a unit failure or malfunction.
CAUTION
●Use the GOT in the environment that satisfies the general specifications described in the User's
Manual.
Not doing so can cause an electric shock, fire, malfunction or product damage or deterioration.
●When mounting the GOT to the panel, tighten the mounting screws within the specified torque range.
Undertightening can cause the GOT to drop, short or malfunction. Also, undertightening can disable
waterproof or oil proof effect.
Overtightening can cause a drop, short circuit or malfunction due to the damage of the screws or the
GOT.
Also, "distortion" of the GOT or the panel may disable waterproof or oil proof effect.
●Never drop cutting chips and electric wire chips into the ventilation window of the GOT when you drill
screw holes or perform wiring.
Otherwise, fire, failure or malfunction may be caused.
●When inserting/removing a SD card into/from the GOT, turn the SD card access switch off in
advance.
Failure to do so may corrupt data within the SD card.
●When removing a SD card from the GOT, make sure to support the SD card by hand, as it may pop
out.
Failure to do so may cause the SD card to drop from the GOT and break.
●When installing a USB memory to the GOT, make sure to install the USB memory to the USB
interface firmly.
Failure to do so may cause a malfunction due to poor contact.
●Before removing the USB memory from the GOT, operate the utility screen for removal.
After the successful completion dialog box is displayed, remove the memory by hand carefully.
Failure to do so may cause the USB memory to drop, resulting in a damage or failure of the memory.
●Operate and store the GOT in environments without direct sunlight, high temperature, dust, humidity,
and vibrations.
●When using the GOT in the environment of oil or chemicals, use the protective cover for oil.
Failure to do so may cause failure or malfunction due to the oil or chemical entering into the GOT.

A - 4
[WIRING PRECAUTIONS]
[TEST OPERATION PRECAUTIONS]
WARNING
●Be sure to shut off all phases of the external power supply used by the system before wiring.
Failure to do so may result in an electric shock, product damage or malfunctions.
●Always ground the FG terminal of the GOT power to the protective ground conductors dedicated to
the GOT.
Not doing so may cause an electric shock or malfunction.
●Correctly wire the GOT power supply section after confirming the rated voltage and terminal
arrangement of the product.
Not doing so can cause a fire or failure.
●Tighten the terminal screws of the GOT power supply section in the specified torque range.
Undertightening can cause a short circuit or malfunction.
Overtightening can cause a short circuit or malfunction due to the damage of the screws or the GOT.
●Exercise care to avoid foreign matter such as chips and wire offcuts entering the GOT.
Not doing so can cause a fire, failure or malfunction.
CAUTION
●The cables connected to the unit must be run in ducts or clamped.
Not doing so can cause the unit or cable to be damaged due to the dangling, motion or accidental
pulling of the cables or can cause a malfunction due to a cable connection fault.
●When unplugging the cable connected to the unit, do not hold and pull the cable portion.
Doing so can cause the unit or cable to be damaged or can cause a malfunction due to a cable
connection fault.
●Plug the communication cable into the connector of the connected unit and tighten the mounting and
terminal screws in the specified torque range.
Undertightening can cause a short circuit or malfunction. Overtightening can cause a short circuit or
malfunction due to the damage of the screws or unit.
WARNING
●Before performing the test operations of the user creation monitor screen (such as turning ON or
OFF bit device, changing the word device current value, changing the settings or current values of
the timer or counter, and changing the buffer memory current value), read through the manual
carefully and make yourself familiar with the operation method.
During test operation, never change the data of the devices which are used to perform significant
operation for the system.
False output or malfunction can cause an accident.

A - 5
[STARTUP/MAINTENANCE PRECAUTIONS]
WARNING
●When power is on, do not touch the terminals.
Doing so can cause an electric shock or malfunction.
●Correctly connect the battery connector.
Do not charge, disassemble, heat, short-circuit, solder, or throw the battery into the fire.
Doing so will cause the battery to produce heat, explode, or ignite, resulting in injury and fire.
●Before starting cleaning or terminal screw retightening, always switch off the power externally in all
phases.
Not switching the power off in all phases can cause a unit failure or malfunction.
Undertightening can cause a short circuit or malfunction.
Overtightening can cause a short circuit or malfunction due to the damage of the screws or unit.
CAUTION
●Do not disassemble or modify the unit.
Doing so can cause a failure, malfunction, injury or fire.
●Do not touch the conductive and electronic parts of the unit directly.
Doing so can cause a unit malfunction or failure.
●Do not drop or apply strong impact to the unit.
Doing so may damage the unit.
●Do not drop or give an impact to the battery mounted to the unit.
Doing so may damage the battery, causing the battery fluid to leak inside the battery.
If the battery is dropped or given an impact, dispose of it without using.
●For repair of the backlight, contact your local Mitsubishi (Electric System) Service.
●Before touching the unit, always touch grounded metal, etc. to discharge static electricity from
human body, etc.
Not doing so can cause the unit to fail or malfunction.
●Replace battery with GT11-50BAT by Mitsubishi electric Co. only.
Use of another battery may present a risk of fire or explosion.
●Dispose of used battery promptly.
Keep away from children. Do not disassemble and do not dispose of in fire.

A - 6
[DISPOSAL PRECAUTIONS]
[TOUCH PANEL PRECAUTIONS]
[TRANSPORTATION PRECAUTIONS]
CAUTION
●When disposing of the product, handle it as industrial waste.
●When disposing of this product, treat it as industrial waste. When disposing of batteries, separate
them from other wastes according to the local regulations.
(For details of the battery directive in EU member states, refer to the User's Manual of the GOT to be
used.)
CAUTION
●For the analog-resistive film type touch panels, normally the adjustment is not required. However,
the difference between a touched position and the object position may occur as the period of use
elapses. When any difference between a touched position and the object position occurs, execute
the touch panel calibration.
●When any difference between a touched position and the object position occurs, other object may be
activated. This may cause an unexpected operation due to incorrect output or malfunction.
CAUTION
●When transporting lithium batteries, make sure to treat them based on the transport regulations.
(For details on models subject to restrictions, refer to the User's Manual for the GOT you are using.)
●Before transporting the GOT, turn the GOT power on and check that the battery voltage status is
normal on the Time setting & display screen (utilities screen). In addition, confirm that the adequate
battery life remains on the rating plate.
Transporting the GOT with the low battery voltage or the battery the reached battery life may
unstabilize the backup data unstable during transportation.
●Make sure to transport the GOT main unit and/or relevant unit(s) in the manner they will not be
exposed to the impact exceeding the impact resistance described in the general specifications of the
User's Manual, as they are precision devices.
Failure to do so may cause the unit to fail.
Check if the unit operates correctly after transportation.

A - 7
SAFETY PRECAUTIONS .........................................................................................................................A - 1
INTRODUCTION ......................................................................................................................................A - 7
CONTENTS ..............................................................................................................................................A - 7
MANUALS...............................................................................................................................................A - 13
QUICK REFERENCE ............................................................................................................................. A - 13
ABBREVIATIONS AND GENERIC TERMS ...........................................................................................A - 15
HOW TO READ THIS MANUAL .............................................................................................................A - 20
1. OVERVIEW
1.1 Features........................................................................................................................................... 1 - 2
1.1.1 Rough procedure.................................................................................................................. 1 - 3
2. SYSTEM CONFIGURATION
2.1 Overall Configuration ....................................................................................................................... 2 - 1
2.2 System Equipment........................................................................................................................... 2 - 1
2.2.1 GOT (GT14) ......................................................................................................................... 2 - 2
2.2.2 Option ................................................................................................................................... 2 - 3
3. SPECIFICATIONS
3.1 General Specifications..................................................................................................................... 3 - 1
3.2 Performance Specifications ............................................................................................................. 3 - 2
3.3 Power Supply Specifications ........................................................................................................... 3 - 3
4. PARTS NAME
4.1 Front Panel ...................................................................................................................................... 4 - 1
4.2 Back Panel....................................................................................................................................... 4 - 2
4.3 Rear Face ........................................................................................................................................ 4 - 3
5. UL, cUL STANDARDS AND EMC DIRECTIVE
5.1 UL, cUL Standards .......................................................................................................................... 5 - 1
5.2 EMC Directive.................................................................................................................................. 5 - 1
5.2.1 Requirements to Meet EMC Directive .................................................................................. 5 - 2
5.2.2 EMC Directive-Compliant System Configuration.................................................................. 5 - 4
5.2.3 Precautions for Wiring/Connecting the EMC Directive-Compliant Product .......................... 5 - 5
INTRODUCTION
Thank you for choosing Mitsubishi Electric Graphic Operation Terminal (GOT).
Read this manual and make sure you understand the functions and performance of the GOT thoroughly
in advance to ensure correct use.
CONTENTS

A - 8
6. INSTALLATION
6.1 Control Panel Inside Dimensions for Mounting GOT....................................................................... 6 - 1
6.2 Panel Cutting Dimension ................................................................................................................. 6 - 2
6.3 Mounting Position ............................................................................................................................ 6 - 2
6.4 Control Panel Temperature and Mounting Angle ............................................................................ 6 - 3
6.5 Installation Procedure ...................................................................................................................... 6 - 4
7. WIRING
7.1 Power Supply Wiring ....................................................................................................................... 7 - 2
7.1.1 Wiring example ..................................................................................................................... 7 - 2
7.1.2 Grounding the GOT .............................................................................................................. 7 - 2
7.1.3 The cause of malfunctions related wiring/Remedy ............................................................... 7 - 3
7.2 Wiring inside and outside the panel................................................................................................. 7 - 5
7.2.1 Wiring inside ......................................................................................................................... 7 - 5
7.2.2 Outside the panel.................................................................................................................. 7 - 5
7.2.3 Attaching surge killers to control equipment ......................................................................... 7 - 6
8. OPTION
8.1 SD Card ........................................................................................................................................... 8 - 1
8.1.1 Applicable SD card ............................................................................................................... 8 - 1
8.1.2 Installing and removing procedures of the SD card.............................................................. 8 - 1
8.2 USB Memory ................................................................................................................................... 8 - 3
8.2.1 Applicable USB memory....................................................................................................... 8 - 3
8.2.2 Installing and removing procedures of the USB memory ..................................................... 8 - 3
8.3 Battery ............................................................................................................................................. 8 - 4
8.3.1 Applicable battery ................................................................................................................. 8 - 4
8.3.2 Battery specifications............................................................................................................ 8 - 4
8.3.3 Battery replacement procedure ............................................................................................ 8 - 5
8.4 Protective Sheet .............................................................................................................................. 8 - 6
8.4.1 Applicable protective sheet................................................................................................... 8 - 6
8.4.2 Installing procedure .............................................................................................................. 8 - 6
8.5 Protective Cover for Oil.................................................................................................................... 8 - 7
8.5.1 Applicable protective cover for oil ......................................................................................... 8 - 7
8.5.2 Installing procedure .............................................................................................................. 8 - 7
8.6 USB Environmental Protection Cover.............................................................................................. 8 - 9
8.6.1 Applicable USB environmental protection cover................................................................... 8 - 9
8.6.2 Installing procedure .............................................................................................................. 8 - 9
8.7 Stand ............................................................................................................................................. 8 - 10
8.7.1 Applicable stand ................................................................................................................. 8 - 10
8.7.2 Installing procedure ............................................................................................................ 8 - 10
8.8 Connector Conversion Adapter ..................................................................................................... 8 - 11
8.8.1 Applicable connector conversion adapter........................................................................... 8 - 11
8.8.2 Installing procedure of connector conversion adapter ........................................................ 8 - 11
8.9 Serial Multi-Drop Connection Unit ................................................................................................. 8 - 12
8.9.1 Serial multi-drop connection unit ........................................................................................ 8 - 12
8.9.2 Applicable serial multi-drop connection unit ....................................................................... 8 - 12
8.9.3 Installation........................................................................................................................... 8 - 12

A - 9
8.9.4 Parts name ......................................................................................................................... 8 - 13
8.9.5 Caution for compliance with EMC Directive ....................................................................... 8 - 13
8.10 Panel-Mounted USB Port Extension.............................................................................................. 8 - 14
8.10.1 Applicable panel-mounted USB port extension .................................................................. 8 - 14
8.10.2 Parts name ......................................................................................................................... 8 - 14
8.10.3 Installing procedure ............................................................................................................ 8 - 14
8.11 RS-232/485 Signal Conversion Adapter........................................................................................8-16
8.11.1 Applicable RS-232/485 signal conversion adapter............................................................. 8 - 16
8.11.2 Installing procedure of RS-232/485 signal conversion adapter .......................................... 8 - 16
9. UTILITY FUNCTION
9.1 Utility Execution ............................................................................................................................... 9 - 1
9.2 Utility Function List........................................................................................................................... 9 - 2
9.3 Utility Display ................................................................................................................................... 9 - 4
9.3.1 Display operation of main menu ........................................................................................... 9 - 6
9.3.2 Utility basic configuration...................................................................................................... 9 - 8
9.3.3 Basic operation of settings change....................................................................................... 9 - 9
10. COMMUNICATION INTERFACE SETTING (COMMUNICATION SETTING)
10.1 Communication setting .................................................................................................................. 10 - 1
10.1.1 Communication setting functions........................................................................................ 10 - 1
10.1.2 Display operation of Communication Setting...................................................................... 10 - 1
10.1.3 Communication setting contents ........................................................................................ 10 - 2
10.1.4 Communication setting operation ....................................................................................... 10 - 4
10.2 Communication Detail Setting ....................................................................................................... 10 - 8
10.2.1 Communication detail setting functions .............................................................................. 10 - 8
10.2.2 Display operation of Communication Detail setting ............................................................ 10 - 8
10.2.3 Display contents of Communication Detail setting ........................................................... 10 - 10
10.3 Ethernet Setting ........................................................................................................................... 10 - 15
10.3.1 Ethernet setting functions ................................................................................................. 10 - 15
10.3.2 Display operation of Ethernet setting................................................................................ 10 - 15
10.3.3 Display contents of Ethernet setting ................................................................................. 10 - 16
11. DISPLAY AND OPERATION SETTINGS (GOT SET UP)
11.1 Display Setting............................................................................................................................... 11 - 1
11.1.1 Function of Display ............................................................................................................. 11 - 1
11.1.2 Display operation of Display ............................................................................................... 11 - 2
11.1.3 Display operations .............................................................................................................. 11 - 3
11.2 Operation Setting (Settings Regarding Operation) ........................................................................ 11 - 6
11.2.1 Operation setting functions................................................................................................. 11 - 6
11.2.2 Display operation of Operation ........................................................................................... 11 - 7
11.2.3 Setting operation of operation ............................................................................................11-8
11.2.4 Security level change ......................................................................................................... 11 - 9
11.2.5 Utility Call Key Setting ...................................................................................................... 11 - 11
11.2.6 Adjusting the touch panel position (Touch panel calibration) ........................................... 11 - 13
11.2.7 USB mouse/keyboard setting ........................................................................................... 11 - 15
11.2.8 VNC(R) server function setting......................................................................................... 11 - 17
11.3 Transparent Mode Setting ........................................................................................................... 11 - 18
11.4 Backup/Restoration Setting ......................................................................................................... 11 - 19

A - 10
11.5 Behavior of Duplicate IPs ............................................................................................................ 11 - 22
11.6 License Management .................................................................................................................. 11 - 25
12. CLOCK SETTINGS AND BATTERY STATUS DISPLAY
(TIME SETTING AND DISPLAY)
12.1 Time Setting and Display............................................................................................................... 12 - 1
12.1.1 Time setting and display functions...................................................................................... 12 - 1
13. FILE DISPLAY AND COPY(PROGRAM/DATA CONTROL)
13.1 Data Storage Location ................................................................................................................... 13 - 1
13.1.1 Data type and storage location ........................................................................................... 13 - 1
13.1.2 OS version confirmation ..................................................................................................... 13 - 3
13.1.3 Capacity confirmation of the project data downloading location......................................... 13 - 4
13.1.4 Display file .......................................................................................................................... 13 - 4
13.2 Various Data Control ..................................................................................................................... 13 - 5
13.2.1 OS information.................................................................................................................... 13 - 5
13.2.2 Alarm information.............................................................................................................. 13 - 11
13.2.3 Project Information............................................................................................................ 13 - 17
13.2.4 Hard copy information....................................................................................................... 13 - 27
13.2.5 Advanced recipe information ............................................................................................ 13 - 33
13.2.6 Logging information .......................................................................................................... 13 - 53
13.2.7 Memory card format.......................................................................................................... 13 - 63
13.2.8 Memory information .......................................................................................................... 13 - 65
13.2.9 USB device status display ................................................................................................ 13 - 66
13.2.10 SRAM control.................................................................................................................... 13 - 68
13.2.11 GOT data package acquisition ......................................................................................... 13 - 73
13.2.12 Operator information management................................................................................... 13 - 74
14. GOT SELF CHECK (DEBUG AND SELF CHECK)
14.1 Debug ............................................................................................................................................ 14 - 1
14.1.1 System monitor................................................................................................................... 14 - 1
14.1.2 A list editor .......................................................................................................................... 14 - 1
14.1.3 FX list editor........................................................................................................................ 14 - 1
14.1.4 Backup/restoration.............................................................................................................. 14 - 2
14.2 Self Check ..................................................................................................................................... 14 - 3
14.2.1 Memory check .................................................................................................................... 14 - 3
14.2.2 Drawing check .................................................................................................................... 14 - 6
14.2.3 Font check ........................................................................................................................ 14 - 10
14.2.4 Touch panel check............................................................................................................ 14 - 12
14.2.5 I/O check........................................................................................................................... 14 - 14
14.2.6 Ethernet status check ....................................................................................................... 14 - 17
14.3 System Alarm Display.................................................................................................................. 14 - 19
14.4 GOT start time ............................................................................................................................. 14 - 21
15. CLEANING DISPLAY SECTION (CLEAN)
16. INSTALLATION OF COREOS, BOOTOS AND STANDARD MONITOR OS
16.1 BootOS and Standard Monitor OS Required for Installation ......................................................... 16 - 2
16.2 Prior Preparations for Installing BootOS and Standard Monitor OS .............................................. 16 - 3

A - 11
16.3 BootOS and Standard Monitor OS Installation Using SD card or USB Memory ........................... 16 - 4
16.3.1 Installing when starting the GOT ........................................................................................ 16 - 5
16.3.2 Installing using the program/data control function (Utility).................................................. 16 - 7
16.4 When Installing the Different Version of BootOS, Standard Monitor OS ....................................... 16 - 9
16.5 CoreOS........................................................................................................................................ 16 - 11
16.5.1 Installing the CoreOS ....................................................................................................... 16 - 11
16.5.2 When the CoreOS cannot be installed ............................................................................. 16 - 13
17. MAINTENANCE AND INSPECTION
17.1 Daily Inspection ............................................................................................................................. 17 - 2
17.2 Periodic Inspection ........................................................................................................................ 17 - 2
17.3 Cleaning Method............................................................................................................................ 17 - 3
17.4 Battery Voltage Low Detection and Battery Replacement............................................................. 17 - 4
17.5 Backlight Shutoff Detection............................................................................................................ 17 - 7
17.5.1 Backlight shutoff detection and external alarm................................................................... 17 - 7
18. TROUBLESHOOTING
18.1 GOT Restoration Sheet ................................................................................................................. 18 - 1
18.2 Error Message and System Alarm............................................................................................... 18 - 11
18.2.1 Error contents display....................................................................................................... 18 - 11
18.2.2 List of error message/system alarm ................................................................................. 18 - 13
APPENDICES
Appendix.1 External Dimensions..........................................................................................................App - 1
Appendix.2 Usage Condition of Utility Function ...................................................................................App - 7
Appendix.3 Transportation Precautions ...............................................................................................App - 9
Appendix.3.1 Relevant models...........................................................................................................App - 9
Appendix.3.2 Transportation guidelines .............................................................................................App - 9
INDEX
REVISIONS

A - 12

A - 13
MANUALS
The following table lists the manual relevant to this product.
Refer to each manual for any purpose.
QUICK REFERENCE
Creating a project
Connecting a controller to the GOT
Manual Name Packaging Manual Number
(Model code)
GT Works3 Version1 Installation Procedure Manual Enclosed in product -
GT Designer3 Version1 Screen Design Manual (Fundamentals) 1/2, 2/2 Stored in CD-ROM SH-080866ENG
(1D7MB9)
GT Designer3 Version1 Screen Design Manual (Functions) 1/2, 2/2 Stored in CD-ROM SH-080867ENG
(1D7MC1)
GOT1000 Series Connection Manual (Mitsubishi Products) for GT Works3 Stored in CD-ROM SH-080868ENG
(1D7MC2)
GOT1000 Series Connection Manual (Non-Mitsubishi Products 1) for GT Works3 Stored in CD-ROM SH-080869ENG
(1D7MC3)
GOT1000 Series Connection Manual (Non-Mitsubishi Products 2) for GT Works3 Stored in CD-ROM SH-080870ENG
(1D7MC4)
GOT1000 Series Connection Manual (Microcomputer, MODBUS Products, Peripherals) for GT
Works3 Stored in CD-ROM SH-080871ENG (1D7MC5)
GOT1000 Series Connection Manual (α2 Connection) for GT Works3 Stored in CD-ROM JY997D39201
GT Simulator3 Version1 Operating Manual for GT Works3 Stored in CD-ROM SH-080861ENG
(1D7MB1)
GOT1000 Series User's Manual (Extended Functions, Option Functions) for GT Works3 Stored in CD-ROM SH-080863ENG
(1D7MB3)
Obtaining the specifications and operation methods of GT Designer3
GT Designer3 Version1 Screen Design Manual
(Fundamentals) 1/2, 2/2
Setting available functions on GT Designer3
Creating a screen displayed on the GOT
Obtaining useful functions to increase efficiency of drawing
Setting details for figures and objects
GT Designer3 Version1 Screen Design Manual (Functions)
1/2, 2/2
Setting functions for the data collection or trigger action
Setting functions to use peripheral devices
Simulating a created project on a personal computer GT Simulator3 Version1 Operating Manual for GT Works3
Obtaining information of Mitsubishi products applicable to the GOT
GOT1000 Series Connection Manual (Mitsubishi Products)
for GT Works3
Connecting Mitsubishi products to the GOT
Connecting multiple controllersto one GOT (Multi-channel function)
Establishing communication between a personal computer and a
controller via the GOT (FA transparent function)

A - 14
Transferring data to the GOT
Others
Obtaining information of Non-Mitsubishi products applicable to the
GOT
• GOT1000 Series Connection Manual (Non-Mitsubishi
Products 1) for GT Works3
• GOT1000 Series Connection Manual (Non-Mitsubishi
Products 2) for GT Works3
Connecting Non-Mitsubishi products to the GOT
Obtaining information of peripheral devices applicable to the GOT GOT1000 Series Connection Manual (Microcomputer,
MODBUS Products, Peripherals) for GT Works3
Connecting peripheral devices including a barcode reader to the GOT
Connecting α2 with GOT GOT1000 Series Connection Manual (α2 Connection) for GT
Works3
Writing data to the GOT
GT Designer3 Version1 Screen Design Manual
(Fundamentals) 1/2, 2/2
Reading data from the GOT
Verifying a editing project to a GOT project
Configuring the extended function and option function GOT1000 Series User's Manual (Extended Functions, Option
Functions) for GT Works3

A - 15
ABBREVIATIONS AND GENERIC TERMS
GOT
Abbreviations and generic terms Description
GOT1000
Series
GT1695 GT1695M-X Abbreviation of GT1695M-XTBA, GT1695M-XTBD
GT1685 GT1685M-S Abbreviation of GT1685M-STBA, GT1685M-STBD
GT1675
GT1675M-S Abbreviation of GT1675M-STBA, GT1675M-STBD
GT1675M-V Abbreviation of GT1675M-VTBA, GT1675M-VTBD
GT1675-VN Abbreviation of GT1675-VNBA, GT1675-VNBD
GT1672 GT1672-VN Abbreviation of GT1672-VNBA, GT1672-VNBD
GT1665 GT1665M-S Abbreviation of GT1665M-STBA, GT1665M-STBD
GT1665M-V Abbreviation of GT1665M-VTBA, GT1665M-VTBD
GT1662 GT1662-VN Abbreviation of GT1662-VNBA, GT1662-VNBD
GT1655 GT1655-V Abbreviation of GT1655-VTBD
GT16 Abbreviation of GT1695, GT1685, GT1675, GT1672, GT1665, GT1662, GT1655, GT16 Handy GOT
GT1595 GT1595-X Abbreviation of GT1595-XTBA, GT1595-XTBD
GT1585 GT1585V-S Abbreviation of GT1585V-STBA, GT1585V-STBD
GT1585-S Abbreviation of GT1585-STBA, GT1585-STBD
GT157
GT1575V-S Abbreviation of GT1575V-STBA, GT1575V-STBD
GT1575-S Abbreviation of GT1575-STBA, GT1575-STBD
GT1575-V Abbreviation of GT1575-VTBA, GT1575-VTBD
GT1575-VN Abbreviation of GT1575-VNBA, GT1575-VNBD
GT1572-VN Abbreviation of GT1572-VNBA, GT1572-VNBD
GT156 GT1565-V Abbreviation of GT1565-VTBA, GT1565-VTBD
GT1562-VN Abbreviation of GT1562-VNBA, GT1562-VNBD
GT155
GT1555-V Abbreviation of GT1555-VTBD
GT1555-Q Abbreviation of GT1555-QTBD, GT1555-QSBD
GT1550-Q Abbreviation of GT1550-QLBD
GT15 Abbreviation of GT1595, GT1585, GT157 , GT156 , GT155
GT145 GT1455-Q Abbreviation of GT1455-QTBDE, GT1455-QTBD
GT1450-Q Abbreviation of GT1450-QMBDE, GT1450-QMBD, 1450-QLBDE, GT1450-QLBD
GT14 Abbreviation of GT1455-Q, GT1450-Q
GT1275 GT1275-V Abbreviation of GT1275-VNBA, GT1275-VNBD
GT1265 GT1265-V Abbreviation of GT1265-VNBA, GT1265-VNBD
GT12 Abbreviation of GT1275, GT1265
GT115 GT1155-Q Abbreviation of GT1155-QTBDQ, GT1155-QSBDQ, GT1155-QTBDA, GT1155-QSBDA,
GT1155-QTBD, GT1155-QSBD
GT1150-Q Abbreviation of GT1150-QLBDQ, GT1150-QLBDA, GT1150-QLBD
GT11 Abbreviation of GT115 , GT11 Handy GOT,
GT105 GT1055-Q Abbreviation of GT1055-QSBD
GT1050-Q Abbreviation of GT1050-QBBD
GT104 GT1045-Q Abbreviation of GT1045-QSBD
GT1040-Q Abbreviation of GT1040-QBBD
GT1030
Abbreviation of GT1030-LBD, GT1030-LBD2, GT1030-LBL, GT1030-LBDW, GT1030-LBDW2,
GT1030-LBLW, GT1030-LWD, GT1030-LWD2, GT1030-LWL, GT1030-LWDW, GT1030-LWDW2,
GT1030-LWLW, GT1030-HBD, GT1030-HBD2, GT1030-HBL, GT1030-HBDW, GT1030-HBDW2,
GT1030-HBLW, GT1030-HWD, GT1030-HWD2, GT1030-HWL, GT1030-HWDW, GT1030-HWDW2,
GT1030-HWLW
GT1020
Abbreviation of GT1020-LBD, GT1020-LBD2, GT1020-LBL, GT1020-LBDW, GT1020-LBDW2,
GT1020-LBLW, GT1020-LWD, GT1020LWD2, GT1020-LWL, GT1020-LWDW, GT1020-LWDW2,
GT1020-LWLW
GT10 Abbreviation of GT105 , GT104 , GT1030, GT1020

A - 16
Communication unit
*1 A9GT-QJ71LP23 + GT15-75IF900 set
*2 A9GT-QJ71BR13 + GT15-75IF900 set
*3 A8GT-J61BT13 + GT15-75IF900 set
Option unit
*1 GT15-CFEX + GT15-CFEXIF + GT15-C08CF set.
GOT1000
Series
Handy
GOT
GT16
Handy
GOT
GT1665HS-V Abbreviation of GT1665HS-VTBD
GT11
Handy
GOT
GT1155HS-Q Abbreviation of GT1155HS-QSBD
GT1150HS-Q Abbreviation of GT1150HS-QLBD
GT SoftGOT1000 Abbreviation of GT SoftGOT1000
GOT900 Series Abbreviation of GOT-A900 series, GOT-F900 series
GOT800 Series Abbreviation of GOT-800 series
Abbreviations and generic terms Description
Bus connection unit GT15-QBUS, GT15-QBUS2, GT15-ABUS, GT15-ABUS2, GT15-75QBUSL, GT15-75QBUS2L,
GT15-75ABUSL, GT15-75ABUS2L
Serial communication unit GT15-RS2-9P, GT15-RS4-9S, GT15-RS4-TE
RS-422 conversion unit GT15-RS2T4-9P, GT15-RS2T4-25P
Ethernet communication unit GT15-J71E71-100
MELSECNET/H communication unit GT15-J71LP23-25, GT15-J71BR13
MELSECNET/10 communication unit GT15-75J71LP23-Z*1, GT15-75J71BR13-Z*2
CC-Link IE Controller Network communication
unit GT15-J71GP23-SX
CC-Link IE Field Network communication unit GT15-J71GF13-T2
CC-Link communication unit GT15-J61BT13, GT15-75J61BT13-Z*3
Interface converter unit GT15-75IF900
Serial multi-drop connection unit GT01-RS4-M
Connection Conversion Adapter GT10-9PT5S
RS-232/485 signal conversion adapter GT14-RS2T4-9P
Abbreviations and generic terms Description
Printer unit GT15-PRN
Video/RGB unit
Video input unit GT16M-V4, GT15V-75V4
RGB input unit GT16M-R2, GT15V-75R1
Video/RGB input unit GT16M-V4R1, GT15V-75V4R1
RGB output unit GT16M-ROUT, GT15V-75ROUT
Multimedia unit GT16M-MMR
CF card unit GT15-CFCD
CF card extension unit*1 GT15-CFEX-C08SET
External I/O unit GT15-DIO, GT15-DIOR
Sound output unit GT15-SOUT
Abbreviations and generic terms Description

A - 17
Option
Abbreviations and generic terms Description
Memory card
CF card
GT05-MEM-16MC, GT05-MEM-32MC, GT05-MEM-64MC, GT05-MEM-128MC,
GT05-MEM-256MC, GT05-MEM-512MC, GT05-MEM-1GC, GT05-MEM-2GC,
GT05-MEM-4GC, GT05-MEM-8GC, GT05-MEM-16GC
SD card NZ1MEM-2GBSD, NZ1MEM-4GBSD, NZ1MEM-8GBSD, NZ1MEM-16GBSD, L1MEM-2GBSD,
L1MEM-4GBSD
Memory card adaptor GT05-MEM-ADPC
Option function board GT16-MESB, GT15-FNB, GT15-QFNB, GT15-QFNB16M,
GT15-QFNB32M, GT15-QFNB48M, GT11-50FNB, GT15-MESB48M
Battery GT15-BAT, GT11-50BAT
Protective Sheet
For GT16
GT16-90PSCB, GT16-90PSGB, GT16-90PSCW, GT16-90PSGW,
GT16-80PSCB, GT16-80PSGB, GT16-80PSCW, GT16-80PSGW,
GT16-70PSCB, GT16-70PSGB, GT16-70PSCW, GT16-70PSGW,
GT16-60PSCB, GT16-60PSGB, GT16-60PSCW, GT16-60PSGW,
GT16-50PSCB, GT16-50PSGB, GT16-50PSCW, GT16-50PSGW,
GT16-90PSCB-012, GT16-80PSCB-012, GT16-70PSCB-012,
GT16-60PSCB-012, GT16-50PSCB-012, GT16H-60PSC
For GT15
GT15-90PSCB, GT15-90PSGB, GT15-90PSCW, GT15-90PSGW,
GT15-80PSCB, GT15-80PSGB, GT15-80PSCW, GT15-80PSGW,
GT15-70PSCB, GT15-70PSGB, GT15-70PSCW, GT15-70PSGW,
GT15-60PSCB, GT15-60PSGB, GT15-60PSCW, GT15-60PSGW,
GT15-50PSCB, GT15-50PSGB, GT15-50PSCW, GT15-50PSGW
For GT14 GT14-50PSCB, GT14-50PSGB, GT14-50PSCW, GT14-50PSGW
For GT12 GT11-70PSCB, GT11-65PSCB
For GT11 GT11-50PSCB, GT11-50PSGB, GT11-50PSCW, GT11-50PSGW,
GT11H-50PSC
For GT10
GT10-50PSCB, GT10-50PSGB, GT10-50PSCW, GT10-50PSGW,
GT10-40PSCB, GT10-40PSGB, GT10-40PSCW, GT10-40PSGW,
GT10-30PSCB, GT10-30PSGB, GT10-30PSCW, GT10-30PSGW,
GT10-20PSCB, GT10-20PSGB, GT10-20PSCW, GT10-20PSGW
Protective cover for oil GT05-90PCO, GT05-80PCO, GT05-70PCO, GT05-60PCO, GT05-50PCO,
GT16-50PCO, GT10-40PCO, GT10-30PCO, GT10-20PCO
USB environmental protection cover GT16-UCOV, GT16-50UCOV, GT15-UCOV, GT14-50UCOV, GT11-50UCOV
Stand GT15-90STAND, GT15-80STAND, GT15-70STAND, A9GT-50STAND, GT05-50STAND
Attachment GT15-70ATT-98, GT15-70ATT-87, GT15-60ATT-97, GT15-60ATT-96,
GT15-60ATT-87, GT15-60ATT-77, GT15-50ATT-95W, GT15-50ATT-85
Backlight
GT16-90XLTT, GT16-80SLTT, GT16-70SLTT, GT16-70VLTT, GT16-70VLTTA, GT16-70VLTN,
GT16-60SLTT, GT16-60VLTT, GT16-60VLTN, GT15-90XLTT, GT15-80SLTT, GT15-70SLTT,
GT15-70VLTT, GT15-70VLTN, GT15-60VLTT, GT15-60VLTN
Multi-color display board GT15-XHNB, GT15-VHNB
Connector conversion box GT11H-CNB-37S, GT16H-CNB-42S, GT16H-CNB-37S
Emergency stop sw guard cover GT11H-50ESCOV, GT16H-60ESCOV
With wall-mounting Attachment GT14H-50ATT
Memory loader GT10-LDR
Memory board GT10-50FMB
Panel-mounted USB port extension GT14-C10EXUSB-4S, GT10-C10EXUSB-5S

A - 18
Software
License key (for GT SoftGOT1000)
Abbreviations and generic terms Description
GT Works3 Abbreviation of the SW DNC-GTWK3-E and SW DNC-GTWK3-EA
GT Designer3 Abbreviation of screen drawing software GT Designer3 for GOT1000 series
GT Simulator3 Abbreviation of screen simulator GT Simulator3 for GOT1000/GOT900 series
GT SoftGOT1000 Abbreviation of monitoring software GT SoftGOT1000
GT Converter2 Abbreviation of data conversion software GT Converter2 for GOT1000/GOT900 series
GT Designer2 Classic Abbreviation of screen drawing software GT Designer2 Classic for GOT900 series
GT Designer2 Abbreviation of screen drawing software GT Designer2 for GOT1000/GOT900 series
iQ Works Abbreviation of iQ Platform compatible engineering environment MELSOFT iQ Works
MELSOFT Navigator Generic term for integrated development environment software included in the SW DNC-IQWK (iQ
Platform compatible engineering environment MELSOFT iQ Works)
GX Works2 Abbreviation of SW DNC-GXW2-E and SW DNC-GXW2-EA type programmable controller
engineering software
Controller simulator
GX Simulator3 Abbreviation of GX Works3 with the simulation function
GX Simulator2 Abbreviation of GX Works2 with the simulation function
GX Simulator Abbreviation of SW D5C-LLT-E(-EV) type ladder logic test tool function software packages
(SW5D5C-LLT (-EV) or later versions)
GX Developer Abbreviation of SW D5C-GPPW-E(-EV)/SW D5F-GPPW-E type software package
GX LogViewer Abbreviation of SW DNN-VIEWER-E type software package
PX Developer Abbreviation of SW D5C-FBDQ-E type FBD software package for process control
MT Works2 Abbreviation of motion controller engineering environment MELSOFT MT Works2
(SW DNC-MTW2-E)
MT Developer Abbreviation of SW RNC-GSV type integrated start-up support software for motion controller Q series
MR Configurator2 Abbreviation of SW DNC-MRC2-E type Servo Configuration Software
MR Configurator Abbreviation of MRZJW -SETUP E type Servo Configuration Software
FR Configurator Abbreviation of Inverter Setup Software (FR-SW -SETUP-WE)
NC Configurator Abbreviation of CNC parameter setting support tool NC Configurator
FX Configurator-FP Abbreviation of parameter setting, monitoring, and testing software packages for FX3U-20SSC-H
(SW D5C-FXSSC-E)
FX3U-ENET-L Configuration tool Abbreviation of FX3U-ENET-L type Ethernet module setting software (SW1D5-FXENETL-E)
RT ToolBox2 Abbreviation of robot program creation software (3D-11C-WINE)
MX Component Abbreviation of MX Component Version (SW D5C-ACT-E, SW D5C-ACT-EA)
MX Sheet Abbreviation of MX Sheet Version (SW D5C-SHEET-E, SW D5C-SHEET-EA)
CPU Module Logging Configuration Tool Abbreviation of CPU Module Logging Configuration Tool (SW1DNN-LLUTL-E)
Abbreviations and generic terms Description
License GT15-SGTKEY-U, GT15-SGTKEY-P
