Mo-vis Manual Swing 2G User manual

moving forward together
Manual Swing 2G
P031-21 Manual Swing 2G Arm - P031-22 Manual Swing 2G Arm Bundle
Q2M
User manual
Edition 1, October 2022

Other languages
CS: Tito příručku naleznete v češtině na našich webových stránkách.
DA: Du kan finde denne manual på dansk på vores websted.
DE: Auf unserer Website finden Sie diese Anleitung in Deutsch.
EN: You can find this manual in English on our website.
ES: Este manual está disponible en español en nuestro sitio web.
FR: Vous pouvez trouver ce manuel en français sur notre site Web.
IT: nostro sito web è disponibile il presente manuale in italiano.
NO: Du finner denne håndboken på norsk på nettstedet vårt.
NL: De Nederlandse handleiding kunt u op onze website vinden.
PT: Pode encontrar este manual em português na nossa página web.
SL: Slovenski priročnik je na voljo na naši spletni strani.
SV: Du hittar den här handboken på svenska på vår webbplats.
2
2 Manual Swing 2G User manual

About this manual
User manual
Thank you for choosing a mo-vis product!
This manual contains useful and important information about your device. Please read it
carefully before use and store safely for future reference.
Our team (or your authorized dealer) will be happy to answer your questions.
mo-vis bv
Biebuyckstraat 15D . 9850 Deinze . Belgium
http://www.mo-vis.com . con[email protected]om . [phone]
3
Manual Swing 2G User manual 3

User manual (English)
Warning labels
Please read this manual, the safety instructions and warning texts carefully, in order
to reduce the risks associated to the device. Our products are safe under normal and
reasonably foreseeable operating conditions.
NOTE: This symbol indicates general notes and information.
CAUTION: This symbol indicates caution for a hazardous situation that, if not
avoided, could result in minor or moderate injury.
WARNING: This symbol indicates a warning for a hazardous situation that, if not
avoided, could result in death or serious injury.
Other labels:
Catalogue number: indicates the
manufacturer's catalogue number so that
the medical device can be identified.
Batch code: indicates the manufacturer's
batch code so that the batch or lot can be
identified.
Medical device: indicates that the item is a
medical device.
Date of manufacture: indicates the date
when the medical device was manufac-
tured.
Serial number: indicates the
manufacturer's serial number so that a spe-
cific medical device can be identified.
Consult instructions for use or consult elec-
tronic instructions for use: indicates the
need for the user to consult the instruc-
tions for use.
4
4 Manual Swing 2G User manual

Keep dry: indicates a medical device that
needs to be protected from moisture.
Do not use if package is damage and con-
sult instructions for use: indicates that a
medical device that should not be used if
the package has been damaged or opened
and that the user should consult the
instructions for use for additional informa-
tion.
CE label: indicates that the manufacturer
or importer affirms the good's conformity
with European health, safety, and environ-
mental protection standards.
WEEE: indicates that the product should
not be discarded as unsorted waste but
must be sent to separate collection facili-
ties for recovery and recycling.
Manufacturer: indicates the medical device
manufacturer.
Support, scrapping & recycling
Technical support
TROUBLE: In case of technical problems:
• Contact your dealer
• If your dealer is not available or unknown, please contact mo-vis: contact@mo-
vis.com or [phone].
Always state the product code and device serial number when contacting us. This
ensures you are provided with the correct information.
Spare parts and accessories
Contact mo-vis or your dealer for more information about spare parts and accessories.
Scrapping & recycling
CAUTION: For scrapping, adhere to your local waste legislation. Dispose of obsolete
electronic parts responsibly in accordance with local recycling regulations.
5
Manual Swing 2G User manual 5

Limited liability
mo-vis accepts no liability for personal injury or damage to property that may arise from
the failure of the user or other persons to follow the recommendation, warnings and
instructions in this manual.
CAUTION: This product should only be installed by a qualified service engineer.
NOTE: All mo-vis manuals can be found at http://www.mo-vis.com where they can
be consulted in PDF format.
NOTE: In case any serious incident occurs in relation to this device, this should be
reported immediately to mo-vis and the competent authority of the Member State in
which the user is established.
Intended use
The Manual Swing 2G is a versatile arm to mount on a powered wheelchair. With this
arm, devices such as a chin joystick can be positioned to drive, and the arm can be moved
upwards or sideways manually, whenever needed.
The Manual Swing 2G is intended to be fitted on any wheelchair.
Features
The Manual Swing 2G:
• Is designed for the use of a chin control system, but it can also be mounted and
used for the attachment of small and lightweight communication tools, such as a
smartphone or tablet. The maximum weight is 1kg (35.27 oz) at a maximum distance
of 55 cm (21.65 in)
• Can swing away in several directions (up-down / left-right), depending on the
installation method
• Is attached to the rear of the wheelchair's backrest.
For easy mounting, mo-vis proposes a mounting bundle. See Parts and accessories on
page 8 for more information.
• Different types of joysticks or other devices can easily be mounted on the mounting
arm through the Quick-to-mount (Q2M) system
6
6 Manual Swing 2G User manual

Operation
Figure 1: P031-21 Manual Swing 2G
The Manual Swing 2G consists of the arm and an optional mounting set:
• The arm with all its accessories can be positioned in an ideal place for the user.
• An optional mounting set is available to facilitate mounting on the backside of the
wheelchair.
The arm can always be pulled away manually if needed, without damaging the mechanics.
CAUTION: It is advised to only do this in case of emergency and not regularly.
WARNING: Do not cover or block the device to avoid uncontrolled behavior of the
device or the wheelchair.
7
Manual Swing 2G User manual 7

Parts and accessories
Available versions
There are 2 versions available:
• P031-21 Manual Swing 2G
• P031-22 Manual Swing 2G Bundle Q2M
P031-21 Manual Swing 2G Arm
A Manual Swing package consists of the following parts:
• P001-20 Manual Swing Pivot Unit
• M031-66 Q2M Joint Arm Assembly
• M031-73 Q2M Joint Manual Swing 2G Adapter Set
•D-P031-21-70-MX Manual Swing 2G User manual
•D-P031-21-70-M1 Manual Swing 2G Installation manual
P031-22 Manual Swing 2G Arm Bundle Q2M
In the P031-22 Manual Swing 2G Bundle Q2M, the M004-17 Q2M Manual Swing Mounting
Set is included.
Accessories
There are several accessories available to facilitate mounting of the mo-vis joysticks on the
Multi Swing 2G. See Installation manual.
Spare parts
For available spare parts, see Installation manual.
First time use
CAUTION: Only a qualified service engineer may install the device.
CAUTION: An incorrect programming of the wheelchair or device electronics, may
cause damage to the devices or injury to the user.
CAUTION: A qualified service engineer should assist during first time use of the
device and make sure that all functions are clear to the user, including what to do in
case of problems or doubt.
8
8 Manual Swing 2G User manual

Cleaning
The device is maintenance-free. Under regular circumstances of use, the device and
different parts do not require additional maintenance.
WARNING: As dust and dirt could lead to reduced functionality, all parts of the device
should be cleaned on a regular basis (monthly) or whenever needed.
• Gently remove dust and dirt with a damp cloth.
• Use only non-aggressive disinfectant cleaning agents.
CAUTION: Do not immerse in water or use excessive amounts of liquid.
CAUTION: Do not apply additional lubricants to the moving parts.
Dimensions
PART DIMENSIONS (METRIC) DIMENSIONS (IMPERIAL)
Motor unit 137 x 52 x 58 mm 5.39 x 2.05 x 2.28 in
Arm (section) 18 x 18 mm 0.71 x 0.71 in
Extrusion 400 mm + adapter
M031-67
420 mm 16.54 in
Extrusion 150 mm + adapter
M031-68
200 mm 7.87 in
C-rod 120 mm 4.72 in
9
Manual Swing 2G User manual 9
