Modular Closets Corner Tall Hanging Unit Instruction manual

ASSEMBLY AND INSTALLATION
INSTRUCTIONS
CORNER TALL
HANGING UNIT
1-844-969-4247
suppor[email protected]

ASSEMBLY AND INSTALLATION INSTRUCTIONS
CORNER DOUBLE HANGING UNIT
PARTS LIST
1
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Left Side Panel (Qty 1)
Right Side Panel (Qty 1)
Left Vertical Brace (Qty 1)
Right Vertical Brace (Qty 1)
Set Shelf (Qty 2)
Upper Rear Hanging Cleat (Qty 2)
Lower Rear Hanging Cleat (Qty 2)
Hanging Rod (Qty 1)
"O" Rod Bracket (Qty 1)
"U" Rod Bracket (Qty 1)
Cam Post (Qty 24)
Camlock (Qty 24)
Screws, Rod Bracket (4)
Screws, Install, 3" (Qty 8)
A
EFG
BCD
K
L
FRONT
FRONT
FINISHED EDGE FINISHED EDGE
O
P
Q
R
Level
Stud Finder
Drill, 3/32" bit size
Phillips Screwdriver
TOOLS REQUIRED
(not included)
OPQ
R
N
1.1
1.2
Lay parts out on a protective surface to prevent damage. Tip: Spread out the cardboard packaging to use as a
protective surface.
Inventory parts against the Parts List. Make sure all parts are present before proceeding.
M
JI
H

ASSEMBLY AND INSTALLATION INSTRUCTIONS
CORNER TALL HANGING UNIT
2
3
2.1 Install one Cam Post (K) into each of the eight holes on Left Side Panel (A)
and Right Side Panel (B). Tighten until Cam Posts are seated against Side
Panels.
A
C
D
KK
K
K
K
K
K
K
B
3.1
3.2
Install one Cam Post (K) into each of the two holes on Left Vertical Brace (C). Install one Cam Post (K) into each
of the seven holes on Right Vertical Brace (D).
Tighten Cam Posts (K) until Posts are seated against Vertical Braces.

ASSEMBLY AND INSTALLATION INSTRUCTIONS
CORNER TALL HANGING UNIT
4
5
4.1
4.2
Assemble Left Vertical Brace (C) onto Right Vertical Brace (D) by sliding Left Brace onto the Cam Posts (K) on
Right Brace. BE SURE dowel pins in Left Brace engage drilled holes in Right Brace, and Left Brace is pressed
flush against Right Brace.
Insert Camlocks (L) in holes in Left Vertical Brace (C), with arrow pointing toward Cam Post opening. Be sure
Camlocks engage Cam Posts, and are fully seated Left Brace. Tighten Camlocks (L) clockwise to lock.
ARROW TOWARD
CAM POST OPENING
ARROW TOWARD
CAM POST OPENING
C
L
K
K
L
D
5.1
5.2
Assemble Set Shelves(E), Upper Rear Hanging Cleat (F), and Lower Rear Hanging Cleat (G) onto assembled
Vertical Brace by sliding parts onto the Cam Posts (K) on Brace. BE SURE dowel pins in parts engage drilled holes
in Brace, and all parts are pressed flush against Brace.
Insert Camlocks (L) in holes in Set Shelves (E), Upper Rear Hanging Cleat (F), and Lower Rear Hanging Cleat (G),
with arrow pointing toward Cam Post opening. Be sure Camlocks engage Cam Posts, and are fully seated. Tighten
Camlocks (L) clockwise to lock.
E
L
L
KK
K
E
F
K
L
G
L

6
7
ASSEMBLY AND INSTALLATION INSTRUCTIONS
CORNER TALL HANGING UNIT
A
E
E
F
G
6.1 Install Left Side Panel (A) onto assembled Set Shelves (E) and Upper and Lower Rear Hanging Cleats (F, G). BE
SURE dowel pins in Shelves and Cleats engage drilled holes in Side Panel, and Side Panel is pressed flush against
Set Shelves and Cleats.
LL
E
E
G
L
L
7.1
7.2
Insert Camlocks (L) in holes in Set Shelves (E) and Upper and Lower Rear Hanging Cleats (F, G), with arrow pointing
toward Cam Post opening. Be sure Camlocks engage Cam Posts, and are fully seated in Shelves and Cleats.
Tighten Camlocks (L) clockwise to lock.
ARROW TOWARD
CAM POST OPENING

8
9
ASSEMBLY AND INSTALLATION INSTRUCTIONS
CORNER TALL HANGING UNIT
ARROW TOWARD
CAM POST OPENING
8.1
8.2
8.3
Rotate assembled unit 90 degrees to allow for
installation of Right Side Panel.
Assemble Upper Rear Hanging Cleat (F) and Lower
Rear Hanging Cleat (G) onto assembled Vertical Brace
by sliding parts onto the Cam Posts (K) on Brace. BE
SURE dowel pins in Cleats engage drilled holes in Brace,
and parts are pressed flush against Brace.
Insert Camlocks (L) in holes in two Rear Hanging Cleats (G), with arrow pointing toward Cam Post opening.
Be sure Camlocks engage Cam Posts, and are fully seated.Tighten Camlocks (L) clockwise to lock.
G
K
L
L
F
9.1 Install Right Side Panel (B) onto assembled Set Shelves
(E) and Upper and Lower Rear Hanging Cleats (F, G).
BE SURE dowel pins in Shelves and Cleats engage drilled
holes in Side Panel, and Side Panel is pressed flush against
Set Shelves and Cleats.
E
E
B
F
G

ASSEMBLY AND INSTALLATION INSTRUCTIONS
CORNER TALL HANGING UNIT
10
11
10.1
10.2
Insert Camlocks (L) in holes in Set Shelves (E) and Upper and Lower Rear Hanging Cleats (F, G), with arrow
pointing toward Cam Post opening. Be sure Camlocks engage Cam Posts, and are fully seated in Shelves and
Cleats.
Tighten Camlocks (L) clockwise to lock.
L
L
L
L
E
E
G
ARROW TOWARD
CAM POST OPENING
INSTALLATION
STANDARD
HEIGHT
-
84" FROM
FLOOR
D
D
11.1
11.2
11.3
Determine the mounting location for the
unit.
Using a stud finder, locate studs to which
the unit will be secured. Mark stud
locations with a pencil.
With the unit positioned at the desired
location, level the unit, then drill pilot
holes through Upper and Lower Rear
Hanging Cleats (F, G).
STUDS
PILOT HOLES
GG
HH

ASSEMBLY AND INSTALLATION INSTRUCTIONS
CORNER TALL HANGING UNIT
12
13
G
G
G
G
N
12.1 Secure Upper and Lower Rear
Hanging Cleats (F, G) to studs
using 3" Install Screws (N).
J
M
M
13.1 Determine the side of the unit on
which you wish to install the rods.
Position "U" Bracket (J) on left or
right side Lower Rear Hanging
Cleat (G), as appropriate, and
secure Bracket with two screws
(M).

ASSEMBLY AND INSTALLATION INSTRUCTIONS
CORNER TALL HANGING UNIT
14
14.1
14.2
14.3
Insert one end of Hanging Rod
(H) into "O" Bracket (I).
Slide assembled Hanging Rod
(H) and "O" Bracket (I) into unit.
Rest free end of Hanging Rod in
"U" Bracket.
Secure "O" Bracket (I) to Left
Side Panel (A) or Right Side
Panel (B), as appropriate, with
two Rod Bracket Screws (M).
NOTE: Use care when installing
Hanging Rod (H) to avoid
scratching finish inside unit.
H
I
M
M
