Modular Closets DOUBLE HANGING UNIT Instruction manual

ASSEMBLY AND INSTALLATION
INSTRUCTIONS
DOUBLE HANGING UNIT
1-844-969-4247 suppor[email protected]

A B
D
C
E
FRONT FRONT
FINISHED EDGE
FINISHED EDGE
C
D
E
F
G
H
I
J
Set Shelf (Qty 2)
Rear Cleat (Qty 2)
Hanging Rod (Qty 2)
Rod Bracket (Qty 4)
Cam Post (Qty 12)
Camlock (Qty 12)
Screw, 5/8" (Qty 4)
Screw, Square Drive, 2.5" (Qty 4)
A
BLeft Side Panel Right Side Panel
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
DOUBLE HANGING UNIT
J
G
H
I
PARTS LIST
BOX 1 BOX 2
Level
Stud Finder
Drill, 3/32" bit size
Phillips Screwdriver
Drill Bit, Square,
#2
TOOLS REQUIRED
(not included unless noted)
1A
1B
1.1
1.2
Lay parts out on a protective surface to
prevent damage. Tip: Spread out the
cardboard packaging to use as a
protective surface.
Inventory parts against the Parts List. Make
sure all parts are present before proceeding.
F

2
3
IMPORTANT NOTES
Install Set Shelves (D) with finished edges
facing forward (toward front of unit).
Install Rear Hanging Cleats (C) with holes
for Cam Locks facing the rear of the unit and
the unfinishededge against the Set Shelf (D).
Install upper Set Shelf (D) with holes for Cam
Locks facing the top of the unit.
Install lower Set Shelf (D) with holes for Cam
Locks facing the bottom of the unit.
B
A
G
G
2.1 Install one Cam Post (G) into each of the eight holes on Left Side Panel (A)
and Right Side Panel (B). Tighten until Cam Posts are seated against Side
Panels.
D
D
C
C
G
G
B
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
DOUBLE HANGING UNIT
TOP
3.1 Assemble Set Shelves (D) and Rear Hanging Cleats (C) onto Right Side
Panel (B) by sliding the Shelves and Cleats onto the Cam Posts (G )on
Right Side Panel. BE SURE dowel pins in Shelves and Cleats engage
drilled holes in RightSide Panel, and all parts are pressed flush
against Right Side Panel.
TOP

4
5
5.1
5.2
Insert Camlocks (H) in holes in Set Shelves (D)
and Rear Hanging Cleats (C), with arrow pointing
toward Cam Post opening. Be sure Camlocks engage
Cam Posts, and are fully seated in Shelves and
Cleats.
Tighten Camlocks (H) clockwise to lock.
ARROW TOWARD
CAM POST OPENING
3.1 Install Left Side Panel (A) onto
assembled Set Shelves (D) and
Rear Hanging Cleats (C). BE SURE
dowel pins in Shelves and Cleats
engage drilled holes in Left Side
Panel, and Left Side Panel is pressed
flush against Set Shelves and Cleats.
C
C
D
D
A
B
H
H
H
H
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
DOUBLE HANGING UNIT
TOP
TOP

INSTALLATION
6
6.1
6.2
6.3
Determine the mounting location for the unit.
Using a stud finder, locate studs to which the unit will be secured. Mark stud locations with a pencil.
With the unit positioned at the desired location, level the unit, then drill pilot holes through Rear Hanging Cleats (C),
NOTE: For 24" units, it is likely that only one stud will pass through the unit. In these cases, use two screws through each
Rear Hanging Cleat.
STANDARD
HEIGHT
-
84" FROM
FLOOR
PILOT HOLES
STUDS
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
DOUBLE HANGING UNIT
C
C

7
7.1 Secure Rear Hanging Cleats (C) to studs using 2.5" Screws (J). Tighten Screws using Square Drill Bit (provided)
and Drill.
C
J
C
J
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
DOUBLE HANGING UNIT

8
8.1 Install two Rod Brackets (F) on Left Side Panel (A) and Right Side Panel (B) and secure each Bracket with one
screw (I).
A
F
F
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
DOUBLE HANGING UNIT
F
I
F
I

9
9.1 Lower each Hanging Rod (E) into Rod Brackets (F) on Left Side Panel (A) and Right Side Panel (B).
NOTE: Use care when installing Hanging Rods (E) to avoid scratching finish inside unit.
B
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
DOUBLE HANGING UNIT
E
F
E
F
A
E
F
E
F
