Modular Closets TALL HANGING UNIT Instruction manual

ASSEMBLY AND INSTALLATION
INSTRUCTIONS
TALL HANGING UNIT
1-844-969-4247 suppor[email protected]

J
EF
A
D
C
B
GHI
H
I
J
Camlock (Qty 12)
Screw, 5/8" (Qty 2)
Screw, Square Drive,
2.5" (Qty 4)
C
D
E
F
G
Rear Hanging Cleat (Qty 2)
Set Shelf (Qty 2)
Hanging Rod
Rod Bracket (Qty 2)
Cam Post (Qty 12)
A
BLeft Side Panel Right Side Panel
FRONT
FINISHED EDGE
FINISHED EDGE
FRONT
1.1
1.2
Lay parts out on a protective surface
to prevent damage. Tip: Spread out
the cardboard packaging to use as a
protective surface.
Inventory parts against the Parts List.
Make sure all parts are present before
proceeding.
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
TALL HANGING UNIT
PARTS LIST
BOX 1 BOX 2
Level
Stud Finder
Drill, 3/32" bit size
Phillips Screwdriver
Drill Bit, Square #2
TOOLS REQUIRED
(not included unless noted)
1A
1B

2
3
2.1 Install one Cam Post (G) into each of the eight holes on Left Side Panel (A)
and Right Side Panel (B). Tighten until Cam Posts are seated against Side Panels.
3.1 Assemble Set Shelves (D) and Rear Hanging Cleats (C)
onto Right Side Panel (B) by sliding the Shelves and
Cleats onto the Cam Posts (G)on Right Side Panel. BE
SURE dowel pins in Shelves and Cleats engage drilled
holes in RightSide Panel, and all parts are pressed flush
against Right Side Panel.
IMPORTANT NOTES
Install Set Shelves (D) with finished edges facing
forward (toward front of unit).
Install Rear Hanging Cleats (C) with holes for Cam
Locks facing the rear of the unit and the unfinished
edge against the Set Shelf (D).
Install upper Set Shelf (D) with holes for Cam Locks
facing the top of the unit.
Install lower Set Shelf (D) with holes for Cam Locks
facing the bottom of the unit.
B
A
G
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
TALL HANGING UNIT
G
B
D
D
G
G
C
C
TOP
TOP

ASSEMBLY AND INSTALLATION INSTRUCTIONS
TALL HANGING UNIT - 18" / 24" / 30" / 36"
4
5
I
I
I
I
A
B
D
D
C
C
5.1
5.2
Insert Camlocks (I) in holes in Set Shelves (C)
and Rear Hanging Cleats (D), with arrow pointing
toward Cam Post opening. Be sure Camlocks engage
Cam Posts, and are fully seated in Shelves and
Cleats.
Tighten Camlocks (I) clockwise to lock.
ARROW TOWARD
CAM POST OPENING
3.1 Install Left Side Panel (A) onto assembled Set
Shelves (C) and Rear Hanging Cleats (D). BE
SURE dowel pins in Shelves and Cleats engage
drilled holes in Left Side Panel, and Left Side
Panel is pressed flush against Set Shelves and
Cleats.

INSTALLATION
6
7
STUDS
STANDARD
HEIGHT
-
84" FROM
FLOOR
7.1 Secure Rear Hanging Cleats (C) to
studs using 2.5" Screws (J). Tighten
Screws using Square Drill Bit (provided)
and Drill.
D
C
C
6.1
6.2
6.3
Determine the mounting location for the
unit.
Using a stud finder, locate studs to which
the unit will be secured. Mark stud
locations with a pencil.
With the unit positioned at the desired
location, level the unit, then drill pilot
holes through Rear Hanging Cleats (C),
PILOT HOLES
NOTE: For 18" and 24" units, it is likely that
only one stud will pass through the
unit. In these cases, use two screws
through each Rear Hanging Cleat.
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
TALL HANGING UNIT
C
J

8
9
8.1 Install one Rod Bracket (F) on Left
Side Panel (A) and Right Side Panel
(B) and secure each Bracket with one
screw (I).
9.1 Lower Hanging Rod (E) into Rod
Brackets (F) on Left Side Panel (A)
and Right Side Panel (B).
A
NOTE: Use care when installing Hanging
Rod (E) to avoid scratching finish
inside unit.
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
TALL HANGING UNIT
F
B
B
F
I
A
EF
E
F
