Modular Closets HANGING TOWER UNIT Instruction manual

ASSEMBLY AND INSTALLATION
INSTRUCTIONS
HANGING TOWER UNIT
1-844-969-4247 suppor[email protected]

A B
FRONT
FRONT
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HANGING TOWER
PARTS LIST
BOX 1 BOX 2 / BOX 3
1A
A
BLeft Side Panel (Qty 1) Right Side Panel (Qty 1)
C
D
H
I
J
K
N
Rear Hanging Cleat (Qty 2 each box)
Set Shelf (Qty 2 each box)
Hanging Rod (Qty1 - Box 2)
Rod Bracket (Qty 2 - Box 2)
Cam Post (Qty 12 each box)
Camlock (Qty 12 each box)
Screw, Square Drive, 2.5" (Qty 4 each box)
J
K
N
D
C
FINISHED EDGE
FINISHED EDGE
BOX 4
E
LAdjustable Shelf (Qty 2) Shelf Pins (Qty 8)
L
EFINISHED EDGE
BOX 5 - Leg Extension Kit (Optional)
F G
FRONT FRONT
CFINISHED EDGE C
F
G
J
K
M
Rear Hanging Cleat (Qty 1)
Left Leg Extension (Qty 1)
Right Leg Extension (Qty 1)
Cam Post (Qty 2)
Camlock (Qty 2)
Wood Dowels (Qty 4)
JM K
OI
H

2
2.1 Install one Cam Post (J) into each of the 12 holes on Left Side Panel (A) and Right Side Panel (B). Tighten until
Cam Posts are seated against Side Panels.
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HANGING TOWER
B
A
J
J
J
J
TOP
1B Level
Stud Finder Drill, 3/32" bit size Phillips Screwdriver
TOOLS REQUIRED
(not included unless noted)
1.1
1.2
Lay parts out on a protective surface to prevent damage.
Tip: Spread out the cardboard packaging to use as a protective
surface.
Inventory parts against the Parts List. Make sure all parts are
present before proceeding.
Drill Bit, Square, #2

3
3.1 Assemble Set Shelves (D) and Rear Hanging Cleats (C) onto Right Side Panel (B) by sliding the Shelves and
Cleats onto the Cam Posts (J) on Side Panel. BE SURE dowel pins in Shelves and Cleats engage drilled holes
in Side Panel, and all parts are pressed flush against Side Panel.
IMPORTANT NOTES
Install Set Shelves (D) with finished edges facing forward (toward front of unit).
Install Rear Hanging Cleats (C) with holes for Cam Locks facing the rear of the unit and the unfinished edge against
the Set Shelf (D).
Install upper Set Shelves (D) with holes for Cam Locks facing the top of the unit.
Install lower Set Shelves (D) with holes for Cam Locks facing the bottom of the unit.
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HANGING TOWER
D
D
J
J
J
J
D
D
C
C
C
C
TOP

4
4.1 Install Left Side Panel (A) onto assembled Set Shelves (D) and Rear Hanging Cleats (E). BE SURE
dowel pins in Shelves and Cleats engage drilled holes in Side Panel, and Side Panel is pressed flush against
Set Shelves and Cleats.
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HANGING TOWER
B
D
D
D
D
A
C
C
C
C
TOP

5
5.1
5.2
Insert Camlocks (K) in holes in Set Shelves (D) and Rear Hanging Cleats (C), with arrow pointing toward Cam
Post opening. Be sure Camlocks engage Cam Posts, and are fully seated in Shelves and Cleats.
Tighten Camlocks (K) clockwise to lock.
ARROW TOWARD
CAM POST OPENING
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HANGING TOWER
D
D
C
C
C
C
K
KK
K
KK
K
K
K
K
TOP

6
FOR LEG EXTENSION KIT INSTALLATIONS ONLY
Leg Extension Kit purchased separately)
6.1
6.2
6.3
6.4
6.5
Insert four Wood Dowels (M) into holes in edges of Left Leg
Extension (F) and Right Leg Extension (G).
Install one Cam Post (J) each into Left Leg Extension (F)
and Right Leg Extension (G). Tighten until Cam Posts are
seated against Leg Extensions.
Assemble Left Leg Extension (F) and Right Leg Extension
(G) onto Rear Hanging Cleat (C) by sliding the Cam Posts (J)
into Cleat. BE SURE wood dowels in Cleat engage drilled
holes in Leg Extensions, and all parts are pressed flush against
each other.
Insert Camlocks (K) in holes in Rear Hanging Cleat (C),
with arrow pointing toward Cam Post opening. BE SURE
Camlocks engage Cam Posts, and are fully seated in Cleat.
Tighten Camlocks (K) clockwise to lock.
Align Wood Dowels (K) in assembled Leg Extensions with
holes in Shelf Tower, and press Tower and Leg Extensions
together.
F
G
C
K
M
MJ
ARROW TOWARD
CAM POST OPENING
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HANGING TOWER

7
INSTALLATION
7.1
7.2
7.3
Determine the mounting location for the unit. The unit can be wall mounted or floor mounted (by installing the Floor
Support Panels as shown in step 6).
Using a stud finder, locate studs to which the unit will be secured. Mark stud locations with a pencil.
With the unit positioned at the desired location, level the unit, then drill pilot holes through Rear Hanging Cleats (C),
NOTE: For 18" and 24" units, it is likely that only one stud will pass through the unit. In these cases, use two screws
through each Rear Hanging Cleat.
WITH LEG
EXTENSION KIT WITHOUT LEG EXTENSION KIT
12" FROM
FLOOR
STUDS
PILOT
HOLES
PILOT
HOLES
PILOT
HOLES
PILOT
HOLES
C
C
C
C
C
C C
C
C
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HANGING TOWER

8
8.1 Secure Rear Hanging Cleats (C) to
studs using 3" Screws (N).
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HANGING TOWER
C
N

9
9.1 Install one Rod Bracket (I) on Left Side Panel (A) and Right Side Panel (B) and secure each Bracket with one
screw (O).
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HANGING TOWER
I
I
A
O

10.1 Lower Hanging Rod (H) into Rod Brackets (I) on Left Side Panel (A) and Right Side Panel (B).
NOTE: Use care when installing Hanging Rod (H) to avoid scratching finish inside unit.
10
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HANGING TOWER
H
A
B
H
I
I

E
L
L
L
11.1
11.2
Insert eight Shelf Pins (L) into pin holes inside the Tower at the desired height.
Rest Adjustable Shelves (E) on Shelf Pins (L).
11
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HANGING TOWER
