Modular Closets ISLAND Instruction manual

ASSEMBLY AND INSTALLATION
INSTRUCTIONS
ISLAND
suppor[email protected]
1-844-969-4247

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
ISLAND
BOX 1
B
AC
D
E
GF
PARTS LIST - BOX 1
A
B
C
D
E
F
G
H
Side Panel (Qty 2)
Vertical Panel (Qty 1)
Top Panel (Qty 1)
Fixed Shelf (Qty 2)
Cleat (Qty 2)
Cam Post (Qty 26)
Camlock (Qty 26)
Wood Dowels (Qty 4)
1A
H

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
ISLAND
1B
1C
1.1
1.2
Lay parts out on a protective surface to prevent damage. Tip: Spread out the cardboard packaging to
use as a protective surface.
Inventory parts against the Parts List. Make sure all parts are present before proceeding.
Drill, 5/32" bit size
Phillips Screwdriver
TOOLS REQUIRED
(not included)
PARTS LIST (each box)
H
I
J
K
L
M
N
Drawer Panel, Front (Qty 2)
Drawer Panel, Rear (Qty 2)
Drawer Panel, Side (Qty 4)
Drawer Bottom (Qty 2)
Drawer Front (Qty 2)
Drawer Slide (Qty 4)
Shelf Slide (Qty 4)
O
P
Q
R
S
T
Drawer Pull (2)
Screw, Shelf Slide, 5/8" (Qty 8)
Screw, Drawer Slide, 5/8" (Qty 8)
Screw, Drawer Front, 1.0" (Qty 8)
Screw, Drawer Pull, 1.5" (Qty 4)
Screw, Drawer Side, 1.0" (Qty 8)
NOTE: Each set of Drawer Slides (M) and Shelf Slides (N) are shipped assembled. To separate, lift the plastic
catch on the Drawer Slide (M) and pull the Slide out of the Shelf Slide (N).
BOX 2 - 5
J
K
M
O
N
PQ R S
I
T
H
L

2
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
ISLAND
3
2.1
2.2
Install one Cam Post (F) into each of the ten holes on two Side Panels
(A). Tighten until Cam Posts are seated against Side Panels.
Insert four Wood Dowels (H) into holes in top edges of two Side Panels
(A).
3.1 Install one Cam Post (F) into each of the six holes on Top Panel (C). Tighten until Cam Posts are seated against
Top Panel.
A
H
HH
HA
C
F
F
F
F
F
FFFFFF
F
F
F
F
TOP
F
F
F

4
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
ISLAND
4.1 Assemble Vertical Panel (B) and two Cleats (E) onto Side Panel (A) by sliding the Vertical Panel and Cleats onto
the Cam Posts (F) on Side Panel (A). BE SURE dowel pins in Vertical Panel and Cleats engage drilled holes in
Side Panel, and all parts are pressed flush against Side Panel.
IMPORTANT NOTE
Install Cleats (E) with holes for Cam Locks facing the center of the unit and the unfinished edge facing the top of
the unit.
A
B
E
E
F
F
F
TOP

5
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
ISLAND
5.1 Assemble two Fixed Shelves (D) onto Side Panel (A) by sliding the Shelves onto the Cam Posts (F) on Side Panel
(A). BE SURE dowel pins in Shelves engage drilled holes in Side Panel, and all parts are pressed flush against
Side Panel.
IMPORTANT NOTE
Install Fixed Shelves (D) with holes for Cam Locks facing the bottom of the unit and the unfinished edge facing
Vertical Panel (B).
A
B
D
D
F
F
TOP

6
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
ISLAND
6.1 Install second Side Panel (A) onto assembled Vertical Panel (B), Fixed Shelves (D) and Cleats (E). BE SURE
dowel pins in Vertical Panel, Shelves and Cleats engage drilled holes in Side Panel, and Side Panel is pressed
flush against Panel, Shelves and Cleats.
TOP
A
B
D
E

7
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
ISLAND
TOP
ARROW TOWARD
CAM POST OPENING
7.1
7.2
Insert Camlocks (G) in holes in Vertical Panel (B), Fixed Shelves (D) and Cleats (E), with arrow pointing toward
Cam Post opening. Be sure Camlocks engage Cam Posts, and are fully seated in Panel, Shelves and Cleats.
Tighten Camlocks (G) clockwise to lock.
G
B
D
E
G
G
G

8
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
ISLAND
8.1
8.2
8.3
8.4
Stand the Island frame upright.
Lower the Top Panel (C) onto the Island frame. BE SURE dowel pins in Side Panels (A) and Vertical Panel (B)
engage drilled holes in Top Panel, and Top Panel is pressed flush against Side Panels and Vertical Panel.
Insert Camlocks (G) in holes in Vertical Panel (B) with arrow pointing toward Cam Post opening. Be sure Camlocks
engage Cam Posts, and are fully seated in Panel.
Tighten Camlocks (G) clockwise to lock.
ARROW TOWARD
CAM POST OPENING
C
A
A
G
G
G
G
B
G

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
ISLAND
9
9.1 Align Wood Dowels (pre-installed) in Front Drawer Panel (H) and Rear Drawer Panel (I) with holes in one Side
Drawer Panel (J), and press components together until flush.
H
I
K
J
H
I
J
3.1 Align Drawer Bottom (K) with slots in Front Drawer Panel (H) and Rear Drawer Panel (I) then slide Drawer Bottom
into assembled Drawer Panel s until Drawer Bottom is seated against Side Drawer Panel (J).
NOTE: Be sure to install Drawer Bottom (K) with finished side facing up.
10

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
ISLAND
11.1 Align Side Drawer Panel (J) with Wood Dowels (pre-installed) in Front Drawer Panel (H) and Rear Drawer Panel (I)
and press Side Drawer Panel (J) onto assembled components until flush.
12.1 Secure Side Drawer Panels (J) to Front Drawer Panel (H) and Rear Drawer Panel (I) using four 1.0" Drawer Side
Screws (T).
11
12
H
I
J
J
T
T
T
T
H
I
J
J

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
ISLAND
13
14
13.1 Position Drawer Front (L) on each assembled Drawer and secure to Front Drawer Panel (H) with four 1.0"
Screws (R).
14.1
14.2
14.3
For each Drawer, position Drawer Slide (M) against Drawer with
front end of Slide flush and square with rear side of Drawer Front
(L), then secure with two 5/8" Screws (Q) at locations shown.
Repeat for second Drawer Slide (M).
Install Drawer Pull (O) on each Drawer and secure with two 1.5"
Screws (S).
NOTE: DO NOT overtighten Screws (R) or surface of Drawer Front (L) may become dimpled.
Q
H
L
R
R
R
R
O
SS
MQ
Q
MQ
Q
L

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
ISLAND
15
15.1
15.2
For each Drawer, position Shelf Slide (N) over pre-drilled holes in shelf side panel, then secure with two 5/8"
Shelf Slide Screws (P) at locations shown.
Repeat for second Shelf Slide (N).
Tip: For best results, use a small level to ensure Shelf Slides (N) are properly positioned before tightening.
P
P
PP
P
N
N

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
ISLAND
16
16.1 Slide each Drawer onto Shelf Slides until slides latch.
