Modular Closets HUTCH Instruction manual

ASSEMBLY AND INSTALLATION
INSTRUCTIONS
HUTCH
suppor[email protected]
1-844-969-4247

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
1A
FRONT
FRONT
FRONT
FRONT
AB C
D
I,J
EF
GH
FINISHED EDGE
FINISHED EDGE
FINISHED EDGE
FINISHED EDGE FINISHED EDGE
MKL
NO

P
PARTS LIST
Q
R
S
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
1B
T
U
V
W
XY Z
AA BB
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
AA
BB
Left Side Panel, Base (Qty 1)
Right Side Panel, Base (Qty 1)
Top Shelf, Base (Qty 1)
Set Shelf, Base (Qty 1)
Left Side Panel, Upper (Qty 1)
Right Side Panel, Upper (Qty 1)
Set Shelf, Upper (Qty 1)
Adjustable Shelf, Upper (Qty 2)
Rear Cleat (Qty 3)
Toe Kick (Qty 1)
Cam Post (Qty 24)
Camlock (Qty 24)
Shelf Pins (Qty 8)
Wood Dowel, 8mm (Qty 8)
Screw, 2.5" (Qty 6)
Drawer Panel, Front (Qty 5)
Drawer Panel, Rear Qty (5)
Drawer Panel, Side (Qty 10)
Drawer Front (Qty 5)
Drawer Bottom (Qty 5)
Drawer Slide (Qty 10)
Shelf Slide (Qty 10)
Drawer Handle (Qty 5)
Euro Screw, 5/8" (Qty 20)
Screw, 5/8" (Qty 20)
Screw, 1" (Qty 48)
Screw, 1.5" (Qty 10)
Wood Dowel, 6mm (Qty 48)
Level
Stud Finder
Drill, 5/32" bit size
Phillips Screwdriver
TOOLS REQUIRED
(not included unless noted)

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
1C
1.1
1.2
Lay parts out on a protective surface to prevent damage.
Tip: Spread out the cardboard packaging to use as a protective surface.
Inventory parts against the Parts List. Make sure all parts are present before proceeding.
2
3
TOP
2.1 Install one Cam Post (K) into each of the 6 holes on Base Top Shelf (C). Tighten until Cam Posts are seated
against Top Shelf.
3.1 Install one Cam Post (K) into each of the 12 holes on Base Left Side Panel (A)
and Base Right Side Panel (B). Tighten until Cam Posts are seated against
Side Panels.
C
A
B
K
K
K
K
K
K
K

4
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
IMPORTANT NOTES
Install Set Shelf (D) with finished edge facing forward (toward front of unit) and holes for Cam Locks facing up
(toward the top of the unit).
Install lower Rear Hanging Cleat (I) and Toe Kick (J) with holes for Cam Locks facing the rear of the unit and
unfinished edges against Set Shelf (D).
Install upper Rear Hanging Cleat (D) with holes for Cam Locks facing the rear of the unit and the unfinished edge
facing the top of the unit.
4.1 Assemble Base Set Shelf (D), Rear Hanging Cleats (I) and Toe Kick (J) onto Base Right Side Panel (B) by sliding
the Shelves, Cleats and Toe Kick onto Cam Posts (K) on Right Side Panel. BE SURE dowel pins in Shelves, Cleats
and Toe Kick engage drilled holes in Right Side Panel, and all parts are pressed flush against Panel.
D
K
K
K
J
I
I
TOP

5
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
A
I
I
D
5.1 Install Base Left Side Panel (A) onto assembled Set Shelf (D), Rear Hanging Cleats (I) and Toe Kick (J). BE
SURE dowel pins in Shelf, Cleats and Toe Kick engage drilled holes in Side Panel, and Side Panel is pressed
flush against Set Shelf, Cleats and Toe Kick.
TOP

6
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
TOP
ARROW TOWARD
CAM POST OPENING
6.1
6.2
Insert Camlocks (L) in holes in Set Shelf (D), Rear Hanging Cleats (I) and Toe Kick (J) with arrow pointing
toward Cam Post opening. Be sure Camlocks engage Cam Posts, and are fully seated in Shelf, Cleats and
Toe Kick.
Tighten Camlocks (L) clockwise to lock.
L
D
I
I
L
L
L
L

7
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
7.1
7.2
7.3
Insert four Wood Dowels (N) into holes in edges of Base Left Side Panel (A) and Base Right Side Panel (B).
Install Base Top Shelf (C) onto assembled Base. BE SURE dowel pins in Base Left Side Panel (A) and Base
Right Side Panel (B) engage drilled holes in Top Shelf, and Top Shelf is pressed flush against Side Panels and
Rear Hanging Cleat (I).
Insert Camlocks (L) in holes in Base Left Side Panel (A) and Base Right Side Panel (B). BE SURE Camlocks
engage Cam Posts, and are fully seated in Side Panels. Tighten Camlocks (L) clockwise to lock.
ARROW TOWARD
CAM POST OPENING
N
B
C
A
ILL
L
N
N

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
8
9
8.1 Install one Cam Post (K) into each of the 6 holes on Upper Left Side Panel (E)
and Upper Right Side Panel (F). Tighten until Cam Posts are seated against
Side Panels.
TOP
TOP
E
GI
B
K
K
K
K
K
F
IMPORTANT NOTES
Install Set Shelf (D) with finished edge facing forward
(toward front of unit) and holes for Cam Locks facing
the top of the unit.
Install Rear Hanging Cleat (I) with holes for Cam
Locks facing the rear of the unit and unfinished edge
against Set Shelf (D).
9.1 Assemble Upper Set Shelf (G) and Rear Hanging
Cleat (I) onto Upper Right Side Panel (B) by sliding
the Shelf and Cleat onto Cam Posts (K) on Right
Side Panel. BE SURE dowel pins in Shelf and Cleat
engage drilled holes in Right Side Panel, and all
parts are pressed flush against Panel.

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
10
11
TOP
TOP
10.1 Install Upper Left Side Panel (E) onto
assembled Set Shelf (G) and Rear Hanging
Cleat (I). BE SURE dowel pins in Shelf and
Cleat engage drilled holes in Side Panel,
and Side Panel is pressed flush against Set
Shelf and Cleat.
11.1
11.2
Insert Camlocks (L) in holes in Set Shelf
(G) and Rear Hanging Cleat (I) with arrow
pointing toward Cam Post opening. Be sure
Camlocks engage Cam Posts, and are fully
seated in Shelf and Cleats.
Tighten Camlocks (L) clockwise to lock.
E
G
L
GI
LL
I
ARROW TOWARD
CAM POST OPENING

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
N
E
F
N
C
12.1
12.2
Insert four Wood Dowels (N) into holes in edges
of Upper Left Side Panel (E) and Upper Right
Side Panel (F).
Install assembled Upper Shelf onto assembled
Base. BE SURE dowel pins in Upper Left Side
Panel (E) and Upper Right Side Panel (F) engage
drilled holes in Base Top Shelf (C), and Upper
Shelf is pressed flush against Base.
12

STUDS
PILOT HOLES
PILOT HOLES
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
13
INSTALLATION
13.1
13.2
13.3
Determine the mounting location for the unit.
Using a stud finder, locate studs to which the unit will be secured. Mark stud locations with a pencil.
With the unit positioned at the desired location, level the unit, then drill pilot holes through Rear Hanging Cleats (C).
NOTE: Depending on the selected mounting location, it is possible that only one stud will pass through the unit. In this
case, use two screws through each Rear Hanging Cleat.
C
C
C

I
O
14.1 Secure Rear Hanging Cleats (I) to studs using six 2.5" screws (O).
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
14

15.1
15.2
Insert 8 Shelf Pins (M) into pin holes at the desired heights.
Rest Adjustable Shelves (H) on Shelf Pins (M).
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
15
H
MM
MM
M
H

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
16
17
16.1 Insert Wood Dowels (BB) into holes in ends of Front Drawer Panel (P) and Rear Drawer Panel (Q).
P
Q
BB
BB
BB
BB
BB
BB
BB
BB
P
Q
R
17.1 Align Wood Dowels in Front Drawer Panel (P) and Rear Drawer Panel (Q) with holes in one Side Drawer Panel
(R), and press components together until flush.

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
18
19
P
R
Q
T
18.1 Align Drawer Bottom (T) with slots in Front Drawer Panel (P) and Rear Drawer Panel (Q), then slide Drawer
Bottom into assembled Drawer Panels until Drawer Bottom is seated against Side Drawer Panel (R).
NOTE: Be sure to install Drawer Bottom (T) with finished side facing up.
19.1 Align Side Drawer Panel (R) with Wood Dowels in Front Drawer Panel (P) and Rear Drawer Panel (Q) and
press SIde Drawer Panel (R) onto assembled components until flush.
R
P
Q

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
20
21
20.1 Secure Side Drawer Panels (R) to Front Drawer Panel (P) and Rear Drawer Panel (Q) using 1.0" Drawer Side
Screws (Z).
R
P
Z
Z
Z
Z
Q
21.1
21.2
Position Drawer Slide (U) against Side Drawer Panel (R), then secure
with two 5/8" Drawer Slide Screws (Y) at locations shown.
Repeat for second Drawer Slide (F).
U
R
R
Y
Y
Y
Y
U
Y

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
22
22.1
22.2
Position Drawer Front (S) on assembled Drawer and secure to Front Drawer Panel (P) with 1.0" Screws (Z).
Install Drawer Handle (W) on Drawer and secure with two 1.5" Screws (AA).
NOTE: DO NOT overtighten Screws (Z) or surface of Drawer Front (D) may become dimpled.
A
S
Z
Z
W
L
L

23.1
23.2
Position Shelf Slide (V) over pre-drilled holes in Base Side Panel, then secure with two 5/8" Screws (Y) at locations
shown.
Repeat for second Shelf Slide (V).
Tip: For best results, use a small level to ensure Shelf Slides (V) are properly positioned before tightening.
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
23
Z
V
V
V
V
Z
ZZ
Z

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HUTCH
24
24.1
24.2
Slide Drawer onto Shelf Slides until slides latch.
Repeat steps 16 through 24 for the remaining four drawers.
