montpellier MR90CEMX-K User manual

90cm Double Oven Range Cooker
MR90CEMX-K - All Electric - Ceramic
Stainless Steel/Black
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING

Thank you for choosing this Montpellier All Electric, Ceramic Range Cooker.
Our Range Cookers have been designed to provide you with the best combination of style, reliability and
performance to give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing
or using your Cooker to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future reference.
Your Range Cooker is covered by a comprehensive two year Parts & Labour
Guarantee. In the unlikely event that you experience a problem with your
Cooker, you can rest assured that you are fully protected against the cost of
repairs for the first 24 months . Please note that any claim must be
accompanied by the model reference number, serial number and proof of
purchase.
To activate your guarantee, you will need your product serial number. This can
be found on the rear of the machine.
There are two ways to register your Guarantee:
•Online: Visit the Support page on our website and complete the online Product
Registration form. www.montpellier-appliances.com
•By Post: Simply detach and ll in the form provided, attach a stamp and send
it in the post. Don’t forget to include your e-mail address so that we can send
conrmation through to you.
Welcome
Note: We are unable to take registrations over the phone.
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com

2
Description Of The Appliance

3
CONTENTS:
Section 1. Installation
Section 2. Safety Advice
Section 3. Operating the Appliance
Section 4. Maintenance

4
S ection 1. Installation
•Remove all packaging, protective film and securing tape from
the appliance.
•Position the appliance in a dry atmosphere.
•The following dimensions are provided as a guide for
installation – your installer will carry out the installation in
accordance with the current regulations.
•Your installer will connect the power cable in accordance with
the current regulations.
1.1. Positioning the Appliance
•Position the appliance as shown in the diagram below.
•Ensure an air gap of at least 2cm on all sides of the appliance.
•You must ensure a minimum gap of 65cm between the top of
the appliance and a cooker hood. The gap must be 70cm if
there is no cooker hood installed above the appliance.

5
1.2. Electrical Connection
This appliance must be ‘hard wired’ into a suitable
fused spur adjacent to the appliance housing, by a Qualified
Electrician. Please note that a switchable spur should be accessible
above the work surface in order that the power can be turned
off by the consumer.
Your installer will supply and use the appropriate diameter of
electrical cable based on the Power Rating of the appliance as
shown on the Rating Label affixed to the appliance.
Electrical Connection Diagram:

6
1.3. Level the Appliance
Finally, ensure that the appliance is level by adjusting the 4
feet as shown below.

7
Section 2. Safety Advice
-Please read this booklet thoroughly before installing and
switching on the appliance. The manufacturer accepts no
responsibility for incorrect installation and usage.
-This appliance is guaranteed for Domestic Use Only.
-The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the
appliance.
-This appliance must only be used for cooking/heating food
items. Do not use it for any other purpose.
-If using an adaptor, this must be used in accordance with the
manufacturers instructions and ensure that the electrical
circuit is not overloaded as this could cause overheating.
-Do not twist or bend the cables, and keep them away from hot
surfaces.
-Following installation make sure that the power cable is not
trapped underneath the appliance.
-Keep the appliance surfaces clean. Failure to do this could lead
to the appliance malfunctioning.
-The surface of this appliance will get extremely hot during use.
Take care when using the appliance and keep children well
away.
-The interior and surface of this appliance will remain hot after it
has been turned off. Do not touch or clean the appliance until it
has completely cooled down.
-Never lift this appliance using the door handle or ‘open’ door.
-If the power supply cord is damaged, it must be replaced by the
manufacturer, it’s service agent or similarly qualified persons in
order to avoid a hazard.

8
Section 3. Operating the Appliance
3.1. Oven Control Panel
1. Oven Function Control Knob
2. Oven Thermostat Operation Light
3. Oven Thermostat Control Knob
4. Digital Timer
5. Rear Left Heat Zone Control Knob
6. Front Left Heat Zone Control Knob
7. Centre Heat Zone Control Knob
8. Front Right Heat Zone Control Knob
9. Rear Right Heat Zone Control Knob
3.2. Cooking & Functions
3.2.1. Operating the Hotplate
•Turn the appropriate Heat Zone control knob to the required
heat setting (Position 1 is low and position 6 is high – see
diagram below).
•Use only flat bottomed pans.
•Never use a pan with a smaller diameter than that of the heat
zone.

9
•Remember to turn the Heat Zone control knob back to Zero
when you have finished cooking.
3.2.2. Operating the Oven
•Turn the Oven Function Control Knob to the required setting
(See diagram below). See Section 3.2.4 for function list.
•Turn the Oven Thermostat Control Knob to the required heat
setting (See diagram below)
•The Oven Thermostat Operation Light will illuminate whilst the
oven heater is operating.

10
3.2.3. Setting the Timer

11

12

13

14
3.2.4. List of Cooking Functions
Please note that your model may not feature all of the functions
listed below:

15

16
Section 4. Maintenance
Before any maintenance or cleaning work is carried out,
DISCONNECT the appliance from the ELECTRICITY supply and
ensure that the appliance is completely cool.
4.1. Cleaning the Oven
Clean spillages from inside the oven as soon as possible after use.
Always ensure that the surface has cooled down before cleaning.
Use a cloth with warm soapy water to clean the surface. If the
spillage has dried on the surface you may need to use a specialist
oven cleaner, available from all good supermarkets.
Clean the glass door with warm soapy water – always ensure the
glass is cool before you clean it!
4.2. Changing the Oven Bulb (If fitted to your model)
Proceed as follows when the glass is cold:
•Unscrew the glass cover
•Remove the bulb
•Fit new like for like bulb (*)
•Replace glass cover
(*) Must be a 25w Type E14
replacement oven bulb avail;able
from most harware or lighting shops.

17
4.3. Removing the Oven Door
If your oven is fitted with a removable door, proceed as follows:
In order to improve access when
cleaning the oven, you can remove
the door as follows:
Lift the two safety catches up then
close the oven door partially. Now
lift the door upwards and away
from the oven. To refit the door
carry out the above in reverse
order, ensuring the safety catches
are lowered back into place.
If you need to clean in between the
glass door panels, remove the 2
screws and the end panel (as
shown left) and then carefully slide
the glass out of the door frame.
Clean the glass panels and
carefully slide the glass back into
the door frame. Refit the end panel
and ensure that the 2 screws are in
place.
N.B. Your guarantee does not
cover damaged or broken glass on
the oven door.

18
4.4. What to do if something goes wrong
There is no power to the appliance:
-Check there is not a power cut
-Check there is power to the electric socket/appliance
The oven operates but the oven light is not working:
-If your model is fitted with an oven light, replace the oven bulb
as described in section 4.2. above. Please note that bulbs are
not covered under the guarantee.

Here For You
Here For You
After-sales assistance
If you continue to experience problems with your Range Cooker, please call the Montpellier customer service
helpline on: 01759 487839.
Please have all your product details available, including the model number, serial number, date of purchase,
and your retailer’s details before registering a fault.
The service call cannot progress without this information.
Your 2 year Manufacturer’s guarantee
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
Your new Montpellier appliance carries a free guarantee which protects you against the cost of repairs during the
rst 24 months from date of purchase provided that:
Any claim is accompanied by evidence of the model reference, model serial number and proof of purchase, such
as a Sales Receipt, showing that the appliance was purchased within the 24 months prior to the date
of claim.
What is not covered under the Guarantee
•Any appliance not correctly installed and operated in accordance with the manufacturer’s instructions.
•Any appliance that is used for anything other than domestic purposes.
• Any defect caused by accident, misuse, unauthorised modication or inexpert repair.
•Cost of Call-out where a fault cannot be found with the appliance.
• Cost of Call-out for work covering routine maintenance, such as, but not exclusively, cleaning of lters or
defrosting.
•Cost of Call-out for work required to correct the alignment of doors following door reversal procedures carried
out by you.
•Use of the appliance by anyone other than the Householder.
•Use in any commercial environment.
•Consumable items, such as, but not exclusively, fuses in plugs, bulbs and breakable items which require
routine replacement.
•Repair costs incurred that have not been authorised by Repairtech and/or carried out by a non-approved
Repairtech engineer.
YOUR GUARANTEE IS VALID ONLY IN THE UK & ROI.
To register your appliance simply complete the card in your appliance pack and return it with a stamp axed or
alternatively you can register online at www.montpellier-appliances.com/support
SERVICE HELP-LINE
Should your appliance develop a fault, please call the Montpellier customer service helpline on: 01759 487839.
Please remember to have all your product details available, including the model number, serial number, date of
purchase and your retailer’s details before registering a fault.
Your service call cannot progress without this information.
