montpellier MTE51W User manual

Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION, STYLE AND RELIABILITY
LAUNDRY - DISHWASHING - COOKING - COOLING
Freestanding 50cm Twin Cavity Cooker
MTE51W - White
Please read these instruction carefully before attempting to install or use this appliance.
We recomment that you keep these instructions in a safe place for future reference.

Thank you for choosing this Montpellier Freestanding Cooker.
Our cookers have been designed to provide you with the best combination of style, reliability and performance to
give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing
or using your freestanding cooker to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future reference.
Your cooker is covered by a comprehensive two year Parts & Labour Guarantee.
In the unlikely event that you experience a problem with your Cooker, you can
rest assured that you are fully protected against the cost of repairs for the first
24 months . Please note that any claim must be accompanied by the model
reference number, serial number and proof of purchase.
To activate your guarantee, you will need your product serial number. This can
be found on the rear of the machine.
There are two ways to register your Guarantee:
•Online: Visit the Support page on our website and complete the online Product
Registration form. www.montpellier-appliances.com
•By Post: Simply detach and ll in the form provided, attach a stamp and send
it in the post. Don’t forget to include your e-mail address so that we can send
conrmation through to you.
Welcome
Note: We are unable to take registrations over the phone.
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com

EN - 2
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
CAUTION Injury or property damage risk
IMPORTANT Operating the system correctly
Thank you for choosing this product.
This User Manual contains important safety information and instructions on the
operation and maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep this
book for future reference.

CONTENTS
1. SAFETY INSTRUCTIONS ................................................................................................ 4
1.1. General Safety Warnings ..............................................................................................4
1.2. Installation Warnings .....................................................................................................6
1.3. During Use.....................................................................................................................7
1.4. During Cleaning and Maintenance ................................................................................8
2. INSTALLATION AND PREPARATION FOR USE ..........................................................10
2.1. Instructions for the Installer .........................................................................................10
2.2. Electrical Connection and Safety................................................................................. 11
2.3. Anti-tilting kit ................................................................................................................ 12
2.4. Adjusting the feet .........................................................................................................12
3. PRODUCT FEATURES ...................................................................................................13
4. USE OF PRODUCT ........................................................................................................14
4.1. Control of Hob ............................................................................................................14
5. CLEANING AND MAINTENANCE .................................................................................16
5.1. Cleaning 16
5.2. Maintenance ................................................................................................................17
6. TROUBLESHOOTING&TRANSPORT ........................................................................... 18
6.1. Troubleshooting ........................................................................................................... 18
6.2. Transport 18
EN - 3

EN - 4
1. SAFETY INSTRUCTIONS
•Carefully read all instructions before using your
appliance and keep them in a convenient place for
reference when necessary.
•This manual has been prepared for more than one
model therefore your appliance may not have some
of the features described within. For this reason, it is
important to pay particular attention to any figures
whilst reading the operating manual.
1.1. General Safety Warnings
•This appliance can be used by children aged from 8
years and above and by persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved. Children should not play with the
appliance. Cleaning and user maintenance should
not be made by children without supervision.
•
•
•
•
WARNING: The appliance and its accessible
parts become hot during use. Care should be taken
to avoid touching heating elements. Keep children
less than 8 years of age away unless they are
continually supervised.
WARNING: Unattended cooking on a hob with
fat or oil can be dangerous and may result in fire.
NEVER try to extinguish such a fire with water, but
switch off the appliance and cover the flame with a
lid or a fire blanket.
WARNING: Danger of fire: do not store items on
the cooking surfaces.
WARNING: If the surface is cracked, switch
off the appliance to avoid the possibility of electric

EN - 5
shock.
•For models which incorporate a hob lid, clean any
spillages off the lid before use and allow the cooker
to cool before closing the lid.
•Do not operate the appliance with an external timer
or separate remote-control system.
• WARNING: To prevent
the appliance tipping, the
stabilising brackets must
be installed. (For detailed
information refer to the
anti-tilting kit set guide.)
•During use the appliance will get hot. Care should be
taken to avoid touching heating elements inside the
oven.
•Handles may become hot after a short period of
time during use.
•Do not use harsh abrasive cleaners or scourers to
clean oven surfaces. They can scratch the surfaces
which may result in shattering of the door glass or
damage to surfaces.
•Do not use steam cleaners to clean the appliance.
•
•
WARNING: To avoid the possibility of electric
shocks, make sure that the appliance is switched off
before replacing the lamp.
CAUTION: Accessible parts may be hot when
cooking or grilling. Keep young children away from
the appliance when it is in use.
•Your appliance is produced in accordance with all
applicable local and international standards and
regulations.
•Maintenance and repair work should only be carried
out by authorised service technicians. Installation
and repair work that is carried out by unauthorised

EN - 6
technicians may be dangerous. Do not alter or
modify the specifications of the appliance in any
way. Inappropriate hob guards can cause accidents.
•Before connecting your appliance, make sure
that the local distribution conditions (nature of the
gas and gas pressure or electricity voltage and
frequency) and the specifications of the appliance
are compatible. The specifications for this appliance
are stated on the label.
• CAUTION: This appliance is designed only for
cooking food and is intended for indoor domestic
household use only. It should not be used for any
other purpose or in any other application, such as
for non-domestic use, in a commercial
environment or for heating a room.
•Do not use the oven door handles to lift or move the
appliance.
•All possible measures have been taken to ensure
your safety. Since the glass may break, care should
be taken while cleaning to avoid scratching. Avoid
hitting or knocking the glass with accessories.
•Make sure that the supply cord is not trapped or
damaged during installation. If the supply cord is
damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in
order to prevent a hazard.
•Do not let children climb on the oven door or sit on it
while it is open.
1.2. Installation Warnings
•Do not operate the appliance before it is fully
installed.
•The appliance must be installed by an authorised
technician. The manufacturer is not responsible

EN - 7
for any damage that might be caused by incorrect
placement and installation by unauthorised people.
•When the appliance is unpacked, make sure that it
has not been damaged during transportation.
In the case of a defect, do not use the appliance and
contact a qualified service agent immediately. The
materials used for packaging (nylon, staplers,
styrofoam, etc.) may be harmful to children and they
should be collected and removed immediately.
•Protect your appliance from the atmosphere. Do not
expose it to sun, rain, snow, dust or excessive
humidity.
•Materials around the appliance (i.e. cabinets) must
be able to withstand a minimum temperature of 100°
C.
1.3. During Use
•When you first use your oven you may notice a slight
smell. This is perfectly normal and is caused by the
insulation materials on the heater elements. We
suggest that, before using your oven for the first
time, you leave it empty and set it at maximum
temperature for 45 minutes. Make sure that the
environment in which the product is installed is well
ventilated.
•Take care when opening the oven door during or
after cooking. The hot steam from the oven may
cause burns.
•Do not put flammable or combustible materials in or
near the appliance when it is operating.
•Always use oven gloves to remove and replace food
in the oven.
•Do not leave the cooker unattended when cooking
with solid or liquid oils. They may catch fire

EN - 8
under extreme heating conditions. Never pour water
on to flames that are caused by oil, instead switch
the cooker off and cover the pan with its lid or a fire
blanket.
•Always position pans over the centre of the cooking
zone, and turn the handles to a safe position so they
cannot be knocked.
•If the product will not be used for a long period of
time, turn the main control switch off. Turn the gas
valve off when gas appliances are not in use.
•Make sure the appliance control knobs are always in
the “0” (stop) position when the appliance is not in
use.
•The trays incline when pulled out. Take care not
to spill or drop hot food when removing it from the
oven.
•Do not place anything on the oven door when it is
open. This could unbalance the oven or damage the
door.
•Do not place heavy or flammable items (e.g. nylon,
plastic bags, paper, cloth, etc.) into the drawer. This
includes cookware with plastic accessories (e.g.
handles).
• CAUTION: The inside surface of the storage
compartment may get hot when the appliance is
in use. Avoid touching the inside surface.
•Do not hang towels, dishcloths or clothes from the
appliance or its handles.
1.4. During Cleaning and Maintenance
•Always turn the appliance off before operations
such as cleaning or maintenance.
•Do not remove the control knobs to clean the
control panel.

•To maintain the efficiency and safety of your
appliance, we recommend you always use original
spare parts and to call our authorised service agents
when needed.
CE Declaration of conformity
We declare that our products meet the
applicable European Directives, Decisions
and Regulations and the requirements listed
in the standards referenced.
This appliance has been designed to be used only for
home cooking. Any other use (such as heating a room)
is improper and dangerous.
The operating instructions apply to several models.
You may notice differences between these
instructions and your model.
Disposal of your old machine
This symbol on the product or on its
packaging indicates that this product should
not be treated as household waste. Instead it
should be handed over to the applicable
collection point for the recycling of electrical
and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential
negative consequences for the environment and
human health, which could otherwise be caused by
inappropriate waste handling of this product. For more
detailed information about recycling of this product,
please contact your local city office, your household
waste disposal service or the retailer who you
purchased this product from.
EN - 9

EN - 10
2. INSTALLATION AND
PREPARATION FOR USE
WARNING : This appliance must be
installed by an authorised service
person or qualified technician,
according to the instructions in this
guide and in compliance with the current
local regulations.
•Incorrect installation may cause harm
and damage, for which the manufacturer
accepts no responsibility and the
warranty will not be valid.
•Prior to installation, ensure that the local
distribution conditions (electricity
voltage and frequency and/or nature of
the gas and gas pressure) and the
adjustments of the appliance are
compatible. The adjustment conditions
for this appliance are stated on the label.
•The laws, ordinances, directives and
standards in force in the country of use
are to be followed (safety regulations,
proper recycling in accordance with the
regulations, etc.).
2.1. Instructions for the Installer
General instructions
•After removing the packaging material
from the appliance and its accessories,
ensure that the appliance is not
damaged. If you suspect any damage,
do not use it and contact an authorised
service person or qualified technician
immediately.
•Make sure that there are no flammable
or combustible materials in the close
vicinity, such as curtains, oil, cloth etc.
which may catch fire.
•The worktop and furniture surrounding
the appliance must be made of
materials resistant to temperatures
above 100°C.
•The appliance should not be installed
directly above a dishwasher, fridge,
freezer, washing machine or clothes
dryer.
•The appliance can be placed close to
other furniture on condition that, in the
area where the appliance is set up, the
furniture’s height does not exceed the
height of the cooktop.
Installation of the Cooker
•If the kitchen furniture is higher than the
cooktop, the kitchen furniture must be at
least 10 cm away from the sides of
appliance for air circulation.
•There should be a minimum 2cm blank
space around the appliance for air
circulation.
•If a cooker hood or cupboard is to be
installed above the appliance, the safety
distance between cooktop and any
cupboard/cooker hood should be as
shown below.
A (mm) 420
B (mm) Cooker Hood/Cupboard 650/700
C (mm) 20
D (mm) Product Width
E (mm) 50

EN - 11
ABCC
DE
2.2. Electrical Connection and Safety
WARNING: The electrical connection
of this appliance should be carried out
by an authorised service person or
qualified electrician, according to the
instructions in this guide and in
compliance with the current local
regulations.
WARNING: THE APPLIANCE MUST
BE EARTHED.
•Before connecting the appliance to the
power supply, the voltage rating of the
appliance (stamped on the appliance
identification plate) must be checked for
correspondence to the available mains
supply voltage, and the mains electric
wiring should be capable of handling the
appliance’s power rating (also indicated
on the identification plate).
•During installation, please ensure
that isolated cables are used. An
incorrect connection could damage your
appliance. If the mains cable is damaged
and needs to be replaced this should be
done by a qualified personnel.
•
•
Do not use adaptors, multiple sockets
and/or extension leads.
The supply cord should be kept away
from hot parts of the appliance and must
not be bent or compressed. Otherwise
the cord may be damaged, causing a
short circuit.
•If the appliance is not connected to the
mains with a plug, a multi-pole isolator
switch (with at least 3 mm contact
spacing) must be used in order to meet
the safety regulations.
•The appliance is designed for a power
supply of 220-240 V~. If your supply is
different, contact the authorized service
personnel or qualified electrician.
•The power cable (H05VV-F) must be
long enough to be connected to the
appliance.
•The fused switch must be easily
accessible once the appliance has been
installed.
•Ensure all connections are adequately
tightened.
•Fix the supply cable in the cable clamp
and then close the cover.
•The terminal box connection is placed
on the terminal box.
44
NN PE
PE
L3 L2 L1 L
5 5
33
22 11

EN - 12
•
•
Green/Yellow (Earth) wire to the
terminal marked "PE".
Brown (Live) wire to the terminal
marked "L".
•Blue (Neutral) wire to the terminal
marked "N".
•For this connection, a ‘Twin and Earth
6242Y’ type cable should be used.
2.3. Anti-tilting kit
Anti-tilting
Bracket
(x1) (will be
attached to the
wall) Dowel (x1)
Screw (x1)
1 2
3
The document bag contains an anti-tilting
kit. Loosely attach the anti-tilting bracket (1)
to the wall using the screw (2) and dowel (3),
following the measurements shown in the
figure and table below. Adjust the height of
the anti-tilting bracket so that it lines up
with the slot on the cooker and tighten the
screw. Push the appliance towards the wall
making sure that the anti-tilting bracket
is inserted into the slot on the rear of the
appliance.
A
B
Anti-
tilting
bracket
Wall
Product Dimensions
(Width X Depth X Height) (Cm) A (mm) B (mm)
60x60x90 (Double Oven) 297.5 52
50x60x90 (Double Oven) 247.5 52
90x60x85 430 107
60x60x90 309.5 112
60x60x85 309.5 64
50x60x90 247.5 112
50x60x85 247.5 64
50x50x90 247.5 112
50x50x85 247.5 64
2.4. Adjusting the feet
Your product stands on four adjustable
feet. For safe operation, it is important that
your appliance is correctly balanced. Make
sure the appliance is level prior to cooking.
To increase the height of the appliance,
turn the feet anti-clockwise. To decrease
the height of the appliance, turn the feet
clockwise.
It is possible to raise the height of the
appliance up to 30 mm by adjusting the
feet. The appliance is heavy and we
recommend that a minimum of 2 people
lift it. Never drag the appliance.

EN - 13
3. PRODUCT FEATURES
Important: Specifications for the product vary and the appearance of your appliance
may differ from that shown in the figures below.
List of Components
1. Cooktop
2. Control Panel
3. Top Oven Door Handle
4. Top Oven Door
5. Main Oven Door Handle
6. Main Oven Door
7. Adjustable Feet
1
2
3
4
5
6
7
Control Panel
8. Top Oven Control Knob
9. Main Oven Control Knob
10. Hob Control Knob
8910 10 10 10

EN - 14
4. USE OF PRODUCT
4.1. Control of Hob
Control of the hotplate
The hotplate is controlled by a 6 position
switch.
The hotplate can be operated by switching
the control knob to one of these positions.
Near each hob control knob, there is a small
symbol that shows which hotplate is
controlled by that knob. The on/off light on
the control panel shows which hotplates
are in use.
Knob
Position Function
0Off position
1To melt butter etc. and to warm small
quantities of liquid
2To warm bigger quantities of liquid. To
prepare creams and sauces
3To defrost food for cooking
4To cook delicate meat and fish
5To roast meat and steak
6To boil big quantities of liquid or to fry
WARNING:
•When operating the hotplate for the
first time or whenever it has not been
used for a prolonged period of time, it
is necessary to eliminate any humidity
which may have accumulated around
the electrical elements of the plate. To
do this, operate the hotplate on its
lowest setting for about 20 minutes.
•Never operate a hotplate without pans
on.
•Only use flat-bottomed pans with thick
bases.
•Make sure the bottom of the pan is dry
before placing it on a hotplate
•When a hotplate is in operation, make
sure that the pan is centered correctly
on it.
•Never use a pan with a smaller or larger
diameter than that of the hotplate as this
will waste energy.
Circular Saucepan
Base
Small Saucepan
Diameter
Saucepan base that
has not settled
•
•
If possible, always place lids on the
pans.
The temperature of accessible parts
maybe high when the appliance is
operating. It is imperative to keep
children and animals well away from
the hob during use and until it has fully
cooled after use.
•If you notice a crack on the cook top it
must be immediately switched off and
replaced by an authorized service
personnel or technician.
Main Oven Functions
* The functions of your oven may be
different due to the model of your
product. Static Cooking
Function: Switch on
the STATIC function
by using the main oven
function control knob.
The oven’s thermostat
and warning lights will
be turned on and the
lower and upper heating elements will start
operating. Adjust to the required
temperature using the main oven function
control knob. The static cooking function
emits heat, ensuring even cooking of the
food. This is ideal for making pastries,
cakes, baked pasta, lasagne and pizza.
Prehating the oven for 10 minutes is

EN - 15
recommended and it is best to cook on
only one shelf at a time in this function.
Lower Heating
Function: Switch on
the LOWER function by
using the main oven
function control knob.
The oven’s thermostat
and warning lights will
be turned on and the
lower heating element will start operating.
The temperature setting will be at the
highest level at this function. The lower
heating function is ideal for heating pizza,
as the heat rises from the bottom of the
oven and warms the food up. This function
is appropriate for heating the food instead
of cooking.
Upper Heating
Function: Switch on
the UPPER function by
using the main oven
function control knob.
The oven’s thermostat
and warning lights will
be turned on and the
upper heating element will start operating.
The temperature setting will be at the
highest level in this function. In this type of
cooking, the heat emanating from upper
heating element cooks the upper side of the
food. The upper heating function is ideal for
frying the upper side of already cooked food
and for heating the food.
Top Oven Function
*The functions available on your oven may
differ from those listed below depending on
the model purchased.Grilling Function:
Switch on the GRILL
function using the
function selector
knob. The oven
thermostat and
warning lights will
illuminate and the grill
heating element will switch on. Select the
required temperature using the function
selector knob. Refer to the cooking table
for further information. Use this function for
grilling. When you have finished grilling,
switch the top oven off. Keep children away
from the oven during grilling and until it has
fully cooled after use.
Warning: The top oven door must be
kept open when using this function.
Grill Heat Shield
WARNING
When using the grill for longer than
15 minutes, always fit the heat shield
provided, to prevent the control knobs
from overheating. Take care to avoid
touching the heat shield when closing the
oven door. Allow the heat shield to cool
before removing.
Wire Grid
The wire grid is used when grilling or
processing food in other containers.
WARNING: The wire grid is used
when grilling or processing food
in other containers.

EN - 16
5. CLEANING AND
MAINTENANCE
5.1. Cleaning
WARNING: Switch off the appliance
and allow it to cool down before
cleaning your appliance.
General Instructions
•Check whether the cleaning materials
are appropriate and recommended by
the manufacturer before using on your
appliance.
•Use cream cleaners or liquid cleaners
which do not contain particles. Do not
use caustic (corrosive) creams, abrasive
cleaning powders, rough wire wool or
hard tools as they may damage the
cooker surfaces.
•Do not use cleaners that contain
particles, as they might scratch the
glass, enameled and/or painted
parts of your appliance.
•Should any liquids overflow, clean them
up immediately to avoid parts becoming
damaged.
•Do not use steam cleaners for cleaning
any part of the appliance.
Cleaning the inside of the Oven
•The inside of enamelled ovens are best
cleaned when the oven is warm.
•Wipe the oven with a soft cloth soaked
in soapy water after each use. Then
wipe the oven over again with a wet
cloth and then dry it.
•You may need to use a liquid cleaning
material occasionally to completely
clean the oven.
Cleaning the Hotplate Heater
•Clean the hotplate heater on a regular
basis.
•Wipe the hotplate with a soft cloth
soaked in only water. Then run
the hotplate for a short time to dry
completely.
Cleaning the Enamelled Parts
•Clean the enamelled parts of your
appliance on a regular basis.
•Wipe the enamelled parts with a soft
cloth soaked in soapy water. Then wipe
them over again with a wet cloth and
then dry them.
•Do not wash the enamelled parts when
they are still hot from cooking.
•Do not leave vinegar, coffee, milk, salt,
water, lemon or tomato juice on the
enamel for a long time.
Cleaning the Stainless Steel Parts (If
avaliable)
•Clean the stainless steel parts of your
appliance on a regular basis.
•Wipe the stainless steel parts with a soft
cloth soaked in only water. Then dry
them thoroughly with a dry cloth.
•Do not wash the stainless steel parts
when they are still hot from cooking.
•Do not leave vinegar, coffee, milk, salt,
water, lemon or tomato juice on the
stainless steel for a long
time.
Removal of Oven Door
Before cleaning the oven door glass, you
must remove the oven door as shown: 1.
Open the oven door.

EN - 17
2. Open the saddle bracket (a)(with the aid
of a screwdriver) up to the end position.
a
3. Close the door until it almost reaches the
fully closed position and remove the door
by pulling it towards you.
5.2. Maintenance
WARNING: The maintenance of this
appliance should be carried out by an
authorised service person or qualified
technician.
Change of Oven Lamp
WARNING: Switch off the appliance
and allow it to cool down before
cleaning your appliance.
•Remove the glass lense and then
remove the bulb.
•Insert the new bulb (resistant to 300°C)
to replace the bulb that you removed
(230 V, 15-25 Watt, Type E14).
•Replace the glass lens, then your oven
is ready for use.
The lamp design is designed specifically
for use in household cooking
appliances. It is not suitable for
household room illumination.

EN - 18
6. TROUBLESHOOTING&TRANSPORT
6.1. Troubleshooting
After checking these basic trouble shooting, if you have still problem with your
appliance, please contact with an authorised service person or qualified technician.
Problem Possible Cause Solution
The hob or cooking
zones cannot be
switched on.
There is no power supply.
Check the household fuse for the appliance.
Check whether there is a power cut by trying
other electronic appliances.
The hob produces an
odour during the first
cooking sessions.
New appliance Heat a saucepan full of water on each
cooking zone for 30 minutes.
Oven does not turn on. Power is turned off.
Check whether there is power supplied.
Also check that other kitchen appliances
are working.
No heat or oven does
not warm up.
Oven temperature control is
incorrectly set.
Oven door has been left open.
Check the oven temperature control knob
is set correctly.
Cooking is uneven within the
oven.
Oven shelves are incorrectly
positioned.
Check that the recommended temperatures
and shelf positions are being used.
Do not frequently open the door unless you
are cooking things that need to be turned. If
you open the door often, the interior
temperature will be lower and this may affect
the results of your cooking.
Oven light (if avaliable) does
not operate.
Lamp has failed.
Electrical supply is
disconnected or switched off.
Replace lamp according to the instructions.
Make sure the electrical supply is turned on
at wall socket outlet.
The oven fan (if avaliable) is
noisy. Oven shelves are vibrating.
Check that the oven is level.
Check that the shelves and bakeware are
not vibrating in contact with the oven
back panel.
6.2. Transport
If you need to transport the product, use the original product packaging and carry it using
its original case. Follow the transport signs on the packaging. Tape all independent parts to
the product to prevent damaging the product during transport.
If you do not have the original packaging; prepare a carriage box so that the appliance,
especially the external surfaces of the product, are protected against external threats.

EN - 19
Brand
Model MTE51W
Type of Oven ELECTRIC
Mass kg 42
Upper Cavity
Energy Efficiency Index - conventional -
Energy Efficiency Index - fan forced -
Energy Class -
Energy consumption (electricity) - conventional kWh/cycle -
Energy consumption (electricity) - fan forced kWh/cycle -
Heat Source ELECTRIC
Volume l 30
Lower Cavity
Energy Efficiency Index - conventional 94,5
Energy Efficiency Index - fan forced -
Energy Class A
Energy consumption (electricity) - conventional kWh/cycle 0,73
Energy consumption (electricity) - fan forced kWh/cycle -
Heat Source ELECTRIC
Volume l 53
Number of cavities 2
This oven complies with EN 60350-1
Energy Saving Tips
Oven
- Cook the meals together, if possible.
- Keep the pre-heating time short.
- Do not elongate cooking time.
- Do not forget to turn-off the oven at the end of
cooking.
- Do not open oven door during cooking period.
