iTeach®High Capacity Charging Cart
Owner’s Manual

www.moorecoinc.com | 800.749.22582
Exterior Features:
ALocking double doors on both front and back
BKeyed security lock
CVentilation slots on each side
DCurved ergonomic push handle on each side
EPower cord wrap hooks
FReceptacle for AC power cord
GFour heavy-duty swivel casters (two locking)
Interior Features:
HKeyed security lock
I16, 32, or 48 horizontal easy load slots
JUSB connector for device cable
KLED charge indicators
Physical Features
LEDs shown lit for illustration purposes only.

800.749.2258 | www.moorecoinc.com 3
Electrical Testing
▪Before using your new iTeach®High Capacity Charging
Cart, have a qualied electrician verify the current draw
does not exceed the rating of the unit when all the
devices are installed.
▪Test the branch circuit for ground integrity and branch
circuit protection.
▪Do not plug in the unit if the receptacle or power cord
have been damaged, or if the ground prong is missing
from the AC plug. If repairs are ever needed, they
should be performed by a qualied electrician.
Safety First!
▪This unit must always be used by adults or with adult
supervision.
▪Liquids should not be in, on, or around the iTeach High
Capacity Charging Cart.
▪Do not use outdoors.
▪Do not use the unit if the cord appears to be damaged
or if the ground prong is missing. When the unit is
not plugged in, wrap the power cord around the cord
wraps.
▪Do not use an extension cord with this unit.
▪Do not use the power cord to pull the cart.
First Steps
▪Remove packing materials and loose components,
including the power cord, lock keys, and printed cart
documentation.
▪Always use a qualied electrical circuit to be sure you
are powering the cart properly and in accordance to
the cart’s specications and requirements.
Getting Started
▪Read owner’s manual and understand safe use
guidelines before operating cart to ensure personal
safety.
▪Plug AC power cord into receptacle on side of cart.
Plug AC power cord into wall outlet. Cart will power
ON.
▪Release lock and open doors to reveal 16, 32, or 48
horizontal device slots.
▪Red LED indicators should be lit to indicate power to
the cart.
▪Plug desired device cords into exposed USB ports.
▪Slide up to 48 devices into slots with power port side
out, and plug corresponding cord into device.
▪LED indicators will change color based on charge time
of device. See technical specs on page 5 for LED
charging indication.

www.moorecoinc.com | 800.749.22584
The iTeach®High Capacity Charging Cart is designed to
charge Apple iPad devices, Apple iPod Touch devices,
Samsung Galaxy tablets, Amazon Kindle, Barnes and
Noble Nook, and other devices that support charging via
USB. Multiple brands can be mixed within the iTeach High
Capacity Charging Cart. Please contact MooreCo at 1-800-
749-2258 for additional compatibility information.
Before using the iTeach High Capacity Charging Cart, it
must be plugged into an AC outlet (100-120 VAC, 60Hz)
with a minimum of 15 Amp rating. The iTeach High Capacity
Charging Cart uses a maximum of 10.0 Amps, but should
be powered by an outlet with extra capacity.
Prior to opening or using the iTeach High Capacity Charging
Cart, the locks on the two locking casters should be
engaged to prevent the cart from moving. Any time the
iTeach High Capacity Charging Cart needs to be moved,
the two locks on the locking casters must be disengaged.
The iTeach High Capacity Charging Cart top is a convenient
work surface, but designed for use only when closed.
Please close all doors prior to use as a work surface.
Each charging port consists of a row of four LEDs and
a charging cable ending with a female USB Type A
connector. In order to charge a particular type of device,
the corresponding style cable must be plugged into the
charging cable. For example, an Apple iPad cable is
required for charging an iPad.
As a tablet is charged, additional blue LEDs will appear to
indicate charging time. One blue LED is visible for the initial
90 minutes (1.5 hours) of charging. After 90 minutes, a
second blue LED appears. Once an additional 90 minutes
has passed, a third blue LED lights up. The fourth blue
LED becomes visible after the tablet has been charged 4.5
hours.
The following list summarizes the meaning of each LED
status indication:
1 red LED: Nothing connected
1 blue LED: tablet connected, less than 1.5 hours
charge time
2 blue LEDs: tablet connected, charge time between
1.5 and 3 hours
3 blue LEDs: tablet connected, charge time between
3 and 4.5 hours
4 blue LEDs: tablet connected, charge time more
than 4.5 hours
Any time the iTeach High Capacity Charging Cart has
power, each port should display one of the LED indications
above.
The iTeach High Capacity Charging Cart does not have a
power switch. Therefore, it must be unplugged from the AC
outlet to be turned off.
In the event that the iTeach High Capacity Charging Cart
is plugged into an AC outlet without lighting any LEDs,
the cart is not receiving power. This can be caused by a
blown fuse located inside the AC receptacle of the iTeach
High Capacity Charging Cart, or by a problem with the AC
outlet (such as a blown breaker). In such circumstances,
a properly trained technician should be contacted to
address the situation. The fuse type used in the iTeach High
Capacity Charging Cart is a F 10AL 250V (Fast Acting/Fast
Blow, 10 Amp, Low Breaking Capacity, 250 Volt).
Cart Operation

800.749.2258 | www.moorecoinc.com 5
Technical Specifications
Item Specification
Body Powder-coated steel
Top Coordinating HPL with edgebanding and keyed locking device
Casters Extra durable 5" swivel casters, two locking
Tablet Compartments Five stage LED light indicators in cushioned tablet slots. LED attached/detached
indicator. Slots measure 12.26"H x 8.2"W x .96"D. Hold tablet and case up to
.875" thick.
Handles Full width angular handle for maneuvering, ts through all standard doorways.
Capacity 32 tablets
Recommended Devices Versions of the Apple iPad, Apple iPad Mini, Kindle Fire, Barnes & Noble Nook, HP
TouchPad, Dell Streak, Samsung Galaxy. Call for assistance with specic device
compatibility.
Input 100-120 VAC 50-60Hz, 10 Amps
Output 32 x 5 VDC at 2.1A
Prole Automatic charger emulation prole cycling for USB-IF BC1.2DCP (Android),
YD/T-1591 (Apple iPad and iPhone), and RIM (Blackberry) devices. Firmware is
upgradable for future devices. Contact MooreCo for rmware update options.
Operating Ambient Temperature: 32° to 95° F (0° to 35° C)
Nonoperating Ambient Temperature: -4° to 113° F (-20° to 45° C)
Relative Humidity: 5% to 95% noncondensing
Dimensions 36"H x 26"W x 34.5"D
Weight 160 lbs
Exterior Additional 4 outlet power strip accessory with on/off switch
Cord 6 ft power cord
Certication IEC 60950-1
Warranty 10 year cart and 2 year electrical
Shipping Ships fully assembled
LED Indicator Details 1 red LED: No device charging
1 blue LED: Device charging for less than 1.5 hours
2 blue LEDs: Device charging between 1.5 and 3 hours
3 blue LEDs: Device charging between 3 and 4.5 hours
4 blue LEDs: Device charging more than 4.5 hours

www.moorecoinc.com | 800.749.22586
Cart Use
▪Ensure cart is closed and locked before moving.
▪MooreCo, Inc. does not accept liability for damage
to cart if misused, inadequately repaired, or modied.
Any of the above will void warranty.
▪Do not tilt or operate cart on a slope.
▪Use of cart is intended for adults only. Do not allow
use by children or students unless fully supervised
by a responsible adult.
▪Do not sit on or exceed cart weight limit.
▪Do not use top as work surface unless completely
closed.
▪Cart is designed for indoor use only.
▪Be sure all external power cords are unplugged and
correctly stored before moving cart.
▪Keep casters locked when cart is stationary.
▪Do not run cords in high trafc areas or through
doorways, hallways, holes in ceilings, walls, or oors.
▪Cart is designed to be pushed. Do not pull.
Electrical Safety
WARNING: Failure to follow
electrical guidelines may result
in fire, injury, or electrical shock.
▪Be sure not to exceed electrical rating of 10 amps.
▪Do not plug in or use unit if any power plug or
electrical cord has been damaged.
▪Contact MooreCo or qualied electrician before
attempting to perform any sort of maintenance or
modication to cart electronics.
▪Do not plug cart into extension cord or movable
power strip.
▪Do not remove or modify any prongs or pins of
power cord in any way.
▪Keep all liquids away from cart. Do not use cart if
wet.
▪Do not operate near ammable materials.
▪Do not block ventilation of cart. Proper airow is
required to avoid overheating or damage to cart.
Safety

800.749.2258 | www.moorecoinc.com 7
Trouble Shooting
Technical changes are not intended to be performed
by anyone other than a qualied professional. Please
contact MooreCo, Inc. or seek a qualied professional for
assistance.
MooreCo, Inc. offers ten (10) years of limited coverage
for non-electrical components, and two (2) years on all
electrical components. Additional details can be found at
www.moorecoinc.com/core/warranties/iTeach_Products_
Warranty.pdf
Warranty
Notes

Balt®& Best-Rite®are brand
divisions of MooreCo Inc.
2885 Lorraine Ave
Temple, TX 76501
p: 800.749.2258
f: 800.697.6258
www.moorecoinc.com
Rev 12/09/14 RMC
