morse GRIP+GO 290F User manual

Copyright 2020 - Morse Mfg. Co., Inc. Form PL290F (291995-______) (Updated 26 Oct, 2020) 1
The Specialist In Drum Handling Equipment
Model 290F
Power Grip Fork Mount Drum Handler
[email protected] 103 Kuhn Rd.
Syracuse, NY, 13208 U.S.A.
morsedrum.com [phone]
CONTENTS
Page
Receiving Procedures. . . . . . . . . . . . . . . . . . . . 1
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Information. . . . . . . . . . . . . . . . . . . . . 1 - 2
Machine Description. . . . . . . . . . . . . . . . . . . 3
Operating Instructions. . . . . . . . . . . . . . . . . . . . 3
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . 4
Parts Lists and Diagrams. . . . . . . . . . . . . . . . . . 5
Lost Load on Equipment. . . . . . . . . . . . . . . . . . . . 6
Operator’s Manual
for Morse
Power-Grip Fork Mount Drum Handler
Model 290F
Serial Number 291995 to ______
Receiving Procedures
Every Morse drum handler is inspected prior to shipping. However,
damage may be incurred during transit.
Check for visible damage. If you choose to accept damaged•
freight, always sign noting the damage on the Bill of
Lading.
Document the damage and have the truck driver sign. We•
recommend keeping a digital camera at your receiving dock
for this purpose.
Open packages expeditiously to check the condition of the•
goods. There is only a 24 hour window to notify the carrier
of any concealed damage.
Immediately• report all damage to the shipping company!
Then you may contact Morse for assistance with your
freight claim.
Morse Manufacturing will not be held responsible for any•
damaged freight that is not signed for as damaged.
Limited 2 Year Warranty
Morse drum handling equipment is guaranteed against defects in
workmanship or materials for two years when used properly within
its rated capacity. Warranty does not cover wear from normal use
or damage from accident or abuse. Motors and other purchased
parts carry the warranties of their manufacturers.
For warranty claims, contact your Morse Dealer to obtain a
return authorization number, and for return freight advice. Return
freight must be prepaid.
In all instances, liability is limited to the purchase price paid or to
repairing or replacing the product. Customer assumes liability for
anymodications,unauthorizedrepairsorpartssubstitution.
Safety Information
While Morse Manufacturing Co. drum handling equipment is
engineeredforsafetyande󰀩ciency,ahighdegreeofresponsibility
must be placed upon the machine operator to follow safe practices,
based primarily on common sense, upon which true safety
depends.
Failure to follow the safety precautions in this manual can result in
personal injury or property damage. Observe the same precautions
as with similar machinery where carelessness in operating or
maintenance is hazardous to personnel. Carefully read the safety
precautions below and throughout this manual.
Review the Material Safety Data Sheet(s) for the material(s) in
the drum(s) and take all necessary precautions. Safety shoes,
work gloves, hard hat and other personal protective devices are
recommended.
Prior to initial use, inspect all moving parts and test rotation of
chain wheel and saddle assembly. Inspect saddle assembly
for proper operation. Perform necessary load test, inspections,
operator training, etc.

The Specialist In Drum Handling Equipment
Operator’s Manual for Morse Power Grip Fork Mount Drum Handler Model 290F
Serial Number 291995 to ______
morsedrum.com
Copyright 2020 - Morse Mfg. Co., Inc. Form PL290F (291995-______) (Updated 26 Oct, 2020) 2
Model 290F
Power Grip Fork Mount Drum Handler
Safety Information (continued)
DANGER - Indicates a situation which, if not avoided, will result in serious injury or death.
This signal word is limited to the most extreme situations.
WARNING - Indicates a situation which, if not avoided, could result in serious injury or
death.
CAUTION - Indicates a situation which, if not avoided, can result in damage to the machine.
CAUTION – Do Not Transport with Drum Raised. Always lower the drum holder to lowest position
before transporting.
WARNING - The Power-Grip Fork Mount Drum Handler is designed to handle one drum of the types
listed at the top of page 3, Machine Description. DO NOT attempt to handle any other type of drum or
object. DO NOT exceed the weight capacity.
WARNING -DoNotModifytheUnit.Undernocircumstancesshouldanymodicationsbemadeto
theMorsemachinerywithoutfactoryauthorization.Anymodicationsmayvoidthewarranty.This
machinewasdesignedtoperformaspecicjobandalterationsmayresultininjurytooperatoror
machine.
WARNING -NoLooseFittingClothing.Wearclose-ttingclothingandsafetyequipmentappropriate
tothejob.Loosettingclothingmaybecomecaughtonthemachineryandcauseseverepersonal
injury.
CAUTION - Wear safety shoes with non-slip soles and hard toe protection.
CAUTION: DONOTallowdrumtoimpactonoor,ground,ordumpingstation,etc.
WARNING: This product can expose you to chemicals including lead and arsenic, which are known to the
State of California to cause cancer and birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov
WARNING: This product can expose you to chemicals including barium sulfate, cobalt, titanium dioxide, and
2-methylimidazole, which are known to the State of California to cause cancer, and bisphenol-A, which is known to
the State of California to cause birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov

The Specialist In Drum Handling Equipment
Operator’s Manual for Morse Power Grip Fork Mount Drum Handler Model 290F
Serial Number 291995 to ______
morsedrum.com
Copyright 2020 - Morse Mfg. Co., Inc. Form PL290F (291995-______) (Updated 26 Oct, 2020) 3
Model 290F
Power Grip Fork Mount Drum Handler
Machine Description
The Model 290F GRIP+GOTM Power-Grip Fork Mount Drum
Handler is designed to lift, transport, and dispense a steel, plastic
orberdrum14”to24”(35.6to61cm)indiameter.
The maximum capacity is 1500 Lb. (680 kg).
Options
Option # 6149i-P
Wireless Control provides safe, simple and reliable wireless
machine grip and tilt control with up to 300 foot (91 m) operating
range. It features 900MHz frequency hopping technology for
eliminating interference from other RF sources. Easily switch
between direct wire pendant control and wireless remote control.
Quick DC power disconnect for locking out the equipment.
Option 6172-P
GripPadsrequiredtohandleaplasticorberdrum.
Operating Instructions
Replace the RED shipping plug from the hydraulic reservoir with
the supplied BLACK breather BEFORE operation.
Before sliding forklift forks into the fork tubes, adjust forks to1.
aninsidespreadof24.5”(62.2cm)minimum.Lockforksinto
position on the forklift carriage.
Drive the forklift forward to slip the forks into the fork tubes.2.
Loop the carabiner and chain through the mast and securely
attach to mast, ensuring no slack in the chain. Transport to
drum to be handled.
With the3. GRIP+GOTM grippers in the full open position,
drivetheforkliftwiththeforkliftattachmentnearoorlevel
to position the GRIP+GOTM around the middle of the drum
between the ribs.

The Specialist In Drum Handling Equipment
Operator’s Manual for Morse Power Grip Fork Mount Drum Handler Model 290F
Serial Number 291995 to ______
morsedrum.com
Copyright 2020 - Morse Mfg. Co., Inc. Form PL290F (291995-______) (Updated 26 Oct, 2020) 4
Model 290F
Power Grip Fork Mount Drum Handler
Maintenance
Usinggreasettingstolubeeachendofthecylinderclevisesindrumgrabassembly.Recommendedfrequency:Every6months.1.
Clean and oil moving parts periodically. Clean & lubricate more often in environments where dust, dirt or other foreign particles will2.
e󰀨ecttheperformanceofmovingparts.
Periodicinspectionforthegeneralconditionofstructuralandmechanicalcomponentsisimperativeforsafeande󰀩cientoperation.3.
Periodically inspect all moving parts, framework, and contact areas for signs of wear, fatigue, or loosening. Tighten, adjust, or replace4.
parts as necessary to prevent failure and maintain proper function.
Inspectthehydraulicsystemforoildrips,hosedamage,orothersignsofwear.Inspectthelevelandconditionofthehydraulicuid.5.
Replace any parts that show signs of wear.
Worn or damaged parts must be properly replaced with the correct, genuine Morse parts.6.
HydraulicpumpisshippedlledwithNocoPremiumplusautomatictransmissionuidd/m.Materialsafetydatasheet(msds)7.
is available online. Change oil yearly, or sooner depending on dirty conditions or outdoor use. Replace oil with Mobil dte 24 or
equivalent for indoor use (Mobil dte 13 for outdoor use).
Using Proper Grip Pressure:4.
PresstheGRIP“CLOSE”buttontoclosethegrippersaround
the drum, ensuring there is adequate pressure to handle the
drum but not crush it.
Grip Pressure Adjustment:
With11/16”wrenchloosenlocknut.Thenuse3/16”hex
wrench to adjust the pressure control valve. Clockwise will
increase the hydraulic pressure.
Raiseforkstocleartheoorandtransportdruminvertical5.
position to dispensing location.
Topourdrum:PresstheTILT“FWD”buttononthependant,6.
rotating drum to angle required for dispensing.
When dispensing is completed, rotate the drum back to7.
verticalbypressingtheTILT“REV”buttononthependant.
While transporting, ensure that the drum is raised away from
theoortopreventthedrumbottomfrominterferingwitha
pallet or other obstacle.
Lowerdrumtorestonoor,pallet,orothersuitablesurface.8.
To release drum grip, hold down the red SAFETY button, and9.
presstheGRIP“OPEN”button.ThegripperswillNOTopenby
pressingonlytheGRIP“OPEN”button.
Operating Instructions (continued)

The Specialist In Drum Handling Equipment
Operator’s Manual for Morse Power Grip Fork Mount Drum Handler Model 290F
Serial Number 291995 to ______
morsedrum.com
Copyright 2020 - Morse Mfg. Co., Inc. Form PL290F (291995-______) (Updated 26 Oct, 2020) 5
Model 290F
Power Grip Fork Mount Drum Handler

The Specialist In Drum Handling Equipment
Operator’s Manual for Morse Power Grip Fork Mount Drum Handler Model 290F
Serial Number 291995 to ______
morsedrum.com
Copyright 2020 - Morse Mfg. Co., Inc. Form PL290F (291995-______) (Updated 26 Oct, 2020) 6
Model 290F
Power Grip Fork Mount Drum Handler
