morse 195 Series User manual

CONTENTS
Page
Receiving Procedures. . . . . . . . . . . . . . . . . . . . 1
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Information. . . . . . . . . . . . . . . . . . . . . 1 - 2
Machine Description. . . . . . . . . . . . . . . . . . . 3
Operating Instructions. . . . . . . . . . . . . . .. . . . . 4
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . 4
Parts Lists and Diagrams. . . . . . . . . . . . . . . . . . 5 - 6
Operator’s Manual
for Morse Kontrol-Karriers
with AC Power Tilt
Models 195A-1-115, 195A-3-230,
195A-1-220-50 and 195A-3-460
with Serial Number 285276 to 296110
Receiving Procedures
Every Morse drum handler is inspected prior to shipping. However,
damage may be incurred during transit.
Check for visible damage. If you choose to accept damaged•
freight, always sign noting the damage on the Bill of
Lading.
Document the damage and have the truck driver sign. We•
recommend keeping a digital camera at your receiving dock
for this purpose.
Open packages expeditiously to check the condition of the•
goods. There is only a 24 hour window to notify the carrier
of any concealed damage.
Immediately• report all damage to the shipping company!
Then you may contact Morse for assistance with your
freight claim.
Morse Manufacturing will not be held responsible for any•
damaged freight that is not signed for as damaged.
Limited 2 Year Warranty
Morse drum handling equipment is guaranteed against defects in
workmanship or materials for two years when used properly within
its rated capacity. Warranty does not cover wear from normal use
or damage from accident or abuse. Motors and other purchased
parts carry the warranties of their manufacturers.
For warranty claims, contact your Morse Dealer to obtain a
return authorization number, and for return freight advice. Return
freight must be prepaid.
In all instances, liability is limited to the purchase price paid or to
repairing or replacing the product. Customer assumes liability for
anymodications,unauthorizedrepairsorpartssubstitution.
Safety Information
While Morse Manufacturing Co. drum handling equipment is
engineeredforsafetyandefciency,ahighdegreeofresponsibility
must be placed upon the machine operator to follow safe practices,
based primarily on common sense, upon which true safety
depends.
Failure to follow the safety precautions in this manual can result in
personal injury or property damage. Observe the same precautions
as with similar machinery where carelessness in operating or
maintenance is hazardous to personnel. Carefully read the safety
precautions below and throughout this manual.
Review the Material Safety Data Sheet(s) for the material(s) in
the drum(s) and take all necessary precautions. Safety shoes,
work gloves, hard hat and other personal protective devices are
recommended.
Prior to initial use, inspect all moving parts and test rotation of
saddle assembly. Inspect saddle assembly for proper operation.
Perform necessary load test, inspections, operator training, etc.
MORSEMFG.CO.,INC.•727WestManliusStreet•P.O.Box518•EastSyracuse,NY13057-0518
Phone: 315-437-8475     •     Fax: 315-437-1029     •     Email: [e-mail]•Webpage:morsedrum.com
Copyright 2018 - Morse Mfg. Co., Inc. Form PL195A-AC (285276-296110) (Updated 6 Feb, 2018 3:32 PM) 1
The Specialist In Drum Handling Equipment
195 Series
Kontrol-Karriers with AC Power Tilt

The Specialist In Drum Handling Equipment
195 Series
Kontrol-Karriers with AC Power Tilt
Operator’s Manual for Morse Models 195A-1-115, 195A-3-230, 195A-1-220-50 and 195A-3-460
Serial Number 285276 to 296110
morsedrum.com
Copyright 2018 - Morse Mfg. Co., Inc. Form PL195A-AC (285276-296110) (Updated 6 Feb, 2018 3:32 PM) 2
Safety Information (continued)
DANGER - Indicates a situation which, if not avoided, will result in serious injury or death.
This signal word is limited to the most extreme situations.
WARNING - Indicates a situation which, if not avoided, could result in serious injury or
death.
CAUTION - Indicates a situation which, if not avoided, can result in damage to the machine.
WARNING - Kontrol-Karriers are designed to handle one drum of the types listed at the top of page 3.
Machine Description. DO NOT attempt to handle any other type of drum or object.
WARNING - DO NOT exceed the weight capacity of 1500 Lb. (680 kg).
WARNING - DO NOT operate damaged or malfunctioning unit, or a unit with missing parts.
WARNING - DO NOT lift people or suspend loads over people. Stay clear of suspended loads.
WARNING - DO NOT lift loads higher than necessary.
WARNING - DO NOT leave suspended loads unattended.
WARNING - DO NOT remove or obscure warning labels.
WARNING -DONOToperatewithoutrsthavingreadandunderstoodoperatingmanual.
WARNING - DO NOT make alterations or modify the unit. Under no circumstances should any
modicationsbemadetotheMorsemachinerywithoutfactoryauthorization.Anymodicationsmay
voidthewarranty.Thismachinewasdesignedtoperformaspecicjobandalterationsmayresultin
injury to operator or machine.
WARNING - Wear safety shoes with non-slip soles and hard toe protection.
CAUTION: DONOTallowdrumtoimpactonoor,ground,etc.

The Specialist In Drum Handling Equipment
195 Series
Kontrol-Karriers with AC Power Tilt
Operator’s Manual for Morse Models 195A-1-115, 195A-3-230, 195A-1-220-50 and 195A-3-460
Serial Number 285276 to 296110
morsedrum.com
Copyright 2018 - Morse Mfg. Co., Inc. Form PL195A-AC (285276-296110) (Updated 6 Feb, 2018 3:32 PM) 3
Machine Description
The Power Tilt Kontrol-Karrier is designed to lift, transport, and dispense
a ribbed 55-gallon (210 liter) steel drum 22.5” (57.2 cm) in diameter. The
maximum full-drum capacity is 1500 Lb. (680 kg). The capacity is derated to
800 Lb. (363 kg) for a half-full drum. The half-full rating is based on the tilt
mechanism’s capacity for handling an unbalanced bottom-heavy drum.
Options
A smaller diameter drum can be handled with the correct size 55/30 Series Diameter Adaptor installed (see• Diameter Adaptor
literature).
The• Bracket Assembly (Part # 4556-P) is required to handle a plastic drum. It is also recommended to more securely handle a
berdrum.YoucanusetheBracketAssemblywitha55-gallon(210liter)plastic,steelorberdrum.Thebraceattopandbottomof
the drum prevent it from slipping lengthways through the drum holder. It adjusts for a drum 31” to 37” (79 to 94 cm) tall.
Important
Please read all instructions thoroughly before attempting to operate your new Morse drum handler.1.
When loading, unloading, operating, or maintaining your MORSE drum handler, always use care and good judgment. Maintain2.
securefootingandarmhold.Keephandsandlooseclothingawayfromallmovingparts.Neverallowanyonetobebelowanypart
of a raised drum handler or drum. Read operating instructions and review the pictures in the sales brochure before operation.
The 195 Series are a “Group 1 structural and mechanical” below-the-hook lifting device which are covered by the American National3.
StandardASMEB30.20.Theusershouldcomplywithallaspectsofthisstandard.
Diameter Adaptors for drums from 18.5” to 22” (47
to 55.9 cm) in diameter do not have hold-down
brackets.Theytbetweentheribsofasteeldrum.
Forplasticorberdrum,useDiameterAdaptorin
combinationwiththeBracketAssemblytoprevent
the drum from slipping lengthways through the
drum holder.
Diameter Adaptors for smaller drums from 14” to
17.5” (35.6 to 44.5 cm) in diameter are equipped
with adjustable hold-down brackets to prevent your
drum from slipping lengthways through the drum
holder. Handle a drum up to 38” (96.5 cm) tall.
A 55-gallon (208 liter) plastic drum can be handled
iftheunitisequippedwiththeadjustableBracket
Assembly (Part # 4556-P). This bracket bolts onto
the drum holder, and prevents a 55-gallon (208 liter)
plastic drum from slipping lengthways.

The Specialist In Drum Handling Equipment
195 Series
Kontrol-Karriers with AC Power Tilt
Operator’s Manual for Morse Models 195A-1-115, 195A-3-230, 195A-1-220-50 and 195A-3-460
Serial Number 285276 to 296110
morsedrum.com
Copyright 2018 - Morse Mfg. Co., Inc. Form PL195A-AC (285276-296110) (Updated 6 Feb, 2018 3:32 PM) 4
Assembly Instructions
Remove the metal screw-plug on top of the speed reducer.1.
Look into the hole to verify oil is in the speed reducer.2.
Install the plastic vent-plug in place of the metal screw-plug to allow internal3.
pressure to equalize with atmospheric pressure.
Consult an electrician to complete the wiring into the control box.4.
Prior to initial use, inspect all moving parts and test rotation of saddle5.
assembly. Inspect ratchet web straps for proper operation. Perform
necessary load test, inspections, operator training, etc. as prescribed in the
ANSI/ASMEB30.20standard.
Operating Instructions
1. WithKontrol-Karrierstandingontheoor,lowerhoistandengagehoisthook
into the lifting eye.
2. RaisehoisttoliftKontrol-Karrierclearofoorandmoveittothedrum.
3. Position Kontrol-Karrier at a height which aligns the saddle band with the
center of the drum. Swing open ratchet hinge plate.
4. With the ratchet straps hanging freely, push Kontrol-Karrier against the drum
to surround the drum with the saddle band.
5. Drape the straps across the front of the drum and place each strap between
clevis and secure with pin. Operate ratchet to tighten straps against the
drum.
6. Raise hoist and position the drum at the pouring station.
7. Pour the drum by pushing forward button on the control pendant (item 24).
8. After pouring is completed, rotate the drum back to vertical position and
lowerhoisttoreturndrumtooor.
9. To remove drum: Operate the ratchet to loosen each web strap around the
drum. Release both straps from clevis and swing open ratchet hinge plate.
Maintenance
1. Inspectoillevelingearbox/speedreducerandllwithhighquality,synthetic
lubricant for gears if necessary. Use Klubersynth UH1 6-460 (#096060)or
equivalent.
2. Periodically inspect all moving parts, framework, ratchet, straps, fasteners and
contact areas for signs of wear, fatigue, or loosening. The web strap should be
removed from service & replaced if any of the following are visible:
• Acidorcausticburns
• Meltingorcharringofanypartofthestrap
• Holes,tears,cuts,snagsorembeddedarticles
• Brokenorwornstitchinginloadbearingsplices
• Excessiveabrasivewear
3. Perform all inspections, load tests, and maintenance according to the ANSI/
ASMEB30.20standard.
4. Ensure all labels are in place. Product labels should be inspected periodically
and cleaned as necessary to maintain good legibility. Please contact Morse
Mfg. Co. for replacement labels.
