morse 195A Series User manual

Operator’s Manual
for Morse Kontrol-Karriers
with AC Power Tilt
Models 195A-1-115, 195A-3-230,
195A-1-220-50 and 195A-3-460
with Serial Number 414504 to ______
Receiving Procedures
Every Morse drum handler is inspected prior to shipping. However,
damage may be incurred during transit.
• Check for visible damage. If you choose to accept damaged
freight, always sign noting the damage on the Bill of
Lading.
• Document the damage and have the truck driver sign. We
recommend keeping a digital camera at your receiving dock
for this purpose.
• Open packages expeditiously to check the condition of the
goods. There is only a 24 hour window to notify the carrier
of any concealed damage.
• Immediately report all damage to the shipping company!
Then you may contact Morse for assistance with your
freight claim.
• Morse Manufacturing will not be held responsible for any
damaged freight that is not signed for as damaged.
Limited 2 Year Warranty
Morse drum handling equipment is guaranteed against defects in
workmanship or materials for two years when used properly within
its rated capacity. Warranty does not cover wear from normal use
or damage from accident or abuse. Motors and other purchased
parts carry the warranties of their manufacturers.
For warranty claims, contact your Morse Dealer to obtain a
return authorization number, and for return freight advice. Return
freight must be prepaid.
In all instances, liability is limited to the purchase price paid or to
repairing or replacing the product. Customer assumes liability for
any modications, unauthorized repairs or parts substitution.
Safety Information
While Morse Manufacturing Co. drum handling equipment is
engineered for safety and e󰀩ciency, a high degree of responsibility
must be placed upon the machine operator to follow safe practices,
based primarily on common sense, upon which true safety
depends.
Failure to follow the safety precautions in this manual can result in
personal injury or property damage. Observe the same precautions
as with similar machinery where carelessness in operating or
maintenance is hazardous to personnel. Carefully read the safety
precautions below and throughout this manual.
Review the Material Safety Data Sheet(s) for the material(s) in
the drum(s) and take all necessary precautions. Safety shoes,
work gloves, hard hat and other personal protective devices are
recommended.
Prior to initial use, inspect all moving parts and test rotation of
saddle assembly. Inspect saddle assembly for proper operation.
Perform necessary load test, inspections, operator training, etc.
Copyright 2024 - Morse Mfg. Co., Inc. Form PL195A-AC (414504-______) (Updated 16 Jan, 2024) 1
The Specialist In Drum Handling Equipment
195A Series
AC Power Tilt Kontrol-Karriers
[email protected] 103 Kuhn Rd.
Syracuse, NY, 13208 U.S.A.
morsedrum.com [phone]
CONTENTS
Page
Receiving Procedures. . . . . . . . . . . . . . . . . . . . 1
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Information. . . . . . . . . . . . . . . . . . . . . 1 - 2
Machine Description. . . . . . . . . . . . . . . . . . . 3
Assembly Instructions. . . . . . . . . . . . . . .. . . . . 4
Operating Instructions. . . . . . . . . . . . . . .. . . . . 4
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . 4
Parts List and Diagram. . . . . . . . . . . . . . . . . . 5 - 6

The Specialist In Drum Handling Equipment
195A Series
AC Power Tilt Kontrol-Karriers
Operator’s Manual for Morse Models 195A-1-115, 195A-3-230, 195A-1-220-50 and 195A-3-460
Serial Number 414504 to ______
morsedrum.com
Copyright 2024 - Morse Mfg. Co., Inc. Form PL195A-AC (414504-______) (Updated 16 Jan, 2024) 2
Safety Information (continued)
DANGER - Indicates a situation which, if not avoided, will result in serious injury or death.
This signal word is limited to the most extreme situations.
WARNING - Indicates a situation which, if not avoided, could result in serious injury or
death.
CAUTION - Indicates a situation which, if not avoided, can result in damage to the machine.
WARNING - Kontrol-Karriers are designed to handle one drum of the types listed at the top of page 3.
Machine Description. DO NOT attempt to handle any other type of drum or object.
WARNING - DO NOT exceed the weight capacity of 1500 Lb. (680 kg).
WARNING - DO NOT operate damaged or malfunctioning unit, or a unit with missing parts.
WARNING - DO NOT lift people or suspend loads over people. Stay clear of suspended loads.
WARNING - DO NOT lift loads higher than necessary.
WARNING - DO NOT leave suspended loads unattended.
WARNING - DO NOT remove or obscure warning labels.
WARNING - DO NOT operate without rst having read and understood operating manual.
WARNING - DO NOT make alterations or modify the unit. Under no circumstances should any
modications be made to the Morse machinery without factory authorization. Any modications may
void the warranty. This machine was designed to perform a specic job and alterations may result in
injury to operator or machine.
WARNING - Wear safety shoes with non-slip soles and hard toe protection.
CAUTION: DO NOT allow drum to impact on oor, ground, etc.
WARNING: This product can expose you to chemicals including barium sulfate, cobalt, titanium dioxide, and
2-methylimidazole, which are known to the State of California to cause cancer, and bisphenol-A, which is known to
the State of California to cause birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov

The Specialist In Drum Handling Equipment
195A Series
AC Power Tilt Kontrol-Karriers
Operator’s Manual for Morse Models 195A-1-115, 195A-3-230, 195A-1-220-50 and 195A-3-460
Serial Number 414504 to ______
morsedrum.com
Copyright 2024 - Morse Mfg. Co., Inc. Form PL195A-AC (414504-______) (Updated 16 Jan, 2024) 3
Machine Description
The Power Tilt Kontrol-Karrier is designed to lift, transport, and dispense a ribbed
55-gallon (210 liter) steel drum 22.5” (57.2 cm) in diameter.
Maximum full-drum capacity is 1500 Lb. (680 kg). Capacity is derated to 800 Lb. (363 kg)
for half-full drum. Half-full rating is based on the tilt mechanism’s capacity for handling an
unbalanced, bottom-heavy drum.
Important
1. Please read all instructions thoroughly before attempting to operate your new Morse drum handler.
2. When loading, unloading, operating, or maintaining your MORSE drum handler, always use care and good judgment. Maintain
secure footing and a rm hold. Keep hands and loose clothing away from all moving parts. Never allow anyone to be below any part
of a raised drum handler or drum. Read operating instructions and review the pictures in the sales brochure before operation.
3. The 195 Series are a “Group 1 structural and mechanical” below-the-hook lifting device which are covered by the American National
Standard ASME B30.20. The user should comply with all aspects of this standard.
55/30 Series Diameter Adapters for
drum with diameter smaller than 22”
(56 cm). To handle a smaller drum,
insert the correct size Diameter Adapter
into the standard drum holder. See
Diameter Adapter info at:
https://morsedrum.com/products/
diameter-adapters
ONLY Diameter Adapters for drum with
17.5” (44.5 cm) diameter or smaller
have integrated brackets to prevent
drum slipping length-ways.
NOTE: For 30-gallon (114 Liter)
PLASTIC drum, insert Diameter
Adapter; AND install Bracket or Top
Rim Clamp to prevent drum slipping.
IMPORTANT: To prevent 30 to 55 gallon (114 to 210 L) size plastic drum from
slipping, you MUST install either Top Rim Clamp Kit or Bracket Assembly Kit.
1. Bracket Assembly Kit # 4556-P is required to handle a RIMLESS
plastic drum (gure 2.1), and is also recommended for a ber drum.
The Bracket adjusts for a 31” to 39” (79 to 99 cm) tall drum.
You can also handle a rimmed drum with the Bracket installed.
2. Top Rim Clamp Kit # 4560B-P to handle a RIMMED plastic drum
(gure 2.2). Install the Top Rim Clamp Kit to handle a RIMMED
plastic, steel or ber drum with suitable top rim.
ACCESSORIES
Figure 2.2
Kit # 4560B-P
Install Top Rim Clamp Kit
to handle RIMMED plastic
drum
Figure 2.1
Kit # 4556-P
Install Bracket Assembly Kit
to handle RIMLESS or
RIMMED plastic drum

The Specialist In Drum Handling Equipment
195A Series
AC Power Tilt Kontrol-Karriers
Operator’s Manual for Morse Models 195A-1-115, 195A-3-230, 195A-1-220-50 and 195A-3-460
Serial Number 414504 to ______
morsedrum.com
Copyright 2024 - Morse Mfg. Co., Inc. Form PL195A-AC (414504-______) (Updated 16 Jan, 2024) 4
Assembly Instructions
1. Remove the metal screw-plug on top of the speed reducer.
2. Look into the hole to verify oil is in the speed reducer.
3. Install the plastic vent-plug in place of the metal screw-plug to allow internal
pressure to equalize with atmospheric pressure.
4. Consult an electrician to complete the wiring into the control box.
5. Prior to initial use, inspect all moving parts and test rotation of saddle
assembly. Inspect ratchet web straps for proper operation. Perform
necessary load test, inspections, operator training, etc. as prescribed in the
ANSI/ASME B30.20 standard.
Operating Instructions
1. With Kontrol-Karrier standing on the oor, lower hoist and engage hoist hook
into the lifting eye.
2. Raise hoist to lift Kontrol-Karrier clear of oor and move it to the drum.
3. Position Kontrol-Karrier at a height which aligns the saddle band with the
center of the drum. Swing open ratchet hinge plate and strap hinge plates.
4. With the ratchet straps hanging freely, push Kontrol-Karrier against the drum
to surround the drum with the saddle band.
5. Drape the straps across the front of the drum and thread each strap through
slot in ratchet. Operate ratchet to tighten straps against the drum.
6. Raise hoist and position the drum at the pouring station.
7. Pour the drum by pushing forward button on the control pendant (item 24).
8. After pouring is completed, rotate the drum back to vertical position and
lower hoist to return drum to oor.
9. To remove drum: Operate the ratchet to loosen each web strap around the
drum. Release straps from ratchets and swing open hinge plates.
Maintenance
1. Inspect oil level in gear box / speed reducer and ll with high quality, synthetic
lubricant for gears if necessary. Use Klubersynth UH1 6-460 (#096060) or
equivalent.
2. Periodically inspect all moving parts, framework, ratchet, straps, fasteners and
contact areas for signs of wear, fatigue, or loosening. The web strap should be
removed from service & replaced if any of the following are visible:
• Acid or caustic burns
• Melting or charring of any part of the strap
• Holes, tears, cuts, snags or embedded articles
• Broken or worn stitching in load bearing splices
• Excessive abrasive wear
3. Perform all inspections, load tests, and maintenance according to the ANSI/
ASME B30.20 standard.
4. Ensure all labels are in place. Product labels should be inspected periodically
and cleaned as necessary to maintain good legibility. Please contact Morse
Mfg. Co. for replacement labels.

The Specialist In Drum Handling Equipment
195A Series
AC Power Tilt Kontrol-Karriers
Operator’s Manual for Morse Models 195A-1-115, 195A-3-230, 195A-1-220-50 and 195A-3-460
Serial Number 414504 to ______
morsedrum.com
Copyright 2024 - Morse Mfg. Co., Inc. Form PL195A-AC (414504-______) (Updated 16 Jan, 2024) 5
MOTOR
MODEL
SUFFIX PART # DESCRIPTION
-1-115 4203-1-P MOTOR, 1/3HP, 1PH, 56C, TEFC
-3-230 4203-3-P MOTOR, 1/3HP, 3PH, 56C, TEFC
-3-460 4203-3-P MOTOR, 1/3HP, 3PH, 56C, TEFC
-1-220-50 4203-1-50-P MOTOR, 1/3HP, 1PH, 56C, 50HZ
CONTROL BOX
MODEL
SUFFIX PART # DESCRIPTION
-1-115 2799-P CONTROL BOX, 195, 1PH/115V
-3-230 2860-P CONTROL BOX, 195, 3PH/230V
-3-460 2859-P CONTROL BOX, 195, 3PH/460V
-1-220-50 4787-P CONTROL BOX, 195
1PH/220V/50HZ

The Specialist In Drum Handling Equipment
195A Series
AC Power Tilt Kontrol-Karriers
Operator’s Manual for Morse Models 195A-1-115, 195A-3-230, 195A-1-220-50 and 195A-3-460
Serial Number 414504 to ______
morsedrum.com
Copyright 2024 - Morse Mfg. Co., Inc. Form PL195A-AC (414504-______) (Updated 16 Jan, 2024) 6
Drum Holder (Saddle) Assembly - Part # 5991-P
