Mosmatic TD-80611 A User manual

car wash technology │high pressure cleaning technology │rotary unions
Datum / Date: 19.11.2015│Änderungen vorbehalten │Subjects to change without notice
MOSMATIC AG
CH-9126 Necker │Phone: [phone] │www.mosmatic.com
1
/
3
Technical Data
Pressure 4000psi
Temperature 250°F
RPM max. 2000 rpm
Housing ø20.5”
Water connection 3/8”NPTF
Nozzle connection 2x 1/8“NPTF
Throughput medium water (pH 3-12)

car wash technology │high pressure cleaning technology │rotary unions
Datum / Date: 19.11.2015│Änderungen vorbehalten │Subjects to change without notice
MOSMATIC AG
CH-9126 Necker │Phone: [phone] │www.mosmatic.com
2
/
3
Indication
(original language German):
•Read all instructions, check overall conditions and safety
requirements before initial operation of the product.
•Our product should only be installed by experienced users
of high pressure equipment.
•Safety regulations and guidelines (Accident Prevention
Rules) from the manufacturer of your high pressure cleaner
are applicable.
•Nozzle installation according to Nozzle manufacturer.
•Do not run the product if the rotor-arm is out of balance or
bent, damage to the swivel will result.
•No modifications to the product are permitted.
Caution:
•Always use protection gear when using products
connected to high pressure.
•Before any maintenance or nozzle-change, turn off the
high pressure water supply, e.g.: turn off and secure the
power switch.
•After turning off the system, allow all selfpropelled
equipment to come to a complete stop before handling.
Risk of injury due the rotor-arm.
•Do not lift up the product while operating.
Warning:
•Never direct any high pressure water-jet at humans,
animals or electric installations.
•Do not touch the rotor-arm during operation. Risk of injury.

car wash technology │high pressure cleaning technology │rotary unions
Datum / Date: 19.11.2015│Änderungen vorbehalten │Subjects to change without notice
MOSMATIC AG
CH-9126 Necker │Phone: [phone] │www.mosmatic.com
3
/
3
Spare parts list
Pos.
Art. Nr.
Description
1
58.553
Swivel
-
90° (DYF)
2
36.905
Carbide seal
-
kit
3
50.155
Quick
-
Connect (M22x1.5
-
F / G1/4“F)
4
900.933
Rubber wheel (ø
5
“
)
5
903.325
HP
-
hose
(G1/4“kM / G1/4“kM)
6
50.903
Quick
-
Connect (M22x1.5
-
F / G1/4“M)
7
51.275
Adapter (M22x1.5
-
M / G1/4“M)
8
29.081
HP
-
gun (4500psi
)
9
1503
HP
-
nozzle (1503)
10
82.891
Rotor arm (ø
18.5“
)
11
903.318
Protection ring (ø20.5“
)
12
900.932
Stainless steel
caste
r (ø
2.4“
)
13
80.621
Protective plate (ø20.5“
)
Assembly instructions
(original language German)
1. Dismount both wheels (4).
2. Install the lower fork (14) with the bolts (15) through the
wheels (4) to the rack (16).
3. Slide the upper fork (17) over the lower fork (14). Secure the
two forks with the bolt (18) and the safety nut (19).
Note: The handle (20) and the ring (21) must point in the same
direction.
4. Connect the HP-gun (8) with the preinstalled adapter (7) to the
quick-connect (6).
13
10
9
11
20
12
1+2
8
3
17
1
6
7
6
19
5
21
14
18
4
15
