Motorola E790 User manual

APPLICANT: MOTOROLA, INC.FCCID: IHDT56ES1
EXHIBIT 8
INSTRUCTION MANUAL
A preliminary draft copy of the Users Manual follows:

E790
GSM

1
HELLOMOTO
Introducing your new Motorola E790 GSM wireless phone.
Here’s a quick anatomy lesson.
Left Soft Key
Perform function
in lower left
display.
Headset Jack
Stereo Speakers
(both sides)
Camera Key
Activate camera
& take photos.
Volume Key
Smart Key
5-Way Navigation
Joystick with
Center Select
Scroll through
menus, press in
to select items.
Menu Key
Accessory
Connector Port
Insert charger
& phone
accessories.
Right Soft Key
Perform function
in lower right
display.
Power & End Key
Turn phone
on/off, end calls,
exit menu
system.
Send Key
Make & answer
calls.

2
check it out!
check it out!
feature
download
music files
Use the memory card as the default USB
connection:
M > Settings > Connection > USB Settings
> Memory Card
On your computer, open iTunes, connect
your phone to your computer, and drag
and drop music files to your phone.
play music Play a song on your phone:
iTunes > Songs > song name > Play
Tip: Your phone must be disconnected
from your computer to play songs.
032385o.eps
Camera Key
Activate camera
& take photos.
Mirror
Aim camera lens
for self portraits.
Camera Lens
Integrated Short-
Range Light
Stereo Speakers
(both sides)

3
check it out!
create playlist Create a playlist of songs on your phone:
On your computer, open iTunes, click the
Add ( + ) button, and type a name for the
playlist. Then drag songs from your
music library to your playlist.
Connect your phone to your computer
and drag and drop the playlist onto your
phone.
rhythm lights Activate lights to flash in sync with the
sounds around you:
M > Settings > Personalize > Rhythm Lights
ring lights Choose ring lights for incoming calls:
M > Settings > Ring Styles> Ring Lights >
> light pattern
take photo &
send
Press j to activate the camera. Point
lens and press
CAPTURE to take a photo.
To send, press the
STORE key and
select
Send In Message .
phone skin Apply different skins to the display:
M > Settings > Personalize> Skin > skin
send
multimedia
message
Send a message with pictures,
animations, sounds, and videos:
M > Messages > Create Message > New
Multimedia Message
feature

4
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. All other product or service names are the property of
their respective owners.
The Bluetooth trademarks are owned by their proprietor and used by
Motorola, Inc. under license.
Microsoft, Windows, ActiveSync and Windows Media are registered
trademarks of Microsoft Corporation; and Windows XP and Windows
Mobile are trademarks of Microsoft Corporation.
© Motorola, Inc., 2005.
Caution: Changes or modifications made in the radio phone, not expressly
approved by Motorola, will void the user’s authority to operate the
equipment.
The information contained in Motorola's user's guides is believed to be
correct at the time of printing. Motorola reserves the right to change or
modify any information or specifications without notice. The contents of
Motorola’s user's guides are provided “as is.” Except as required by
applicable law, no warranties of any kind, either express or implied,
including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose, are made in relation to the accuracy,
reliability, or contents of this guide.
Manual Number: 68XXXXXX92-O

5
HELLOMOTO
contents
check it out! . . . . . . . . . . 2
contents . . . . . . . . . . . . . 5
Safety Information . . . . . 7
EU Conformance. . . . . . 14
Recycling Information . 15
essentials . . . . . . . . . . . 16
about this guide . . . . . 16
SIM card . . . . . . . . . . . 17
battery. . . . . . . . . . . . . 17
turn it on & off. . . . . . . 20
make a call . . . . . . . . . 20
answer a call . . . . . . . . 20
your phone number . . 21
main attractions . . . . . . 22
use iTunes. . . . . . . . . . 22
take & send a photo . . 26
record & play video clip. .
28
multimedia messages. 31
lights . . . . . . . . . . . . . . 33
memory card . . . . . . . 35
Bluetooth® connections .
38
basics. . . . . . . . . . . . . . . 42
display. . . . . . . . . . . . . 42
menus. . . . . . . . . . . . . 46
text entry . . . . . . . . . . 48
volume . . . . . . . . . . . . 52
navigation key . . . . . . . 52
smart key . . . . . . . . . . 53
handsfree speaker . . . 53
codes & passwords . . 53
lock & unlock phone . . 54
customize . . . . . . . . . . . 55
ring style . . . . . . . . . . . 55
time & date. . . . . . . . . 56
wallpaper . . . . . . . . . . 56
screen saver . . . . . . . . 57
themes . . . . . . . . . . . . 57
display appearance . . . 58
answer options . . . . . . 58
vibrations . . . . . . . . . . 59

6
HELLOMOTO
calls . . . . . . . . . . . . . . . 60
turn off a call alert . . . 60
recent calls . . . . . . . . 60
redial . . . . . . . . . . . . . 61
return a call . . . . . . . . 62
notepad . . . . . . . . . . . 62
hold or mute a call. . . 62
call waiting . . . . . . . . 63
caller ID . . . . . . . . . . . 63
emergency calls . . . . 64
international calls. . . . 64
1-touch dial . . . . . . . . 64
voicemail . . . . . . . . . . 65
other features . . . . . . . 66
advanced calling . . . . 66
phonebook . . . . . . . . 68
messages . . . . . . . . . . 74
email . . . . . . . . . . . . . . 76
instant messaging . . . 78
chat . . . . . . . . . . . . . . 79
personalizing . . . . . . . 79
call times & costs . . . 82
handsfree . . . . . . . . . 83
data & fax calls . . . . . 84
network . . . . . . . . . . . 85
personal organizer . . . 85
security . . . . . . . . . . . 87
fun & games . . . . . . . 87
troubleshooting . . . . . 89
SAR Data . . . . . . . . . . . 90
SAR Data . . . . . . . . . . . 92
Index . . . . . . . . . . . . . . 94

7
Safety Information
Safety and General Information
Safety In formatio n
IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ
THIS INFORMATION BEFORE USING YOUR PHONE.
1
Exposure To Radio Frequency (RF) Energy
Your phone contains a transmitter and a receiver. When it is ON, it receives
and transmits RF energy. When you communicate with your phone, the
system handling your call controls the power level at which your phone
transmits.
Your Motorola phone is designed to comply with local regulatory
requirements in your country concerning exposure of human beings to RF
energy.
Operational Precautions
To assure optimal phone performance and make sure human exposure to
RF energy is within the guidelines set forth in the relevant standards,
always adhere to the following instructions.
External Antenna Care
If your phone has an external antenna, use only the supplied or
Motorola-approved replacement antenna. Unauthorized antennas,
modifications, or attachments could damage the phone and/or may result
in non-compliance with local regulatory requirements in your country.
Do NOT hold the external antenna when the phone is IN USE. Holding the
external antenna affects call quality and may cause the phone to operate
at a higher power level than needed.
Phone Operation
When placing or receiving a phone call, hold your phone as you would a
wireline phone.

8
Safety Information
Body-Worn Operation: Voice Communication
To maintain compliance with RF energy exposure guidelines, if you wear a
phone on your body when transmitting voice communications, always
place the phone in a Motorola-supplied or approved clip, holder, holster,
case, or body harness for this phone, if available. Use of accessories not
approved by Motorola may exceed RF energy exposure guidelines.
If you do not use one of the body-worn accessories approved or supplied by
Motorola, and are not using the phone held in the normal use position,
ensure the phone and its antenna are at least 2.5 centimeters (1 inch) from
your body when transmitting.
Data Operation
When using any data feature of the phone, with or without an accessory
cable, position the phone and its antenna at least 2.5 centimeters (1 inch)
from your body.
Approved Accessories
Use of accessories not approved by Motorola, including but not limited to
batteries, antennas, and convertible covers, may cause your phone to
exceed RF energy exposure guidelines. For a list of approved Motorola
accessories, visit our website at
www.motorola.com .
RF Energy Interference/Compatibility
Note: Nearly every electronic device is susceptible to RF energy
interference from external sources if inadequately shielded, designed, or
otherwise configured for RF energy compatibility. In some circumstances
your phone may cause interference.
Note: This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.

9
Safety Information
Facilities
Turn off your phone in any facility where posted notices instruct you to do
so. These facilities may include hospitals or health care facilities that may
be using equipment that is sensitive to external RF energy.
Aircraft
Turn off your wireless device whenever instructed to do so by airline staff.
If your device offers a flight mode or similar feature, consult airline staff
about use in flight. If your device offers a feature that automatically turns
on the phone, then turn off this feature before boarding an airplane or
entering an area where the use of wireless devices is restricted.
Medical Devices
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of
15 centimeters (6 inches) be maintained between a handheld wireless
phone and a pacemaker.
Persons with pacemakers should:
• ALWAYS keep the phone more than 15 centimeters (6 inches) from
your pacemaker when the phone is turned ON.
• NOT carry the phone in the breast pocket.
• Use the ear opposite the pacemaker to minimize the potential for
interference.
• Turn OFF the phone immediately if you have any reason to suspect
that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your hearing aid
manufacturer to discuss alternatives.

10
Safety Information
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of
your device to determine if it is adequately shielded from RF energy. Your
physician may be able to assist you in obtaining this information.
Use While Driving
Check the laws and regulations on the use of phones in the area where you
drive. Always obey them.
When using your phone while driving, please:
• Give full attention to driving and to the road. Using a phone may be
distracting in certain circumstances. Discontinue a call if you can’t
concentrate on driving.
• Use handsfree operation, if available.
• Pull off the road and park before making or answering a call if
driving conditions so require.
Responsible driving best practices can be found in the “Wireless Phone
Safety Tips” at the end of this guide and/or at the Motorola website:
www.motorola.com/callsmart .
Operational Warnings
For Vehicles With an Air Bag
Do not place a phone in the area over an air bag or in the air bag
deployment area. Air bags inflate with great force. If a phone is placed in
the air bag deployment area and the air bag inflates, the phone may be
propelled with great force and cause serious injury to occupants of the
vehicle.
Gas or Petrol Stations
Obey all posted signs with respect to the use of radio equipment in gas or
petrol stations. Turn off your wireless device if instructed by authorized
staff.

11
Safety Information
Potentially Explosive Atmospheres
Turn off your phone prior to entering any area with a potentially explosive
atmosphere. Do not remove, install, or charge batteries in such areas.
Sparks in a potentially explosive atmosphere can cause an explosion or fire
resulting in bodily injury or even death.
Note: The areas with potentially explosive atmospheres referred to above
include fueling areas such as below decks on boats, fuel or chemical
transfer or storage facilities, areas where the air contains chemicals or
particles, such as grain, dust, or metal powders. Areas with potentially
explosive atmospheres are often but not always posted.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn OFF your
phone when you are near electrical blasting caps, in a blasting area, or in
areas posted “Turn off electronic devices.” Obey all signs and instructions.
Damaged Products
If your phone or battery has been submerged in water, punctured, or
subjected to a severe fall, do not use it until you take it to a Motorola
Authorized Service Center to determine if it has been damaged. Do not
attempt to dry it with an external heat source, such as a microwave oven.
Batteries and Chargers
Batteries can cause property damage and/or bodily injury such as burns if a
conductive material such as jewelry, keys, or beaded chains touch exposed
terminals. The conductive material may complete an electrical circuit (short
circuit) and become hot. Take care when handling a charged battery,
particularly when placing it inside a pocket, purse, or other container with
metal objects.
Use only Motorola Original™ batteries and chargers.
Caution:
To avoid risk of personal injury, do not dispose of your battery in a
fire.
Your battery, charger, or phone may contain symbols, defined as follows:

12
Safety Information
Choking Hazards
Your phone or its accessories may include detachable parts, which may
present a choking hazard to small children. Keep your phone and its
accessories away from small children.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when
exposed to flashing lights, such as when watching television or playing
video games. These seizures or blackouts may occur even if a person never
had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family
history of such occurrences, please consult with your doctor before playing
video games on your phone or enabling a flashing-lights feature on your
phone. (The flashing-light feature is not available on all products.)
Parents should monitor their children's use of video game or other features
that incorporate flashing lights on the phones. All persons should
discontinue use and consult a doctor if any of the following symptoms
Symbol Definition
Important safety information will follow.
Your battery or phone should not be disposed of in a
fire.
Your battery or phone may require recycling in
accordance with local laws. Contact your local
regulatory authorities for more information.
Your battery or phone should not be thrown in the trash.
Your phone contains an internal lithium ion battery.
032374o
032376o
032375o
032377o
032378o
Li Ion BATT

13
Safety Information
occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation.
To limit the likelihood of such symptoms, please take the following safety
precautions:
• Do not play or use a flashing-lights feature if you are tired or need
sleep.
• Take a minimum of a 15-minute break hourly.
• Play in a room in which all lights are on.
• Play at the farthest distance possible from the screen.
Repetitive Motion Injuries
When you repetitively perform actions such as pressing keys or entering
finger-written characters, you may experience occasional discomfort in
your hands, arms, shoulders, neck, or other parts of your body. Follow these
instructions to avoid problems such as tendonitis, carpal tunnel syndrome,
or other musculoskeletal disorders:
• Take a minimum 15-minute break every hour of game playing.
• If your hands, wrists, or arms become tired or sore while playing,
stop and rest for several hours before playing again.
• If you continue to have sore hands, wrists, or arms during or after
play, stop playing and see a doctor.
1. The information provided in this document supersedes the general safety
information in user’s guides published prior to January 28, 2005.

14
EU Conformance
European Union Directives
Conformance Statement
EU Confor mance
Hereby, Motorola declares that this product is in compliance
with:
• The essential requirements and other relevant provisions of
Directive 1999/5/EC
• All other relevant EU Directives
The above gives an example of a typical Product Approval Number.
You can view your product’s Declaration of Conformity (DoC) to Directive
1999/5/EC (to R&TTE Directive) at www.motorola.com/rtte. To find your
DoC, enter the product Approval Number from your product’s label in the
“Search” bar on the Web site.
0168
Product
Approval
Number

15
Recycling Information
Recycling Information
Caring for the Environment by
Recycling
When you see this symbol on a Motorola product, do not dispose
the product with household waste.
Recycling Mobile Phones and
Accessories
Do not dispose of mobile phones or electrical accessories, such as chargers
or headsets, with your household waste. In some countries or regions,
collection systems are set up to handle electrical and electronic waste
items. Contact your regional authorities for more details. If collection
systems aren’t available, return unwanted mobile phones or electrical
accessories to any Motorola Approved Service Centre in your region.

16
essentials
essentials
about this guide
This guide shows how to locate a menu feature as follows:
Find it: Press M > Recent Calls > Dialed Calls
This example shows that, from the home screen, you press
M to open the menu, highlight and select sRecent Calls , then
highlight and select
Dialed Calls .
Press
S to scroll to and highlight a menu feature. Press the
SELECT key to select the highlighted menu feature.
symbols
This means a feature is network/subscription
dependent and may not be available in all areas.
Contact your service provider for more information.
This means a feature requires an optional accessory.
CAUTION: Before using the phone for the
first time, read the
Important Safety and
Legal Information
included in the
gray-edged pages at the back of this guide.
032257o

17
essentials
SIM card
Yo u r Subscriber Identity Module (SIM) card contains personal
information like your phone number and phonebook entries.
Caution: Don’t bend or scratch your SIM card. Keep it away
from static electricity, water, and dirt.
battery
battery tips
Battery life depends on the network, signal strength,
temperature, features, and accessories you use.
032386o
1.
032387o
2.
032388o
3.
032389o
4.
