Motorola i730 User manual

Nextel
iDEN
Digital Multi-service Data-capable Phone
i730 Phone User’s Guide
@NNTN4759B@
NNTN4759B

i
Contents
Getting Started........................................... 1
Removing the Battery Door...............................3
Locating Your SIM Card....................................3
Battery...............................................................4
Powering On and Off.........................................6
Activating Service..............................................7
Enabling Security ..............................................7
Phone Programming .........................................7
Finding Your Phone Number and Direct
Connect®Number ........................................7
Nextel® Voice Mail.............................................8
Nextel Worldwide®Service ...............................8
Customizing Features .......................................8
Phone Basics ....................................................9
SIM Card Security...........................................13
Locking the Keypad.........................................16
Antenna...........................................................17
Accessories.....................................................18
Wireless Local Number Portability: Bringing
Your Phone Number From Another
Carrier.........................................................18
Nextel®Customer Care...................................19
Making Calls .............................................21
Phone Calls.....................................................21
Direct Connect®Calls .....................................21
Receiving Calls ...............................................22
Ways to Enter a Number.................................23
Missed Phone Calls ........................................26
Using Speakerphone.......................................26
Using Mute......................................................26
Making Emergency Phone Calls.....................26
Call Alerts..................................................28
Sending Call Alerts..........................................28
Receiving Call Alerts.......................................28
Using the Call Alert Queue..............................28
Recent Calls..............................................30
Storing Recent Calls to Contacts ....................30
Deleting Recent Calls......................................31
Entering Text ............................................32
Using Alpha Mode...........................................32
Using Word Mode ...........................................32

ii
Special Function Keys.....................................33
Using Numeric Mode.......................................34
Using Symbols Mode ......................................34
Contacts ................................................... 35
Viewing Contacts.............................................36
Creating Entries...............................................37
Storing Numbers Faster..................................38
Editing Entries.................................................39
Deleting Entries...............................................39
Checking Capacity ..........................................39
Creating Pauses and Waits.............................39
International Numbers.....................................40
Memo ........................................................ 41
Call Forwarding........................................ 42
Forwarding All Calls ........................................42
Turning Off Call Forwarding ............................43
Forwarding Missed Calls.................................43
Viewing Call Forwarding Settings....................44
Advanced Calling Features..................... 45
Call Waiting.....................................................45
Switching Between Calls.................................45
Putting a Call on Hold .....................................46
Calling 2 People..............................................46
Creating Pauses and Waits While Dialing.......47
Making International Calls...............................47
Setting One Touch Direct Connect .................47
Setting Flip Actions .........................................48
Group ConnectSM Calls...................................49
Call Timers......................................................50
Using Your Phone as a Modem ......................51
Making TTY Calls............................................52
Special Dialing Codes.....................................54
Nextel®Phone Services...........................55
Caller ID ..........................................................55
Per-Call Blocking.............................................55
Per-Line Blocking............................................55
Alternate Line Service.....................................55
Call Restrictions ..............................................56
Nextel®411.....................................................56
Ring Tones................................................57
Setting Your Phone to Vibrate.........................57

iii
Assigning Ring Tones to Contacts..................58
Ring and Vibrate..............................................58
Viewing Ring Tone Assignments.....................58
Downloading More Ring Tones.......................58
Managing Memory...........................................59
Deleting Custom Ring Tones ..........................59
Messages ................................................. 60
Message Notifications.....................................60
Voice Mail........................................................61
Text and Numeric Messages...........................61
Net Alerts.........................................................62
Nextel®Voice Mail ................................... 63
Setting Up Your Voice Mail Box ......................63
Playing Messages...........................................63
Changing Your Password................................64
Recording Your Name.....................................64
Recording Your Active Greeting......................65
Advanced Voice Mail Features........................65
Nextel®Voice Mail Tree..................................70
Wireless Data Services............................71
Wireless Data Services...................................71
Accessing Wireless Data Services From Your
Phone .........................................................72
Navigation Keys ..............................................72
Guides and Demos .........................................73
Voice Records ..........................................74
Creating Voice Records ..................................74
Playing Voice Records....................................74
Labeling Voice Records ..................................74
Deleting Voice Records...................................75
Locking Voice Records ...................................75
Managing Memory ..........................................75
Java Applications.....................................77
Installing Applications......................................77
Running Applications ......................................77
Suspending Applications.................................77
Resuming Applications....................................78
Ending Applications.........................................78
Downloading Applications...............................78
Deleting Applications.......................................78

iv
Managing Memory...........................................79
Shortcuts on the Main Menu ...........................79
Java Applications and GPS Enabled...............80
GPS Enabled............................................ 83
IMPORTANT: Things to Keep in Mind ............83
Making an Emergency Call .............................84
Viewing Your Approximate Location ...............85
Enhancing GPS Performance.........................86
Updating Satellite Almanac Data.....................88
Setting Privacy Options...................................89
Using GPS with Map Software........................90
Datebook .................................................. 93
Viewing Datebook ...........................................93
Creating Events...............................................94
Editing Events .................................................96
Deleting Events...............................................97
Receiving Reminders......................................97
Making Calls From Datebook..........................98
Customizing Datebook Setup..........................98
Customizing Your Phone.......................100
Setting the Volume........................................100
Setting Your Phone to Vibrate.......................100
Changing the Look of Your Phone................101
Airplane Mode—Temporarily Turning Off Calls ..
102
Using Settings...............................................102
Profiles ....................................................107
Viewing Profiles.............................................107
Switching Profiles..........................................107
How Changing Settings Affects Profiles........107
Temporary Profiles........................................108
Creating Profiles............................................109
Editing Profiles ..............................................109
Deleting Profiles............................................109
Setting Call Filtering......................................110
Shortcuts.................................................111
Creating a Shortcut.......................................111
Using a Shortcut............................................111
Editing a Shortcut..........................................111
Deleting Shortcuts.........................................112

v
Using a Headset..................................... 113
Attaching a Headset......................................113
Using a Remote PTT Button .........................113
Nextel®Customer Care......................... 114
Domestic Customer Care..............................114
Nextel Worldwide®Customer Care...............115
Understanding Status Messages......... 116
Nextel®Terms and
Conditions of Service........................ 119
Safety and General Information ........... 141
RF Operational Characteristics.....................141
Portable Radio Product EME Exposure
Information................................................141
Electro Magnetic Interference/Compatibility..144
Medical Devices............................................144
Operational Warnings....................................145
Operational Cautions.....................................146
Accessory Safety Information........................147
MOTOROLA LIMITED WARRANTY.......149
Patent and Trademark Information.......153
Index........................................................154

vi
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola, Inc.
Address: 8000 West Sunrise Boulevard
Plantation, FL 33322 USA
Phone Number: 1 [phone]
Hereby declares that the product:
Product Name: i730
Model Number: H63XAN6RR4AN
Conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a),
15.107(d) and section 15.109(a)
Class B Digital Device
As a personal computer peripheral, this device
complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.

1
Getting Started
volume
controls
Push-to-talk (PTT)
button
accessory connector
audio jack
speaker
(in back)
retractable
antenna
external
display
microphone
space key
back key
earpiece
light sensor
internal
display
navigation
key
power
button

2
Getting Started
To start using your i730 phone:
•Make sure your SIM card is in place.
•Charge the battery.
•Activate your service.
•Enable over-the-air security.
pPower button.
Navigation key — press the arrows to
scroll through menus and lists.
OOK key — selects highlighted item;
answers calls.
mMenu key — accesses context-sensitive
menus.
AOption key — selects the option
appearing above it on the display.
Note: Throughout this User’s Guide,
the option keys will be
represented by A.
sSend key — places phone calls.
eEnd key — ends phone calls; returns to
idle screen; using Wireless Data
Services, returns to Net main menu.
tActs like swhen the flip is closed; turns
Direct Connect® / Group ConnectSM
speaker on and off; used with voice
names and voice records.
.Acts like ewhen the flip is closed;
accesses recent calls; sends incoming
calls to voice mail.

3
Removing the Battery Door
Removing the Battery Door
1Make sure the phone is powered off. See
“Powering On and Off” on page 6.
2Slide the release buttonbackuntil it releasesthe
battery door.
3Allow the battery door to pop up, slide it forward,
and remove it from the back of your phone.
Locating Your SIM Card
Your SIM (Subscriber Identity Module) card is a
small piece of white plastic located in the SIM card
holder in the back of your phone, underneath the
battery.
If there is no SIM card in your phone, contact
Nextel Customer Care at 1-800-639-6111.
If you want to use a SIM card other than the one
that is in your phone, please contact Nextel
Customer Care to verify that the SIM card you want
to use is compatible with your phone.
speaker
SIM card

4
Getting Started
Battery
Inserting the Battery
Your phone comes with a Standard Lithium Ion
Battery.
1With the phone powered off, remove the battery
door.
2Insert the top of the battery into the battery area.
Press the bottom of the battery to secure it.
3Replace the battery door and press itgentlyuntil
you hear a click.
Charging the Battery
Your phone comes with a rapid travel charger.
1Plug the charger into an electrical outlet.
2Open the connector cover.
connector
cover

5
Battery
3Plug the other end of the charger into the
accessory connector.
ChargerAttachedorDeviceAttached appears
on the internal display.
Tip: To remove the charger from the accessory
connector: Press the buttons on the sides
of the plug. Pull the plug straight out.
4If you have purchased optional batteries or
chargers, see “Charging Times”.
Note: While the phone is charging, the keypad
backlight will not illuminate.
Charging Times
Check your battery and charger type against the
below grid to determine appropriate charging
times.
Recommended charging times:
For best results, charge the batteries within the
temperature range of 50°F to 104°F (10°C to
40°C).
Prolonged charging is not recommended.
Battery Charger
Rapid Standard
Standard
Lithium Ion 2 hours 4 hours
High
Capacity
Lithium Ion
3 hours 7 hours

6
Getting Started
Removing the Battery
1With the phone powered off, remove the battery
door.
2Remove the battery by pushing the battery
toward the antenna and lifting it out.
Battery Use and Maintenance
•The Motorola iDEN Approved Lithium Ion
chargers provide optimum performance. Other
chargers may not fully charge the iDEN Lithium
Ion battery or may yield a reduced number of
lifetime charge cycles.
•Extreme temperatures degrade battery
performance. Do not store the battery where
temperatures exceed 140°F (60°C) or fall below
4°F (-20°C).
•Lithium Ion batteries have a self discharge rate
and without use, lose about 1% of their charge
per day.
•The battery capacity is degraded if the battery is
stored for long periods while fully charged. If
long term storage is required, store at half
capacity.
Powering On and Off
To power your phone on:
1Open the flip.
2Press p.
Note: Pressing pfor more than 5 seconds turns
on Airplane mode. See “Airplane Mode—
Temporarily Turning Off Calls” on page
102.
As your phone connects to the network, you will
see a connecting message. When the idle screen
appears, the phone is ready to use.

7
Activating Service
To power your phone off:
1Open the flip.
2Press and hold p.
Activating Service
The first time you power on your phone, your
service is activated.
A screen then appears prompting you to select Ok
to update your browser information. This screen
will only appear during initial activation. See
“Enabling Security”.
Enabling Security
You must enable security the first time you power
on your phone or within 10 days offirst activation of
your phone.
1Press Aunder Ok.
Note: If you press Aunder Later, the idle
screen will appear. The next time you
select Net from the main menu, you will
be prompted to enablesecurity before you
can use Wireless Data Services.
2You are prompted to enable security. Press A
under Yes. A series of screens and then the
default homepage displays.
3Press eto return to the idle screen.
Phone Programming
Within 24 hours of enabling security, you will
receive an alert notification containing your
Personal Telephone Number (PTN), Nextel
Customer Care number, Direct Connect number,
and Talkgroups.
1When you receive a Net alert saying New
Browser Message - Receive Programming
Info, press Aunder Goto.
2You are prompted to accept changes to your
lists. Press Aunder Ok.
3You are prompted again to accept changes to
your lists. Press Aunder Ok.
4A confirmation screen displays. Press Aunder
Ok.
5Press eto return to the idle screen.
Finding Your Phone Number
and Direct Connect®Number
1Press mto access the main menu.
2Scroll to My Info.
3Press O.
4Scroll to see your information:
•Name— Enter your name. See “Entering
Text” on page 32.

8
Getting Started
• Line 1 and Line 2 — your phone numbers for
phone lines 1 and 2. These are filled in when
you receive your first Net alert after enabling
over-the-air security on your phone.
•DirectConnect— Your Direct Connect
number is the number that others use to
contact you usingDirect Connect service. It is
filled in when you receive your first Net alert
after enabling over-the-air security on your
phone.
• Group ID — the number of the Talkgroup you
have joined.
• Carrier IP — the IP address assigned to
Nextel. It is filled in when you register for
packet data services.
• IP1 Address and IP2 Address — the IP
addresses assigned to you for using the
Internet with your phone.
•Ckt— Your circuit data number is the number
you use if you want to use your phone to
transfer circuit data. See “Using Your Phone
as a Modem” on page 51. You receive this
number from Nextel.
• Service Status — This information may be
used by Nextel Customer Care if there is a
problem with your phone’s services.
Nextel® Voice Mail
You must set up your voice mail box before you
can retrieve messages. See “Setting Up Your
Voice Mail Box” on page 63.
Nextel Worldwide®Service
You can use your phone to make calls
internationally in select cities using other iDEN®
networks by calling Nextel Customer Care to
activate international dialing on your account.
Countries in which you can useyour phone include
Argentina, Brazil, Canada, Israel, Jordan, Mexico,
Peru, the Philippines, and Singapore*.
* Credit approval may be required. Other conditions may apply.
Customizing Features
You can control many features of your phone,
including the size ofthe text on the display, the way
you access main menu items, and the volume of
incoming sound, rings, and other tones. See
“Customizing Your Phone” on page 100.

9
Phone Basics
Phone Basics
Display
Any time your phone is powered on, the display
provides you with information and options.
The external display shows a shortened version of
the internal display. To see more information, open
the phone cover.
The screen shown above is the idle screen. The
idle screen appears when your phone is on, but not
engaged in any activity.
Text Area
This area displays menus, messages, names,
phone numbers, and other information.
Display Options
Two display options appear at the bottom of most
screens. You select a display option by pressing
the option key below it.
Menus and Lists
Your phone’s features are arranged in menus,
submenus, and lists.
To access the items in a menu or list, scroll using
the navigation key at the top of your keypad. This
key lets you scroll up, down, left, or right. Holding
down the appropriate part of the navigation key
speeds up scrolling.
In this guide, this symbol >tells you to select a
menu or list item. For example, Settings >
Security means:
1Scroll to Settings on the main menu.
2Press Oto see the Settings screen.
3Scroll to Security.
4Press Oto see the Security screen.
status icons
text area
menu icon
display options

10
Getting Started
Quick Access to Main Menu Items
Each arrow in the navigation key and Ocan be
used to access a main menu item from the idle
screen. Each of these keys is assigned to a main
menu item when your receive your phone. To
assign differentmain menu items,see “Personalize
Features” on page 104.
OK Key
Pressing O:
•Selects the highlighted menu item or list item
•Sets options
•Confirms actions
•Places and answer calls
•From the idle screen, accesses ring tones list.
This is the default setting. You can assign a
different main menu item to O.
Menu Key
Many features provide context-sensitive menus
that let you access related features and actions.
The micon appears any time a context-sensitive
menu is available. Press mto access the menu.
Main Menu
All your phone’s features can be accessed through
the main menu. You can set the main menu to
appear as a list or as large icons (see “Setting the
Menu View” on page 101).
aNet Access to Nextel Wireless
Data services. See
page 71.
qJava Apps Java applications on your
phone. See page 77.
bSettings
Display/Info
Phone Calls
DC/GC Options
Personalize
Volume
Security
Advanced
Customize your phone.
See page 100.
mRing Tones
VibeAll
list of ring tones
Ring Tones menu
Assign ring tones and turn
ringer off. See page 57.
cVoiceRecord Record and play audio
messages. See page 74.

11
Phone Basics
jMy Info View personal phone
information, including
phone number and Direct
Connect number. See
page 7.
nDownloads Provides a catalog of ring
tones, wallpaper, games
and applications that you
can download directly from
your phone. Browse
through the catalog to add
a new ring tone, a
wallpaper to serve as the
background image on your
phone, a game for
entertainment, or an
application that serves
your business and
productivity needs. Items
in these catalogs change
frequently, so check
regularly for fresh content.
See page 58.
lGPS Find your approximate
geographical location. See
page 83.
dContacts
new contact form
list of contacts
Contacts menu
Create, view, store, edit
contacts. See page 35.
eMessages
Voice Mail
Net Alert
Text Msgs
Access messages. See
page 60.
fCall Forward Setcall forwardingoptions.
See page 42.
oDatebook
new event form
list of events
Datebook menu
Schedule appointments.
See page 93.
gMemo Store a number to access
later. See page 41.
hCall Timers Phone usage information.
See page 50.
iRecent Calls
list of calls
recent calls menu
Call Setup menu
Lists recent calls. See
page 30.
sShortcuts Create shortcuts to
screens. See page 111.

12
Getting Started
Status Icons
Status icons appear at the top of the display. Some
appear at all times. Others appear only when your
phone is engaged in certain activities or when you
have activated certain features.
pProfiles
new profile form
list of profiles
Profiles menu
Groups of settings you
apply together. See
page 107.
kCall Alert
list of call alerts
Call Alerts menu
Lists call alerts. See
page 28.
abcd
efgd
Battery Strength — A fuller battery
indicates a greater charge.
opqr
s
Signal Strength — More bars next
to the antenna indicate a stronger
signal.
APhone In Use — Your phone is
active on a phone call.
BDirect Connect In Use — Your
phone is active on a Direct Connect
call.
CTalkgroup In Use — Your phone is
active on a Group Connect call.
12Active Phone Line — 1 indicates
phone line 1 is ready to make calls;
2 indicates phone line 2 is ready to
make calls.
GL
IJ
HK
Call Forward — Your phone is set
to forward calls. See “Call
Forwarding” on page 42.
MQRinger Off — Your phone is set not
to ring. See “Setting Your Phone to
Vibrate” on page 57.
u Speaker Off — Sets Direct
Connect and Group Connect sound
to come throughthe earpiece rather
than through the speaker. Your
phone does not ring for Direct
Connect and Group Connect calls if
Alert Type is set to Silent or
Vibrate.
wxT
yz
Messages — You have one or
more messages. See “Messages”
on page 60.

13
SIM Card Security
SIM Card Security
Your SIM card stores all your Contacts and
protects your personal information. Since this
information is stored on your SIM card, not in your
phone, you can remove the information by
removing your SIM card.
Note: Except for making emergency calls, your
phone will not function without the SIM
card.
To prevent unauthorized use of your phone, your
SIM card is protected by a PIN that you enter each
time the phone is powered on. You can change the
PIN or turn off the requirement that it be entered.
Turning the PIN Requirement On and
Off
When the SIM PIN requirement is off, your phone
can be used without entering a PIN.
Important: When the SIM PIN requirement is off,
the personal data on your SIM card is
not protected. Anyone can use your
phone and access your personal data.
When the SIM PIN requirement is on, you are
prompted to enter your PIN each time you power
on your phone.
Note: If a SIM PIN is required, your phone will
not function until the SIM PIN is entered,
except for making emergency calls.
1From the main menu, select Settings >
Security > SIM PIN.
2Select On or Off.
3Enter the current SIM PIN.
DE Internet — You are ready to
browse the internet or are browsing
the internet using a secure
connection.
UAirplane Mode — Your phone is
set to Airplane Mode. See “Airplane
Mode—Temporarily Turning Off
Calls” on page 102.
YZPacket Data — You are ready to
transfer packet data or are
transferring packet data. See “Using
Your Phone as a Modem” on page
51.
N O TTY — You are ready to use your
phone to make calls using a
teletypewriter device. See “Making
TTY Calls” on page 52.
