Motorola i870 User manual

SouthernLINC Wireless
iDEN
Digital Multi-service Data-capable Phone
i870 Phone User’s Guide
@NNTN6539A@
NNTN6539A

IMPORTANT NOTICE: PLEASE READ
PRIOR TO USING YOUR PHONE
The SIM card provided in this kit is intended for use with
the phone provided in this package.
Loss of certain features will result when using a SIM
card from one of the following models: i30sx, i35s,
i50sx, i55sr, i58s, i60c, i80s, i85s, i88s, i90c, i95cl
series, and the i2000 series.
For more information on SIM card compatibility, go to
www.motorola.com/iden/support.
Defects or damage to your Motorola phone that result
from the use of non-Motorola branded or certified
Accessories, including but not limited to replacement
housings and or other peripheral accessories, are
excluded from warranty coverage. Please refer to the
text of Motorola's Limited One Year warranty located in
this user’s guide for complete details.

i
Contents
Getting Started........................................... 1
Locating Your SIM Card....................................3
Battery...............................................................4
Activating Service..............................................7
Powering On and Off.........................................7
Enabling Over-the-Air Security..........................8
Finding Your Phone Number and LINC ID........8
Phone Basics ....................................................8
Using the Memory Card ..................................13
SIM Card Security ...........................................13
Antenna...........................................................18
Accessories.....................................................19
For More Information.......................................19
Making Calls............................................. 20
Phone Calls.....................................................20
InstantLINC Mobile to Mobile Calls .................20
Receiving Calls................................................21
Choosing a Number to Call .............................22
Missed Phone Calls.........................................23
Using Speakerphone.......................................23
Using Mute......................................................24
Making Emergency Phone Calls.....................24
LINCaroundSM...........................................25
Channels and Codes.......................................26
Private LINCaround Calls................................28
Making Emergency Calls while in LINCaroundSM
Mode...........................................................29
Setup Options .................................................29
Call Alerts..................................................31
Sending Call Alerts..........................................31
Receiving Call Alerts.......................................31
Using the Call Alert Queue..............................31
Recent Calls..............................................33
Calls and Call Alerts........................................33
My Info From Other Phones............................33
Contact Information From Other Phones........34
Viewing the Recent Calls List..........................34
Storing Items to Contacts................................35
Deleting Items .................................................35
Making Calls From the Recent Calls List........36

ii
Contacts ................................................... 38
Accessing Contacts.........................................39
Creating Entries...............................................39
Storing Numbers Faster..................................41
Editing Entries.................................................41
Viewing Entries................................................42
Deleting Entries...............................................44
Checking Capacity ..........................................44
Creating Pauses and Waits.............................45
International Numbers.....................................45
Making Calls From Contacts ...........................45
Accessing Contacts with GSM Phones...........46
Call Forwarding........................................ 47
Forwarding All Calls ........................................47
Turning Off Call Forwarding ............................48
Forwarding Missed Calls.................................48
Viewing Call Forwarding Settings....................49
Advanced Calling Features..................... 50
Call Waiting.....................................................50
Switching Between Calls.................................50
Putting a Call on Hold......................................51
Calling 2 People..............................................51
Creating Pauses and Waits While Dialing.......52
Making International Calls...............................52
One Touch PTT...............................................52
Setting Flip Actions .........................................53
Group Calls .....................................................53
Call Timers......................................................54
Using Your Phone as a Modem ......................55
Making TTY Calls............................................57
Memo.........................................................59
Ring Tones................................................60
Setting Your Phone to Vibrate.........................60
Ring and Vibrate .............................................61
Assigning Ring Tones to Contacts..................61
Viewing Ring Tone Assignments ....................62
Downloading More Ring Tones.......................62
About DRM Ring Tones ..................................62
Managing Memory ..........................................62
Deleting Custom Ring Tones ..........................63

iii
Entering Text............................................ 64
Using Word Mode............................................64
Special Function Keys.....................................65
Messages ................................................. 66
Message Notifications.....................................66
Message Center..............................................67
Voice Mail Messages............................... 68
Receiving a Message......................................68
Accessing Voice Mail from
the Message Center ...................................68
Sending Unanswered Calls to Voice Mail .......68
Text Messaging........................................ 69
Setting Up........................................................69
Receiving a Message......................................69
Reading from the Message Center .................70
Creating and Sending Messages ....................70
Sorting Messages............................................73
Managing Memory...........................................73
Memory Card............................................ 74
Ensuring Files on the Memory Card Are
Compatible With Your Phone.....................74
Using the Memory Card With
Your Phone.................................................76
Using the Memory Card With
Your Computer ...........................................78
Other Memory Cards Compatible with Your
Phone .........................................................80
Camera ......................................................81
Accessing the Camera....................................81
Taking Pictures ...............................................81
More Actions for Captured Pictures ................83
Recording Videos............................................84
Changing Storage Preference.........................85
Accessing the Media Center ...........................86
Customizing the Camera.................................86
Managing Memory ..........................................87
Media Center.............................................88
Viewing the Media Center...............................88
Forward Locked Items.....................................90
DRM Items ......................................................91
Pictures ...........................................................91
Videos .............................................................92

iv
Audio Recordings............................................93
Renaming Items..............................................93
Locking Items..................................................94
Deleting Items .................................................94
Copying and Moving Items..............................95
Changing Storage Preference.........................95
Accessing the Audio Player.............................95
Accessing the Camera....................................96
Managing Memory...........................................96
Audio Player............................................. 97
Playing Audio Files with the Flip Closed .........97
Playing Audio Files with the Flip Open............97
How Your Audio Files Are Organized..............99
Searching By First Letter...............................100
Playing a List, Repeat, and Shuffle ...............100
Working with Playlists....................................101
Deleting Audio Files ......................................104
DRM Items ....................................................104
Setting Audio and Visual Options..................105
Digital Rights Management................... 106
Installing Items ..............................................106
Understanding DRM Status Icons.................106
Sharing Items................................................106
Managing DRM Items ...................................107
Using LINC View.....................................110
Sending a Picture..........................................110
Receiving a Picture .......................................111
Sending My Info and Contact Information.....112
My Info.....................................................115
Viewing My Info.............................................115
Editing My Info ..............................................115
Setting Sending Options ...............................116
Datebook.................................................117
Viewing Datebook .........................................117
Creating Events.............................................118
Editing Events ...............................................120
Deleting Events.............................................120
Receiving Reminders....................................121
Making Calls From Datebook and Datebook
Reminders................................................121
Customizing Datebook Setup........................122

v
Java Applications.................................. 124
Installing Applications....................................124
Running Applications.....................................124
Suspending Applications...............................124
Resuming Applications..................................125
Ending Applications.......................................125
Downloading Applications.............................125
Deleting Applications.....................................126
Managing Memory.........................................126
Shortcuts on the Main Menu .........................126
Java Applications and GPS Enabled.............127
Bluetooth®............................................. 130
Understanding Bluetooth®Access Settings..130
Setting Your Phone for Bluetooth®.....................130
Accessing Bluetooth®...................................131
Making a Bluetooth®Connection ..................132
Setting Device Details ...................................134
Sending Contacts, Datebook Events and
Pictures.....................................................135
Receiving Items.............................................136
GPS Enabled...........................................138
IMPORTANT: Things to Keep in Mind ..........138
Making an Emergency Call ...........................140
Viewing Your Approximate Location .............141
Enhancing GPS Performance.......................142
Setting Privacy Options.................................143
Using GPS with Map Software......................144
Voice Records ........................................147
Viewing Voice Records.................................147
Creating Voice Records ................................147
Playing Voice Records..................................148
Labeling Voice Records ................................148
Locking Voice Records .................................148
Deleting Voice Records.................................149
Managing Memory ........................................149
Customizing Your Phone.......................150
Setting the Volume........................................150
Setting Your Phone to Vibrate.......................150
Changing the Look of Your Phone................150
Temporarily Turning Off Transmissions........152
Using Settings...............................................152

vi
Profiles ................................................... 157
Viewing Profiles.............................................157
Switching Profiles..........................................157
How Changing Settings Affects Profiles........157
Temporary Profiles........................................158
Creating Profiles............................................159
Editing Profiles ..............................................159
Deleting Profiles............................................159
Setting Call Filtering ......................................160
Shortcuts................................................ 162
Creating a Shortcut .......................................162
Using a Shortcut............................................162
Editing a Shortcut..........................................163
Deleting Shortcuts.........................................163
Using a Headset..................................... 164
Using a Bluetooth Headset............................164
Attaching a Headset......................................164
Using a Remote PTT Button .........................164
Understanding Status Messages..........166
Safety and General Information............168
RF Operational Characteristics.....................168
Portable Radio Product Operation and EME
Exposure...................................................168
Electromagnetic Interference/Compatibility...171
Medical Devices............................................171
Operational Warnings ...................................172
Operational Cautions ....................................173
Accessory Safety Information .......................174
Hearing Aid Compatibility .....................176
Caring for the Environment by
Recycling.............................................178
Disposal of your Mobile Telephone and
Accessories ..............................................178
MOTOROLA LIMITED WARRANTY.......179
Patent and Trademark Information.......183
Index........................................................184
Driving Safety Tips.................................191

vii
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola, Inc.
Address: 8000 West Sunrise Boulevard
Plantation, FL 33322 USA
Phone Number: 1 [phone]
Hereby declares that the product:
Product Name: i870
Model Number: H85XAH6RR5AN
Conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a),
15.107(d) and section 15.109(a)
Class B Digital Device
As a personal computer peripheral, this device
complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.

viii

ix
AgION AntimicrobialTM —
Built-in Protection for
Your Phone
Motorola has incorporated AgION antimicrobial
into the painted surfaces of your phone to help
provide protection against a broad range of product
damaging bacteria, mold, and mildew.
Motorola is the first wireless phone manufacturer to
incorporate AgION antimicrobial into the phone's
painted surfaces.
The antimicrobial technology is an example of
Motorola's pursuit for innovation and creativity to
produce the best quality wireless experience.
The antimicrobial technology in the paint on
Motorola iDEN®phones helps provide protection
against product damage caused by microbes, but
does not extend such protection to the user.
Versatile in application, the EPA-registered AgION
additive is recommended for institutional,
commercial and consumer applications. AgION
antimicrobials are used in many settings including
hospitals, offices, schools and food processing
facilities. They can also be found in leading
footwear, fabrics, appliances, water coolers and
architectural hardware.
Benefits of AgIONTM*
•AgION antimicrobial technology helps provide
protectionagainst product damaging bacteria on
the painted surfaces of the phone.
•AgION antimicrobial is effective in protecting the
product against a broad spectrum of bacteria.
•AgION helps inhibit the ability of microbes to
grow and spread on the painted surfaces of the
phone.
•The active ingredient helps break down
enzymes in the microbe, inhibiting its ability to
reproduce and spread on the painted surfaces of
the phone.
•Studies have shown that surfaces with AgION
antimicrobial can reduce the amount of certain
product damaging bacteria by 99%.
•The AgION coating will protect the painted
surfaces of the product against product
damaging bacteria for the life of the product.
* The antimicrobial technology is applied only to the painted
surfaces of the Motorola iDEN phones, thereby providing
protection against damage to such surfaces caused by microbes,
but does not extend such protection to the end user.

x
Safety
•AgION antimicrobial protection is based on
silver, a safe, non-toxic additive to the phone
paint. Silver is widely used as an antimicrobial
agent in many environments and industries.
•AgION antimicrobial technology is safe to use.
Thorough testing has shown the additive to be
less toxic than table salt and less irritating than
talcum powder.
How It Works
•The technology continuously inhibits the growth
of product damaging bacteria on the phone's
painted surfaces.The active ingredient helps
break down enzymes in the microbe, inhibiting
its ability to reproduce and spread on the painted
surfaces on the phonee.
•The active ingredient in AgION is silver, in the
form of silver ions.
Accreditation
•The AgION antimicrobial compound is
registered with the Environmental Protection
Agency (EPA) as a preservative and
bacteriostatic agent for use in the manufacturing
of polymers and plastics.
•NSF, FDA-listed

1
Getting Started
volume
controls
Push-To-Talk
(PTT) button
audio jack
speaker
(in back)
audioplaye
r
keys
retractable
antenna
mirror
memory
card slot
external
display
flip open
button
camera
lens
spotlight
light sensor
power button
camera key
microphone
accessory
connector

2
Getting Started
Navigation key — press the arrows to
scroll through menus and lists.
OOK key — selects highlighted item;
answers calls.
mMenu key — accesses context-sensitive
menus.
cCamera key — accesses camera;
captures picture.
AOption key — selects the option
appearing above it on the display.
sSend key — places phone calls.
eEnd key — ends phone calls; returns to
idle screen.
tActs like swhen the flip is closed; turns
speaker on; used with voice names and
voice records.
.Acts like ewhen the flip is closed;
accesses recent calls; sends incoming
calls to voice mail.

3
Locating Your SIM Card
To start using your i870 phone:
•Make sure your SIM card is in place.
•Charge the battery.
•Activate your service.
•Enable over-the-air security if you are prompted
to.
Locating Your SIM Card
Your SIM (Subscriber Identity Module) card is a
small piece of plastic located in the SIM card
holder in the back of your phone, underneath the
battery.
If your SIM card is not in the SIM card holder, it
may be in the box your phone came in, attached to
a piece of plastic about the size of a credit card. If
this is the case, carefully detach your SIM card
from the surrounding plastic and insert it as
described in “Inserting Your SIM Card” on page 16.
yAccesses the audio player when the flip is
closed; plays audio files; pauses audio
files.
zWhen an audio file is playing,
fast-forwards and skips to the next audio
file.
xWhen an audio file is playing, rewinds and
skips to the previous audio file.
SIM card

4
Getting Started
If there is no SIM card in your phone or the box,
contact SouthernLINC Wireless at
1-800-406-0151.
Battery
Removing the Battery Door
1Make sure the phone is powered off. See
“Powering On and Off” on page 7.
2Slide the release button backuntil it releasesthe
battery door.
3Allow the battery door topop up, slide it forward,
and remove it from the back of your phone.
Inserting the Battery
Your phone comes with a High Performance
Lithium Ion Battery.
1Remove the battery door.
2Insert the battery into the battery area. Press the
battery down to secure it.
release
button

5
Battery
3Replace the battery doorandpress itgentlyuntil
you hear a click.
Charging the Battery
Your phone comes with a rapid travel charger.
1Plug the charger into an electrical outlet.
2Open the connector cover.
3Plug the other end of the charger into the
accessory connector.
Charger AttachedorDeviceAttached appears
on the internal display.
Tip: To remove the charger from the accessory
connector: Press the buttons on the sides
of the plug. Pull the plug straight out.
4If you have purchased optional batteries or
chargers, see “Charging Times” on page 6.
connector
cover

6
Getting Started
Charging Times
See your battery and charger to determine the
appropriate charging time.
For best results, charge the batteries within the
temperature range of 50°F to 104°F (10°C to
40°C).
Prolonged charging is not recommended.
Removing the Battery
1With the phone powered off, remove the battery
door.
2Remove the battery by pushing it toward the
antenna and lifting it out.
Battery Use and Maintenance
•The Motorola iDEN Approved Lithium Ion
chargers provide optimum performance. Other
chargers may not fully charge the iDEN Lithium
Ion battery or may yield a reduced number of
lifetime charge cycles.
•Extreme temperatures degrade battery
performance. Do not store the battery where
temperatures exceed 140°F (60°C) or fall below
4°F (-20°C).
Battery Charger
Rapid Standard
High
Performance 2 hours 4 hours
Maximum
Capacity 3.5 hours 7.5 hours
