Motorola RAZR User manual

Ataglance
At a glance
Yo u r M OT O R O L A RAZR™ i, with Intel Inside® offers fast
web browsing, a large display in a compact design, strong
materials and more:
•Fast: Get fast web browsing and effortless multi-
tasking with an advanced Intel® Atom™ processor.
•Strong: Protected with Corning® Gorilla® Glass 2,
DuPont™ KEVLAR® fibre and a water-repellent
coating. KEVLAR® not available on all smartphones.
See Motorola.com for details.
•Photographic: Instant launch camera and multi-shot
mode.
TM
Headphones
jack
Volume keys
Power/Sleepkey
Front camera
8MP Photo/
1080pVideo
camera(on
back)
Notification
light
micro SIM
card slot
microSD card
slot
Micro USB/
charger Camerakey
Start
Charge up
Micro SIM in, memory card in (optional), charge up, then
power up. Use the SIM tool to push the SIM or memory
card in, until it clicks into place and locks.
Note: Certain apps and features may not be available in all
countries.
Caution: Before using your phone, please read the
safety, regulatory and legal information provided with
your product.
4:00
1Insert micro SIM card.
micro
SIM
SIM SIM & adapter
2Insert microSD memory
card (optional).
4Power up.
Power key
Press= Screen
On/Off.
Hold = On/Off.
3Charge up.
Note: This product uses a
non-removable battery.
3 H
micro
SIM
SIM SIM & adapter
4Power up.
Power key
Press= Screen
on/off.
Hold = on/off.
3Charge up.
Note: This product uses a
non-removable battery.
3 H
Register
After you power up, create or log into a Google™ account
to access all of your Google Mobile™ services.
Registration is secure and only takes a few minutes.
Tip: To get help transferring your contacts, visit
www.motor ola.com/transferc ontacts .
Note: This phone supports apps and services that use a lot
of data, so make sure your data plan meets your needs.
Contact your service provider for details.
4:00
3Set up.
Make it yours now...
I’ll set up later
Congratulations!
Letus help you personalise your device
now.Want to call a friend first and share
yourexcitement? Don’t worry, you can
setup whenever you’re ready.
1
Welcome
Selectyour language:
English
Español
Start
Select your language. 2Sign in with your
Google™ account.
Make it Google
GotGmail? Sign in now.
Neverlose your stuff again. A Google
accountkeeps everything safe.
Sign in
The best of Google™
Your whole world, organised and accessible. Browse,
locate, watch, shop, play, work...Google has you covered.
One account, access everywhere—phone, tablet,
computer.
Music
Magazines
Books
Apps
Films & TV
Call of the
Wild
Pride and
Prejudice
Google Play
Games
NEW
MUSIC
G
G
G
G
G
a
a
a
a
a
m
m
m
m
m
e
e
e
e
e
s
s
s
s
s
My apps
Accounts
Settings
Help
JaneAusten
JackLondon
Search for apps.
Choose your account and
settings.
On your computer and Android
tablet, sign into your Google
account for all your Google Play
content, Gmail, Google Calendar
events and more.
Homescreen &a pps
Home screen & apps
Start from the Home screen, to explore apps and more.
•Home screen: You’ll see the Home screen when you
turn on your phone or touch Home .
•App & widget list: To show all of your apps and
widgets, touch Apps .
•More: To download more apps and widgets, touch
Apps >
Play Store .
4:00
CameraTextPhone
Play Store Email Browser Guide me
People
CameraTextPhone People
H 89°
L 63°
74°
Sunnyvale
Thu, 5 Jul
4:00
100%
Circles widget
Status & notifications
Favourites tray
Shortcuts
Touch to see all
your apps & widgets.
Flick down for details.
Flick up/down to see more.
Touch to open.
Touch to open.
Control&customise
Control & customise
Take control of your phone:
•Touch: It’s all in the touch. Simple gestures and touch
keys to move abou t.
•Speak: Tell your phone what you want—touch
Apps >
Voice commands .
•Customise: Change notifications or display
settings—flick the status bar down and touch .
4:00
CameraTextPhone
Play Store Email Browser Guide me
People
Phone
H 89°
L 63°
74°
Sunnyvale
Thu, 5 Jul
4:00
100%
Touch to open.
Touch & hold to move or delete.
See your apps & widgets.
Touch & hold an empty spot to
change wallpaper.
Flick left to open or create pages.
Flick right to open Quick settings
Back (one screen)
Home
Recent apps
Browse
Browse
Access to the world. Find a webpage, or just explore:
Find it: Apps >
Browser
•Go to a webpage: Touch the address bar at the top of a
page and enter an address.
•Create or open bookmarks: Open the address bar
(flick down), then touch Menu >
Save to Bookmarks or
Bookmarks .
WWW.
www.google.com/
Web
Images Places News more
Restaurants
Chicago, IL - update
Bars More
History Sign out
Coffee
[email protected]
SettingsiGoogle Help
View Google in: Mobile Classic
Touch a link to select it.Touch &
hold for more options.
Open options for the browser
& page.
Show other browser tabs, or
open a new one.
If you don’t see the URL bar at
the top, drag the page down.
Wantmore?
Get more
There’s more help, updates and information right here:
•Tutorials & answers: Touch Apps >
Guide me to
get walk-through tutorials. For HELP TOPICS, touch the
tab.
•Updates: Get phone updates, PC software, online
help, guides, and more at
www.motorola.com/myrazri
•Accessories: Find accessories for your phone at
www.motorola.com/mobility .
•Apps: Touch Apps >
Play Store .
•News: Get the latest news, apps, tips & tricks, videos
and so much more—join us on:
YouTube™
www.youtube.com/motorola
Facebook™ www.facebook.com/motorola
Twitter
www.twitter.com/motomobile
Google+
www.google.com/+
Grab a barcode scanner from
Google Play and scan this
code.
RAZRi.UMTS.EMARA.ASIA.NGSG.fm Page 1 Thursday, September 6, 2012 5:14 PM

This product meets the applicable SAR limits of 1.6 W/kg (FCC &
IC) and 2.0 W/kg (ICNIRP). The limits and guidelines include a
substantial safety margin designed to assure the safety of all
persons, regardless of age and health. The highest SAR values
measured for this device are listed in the regulatory information
packaged with your product.
Note: When carrying using or wearing the product, either use an
approved accessory such as a holster or otherwise maintain a
distance of 2.5 cm (1 inch) from the body to ensure compliance
with RF exposure requirements. Note that the product may be
transmitting even if you are not making a phone call.
MOTOROLA
RAZR i
TM
EN
Regulatory information
For your safety
Foryour safety
Before assembling, charging or using your mobile device for the first time, please read the
important product safety and legal information provided with your product.
Specific absorption rate (ICNIRP)
SAR(ICNIRP)
YOUR MOBILE DEVICE MEETS INTERNATIONAL
GUIDELINES FOR EXPOSURE TO RADIO WAVES.
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for
exposure to radio waves (radio frequency electromagnetic fields) recommended by international
guidelines. Theguidelines were developed by an independent scientificorganisation (ICNIRP) and
include a substantial safety margin designed to assure the safety of all persons, regardless of
age and health.
The radio wave exposure guidelines use a unit of measurement known as the Specific absorption
rate or SAR. The SAR limit for mobile devices is 2 W/kg.
Tests for SAR are conducted using standard operating positions with the device transmitting at
its highest certified power level in all tested frequency bands
* . The highest SAR values under the
ICNIRP guidelines for your device model are listed below:
During use, the actual SAR values for your device are usually well below the values stated. This
is because, for purposes of system efficiency and to mi nimise int erference on the network, the
operating power ofyour mobile device is automatically decreased when full power is not needed
for the call. The lower the power output of the device, the lower its SAR value.
If you are interested in further reducing your RF exposure then you can easily do so by limiting
your usage or simply using a hands-free kit to keep the device away from the head and body.
Additional information can be found at
www.motorola.com/rfhealth .
* The tests are carried out in accordance with [CENELEC EN50360] [IEC standard PT62209-1].
Head SAR UMTS900, Wi-Fi, Blueto oth 0.85 W/kg
Body-worn SAR UMTS900, Wi-Fi, Bluetooth 0.44 W/kg
European Union directives conformance
statement
EUcon formance
The following CE compliance informationis applicable to Motorola mobile devices that carry one
of the foll owing CE marks:
Hereby, Motorola declares that this product is in compliance with:
• The essential requirements and other relevant provisions of directive 1999/5/EC
• All other relevant EU directives
For products that support Wi-Fi 802.11a (as defined in your product information): This device is
restricted to indoor use when operating in the 5.15 to 5.25 GHz (802.11a) Wi-Fi frequency band.
The following gives an example of a typical Product approval number:
You can view your product's Declaration of Conformity (DoC) to Directive 1999/5/EC (to R&TTE
Directive) at
www.motorola.com/rtte (in English only). To find your DoC, enter the Product
approval number from your product's label in the "Search"bar on the website.
0168
0168
0168
Product
approval
number
FCC notice to users
FCCno tice
The following s tatement applies to all product s that bear the FCC logo a nd/or FCC ID on
the product label.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. See 47 CFR Sec. 15.105(b). These limits are designed to
provide reasonable protection against harmful interference in a residential installation.This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) thisdevice may not cause harmful interference,and (2) this device must accept any
interference received, including interference that may cause undesired operation. See 47 CFR
Sec. 15.19(a)(3).
Motorola has not approved any changes or modifications to this device by the user. Any changes
or modifications could void the user’s authority to operate the equipment. See 47 CFR Sec. 15.21.
For products that support Wi-Fi 802.11a (as defined in product information): In the United States,
do not use your device outdoors while connected to an 802.11aWi-Fi network. The FCC prohibits
such outdoor use since frequencies 5.15-5.25 GHz can cause interference with Mobile Satellite
Services (MSS). Public Wi-Fi access points in this range are optimised for indoor use.
Software notices
Softwarenotices
Warning against unloc king the bootloader or alte ring a product's operatin g system
software:
Motorola strongly recommends against altering a product's operating system, which
includes unlocking the bootloader, rooting a device or running any operating software other than
the approved versions issued by Motorola and its partners. Such alterations may permanently
damage your product, cause your product to be unsafe and/or causey our product to malfunction.
In such cases, neither the product nor any damage resulting therefrom will be covered by
warranty.
Important FCC inf ormation: You must not make or enable any changes to the product that will
impact its FCC grant of equipment authorisation. The FCC grant is based on the product's
emission, modulation and transmission characteristics, including: power levels, operating
frequencies and bandwidths,SAR leve ls, duty-cycle, transmission modes (e.g., CDMA, GSM), and
intended method of using the product (e.g., how the product is held or used in proximity to the
body). A change to any of these factors will invalidate the FCC grant. It is illegal to operate a
transmitting product without a valid grant.
Copyright & trademarks
Copyright & trademarks
Certain features, services and applications are network-dependent and may not be available in
all areas; additional terms,conditions and/or charges may apply. Contact your serviceprovider for
details.
All features, functionality and other product specifications, as well as the information contained
in this guide, are based upon the latest available information and believed to be accurate at the
time of printing. Motorola reserves the right to change or modifyany information or specifications
without notice or obligation.
Note: The images in this guide are examples only.
MOTOROLA and the Stylised M Logo are trademarks or registered trademarks of Motorola
Trademark Holdings, LLC. Google, the Google logo, Google+, Google Maps, Google Talk, Google
Latitude, Gmail, YouTube, Google Drive, Google Finance, Google Local, Google Maps Navigation
Beta, Google Calendar, Google Play, Android Beam, Android, and other marks are trademarks of
Google, Inc. Intel Inside and the Intel Inside logo are trademarks of Intel Corporation in the U.S.
and/or other countries. All other product or service names are the property of their respective
owners.
© 2012 Motorola Mobility LLC. All rights reserved.
Manual number: 68017174007
RAZRi.UMTS.EMARA.ASIA.NGSG.fm Page 2 Thursday, September 6, 2012 5:14 PM
