Motorola iDEN i580 User manual

Motorola
iDEN
Digital Multi-service Data-capable Phone
i580 Phone User’s Guide
@NNTN6777A@
NNTN6777A

IMPORTANT NOTICE: PLEASE READ
PRIOR TO USING YOUR PHONE
The SIM card provided in this kit is intended for use with
the phone provided in this package.
Loss of certain features will result when using a SIM
card from one of the following models: i30sx, i35s,
i50sx, i55sr, i58s, i60c, i80s, i85s, i88s, i90c, i95cl
series, and the i2000 series.
For more information on SIM card compatibility, go to
www.motorola.com/iden/support.
Defects or damage to your Motorola phone that result
from the use of non-Motorola branded or certified
Accessories, including but not limited to replacement
housings and or other peripheral accessories, are
excluded from warranty coverage. Please refer to the
text of Motorola's Limited One Year warranty located in
this user’s guide for complete details.

i
Contents
Getting Started........................................... 1
Locating Your SIM Card....................................3
Battery...............................................................3
Activating Service..............................................6
Powering On and Off.........................................6
Phone Programming .........................................7
Finding Your Phone Number.............................7
Phone Basics ....................................................8
Using a Memory Card .....................................12
SIM Card Security...........................................13
Antenna...........................................................17
Accessories.....................................................18
For More Information.......................................18
Making Calls............................................. 19
Phone Calls.....................................................19
Private Calls....................................................19
Receiving Calls................................................20
Choosing a Number to Call.............................21
Missed Phone Calls.........................................22
Using Speakerphone.......................................22
Using Mute......................................................23
Making Emergency Phone Calls.....................23
MOTOtalkTM .......................................................... 24
Switching to MOTOtalk ...................................24
Exiting MOTOtalk............................................25
Channels and Codes.......................................25
Private MOTOtalk Calls...................................27
Making Emergency Calls While in MOTOtalkTM
Mode...........................................................28
Setup Options .................................................28
Call Alerts..................................................30
Sending Call Alerts..........................................30
Receiving Call Alerts.......................................30
Using the Call Alert Queue..............................30
Recent Calls..............................................32
Viewing the Recent Calls List..........................32
Calls and Call Alerts........................................32
PTX Items in Private Calls ..............................33
Storing Items to Contacts................................36
Deleting Items.................................................37

ii
Making Calls From the Recent Calls List ........37
Contacts ................................................... 39
Accessing Contacts.........................................40
Creating Entries...............................................40
Storing Numbers Faster..................................42
Editing Entries.................................................43
Viewing Entries................................................43
Deleting Entries...............................................45
Checking Capacity ..........................................46
Creating Pauses and Waits.............................46
International Numbers.....................................46
Making Calls From Contacts...........................47
Accessing Contacts with GSM Phones...........48
Call Forwarding........................................ 49
Forwarding All Calls ........................................49
Turning Off Call Forwarding............................49
Forwarding Missed Calls.................................50
Viewing Call Forwarding Settings....................50
Advanced Calling Features..................... 51
Call Waiting.....................................................51
Switching Between Calls.................................51
Putting a Call on Hold .....................................52
Calling 2 People..............................................52
Creating Pauses and Waits While Dialing.......53
Making International Calls...............................53
Setting Flip Actions .........................................53
Call Timers......................................................54
Using Your Phone as a Modem ......................55
Features for the Hearing Impaired ..................56
Group Calls and Selective Dynamic Group
Calls .......................................................59
Group Calls .....................................................59
Selective Dynamic Group (SDG) Calls ...........61
Memo.........................................................66
Ring Tones................................................67
Setting Your Phone to Vibrate.........................67
Ring and Vibrate .............................................68
Assigning Ring Tones to Contacts..................68
Viewing Ring Tone Assignments ....................69
Downloading More Ring Tones.......................69
About DRM Ring Tones ..................................69

iii
Managing Memory...........................................69
Deleting Custom Ring Tones ..........................70
Entering Text............................................ 71
Using Word Mode............................................71
Special Function Keys.....................................72
Messages ................................................. 73
Message Notifications.....................................73
Message Center..............................................74
Voice Mail Messages............................... 75
Receiving a Message......................................75
Accessing Voice Mail From
the Message Center ...................................75
Sending Unanswered Calls to Voice Mail .......75
MOSMS Messages................................... 76
Setting Up........................................................76
Receiving a Message......................................76
Reading from the Message Center .................77
Creating and Sending Messages....................77
Sorting Messages............................................80
Managing Memory...........................................80
Using PTX Features .................................81
PTX Icons........................................................81
Send Messages ..............................................82
Send Pictures..................................................84
Send Datebook Events ...................................87
Send My Info...................................................90
Send Contact Information ...............................91
PT Manager...............................................93
Accessing PTX Features
From PT Manager.......................................93
Turning PTX Features On and Off ..................93
Changing the Quick Notes List........................93
Setting One Touch PTT ..................................94
Setting My Info Sending Option ......................95
Using Quick PTT.............................................96
My Info.......................................................97
Viewing My Info...............................................97
Editing My Info ................................................97
Datebook...................................................99
Viewing Datebook ...........................................99
Creating Events.............................................100

iv
Editing Events ...............................................102
Deleting Events.............................................102
Receiving Reminders....................................103
Making Calls From Datebook and Datebook
Reminders ................................................103
Customizing Datebook Setup........................104
Using a Memory Card............................ 106
Ensuring Files on the Memory Card Are
Compatible With Your Phone ...................106
Using the Memory Card With
Your Phone...............................................108
Using the Memory Card With
Your Computer .........................................110
Memory Cards Compatible
With Your Phone.......................................112
Camera ................................................... 113
Accessing the Camera..................................113
Taking Pictures..............................................113
More Actions for Captured Pictures ..............115
Recording Videos..........................................116
Changing Storage Preference.......................117
Accessing the Media Center .........................118
Customizing the Camera...............................118
Managing Memory ........................................119
Media Center...........................................120
Viewing the Media Center.............................120
Forward Locked Items...................................122
DRM Items ....................................................123
Pictures.........................................................123
Videos...........................................................124
Audio Recordings..........................................125
Renaming Items............................................126
Locking Items................................................126
Deleting Items...............................................127
Copying and Moving Items............................127
Changing Storage Preference.......................128
Accessing the Camera..................................128
Accessing the Audio Player ..........................128
Managing Memory ........................................129
Audio Player ...........................................130
Accessing the Audio Player ..........................130
Exiting the Audio Player................................130
Playing Audio Files........................................130

v
Adjusting the Volume ....................................131
How Your Audio Files Are Organized............131
Searching By First Letter...............................132
Playing a List and Using Repeat and Shuffle132
Working With Playlists...................................133
Deleting Audio Files ......................................136
DRM Items ....................................................137
Setting Audio and Visual Options..................137
Digital Rights Management................... 139
Installing Items ..............................................139
Understanding DRM Status Icons.................139
Sharing Items................................................139
Managing DRM Items....................................140
Java Applications.................................. 143
Installing Applications....................................143
Running Applications.....................................143
Suspending Applications...............................143
Resuming Applications..................................144
Ending Applications.......................................144
Downloading Applications.............................144
Deleting Applications.....................................145
Managing Memory ........................................145
Shortcuts on the Main Menu .........................145
Java Applications and GPS Enabled ............146
Bluetooth®..............................................149
Understanding Bluetooth®Access Settings..149
Setting Your Phone for Bluetooth®................150
Accessing Bluetooth®...................................151
Making a Bluetooth®Connection..................151
Setting Device Details...................................154
Sending Contacts, Datebook Events and
Pictures.....................................................155
Receiving Items.............................................156
GPS Enabled...........................................157
IMPORTANT: Things to Keep in Mind ..........157
Making an Emergency Call ...........................159
Viewing Your Approximate Location.............160
Enhancing GPS Performance.......................161
Updating Satellite Almanac Data ..................162
Setting Privacy Options.................................163
Using GPS with Map Software......................164

vi
Voice Records........................................ 167
Viewing Voice Records .................................167
Creating Voice Records ................................167
Playing Voice Records..................................168
Labeling Voice Records ................................168
Locking Voice Records..................................168
Deleting Voice Records.................................169
Managing Memory.........................................169
Customizing Your Phone...................... 170
Setting the Volume........................................170
Setting Your Phone to Vibrate.......................170
Changing the Look of Your Phone................170
Temporarily Turning Off Transmissions........172
Using Settings...............................................172
Profiles ................................................... 178
Viewing Profiles.............................................178
Switching Profiles..........................................178
Surveillance Profile........................................179
Car Profile .....................................................179
How Changing Settings Affects Profiles........179
Temporary Profiles........................................180
Creating Profiles............................................181
Editing Profiles ..............................................181
Deleting Profiles............................................181
Setting Call Filtering......................................181
Shortcuts.................................................183
Creating a Shortcut.......................................183
Using a Shortcut............................................183
Editing a Shortcut..........................................184
Deleting Shortcuts.........................................184
Using a Headset .....................................185
Using a Bluetooth Headset ...........................185
Attaching a Headset......................................185
Using a Remote PTT Button .........................185
Understanding Status Messages..........187
Safety and General Information............190
RF Operational Characteristics.....................190
Portable Radio Product Operation and EME
Exposure...................................................190
Electromagnetic Interference/Compatibility...193
Medical Devices............................................193

vii
Operational Warnings....................................194
Operational Cautions.....................................195
Accessory Safety Information........................196
Hearing Aid Compatibility..................... 198
Caring for the Environment
by Recycling....................................... 200
Disposal of your Mobile Telephone and
Accessories ..............................................200
MOTOROLA LIMITED WARRANTY ...... 201
Limited Warranty
Motorola Communication Products
(International)..................................... 205
Patent and Trademark Information...... 209
Index ....................................................... 210
Driving Safety Tips................................ 218

viii

ix
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola, Inc.
Address: 8000 West Sunrise Boulevard
Plantation, FL 33322 USA
Phone Number: 1 [phone]
Hereby declares that the product:
Product Name: i580
Model Number: H83XAH6RR4AN
Conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a),
15.107(d) and section 15.109(a)
Class B Digital Device
As a personal computer peripheral, this device
complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.

1
Getting Started
volume
controls
stereo
headset jack
retractable
antenna
mirror
memory
card slot
external
display
PTT button
camera
lens
spotlight
accessory
connector
light sensor
camera key
microphone
power
button
speaker speaker

2
Getting Started
To start using your i580 phone:
•Make sure your SIM card is in place.
•Charge the battery.
•Activate your service.
•Enable over-the-air security if you are prompted
to.
Navigation key — press the arrows to
scroll through menus and lists.
OOK key — selects highlighted item;
answers calls.
mMenu key — accesses context-sensitive
menus.
AOption key — selects the option
appearing above it on the display.
sSend key — places phone calls.
eEnd key — ends phone calls; returns to
idle screen.
t Acts like swhen the flip is closed; turns
speaker on; used with voice names and
voice records.
. Acts like ewhen the flip is closed;
accesses recent calls; sends incoming
calls to voice mail.
cCamera key — accesses camera;
captures picture.

3
Locating Your SIM Card
Locating Your SIM Card
Your SIM (Subscriber Identity Module) card is a
small piece of plastic located in the SIM card
holder in the back of your phone, underneath the
battery.
If your SIM card is not in the SIM card holder, it
may be in the box your phone came in, attached to
a piece of plastic about the size of a credit card. If
this is the case, carefully detach your SIM card
from the surrounding plastic and insert it as
described in “Inserting Your SIM Card” on page 15.
If there is no SIM card in your phone or the box,
contact your service provider.
Battery
Removing the Battery Door
1Make sure the phone is powered off. See
“Powering On and Off” on page 6.
2Slide the release button back until it releases the
battery door.
.
3Allow the battery door to pop up, slide it forward,
and remove it from the back of your phone.
SIM card
release
button

4
Getting Started
Inserting the Battery
Your phone comes with a High Performance
Lithium Ion Battery.
1Remove the battery door.
2Insert the battery into the battery area. Press the
battery down to secure it.
3Replace the battery door and press it gently until
you hear a click.
Charging the Battery
1Plug the charger into an electrical outlet.
2Open the connector cover.
3Plug the other end of the charger into the
accessory connector.
connector
cover

5
Battery
4 Charger Attached or Device Attached appears
on the internal display.
Tip: To remove the charger from the accessory
connector: Press the buttons on the sides
of the plug. Pull the plug straight out.
5If you have purchased optional batteries or
chargers, see “Charging Times”.
Charging Times
See your battery and charger to determine the
appropriate charging time.
For best results, charge the batteries within the
temperature range of 50°F to 104°F (10°C to
40°C).
Prolonged charging is not recommended.
Removing the Battery
1With the phone powered off, remove the battery
door.
2Remove the battery by pushing it toward the
antenna and lifting it out.
Battery Use and Maintenance
•The Motorola iDEN Approved Lithium Ion
chargers provide optimum performance. Other
chargers may not fully charge the iDEN Lithium
Ion battery or may yield a reduced number of
lifetime charge cycles.
•Extreme temperatures degrade battery
performance. Do not store the battery where
temperatures exceed 140°F (60°C) or fall below
-4°F (-20°C).
Battery Charger
Rapid Mid-Rate
High
Performance 2 hours 5 hours
Maximum
Capacity 3 hours 6 hours

6
Getting Started
•Lithium Ion batteries have a self discharge rate
and without use, lose about 1% of their charge
per day.
•The battery capacity is degraded if the battery is
stored for long periods while fully charged. If
long term storage is required, store at half
capacity.
Activating Service
The first time you power on your phone, you must
be in your local calling area. This activates your
service.
Powering On and Off
The first time you power your phone on, a screen
may appear asking you to update your browser
information. This means you must enable security.
To power your phone on:
1Open the flip.
2Press p.
Note: When powering on, if you press pfor
more than 5 seconds, you will turn off
calls and other transmissions. See
“Temporarily Turning Off Transmissions”
on page 172.
To power your phone off:
1Open the flip.
2Press and hold p.
When You Power On For the First
Time
If the Enter SIM PIN Code screen appears, enter
your SIM PIN. See “Entering the PIN” on page 13.
Press Aunder Ok.
When you receive your phone, the SIM PIN is
0000. Change your PIN to prevent fraudulent use
of the SIM card (see “Changing the PIN” on page
13).
As your phone connects to the network, you will
see a welcome message and a connecting
message. When the idle screen appears, the
phone is ready to use.
