Quick Start Guide
1
Congratulations on your purchase of the Motorola
XT502. This Quick Start Guide will help you go
through the basic features of your phone to get
you started.
For more detailed information, see the User
Guide which you can download from
www.motorola.com/support.
What’s in the box?
Your package comes with the following items. If
any are missing, please contact your retailer.
Important: A headset has been provided for
use with your mobile phone. This
headset is the only model headset
that Motorola warrants to operate
with your phone.
Motorola
XT502
AC Adapter Battery
Quick Start
Guide Headset
L
R
F-Series_911_QSG_EN.book Page 1 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
2
Your phone
Home
Call
Trackball
Flash
3.0 Megapixel
camera
Volume:
Slide up/
down to
increase/
decrease
volume
Shutter
Power
Speaker
Microphone
End
Back
Touch
screen
Earpiece
Micro USB
connector
Headset jack
Strap
holes
Browser
Menu
Back cover
F-Series_911_QSG_EN.book Page 2 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
3
Installing SIM card, battery
and memory card
Caution: before assembling, charging or using
your phone for the first time, please read the
important legal and safety information at the back
of this guide.
1. Open the back cover.
2. If the battery is inserted,
lift and remove the
battery.
3. Insert the SIM card.
Make sure the gold
contacts are facing down
and the cut-off corner is
facing towards the battery
slot.
1
2
F-Series_911_QSG_EN.book Page 3 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
4
4. Insert the memory card
with the gold contacts
facing down.
5. Push the memory card
until it clicks into place.
Note:
• To remove the memory card, push it down
to eject it from the slot.
• Do not remove the memory card while the
phone is turned on. Sudden removal of
the memory card may cause data loss or
unpredictable system crashes.
6. Insert the battery. Make
sure the contacts of the
battery are aligned with
the connectors on the
battery slot.
7. Secure the hooks on the
back cover with
designated holes on the
phone and close the back
cover.
1
2
F-Series_911_QSG_EN.book Page 4 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
5
Charging the battery
1. Open the micro USB
connector cover.
2. Connect the USB cable
to the phone.
3. Plug the USB Charger
into a wall outlet to start
charging.
Note: to fully charge battery, charge it for
3 hours. Battery life will vary
depending on the applications used.
Note: the battery can also be charged
when you connect your phone to a
computer using the USB cable.
LED indicators
Your phone has two LED indicators: green and
red.
LED Location Indication
Green
(solid)
Call key Battery is fully
charged.
Red
(solid)
End key Battery is
charging.
Introduction.fm Page 5 Wednesday, June 16, 2010 2:48 PM

Quick Start Guide
6
First start up
After installing the SIM card and charging the
battery, you are now ready to turn on the phone -
press and hold the power key on the top of the
phone.
The Home screen
From the Home screen, you can quickly access
common features and view notifications of missed
calls, receive messages and check connection
status.
Tap the Application Drawer to open the
application menu.
For more information about the home screen,
please refer to the user guide.
Status icons
Application
Drawer
Tap an icon to
open it.
Flick left/right
to show more
home screen
panels.
Notifications - Flick
down to display
F-Series_911_QSG_EN.book Page 6 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
7
Making your first call
On the Home screen, tap Dialler.
To make a call
1. Enter the phone
number using the
keypad.
2. Tip: tap to erase
a wrong number. Tap
and hold to erase
the entire number.
3. Press Call or tap the
number to dial.
4. To end the call, press
End.
To answer a call
To answer a call, press Call.
Entering information
You can enter information using the on-screen
keyboard.
To use the on-screen keyboard
When an application requires text input, tap the
input box to display the on-screen keyboard.
F-Series_911_QSG_EN.book Page 7 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
8
1. Tap the input box to
display the on-screen
keyboard.
Note: to toggle
between upper and
lowercase, tap . To
display the numeric
and the symbols
keyboard, tap .
Tap to toggle
back.
2. Tap keys on the keyboard to enter
characters.
Note: if word completion is activated, the
screen displays a list of suggested words
as you type the characters.
F-Series_911_QSG_EN.book Page 8 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
9
Contacts
To add a contact
1. On the Home screen,
tap Contacts.
2. Tap Menu > New >
Create contact.
3. Enter contact
information, such as
name, phone
number, email
address etc. Tap
Done to save the
contact or tap Revert
to exit without saving
the changes.
Note: Your SIM card only stores the name
and the phone number. To store more
information, such as an email address,
create a new contact on the phone.
To import contacts
1. On the Home screen, tap Contacts.
2. Tap Menu > More > Import Contacts.
3. Select to import contacts from SIM card or
SD card.
4. Select contacts to import or tap Menu again
to select Import all.
F-Series_911_QSG_EN.book Page 9 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
10
Sending a text message
1. On the Home screen,
tap Messaging.
2. Tap New message.
3. In the To field, enter
the phone number or
choose a contact.
4. Type message in the
Type to compose
field.
5. Tap Send.
Sending a
multimedia message
A multimedia message (MMS) can contain
graphic and audio files.
1. On the Home screen, tap Messaging.
2. Tap New message > Menu > Add sbj.
3. The message automatically converts to an
MMS message.
4. Enter the phone number or email address
of the recipient in the To field, then type the
Subject.
5. To add components, tap Menu > Attach to
attach pictures or videos.
6. Tap Send.
F-Series_911_QSG_EN.book Page 10 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
11
Sending a voice MMS
1. On the Home screen,
tap Messaging.
2. Tap New message >
Menu > Attach >
Record audio.
3. Tap to record
your message.
4. Tap to stop
recording.
• Tap to play the
recording.
• Tap Save to store the recording.
• Tap Discard to delete the recording.
• After storing the recording, you can also
tap to Play, Replace and Remove the
recording.
5. Enter the phone number in the To field. The
voice message can be sent to up to 20
recipients.
6. Compose your message and tap Send.
Setting up Wi-Fi™
Connect to a wireless network to browse Internet.
1. On the Home screen, tap > Settings.
F-Series_911_QSG_EN.book Page 11 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
12
2. Tap Wireless controls to access the
Wireless manager.
3. Tap Wi-Fi to activate.
4. Tap Wi-Fi settings > Network notification
to start detecting networks. The available
networks will then be listed.
5. Tap Add Wi-Fi network to add a
connection.
Note: Connecting to a secured network
will prompt for the password. Enter the
password then tap Connect.
Setting up an email account
1. On the Home screen,
tap > Email >
Set up email.
2. Choose from existing
types of email (e.g.
Yahoo, GmailTM,
Microsoft Exchange,
etc).
3. Enter your email
address and
Password. Check
Save password, then
tap Next.
4. The phone will automatically retrieve the
email settings.
F-Series_911_QSG_EN.book Page 12 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
13
Note: If successful, the email setup wizard
displays a successful message, tap Next. If
email settings are not found, tap Manual
setup.
5. Enter Your name and the Account display
name, then tap Next.
6. Tap Done.
Sending and receiving
emails
Composing and sending emails
1. On the Home screen,
tap > Email,
then tap an email
account.
2. Tap Menu >
Compose.
3. In the To field, enter
the recipient’s email
address.
TIP: to add recipients
from Contacts, tap To
or tap Menu > Add
Recipient, then select the names.
4. Enter Subject.
5. Compose your email.
6. Tap Send.
F-Series_911_QSG_EN.book Page 13 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
14
Adding attachments to an email
message
1. Tap Menu > Attach.
2. Select items to attach.
Receiving emails
Emails are automatically received in your Inbox
folder when your phone is connected to a
wireless network.
1. On the Home screen, tap > Email,
then tap an email account.
2. Tap Menu > Send/Receive.
Using the browser
To open a web page
1. Tap > Browser.
2. Tap Menu > Go.
3. Tap the address bar.
4. Type the URL then tap .
F-Series_911_QSG_EN.book Page 14 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
15
Tap Menu to see more options.
To quickly browse Internet from the
Home screen
From the Home screen, you can browse internet
right away with GoogleTM search.
1. Tap the Google search
widget, then type text to search.
2. Tap .
Touch the web
page and
drag/flick it to
scroll.
F-Series_911_QSG_EN.book Page 15 Tuesday, June 15, 2010 1:45 PM

Quick Start Guide
16
Using Bluetooth®
1. On the Home screen,
tap > Settings.
2. Tap Wireless
controls.
3. Tap Bluetooth to
activate.
4. To search for a new
device, tap Bluetooth
settings > Scan for
devices.
5. Tap the detected
device to connect.
6. Enter the Passcode to start pairing, then
tap Next.
Note: the passcode you enter on your
phone must be the same passcode to be
entered on the other bluetooth device.
7. Tap Done.
Taking photos and videos
This phone is equipped with a 3.0 megapixel
camera to take photos and videos.
F-Series_911_QSG_EN.book Page 16 Tuesday, June 15, 2010 1:45 PM
