Motorola W230 Assembly instructions

getting to know your phone
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office.
© Motorola, Inc. 2008
Certain mobile phone features are dependent on the capabilities and settings of your service
provider’s network. Additionally, certain features may not be activated by your service provider,
and/or the provider’s network settings may limit the feature’s functionality. Always contact your
service provider about feature availability and functionality. All features, functionality, and other
product specifications, as well as the information contained in this tutorial, are based on the
latest available information and believed to be accurate at the time of publication. Motorola
reserves the right to change or modify any information or specifications without notice or
obligation.
Service dependent features may vary. Screen images may be
simulated or enhanced to show detail.
Note: Your phone may not appear exactly as the phone image
above, however, all key locations, sequences, and functions remain
the same.

make, end, and answer calls
1.
To make a call:
On the home screen, enter a number and
press N.
Tip: Press DELETE to delete the last
number. Press STORE, and then DONE to
add the number to your contacts.
2.
To end a call:
Press O.
3.
To answer a call:
When your phone rings or vibrates, press
N.
Tip: To answer with any key, go to main
menu and select Settings >In Call Setup.
Set Answer Options to Multi-key On.

save and call contacts
You can save up to 500 contacts!
1.
To save a contact:
On the home screen, enter the number and
press Store.
2.
Enter the contact details.
When you are finished press DONE.
3.
To call a contact:
On the home screen, press s> Contacts.
4.
Select the contact and press N.
Tip: To find contacts in the list, enter the first
letters of the contact.
Tip:
To call a contact using the speed dial
number, press and hold the corresponding
number, 1-9.

send a text message
Your phone can store up to 500 SMS messages!
1.
On the home screen, press s> Messages >
Create.
2.
Select the message type: SMS/EMS or
MMS.
3.
Enter your message and press OK.
Tip: In the text entry screen, press #to
switch text modes.
4.
Scroll to the recipient(s) and press ADD. Press
SEND to send the message.

use FM radio
1.
Insert a 2.5 mm headset into your
phone.
Note: The FM radio works only
when the headset is plugged in.
2.
On the home screen, press s> Multimedia >
FM Radio.
•To tune in a station, press Sleft or right.
•To scan stations, press & hold Sleft or right.
•To adjust volume, press Sup or down.
•To turn radio off, unplug headset.
•To play the radio through the speaker or
headset, press *.
3.
To set radio presets:
Tune in a station, then press and hold a
number 1-9.
To play a preset station, press its number.
Tip: To use your phone while the radio is
playing, press Options > Hide.
FM radio tips:
•To record FM radio clips, press Options > Record. Press STOP to stop recording. Clips are stored in phone memory.
To play clips, from main menu press Multimedia > Music Library > s> Switch Storage Devices > Phone Memory > clip.
•To use FM radio as an alarm, from main menu press Extras (or Office Tools) > Alarm Clock > New Alarm. Set Alert to Radio.
To use FM radio clip as an alarm, set Alert to Ring > Preloaded and downloaded media files > clip.
•To share favorite FM stations with friends, press Options > Send Station Info > SMS/EMS or MMS > OK. Select recipient, press
ADD, then press SEND.

transfer files with a USB cable
Note: Before you connect your phone and PC for the first time, download the USB driver onto your PC, at
http://www.motorola.com/support/W230.
1.
Connect your phone and PC using a USB
cable.
2.
Use the My Computer window to find
Removable Device.
Drag and drop files such as music from your
PC to your phone.
3.
When finished, remove the phone from your
PC by using the Safely Remove Hardware
icon at the bottom of your PC screen. Then
disconnect the USB cable.

play music on my phone
To use the music player, insert a microSD
memory card, an optional accessory.
The music player supports MP3, MIDI,
iMelody, and AMR file formats.
1.
On the home screen, press s> Multimedia
> Music Library.
2.
Select a song or All Songs and press
PLAY.
To control music:
|| pause or fplay
z next song; hold for fast forward
xprevious song; hold for rewind
Tip:
To switch between music stored on the memory card and music stored on your phone
memory, press s> Multimedia > Music Library s> Switch Storage Devices.

customize my phone
1.
To create home screen shortcuts, press
s> Personalise > Home Screen >
Home Keys.
Select Up, Down, Left, Right, or a soft
key and press Change. Select the feature
you want to assign.
2.
To change the order of the main menu, press
s> Personalise > Main Menu > Reorder.
Scroll to the item you want to move and
press Grab. Then scroll to the destination
location and press Insert > Done.
3.
To change the wallpaper or screen saver,
press s> Personalise > Wallpaper or
Screen Saver.
4.
To personalize your ring style, press
s> Settings > Ring Style > Style.
Scroll to the style, press s > Back.
Select style Detail, and customize
the various rings.

access the web
This feature is network, SIM card, or subscription dependent
and may not be available in all areas. Contact your service
provider for more information.
1.
To launch the web browser, press s >
WebAccess > Start Browser.
2.
To download a picture, sound, or MMS
template from a web page, go to the media
file page, highlight the file, then press
SELECT > STORE.
