WA9901 - RFID MODULE UHF LINEAR (NA) ENDCAP
H/W INSTALLATION SHEET
Important: All Approval and safety information is outlined in the ‘WORKABOUTPRO4
Regulatory & Warranty Guide –part number 8000296 provided with each
WORKABOUTPRO4.
Warning:The WORKABOUTPRO4 with the RFID option must not be held closer than 20 cm from
the rest of the body. This product must not be used in a holster or on a belt-clip. RFID cannot be
used in co-transmission with WAN module.

© 2014 Motorola Solutions, Inc. All Rights Reserved.
Sept 10, 2014
8073681 C
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are the property of their respective owners..
1. Product Description
Easily installable expansion modules for the WORKABOUT PRO4 allow you to customise this hand-held
to meet your specific mobile computing requirements. This chapter outlines how to install the NA UHF
Linear RFID Module.
The RFID MODULE UHF LINEAR (WA9901) kit is based on the Sailfish UHF module from
MOTOROLA Inc. (Model: 21-121559). It is made of 4 parts:
ASSY MODULE UHF WAP4 NA
ASSY ANTENNA LINEAR NA WAP4
INSTRUCTION SHEET WAP4 UHF LINEAR NA
LABELS FCC WAP4 UHF LINEAR VARIANT
Figure 1-1 ASSY MODULE UHF WAP4 NA Figure 1-2 ASSY ANTENNA LINEAR NA WAP4
Figure 1-4 LABELS FCC WAP4
UHF LINEAR VARIANT
Figure 1-3 INSTRUCTION SHEET WAP4 UHF LINEAR NA

© 2014 Motorola Solutions, Inc. All Rights Reserved.
Sept 10, 2014
8073681 C
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are the property of their respective owners..
2. Product Installation
Before installing a module in the WORKABOUT PRO4, all power sources must be turned off.
Remove the battery. If your unit is using AC power, disconnect it.
Figure 2-1 Battery location
With the power shut down, you can now install the NA RFID Module UHF Linear.
Remove the existing endcap and pod or backplate
Figure 2-2 WAP4 Disassembled

© 2014 Motorola Solutions, Inc. All Rights Reserved.
Sept 10, 2014
8073681 C
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are the property of their respective owners..
Slide the RFID Module inside the back opening
Figure 2-3 RFID Module Assembly
Drive the 4 screws that fix the RFID module on WAP4 frame
Figure 2-4 RFID Module Assembly

© 2014 Motorola Solutions, Inc. All Rights Reserved.
Sept 10, 2014
8073681 C
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are the property of their respective owners..
Place the antenna in the right slot:
For WAP4 with WLAN only (7528XUHFE), antenna must be placed in the bottom slot
Figure 2-5 Antenna position for WLAN only WAP4 version
For WAP4 with WWAN (7528XPUHFN), antenna must be placed in the middle slot
Figure 2-6 Antenna position for WWAN WAP4 version
Antenna should be correctly inserted in the rubber
Figure 2-7 Right insertion (antenna is pushed totally in the rubber)
Figure 2-8 Wrong insertion (antenna comes out of the rubber)

© 2014 Motorola Solutions, Inc. All Rights Reserved.
Sept 10, 2014
8073681 C
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are the property of their respective owners..
Drive the 2 self-tapping screws to fix the antenna stopper
Figure 2-9 Antenna stopper assembly
Plug the U.FL antenna connector to the Sailfish module.
Warning: Make sure you use the proper RF port (right side of the Sailfish)
Figure 2-5 Linear antenna Assembly

© 2014 Motorola Solutions, Inc. All Rights Reserved.
Sept 10, 2014
8073681 C
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are the property of their respective owners..
Reassemble the pod or backplate and the endcap
Figure 2-6 Final Assembly
IF the model number of WorkAbout Pro4 is 7528XUHFA (WWAN version) put this label:
Figure 2-7 FCC/IC Label for WWAN variant
IF the model number of WorkAbout Pro4 is 7528XPUHFA (WLAN only) put this label type:
Figure 2-8 FCC/IC Label for WLAN variant

© 2014 Motorola Solutions, Inc. All Rights Reserved.
Sept 10, 2014
8073681 C
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are the property of their respective owners..
Stick the label in the location following depends on WorkAbout Pro4 variant:
Figure 2-9 WorkAbout Pro4 Long Alphanumeric Keyboard Figure 2-10 WorkAbout Pro4 Short Numeric Keyboard

© 2014 Motorola Solutions, Inc. All Rights Reserved.
Sept 10, 2014
8073681 C
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are the property of their respective owners..
3. Software installation:
To get current driver for WorkAbout Pro4, go to the website at:
http://community.psion.com/downloads/developer_sdkhdk/m/rfid_sdk/
Copy and install the latest CAB file named “WAP4_WM_RFID_UHF”.
Figure 3-1 Driver CAB file Figure 3-2 Driver sucFCC/ICssfully Installed
After installation, select RFID Demo in the Start menu to start the RFID sample application.
Figure 3-3 RFID demo Icon Figure 3-4 RFID Sample Application Window

© 2014 Motorola Solutions, Inc. All Rights Reserved.
Sept 10, 2014
8073681 C
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are the property of their respective owners..
To read the ID of TAG, press the Start Reading button ID Button. Put the TAG in front of the
antenna. Tap Stop Reading to terminate tag reading.
Figure 3-5 ID Tag Reading
For detailed instructions on how to use the RFID demo application, please visit
http://www.motorolasolutions.com and download ‘RFID Demo Applications User Guide (P/N 72E-
160038-01)’
4. Reading area:
This area depends on the TAG type, TAG packaging, Tag position and environment (metallic
or not).
Figure 4-1 Reading area
Reading Area
Tag

© 2014 Motorola Solutions, Inc. All Rights Reserved.
Sept 10, 2014
8073681 C
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are the property of their respective owners..
RFID MODULE UHF LINEAR NA ENDCAP
RFID Regulatory information
IMPORTANT NOTE FOR NORTH AMERICA:
The RFID must not be used whilst the host WORKABOUTPRO4 is being powered by the ac/dc
adaptor.
FCC Information to Users:
Radiation Exposure Compliance
This product complies with the FCC RF exposure limits for an uncontrolled environment. For
continued compliance, the product must not be held closer than 20 cm from the rest of the body.
This product must not be used in a holster or on a belt-clip.
The host WORKABOUTPRO4 is configured to prevent WAN and RFID to be in co-transmission. The
user cannot activate both at the same time.
Federal Communication Commission Interference Statement.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2)
THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY
CAUSE UNDESIRED OPERATION.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
Emissions Information for Canada:
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

© 2014 Motorola Solutions, Inc. All Rights Reserved.
Sept 10, 2014
8073681 C
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are the property of their respective owners..
This device complies with Industry Canada license-exempt RSS standard(s). Operation is Subject to
the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement
