Motorola MVME712-10 User manual

MVME712-10
Transition Module
User’s Manual
(MVME712-10/D1)

Notice
While reasonable efforts have been made to assure the accuracy of this document,
Motorola, Inc. assumes no liability resulting from any omissions in this document, or
from the use of the information obtained therein. Motorola reserves the right to revise
this document and to make changes from time to time in the content hereof without
obligation of Motorola to notify any person of such revision or changes.
No part of this material may be reproduced or copied in any tangible medium, or
stored in a retrieval system, or transmitted in any form, or by any means, radio,
electronic, mechanical, photocopying, recording or facsimile, or otherwise, without the
prior written permission of Motorola, Inc.
It is possible that this publication may contain reference to, or information about
Motorola products (machines and programs), programming, or services that are not
announced in your country. Such references or information must not be construed to
mean that Motorola intends to announce such Motorola products, programming, or
services in your country.
Restricted Rights Legend
If the documentation contained herein is supplied, directly or indirectly, to the U.S.
Government, the following notice shall apply unless otherwise agreed to in writing by
Motorola, Inc.
Use, duplication, or disclosure by the Government is subject to restrictions as set forth
in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software
clause at DFARS 252.227-7013.
Motorola, Inc.
Computer Group
2900 South Diablo Way
Tempe, Arizona 85282

Safety Summary
Safety Depends OnYou
The following general safety precautions must be observed during all phases of operation, service, and
repair of this equipment. Failure to comply with these precautions or with speciÞc warnings elsewhere in
this manual violates safety standards of design, manufacture, and intended use of the equipment. Motorola,
Inc. assumes no liability for the customer's failure to comply with these requirements.
The safety precautions listed below represent warnings of certain dangers of which Motorola is aware. You,
as the user of the product, should follow these warnings and all other safety precautions necessary for the
safe operation of the equipment in your operating environment.
Ground the Instrument.
To minimize shock hazard, the equipment chassis and enclosure must be connected to an electrical ground.
The equipment is supplied with a three-conductor ac power cable. The power cable must either be plugged
into an approved three-contact electrical outlet or used with a three-contact to two-contact adapter, with the
grounding wire (green) Þrmly connected to an electrical ground (safety ground) at the power outlet. The
power jack and mating plug of the power cable meet International Electrotechnical Commission (IEC) safety
standards.
Do Not Operate in an Explosive Atmosphere.
Do not operate the equipment in the presence of ßammable gases or fumes. Operation of any electrical
equipment in such an environment constitutes a deÞnite safety hazard.
Keep Away From Live Circuits.
Operating personnel must not remove equipment covers. Only Factory Authorized Service Personnel or
other qualiÞed maintenance personnel may remove equipment covers for internal subassembly or
component replacement or any internal adjustment. Do not replace components with power cable
connected. Under certain conditions, dangerous voltages may exist even with the power cable removed. To
avoid injuries, always disconnect power and discharge circuits before touching them.
Do Not Service or Adjust Alone.
Do not attempt internal service or adjustment unless another person, capable of rendering Þrst aid and
resuscitation, is present.
Use CautionWhen Exposing or Handling the CRT.
Breakage of the Cathode-Ray Tube (CRT) causes a high-velocity scattering of glass fragments (implosion).
To prevent CRT implosion, avoid rough handling or jarring of the equipment. Handling of the CRT should
be done only by qualiÞed maintenance personnel using approved safety mask and gloves.
Do Not Substitute Parts or Modify Equipment.
Because of the danger of introducing additional hazards, do not install substitute parts or perform any
unauthorized modiÞcation of the equipment. Contact your local Motorola representative for service and
repair to ensure that safety features are maintained.
Dangerous Procedure Warnings.
Warnings, such as the example below, precede potentially dangerous procedures throughout this manual.
Instructions contained in the warnings must be followed. You should also employ all other safety
precautions which you deem necessary for the operation of the equipment in your operating environment.
!
WARNING
Dangerous voltages, capable of causing death, are present in
this equipment. Use extreme caution when handling,
testing, and adjusting.

The computer programs stored in the read only memories of this device contain
material copyrighted by Motorola, Inc., Þrst published 1988, and may be used only
under a license such as the License for Computer Programs (Article 14) contained in
MotorolaÕs Terms and conditions of Sale, Rev. 1/79.
!
WARNING
This equipment generates, uses, and can radiate radio
frequency energy and if not installed and used in
accordance with the documentation for this product, may
cause interference to radio communications. It has been
tested and found to comply with the limits for a Class A
Computing Device pursuant to Subpart J of Part 15 of FCC
rules, which are designed to provide reasonable protection
against such interference when operated in a commercial
environment. Operation of this equipment in a residential
area is likely to cause interference in which case the user, at
the userÕs own expense, will be required to take whatever
measures necessary to correct the interference.
Motorola
¨
and the Motorola symbol are registered trademarks of Motorola, Inc.
VMEmodule is a trademark of Motorola, Inc.
All other products mentioned in this document are trademarks or registered
trademarks of their respective holders.
© Copyright Motorola 1993
All Rights Reserved
Printed in the United States of America
May 1993

Preface
The MVME712-10 Transition Module UserÕs Manual provides general information,
hardware preparation, installation instructions, and support information for the
MVME712-10 Transition Module.
The MVME712-10 is used as the interface between MotorolaÕs MVME166 Single Board
Computers and their peripheral devices.
This manual is intended for anyone who wants to design OEM systems, supply
additional capability to an existing compatible system, or in a lab environment for
experimental purposes.
A basic knowledge of computers and digital logic is assumed.
To use this manual, you should be familiar with the publications listed in the related
documentation paragraphs on the following page.

Related Documentation
The Motorola publications listed in the table below are referenced in this document. If
not shipped with this product, manuals may be purchased by contacting your local
Motorola sales ofÞce.
Note
Although not shown in the above table, each Motorola
Computer Group manual publication number is suffixed
with characters which represent the revision level of the
document, such as Ò/D2Ó (the second revision of a manual);
a supplement bears the same number as the manual but has
a suffix such as Ò/A1Ó (the first supplement to the manual).
The SCSI speciÞcation referenced in this document is the following:
SCSI-2 (Small Computer Systems Interface - 2), draft document X3.131,
Revision 10c; Global Engineering Documents, P.O. Box 19539, Irvine, CA
92714.
Document Title
Motorola
Publication
Number
MVME166 Single Board Computer UserÕs Manual MVME166/D
MVME166/MVME167/MVME187 ProgrammerÕs
Reference Manual
MVME187PG/D

vii
Contents
Introduction 1-1
Features 1-1
SpeciÞcations 1-2
Cooling Requirements 1-3
FCC Compliance 1-3
General Description 1-4
Cables Required 1-4
Introduction 2-1
Unpacking Instructions 2-1
MVME712-10 Module Preparation 2-1
Serial Port ConÞguration 2-3
Serial Port DCE Configuration 2-3
Serial Port DTE Configuration 2-3
Configuration Register 2-3
Installation Instructions 2-8
MVME712-10 Module Installation 2-8
Front Chassis Mount, External SCSI Devices 2-9
Front Chassis Mount, Internal SCSI Devices 2-11
2-12
Rear Chassis Mount, Internal SCSI Devices 2-13
Introduction 3-1
Manual Terminology 3-1
Interconnect Signals 3-1
EIA-232-D Connectors J1, J2, J3, and J4 3-2
SCSI Connectors J5 and J7 3-3
SCSI Connector J6 3-4
Printer/Parallel Connector J8 3-5
I/O Connector J9 3-6
Ethernet Connector J10 3-13
Parts List 3-14
Schematic Diagram 3-17

List of Figures
MVME712-10 Transition Module with MVME166 1-5
MVME712-10 Connector Locations 2-2
MVME712-10 Serial Port ConÞgured as DCE (to Terminal) 2-5
MVME712-10 Serial Port ConÞgured as DTE (to Modem) 2-6
MVME712-10 ConÞguration Register 2-7
Typical MVME712-10 Installation at Front of Chassis 2-10
Typical MVME712-10 Installation at Front of Chassis 2-12
Typical MVME712-10 Installation at Rear of Chassis 2-14
MVME712-10 Parts Location 3-16

ix
List ofTables
MVME712-10 SpeciÞcations 1-2
EIA-232-D Connectors J1, J2, J3, and J4 Interconnect Signals 3-2
SCSI Connectors J5 and J7 Interconnect Signals 3-3
SCSI Connector J6 Interconnect Signals 3-4
Printer/Parallel Connector J8 Interconnect Signals 3-5
I/O Connector J9 Interconnect Signals 3-6
Ethernet Connector J10 Interconnect Signals 3-13
MVME712-10 Module Parts List 3-14

x

MVME712-10/D1 1-1
1
GENERAL INFORMATION
Introduction
This manual provides general information, hardware preparation, installation
instructions, and support information for the MVME712-10 Transition
Module.
The MVME712-10 is used as the interface between MotorolaÕs MVME166
Single Board Computer VMEmodule and its peripheral devices.
Features
The features of the MVME712-10 Transition Module include:
❏ Four shielded RJ45 jacks for EIA-232-D serial I/O
❏
Shielded DB-25 external parallel or printer port
❏ Shielded external DB-15 Ethernet interface port
❏ SCSI converter (high-density to low-density):
Ð 68-pin high-density, 16-bit-wide SCSI connector and high-density "P
cable" for connection to the MVME166
Ð 50-pin low-density, 8-bit-wide SCSI connector for connection to the
internal SCSI device(s)
❏ 100-pin I/O connector and high-density cable for connection to the
MVME166 for I/O
❏ Radio Frequency Interference (RFI) protection on front panel
❏ Electrostatic Discharge (ESD) protection on front panel

General Information
1-2 MVME712-10 Transition Module and I/O Distribution Set UserÕs Manual
1
Specifications
The MVME712-10 specifications are given in Table 1-1.
Table 1-1: MVME712-10 Specifications
Characteristics SpeciÞcations
Power requirements +5 Vdc, 150 mA typical
+12 Vdc, 50 mA typical
-12 Vdc, 50 mA typical
I/O ports Serial
Printer
Ethernet
Four shielded EIA-232-D serial ports
with RJ45 connectors
SCSI connector converter
Shielded parallel port, DB-25
Shielded parallel port, DB-15
Operating temperature 0 degrees to 55 degrees C at point of entry
of forced air (approximately 5 CFM)
Storage temperature -40 degrees to 85 degrees C
Relative humidity 5% to 90% (non-condensing)
Physical Height
characteristics
Depth
Front panel width
9.187 inches (233.35 mm)
3.2 inches (80 mm)
0.8 inches (20.32 mm)

Specifications
MVME712-10/D1 1-3
1
Cooling Requirements
Motorola VMEmodules are specified, designed, and tested to operate reliably
with an incoming air temperature range from 0 degrees C to 55 degrees C (32
degrees F to 131 degrees F) with forced air cooling.
Temperature qualification is performed in a standard Motorola MVME900
series chassis. Twenty-five watt load boards are inserted in the two card slots,
one on each side, adjacent to the board under test to simulate a high power
density system configuration. An assembly of three axial fans, rated at 71 CFM
per fan, is placed directly under the MVME card cage. The incoming air
temperature is measured between the fan assembly and the card cage where
the incoming airstream first encounters the module under test.
Test software is executed as the module is subjected to ambient temperature
variations. Case temperatures of critical, high power density integrated
circuits are monitored to ensure component vendor specifications are not
exceeded.
While the exact amount of airflow required for cooling depends on the
ambient air temperature and the type, number, and location of boards and
other heat sources, adequate cooling can usually be achieved with 5 CFM
flowing over the module. Less air flow is required to cool the module in
environments having lower maximum ambients.
Under more favorable thermal conditions it may be possible to operate the
module reliably at higher than 55 degrees C with increased air flow. It is
important to note that there are several factors, in addition to the rated CFM of
the air mover, which determine the actual volume of air flowing over a
module.
FCC Compliance
The MVME712-10 transition board was tested in an FCC-compliant chassis,
and meets the requirements for Class A equipment. FCC compliance was
achieved under the following conditions:
❏ Shielded cables on all external I/O ports.
❏ Cable shields connected to earth ground via metal shell connectors
bonded to a conductive module front panel.
❏ Conductive chassis rails connected to earth ground. This provides the
path for connecting shields to earth ground.
❏ Front panel screws properly tightened.

General Information
1-4 MVME712-10 Transition Module and I/O Distribution Set UserÕs Manual
1
For minimum RF emissions, it is essential that the conditions above be
implemented; failure to do so could compromise the FCC compliance of the
equipment containing the modules.
General Description
The MVME712-10 Transition Module is a low-cost I/O transition board for
MotorolaÕs MVME166 Single Board Computer VMEmodules and their
peripheral devices. Refer to Figure 1-1.
The MVME712-10 routes the signals to the appropriate industry standard
connectors on its front panel. This board can be mounted either next to the
MVME166 or in the back of the chassis. The board contains four shielded 8-pin
RJ45 jacks for EIA-232-D serial interface, a shielded DB-15 connector for
Ethernet, and a shielded DB-25 connector for parallel interface.
The MVME712-10 also provides conversion from the 68-pin high-density SCSI
connector to a standard 50-pin low-density SCSI connector.
Each EIA-232-D serial port transmits the following signals:
❏
Data carrier detect
❏ Request to send
❏ Transmit data
❏ Receive data
❏ Clear to send
❏ Data terminal ready
Cables Required
The following cables are needed in order to connect the MVME712-10 to the
MVME166 and other devices:
❏ One 100-conductor, 25 mil pitch cable to connect the MVME712-10 to the
MVME166 for I/O (a 1-foot-long cable is furnished by Motorola).
❏ One 68-conductor, 25 mil pitch P cable to connect the SCSI port on the
MVME712-10 to the SCSI port on the MVME166 (a 1-foot-long cable is
furnished by Motorola).
❏ One 50-conductor, 50 mil pitch A cable for 8-bit wide SCSI connection to
internal SCSI devices (customer-supplied).

Cables Required
MVME712-10/D1 1-5
1
Figure 1-1. MVME712-10 Transition Module with MVME166
100-pin I/O Connector
SCSI Out
SCSI In
MVME
712-10
MOTOROLA
ETHERNET PORTPARALLEL/PRINTER PORT
PORT 1 PORT 4PORT 3PORT 2
SCSI Out
MVME
166
SCSI
FAIL STAT
RUN SCON
LAN RPWR
SCSI VME
TERM VSB
ABORT
RESET
MOTOROLA
CONSOLE
I/O

General Information
1-6 MVME712-10 Transition Module and I/O Distribution Set UserÕs Manual
1

MVME712-10/D1 2-1
2
HARDWARE PREPARATION AND
INSTALLATION INSTRUCTIONS
Introduction
This chapter provides unpacking instructions, hardware preparation, and
installation instructions for the MVME712-10 Transition Module.
Unpacking Instructions
Note
If the carton is damaged upon receipt, request that carrier's
agent be present during unpacking and inspection of the
equipment.
Unpack the equipment from the shipping carton. Refer to the packing list and
verify that all items are present. Save the packing material for storing and
reshipping of the equipment.
MVME712-10 Module Preparation
The location of the connectors on the MVME712-10 is illustrated in Figure 2-1.
The module has been factory tested and is configured for DTE, but can be
operated as DCE with an appropriate external adapter if desired. The
connectors are:
❏ Four RJ45 EIA-232-D serial ports with DTE configuration (J1, J2, J3, J4)
❏ SCSI converter connectors (J5, J6, J7)
❏ Printer/parallel connector (J8)
❏ I/O connector (J9)
❏ Ethernet connector (J10)

Hardware Preparation and Installation
2-2 MVME712-10 Transition Module and I/O Distribution Set UserÕs Manual
2
Figure 2-1. MVME712-10 Connector Locations
J1 J2 J3 J4
J9
J8 J10
J6
J5
J7
PRIMARY SIDE
1142 9302
PORT 4PORT3PORT2PORT1 PARALLEL/PRINTER PORT ETHERNET
CONSOLE
MVME
712-10
MOTOROLA
COMPONENTS REMOVED
FOR CLARITY

MVME712-10 Module Preparation
MVME712-10/D1 2-3
2
Serial Port Configuration
The four RJ45 EIA-232-D serial ports are factory configured as terminal (DTE)
for connection to modem. However, they can be used as modem-to-terminal
(DCE) by using an appropriate user-supplied external DCE adapter.
Serial Port DCE Configuration
Figure 2-2 shows the schematic representation of the DCE configuration of
serial ports 1 through 4, using a user-supplied external DCE adapter.
Serial Port DTE Configuration
Figure 2-3 shows the schematic representation of the DTE configuration of
serial ports 1 through 4, using a user-supplied external DTE adapter.
Configuration Register
Figure 2-4 illustrates the function of the configuration register on the
MVME712-10. The application software on the MVME166 can read the
configuration information to identify the transition board(s) in the system.
On the MVME166, the MC68230 interrupt level is the same as the CD2401. The
interrupt vector is as programmed in the MC68230. The interrupt priority is (1)
first the CD2401, and (2) then the MC68230.
To read the configuration information, the MC68230 (PI/T) must be
programmed as follows:
❏
Port A direction must be:
Ð Mode 0, submode 1X
Ð Bits 7 to 4 as inputs
Ð Bits 3 to 0 as outputs.
❏ Port B direction must be:
Ð Mode 0, submode 1X
Ð Bit 7 as an output
Ð Bits 6 to 0 as inputs
Write port B bits 7 to 0 set configuration mode. Now port A bits 3 to 0 are used
to select a port.

Hardware Preparation and Installation
2-4 MVME712-10 Transition Module and I/O Distribution Set UserÕs Manual
2
Port A bits 7 to 4 are the configuration data returned from the port selected:
Refer to the
MVME166/MVME167/MVME187 Single Board Computer
ProgrammerÕs Reference Manual for more information.
Port A Bits 3 to 0 Port Selected
00
11
22
33
ConÞguration
Register
Port A Bits 7 to 4
Module Type Module Implemented on
0
1
EIA-232 DCE
EIA-232 DTE
MVME712-06
MVME712-06
2-8
Reserved
9EIA-232 RJ45 DTE MVME712-10
A-F Reserved
