Motorola OPERATIONS CRITICAL WIRELESS User manual

OPERATIONS
CRITICAL
WIRELESS

68012002053_combine.book Page 1 Friday, March 25, 2011 11:0
1

i
English
OPERATIONS CRITICAL
WIRELESS
TABLE OF CONTENTS
Foreword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
What Is In Your Package . . . . . . . . . . . . . . . . . . . . . .1
Device Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Clothing Clip Assembly/Disassembly . . . . . . . . . . . . .3
Charging Your device . . . . . . . . . . . . . . . . . . . . . . . . .4
Attaching Your Integrated Microphone/Receiver
Headset (Earpiece) . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Wearing Your Integrated Microphone/Receiver
Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Powering On/Off Device . . . . . . . . . . . . . . . . . . . . . . .6
Wireless Adapter (PMLN5712) . . . . . . . . . . . . . . . . . .7
Pairing Your Audio Device . . . . . . . . . . . . . . . . . . . . .7
Pairing Your Data Device (Remote PTT) . . . . . . . . . .8
Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
PTT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Receiving Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Dark Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Battery Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Error Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . .12
68012002053_combine.book Page i Friday, March 25, 2011 11:0
1

ii
English
FOREWORD
Product Safety and RF Exposure Compliance
ATTENTION!
The radio is restricted to occupational use only to satisfy
ICNIRP/FCC RF energy exposure requirements. Before using
this product, read the RF energy awareness information and
operating instructions in the Product Safety and RF Exposure
booklet enclosed with your radio (Motorola Publication part
number 6881095C98 (US) or 6864117B25 (EMEA)) to ensure
compliance with RF energy exposure limits.
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may
cause undesired operation. Any changes or modifications
not expressly approved by Motorola may void the user’s
authority to operate this device.
Battery Information:
Battery is shipped with a nominal charge between 30 and 50%.
Battery should be stored between -10°C (14°F) and 30°C
(86°F) to minimize permanent capacity loss.
Caution: Storing your fully charged accessory in high-
temperature conditions may permanently reduce the life of the
internal battery.
Note: The battery is not a user replaceable part.
Before using this product, read the operating
instructions for safe usage contained in the
Product Safety and RF Exposure booklet
enclosed with your radio.
!
C a u t i o n
68012002053_combine.book Page ii Monday, March 28, 2011 10:17 AM

iii
English
Important Information:
• Do not charge your accessory in temperatures below
0°C (32°F) or above 45°C (113°F). Conditions inside a
parked car can exceed this range. Do not store your
accessory in a parked car. Do not store your accessory
in direct sunlight.
• Storing your fully charged accessory in high-temperature
conditions may permanently reduce the life of the inter-
nal battery.
• Battery life may temporarily shorten in low-temperature
conditions.
Waste (disposal) of your Electronic and
Electric Equipment
The European Union's WEEE directive requires that products
sold into EU countries must have the crossed out trashbin label
on the product (or the package in some cases). As defined by
the WEEE directive, this crossed out trashbin label means that
customers and end users in EU countries should not dispose of
electronic and electrical equipment or accessories in
household waste. Customers or end-users in EU countries
should contact their local equipment supplier representative or
service centre for information about the waste collection
system in their country.
Warning: Never dispose of batteries in a fire because
they may explode.
032376o
68012002053_combine.book Page iii Friday, March 25, 2011 11:

iv
English
ACOUSTIC SAFETY
Exposure to loud noises from any source for extended periods
of time may temporarily or permanently affect your hearing.
The louder the radio's volume, the less time is required before
your hearing could be affected. Hearing damage from loud
noise is sometimes undetectable at first and can have a
cumulative effect.
To protect your hearing:
• Use the lowest volume necessary to do your job.
• Turn up the volume only if you are in noisy surroundings.
• Turn down the volume before adding headset or ear-
piece.
• Limit the amount of time you use headsets or earpieces
at high volume.
• When using the radio without a headset or earpiece, do
not place the radio's speaker directly against your ear.
68012002053_combine.book Page iv Friday, March 25, 2011 11:
0

1
English
INTRODUCTION
The minimum line-of-sight range for the wireless device is 30
feet. However, the body tends to obstruct the signal, therefore
the normal usage range is 6’ around your body.
When the headset and adapter exceed the range of the
wireless system, the wireless device issues an alert sound,
indicating that the wireless system is not operational. The link
is automatically restored once the units are back within
communication range.
WHAT IS IN YOUR PACKAGE
• Wireless Device with PTT
• Clothing clip
• Integrated Microphone/Receiver Earpiece with attached
Collar clip
• User Manual
• Spare Ear Tube
• Foam Windscreen
• Silicone Earstrap
• Charger
68012002053_combine.book Page 1 Friday, March 25, 2011 11:0
1

2
English
OPERATIONS CRITICAL WIRELESS
Collar Clip
Flower Tip
Earpiece
Portion
Microphone
USB and Charger
Volume Down
Volume Up
PTT
Clothing Clip Power
Battery LED
Recess on
Front Housing
68012002053_combine.book Page 2 Friday, March 25, 2011 11:0
1

3
English
THE OPERATIONS CRITICAL WIRELESS
INTEGRATED MICROPHONE/RECEIVER HEADSET
DEVICE FEATURES
•PTT
• Version 2.1 Bluetooth
• Private listening without occluding the ear
• Loud, clear audio
• Comfortable Earpiece for all day wear
• Volume Control
CLOTHING CLIP ASSEMBLY/DISASSEMBLY
The following steps describe how to assemble your Wireless
Device’s clothing clip:
1. Place the clip horizontally in
the clip track area.
2. While holding the Wireless
Device with both hands,
place both your thumbs
firmly on top of the clip.
68012002053_combine.book Page 3 Friday, March 25, 2011 11:0
1

4
English
3. Press the top of the clip
firmly while sliding it in until
a click is heard.
The following steps describe how to disassemble your
Wireless Device’s clothing clip:
1. Insert a 1.4mm flat head
screwdriver under the metal
spring and lift it.
2. While lifting the metal
spring, slide the clip out of
the back cover with your
thumb.
CHARGING YOUR DEVICE
Prior to using the device for the first time, it should be fully
charged. Recommended charging time is three (3) hours.
Note: Ensure that the dust cap is fitted back on the USB port,
upon removing it from the charger.
Refer to Table 1 for charging status indicators:
State LED Indication
Charging (when connected via USB
to PC or wall charger)
Red LED illuminated
90% charged battery capacity Green LED blinking
100% charged battery capacity Green LED illuminated
Table 1: Battery Charging LED Indicators
68012002053_combine.book Page 4 Friday, March 25, 2011 11:0
1

5
English
ATTACHING YOUR INTEGRATED
MICROPHONE/RECEIVER HEADSET
(EARPIECE)
The following steps describe how to attach/detach your
earpiece:
1. To attach and lock the earpiece, push the connector in and
turn the connector clockwise so that the “unlock” symbol is
NOT aligned with the recess on the front housing.
2. To unlock and detach the earpiece, turn the connector
counterclockwise so that the “unlock” symbol aligns with the
recess on the front housing and pull the connector out.
Note: Please attach your earpiece prior to establishing the
connection with radio.
Note: If the earpiece is replaced or re-attached, the accessory
must be powered off and powered back on to ensure proper
detection and operation of the earpiece with the accessory.
Note: The wireless link is dropped upon accidental or intentional
removal of the earpiece from the device.
WEARING YOUR INTEGRATED MICROPHONE/
RECEIVER HEADSET
The Integrated Microphone/Receiver Headset represents a
breakthrough in voice processing technology. The receiver and
microphone are both built into a lightweight, ergonomic
earpiece, which enables you to hear and be heard even in high
noise conditions. The earpiece does not block normal hearing
which allows important background sounds to be heard.
The earpiece can be worn on either ear by swiveling the flower
tip of the ear tube accordingly.
Note: If poor transmit audio is experienced in windy conditions,
install the foam windscreen to decrease wind noise.
1. Ensure the ear tube is
facing the ear canal.
2. Place the Earpiece over
your ear for correct fit.
68012002053_combine.book Page 5 Friday, March 25, 2011 11:0
1

6
English
3. After placing the earpiece firmly on your ear, ensure that the
flower tip of the ear tube is correctly oriented towards the
ear canal.
4. Use your finger to insert the
ear tube into your ear canal.
5. Use the collar clip to secure the earpiece.
Cleaning and Hygiene:
1. Before each use, clean the
exterior of the ear tube with
an alcohol swab.
2. Remove the ear tube to
clean and disinfect the
interior of the ear tube
weekly.
POWERING ON/OFF DEVICE
Press the power on/off button.
Figure 1: Power ON/OFF Button
Power LED Indication
(Audio and Standalone
PTT Device)
Tone Indication
(Audio Device)
On Blue LED Blinks 3 times
then OFF
Power On Tone.
Hold for 1.0 second.
Off Blue LED Blinks 3 times
then POWER OFF
Power Off Tone.
Hold for 3 seconds.
Table 2: Power ON/OFF LED and Tone Indicators
68012002053_combine.book Page 6 Friday, March 25, 2011 11:0
1

7
English
WIRELESS ADAPTER (PMLN5712)
The wireless adapter acts as a host for the wireless device to
connect to the two-way radio. The wireless adapter can
connect to two devices simultaneously; one with an earpiece
(audio device) and one without an earpiece (data device e.g.
Remote PTT).
The wireless adapter can be placed in Pairing Mode by
pressing the PTT button on the wireless adapter for more than
3 seconds upon radio power-up.
Note: Refer to the Wireless Adapter manual for more details on
pairing.
During a pairing session, the wireless adapter can pair with
multiple devices in a sequential manner. In order for the user to
know which wireless device the wireless adapter is connecting
to, the user is required to press the PTT button on the wireless
adapter upon tone indication (refer to Table 3 on page 9).
PAIRING YOUR AUDIO DEVICE
First time connection steps:
1. Ensure the Earpiece portion of the wireless device is
plugged into the POD portion of the wireless device.
2. Verify that both the radio and the wireless device are
powered ON (First time only: Once the wireless device is
powered ON, it goes into Pairing Mode automatically.)
3. Ensure that device is in pairing mode (refer to Table 3 on
page 9).
4. Both the wireless device and wireless adapter must be
within pairing range (recommended pairing range is within 1
meter).
5. Paired Successfully indication is provided upon successful
pairing (refer to Table 3 on page 9) and a tone is heard on
the audio device’s speaker indicating a connection request.
6. Press the PTT button on the wireless device to start
connection process.
7. The wireless device connects to the radio upon completion
of the connection process.
68012002053_combine.book Page 7 Friday, March 25, 2011 11:0
1

8
English
8. Wireless Link Connected with Host indication is provided
upon successful link establishment (refer to Table 3 on
page 9).
9. You are now ready to use your wireless device.
PAIRING YOUR DATA DEVICE (REMOTE PTT)
Figure 2: Remote PTT
First time connection steps:
1. Ensure the audio device is already connected with the host.
2. Ensure that earpiece is not inserted in to the POD of the
wireless device.
3. Ensure that device and adapter are in pairing mode.
4. Both the wireless device and wireless adapter must be
within pairing range (recommended pairing range is within 1
meter).
5. Paired Successfully LED indication is provided upon
successful pairing (refer to Table 3 on page 9).
6. Once the device is successfully connected to adapter, a
connection successful tone indication is heard on audio
device.
Subsequent connections with same wireless adapter (Audio
and Data Devices):
1. Ensure both devices are within communication range,
recommended communication range is within 30 feet.
2. The wireless device establishes a link with the wireless
adapter automatically.
68012002053_combine.book Page 8 Friday, March 25, 2011 11:0
1

9
English
Subsequent connections with a different wireless adapter
(Audio and Data Devices):
1. Unpair the wireless device.
2. Once the wireless device is powered ON, it goes into
Pairing Mode automatically.
3. Follow steps 2-8 from “Pairing Your Audio Device” in the
previous section.
Unpairing the Wireless device (Audio and Data Devices):
1. Power OFF the wireless device.
2. Press and hold the PTT button while powering ON the
wireless device.
If the Wireless Device has been paired with a radio and needs
to now be paired with a different radio, the Wireless Device is
required to clear its previous pairing information. This can be
achieved by pressing the PTT on the Wireless Device while
powering it on. Refer to “Pairing Your Audio Device” on page 7
to re-establish wireless connection.
State LED Indication
(Audio and Standalone
PTT Device)
Tone Indication
(Audio Device)
Not Paired Blue LED Blinking Pairing Ready Tone
Paired
Successfully
Blue LED Solid for 2
seconds
Pairing Successful
Tone
Wireless Link
Connected with
Host
Blue LED Heartbeat:
Long OFF and Short
ON
Connected Tone
Wireless Link
Disconnected
from Host
Blue LED Solid ON Disconnected Tone
every 2 minutes for 10
minutes
Table 3: Wireless Link and Pairing Indicators
68012002053_combine.book Page 9 Friday, March 25, 2011 11:0
1

10
English
VOLUME CONTROL
The Operations Critical Wireless device has 8 volume levels.
The volume level is controlled using the radio volume control,
or the device’s Volume Up/Volume Down buttons (refer to
Table 4 for volume indicators).
PTT
Press the PTT button on the wireless device to initiate
transmission. PTT location decides the microphone used for
transmission as indicated in Table 5 on page 10.
Button Push Tone Indication
(Audio Device)
Volume Up Volume Tone with increased loudness
Volume Down Volume Tone played with decreased
loudness
Volume Up and Hold Volume Tone played continuously with
increasing loudness
Volume Down and Hold Volume Tone played continuously with
decreasing loudness
Table 4: Volume Indicators
PTT Location Active Microphone
Wireless Device Earpiece Microphone
Remote PTT Device Earpiece Microphone
Wireless Adapter PTT Earpiece Microphone
Radio PTT Radio Microphone
Table 5: PTT Location and Active Microphone
68012002053_combine.book Page 10 Friday, March 25, 2011 11:
0

11
English
RECEIVING AUDIO
Once the wireless device is connected to the two-way radio,
the radio speaker mutes and the audio is heard only from the
wireless device earpiece. In the event of lost link, or if wireless
device is disconnected, the audio is reverted back to the two-
way radio speaker.
DARK MODE
Dark Mode allows the user to turn off the LEDs on the wireless
device. Placing the wireless device in Dark Mode:
• The wireless device can be put in Dark Mode during power
ON by simultaneously pressing Volume Up and Volume
Down buttons.
• A feedback tone is heard to let the user know the LEDs are
turned off.
• Once the device is turned on, it can be toggled IN and OUT
of Dark Mode by simultaneously pressing Volume Up and
Volume Down for 3 seconds.
BATTERY ALERTS
The wireless device is battery powered. It is very important to
pay attention to the low battery warning described in Table 6 to
avoid improper functioning of the device.
State
LED
Indication
(Audio and
Standalone
PTT Device)
Tone
Indication
(Audio Device)
Remaining
Battery Life
Low Battery
Indication
Red LED
Heartbeat
Low Battery Tone
every 2 minutes
Less than 30
minutes
Critical
Battery
Indication
Red LED Rapid
Blinking
Low Battery Tone
every 30 seconds
Less than 5
minutes
Table 6: Battery Alerts
68012002053_combine.book Page 11 Friday, March 25, 2011 11:
0

12
English
ERROR INDICATOR
Any product error is indicated by Amber Blinking or Solid LED
indicators.
TROUBLESHOOTING
If at any time the wireless Connection cannot be re-
established, or the device is operating incorrectly:
1. Power Cycle the device and the two-way radio. The
connection should re-establish.
2. If the problem continues; Refer to “Pairing Your Audio
Device” on page 7 to repeat the connection process.
REPLACEMENT PARTS
To order replacement parts, and for service and support, call
800-422-4210.
The following parts are available:
Description Motorola
Part No.
Wireless Device
(POD only)
NTN8127
Earpiece with 12” cable NTN2572
Earpiece with 9.5” cable NTN2575
Maintenance Kit
(Includes 10 silicone ear tubes, 10 microphone seal
strips, and 2 foam windscreens)
NTN8821
Adhesive Pads (10)
(for secure Attachment)
NTN8986
Ear Straps (10)
(for secure Attachment)
NTN8988
Ear Tubes (10)
(for secure Attachment)
RLN5037
68012002053_combine.book Page 12 Friday, March 25, 2011 11:
0

13
English
Open Source Software Legal Notices:
This Motorola Product contains Open Source Software. For
information regarding licenses, acknowledgements, required
copyright notices, and other usage terms, refer to the
documentation for this Motorola Product at:
https://businessonline.motorola.com. Go to:
>Resource Center>Product Information>Manual>Accessories.
Service and Support:
Please contact Motorola Customer Care at 1-800-422-4210
(US only) or 1-847-538-8023 (International) for ordering or any
technical troubleshooting assistance.
Warranty
Motorola offers a standard one year warranty. Contact your
Motorola dealer for detailed information on the standard
warranty.
Note: Warranty is void after customer replacement of any parts
other than replacement parts listed.
Micro USB Charger:
EU and UK Adapter Plugs Brazil, Chile, Europe, UK,
India and Singapore
PMPN4006A
AU Adapter Plug Australia PMPN4007A
CHINA, No Adapter Plug China PMPN4008A
US/NA, No Adapter Plug US, Mexico, Taiwan and
Japan
PMPN4009A
SPN5334
Description Motorola
Part No.
68012002053_combine.book Page 13 Friday, March 25, 2011 11:
0

14
English
68012002053_combine.book Page 14 Friday, March 25, 2011 11:
0
