TRACKS AIR
USER MANUAL

HELLO,
FREEDOM LOVERS.
OVERVIEW
ASSEMBLY 4
THE GOODS 6
CONNECTING 8
BASICS 11
ADVANCED STUFF 12
CONTACT 14
NOTE
Thebatteryis designed to last the lifeof your
device. You don’t need to take it out or ddle
with it.If you tryto remove orreplace your
batteryit willvoid your warranty and could
cause injury and damage your device.
With your new TRACKS AIR wireless
Bluetooth headset, you are free to
roam around the house at will. Crystal
clear HD calls on your phone, simple
controls in your hand, and high fidelity
sound in your ears — now that’s what
we call Independence.
CAUTION
Before using Tracks Air,pleaseread the safety,
regulatoryandlegalinformationdocument.

ASSEMBLY
Let’s get it together.
PowerTrack™Headband
WirelessA2SoundEngines™
Singlebuttoncablewithmicrophone
USBchargecable
Carryingcase
INSTRUCTIONS
The sound engines have slots in them. Insert the
ends of the PowerTrack™ headband into these
slots and slide them up a bit. Make sure to match
the L (left) and R (right) markings on the sound
engineswiththecorrespondingL and Ron the
PowerTrack™headband. Settle thesoundengines
overyour ears and adjust toa comfortableposition.
For optimumsound,makesure the L andR sound
enginesareover the corresponding ear.
SoundEngineSlot
SoundEngine
PowerTrack™headband
EN USER GUIDE
54 ASSEMBLY

THE GOODS
...at a glance.
POWER
First thing’s rst: give Tracks Air a charge.
Plug thesmallend ofthe USBintothe micro
USB port located on the Right Sound
Engine. It is fully charged when the status
light turns solid green.
VolumeControl
PowerButton
Microphone
NFCReader
Location
PowerButton
Status
Light
NOTE
NFConly located onRightSoundEngine
Multi-functionButton
WiredCableJack
Microphone
MicroUSB Charge Port
EN USER GUIDE
76 THE GOODS

CONNECT
Now let’s get Tracks Air and your device
talking to each other. There are two ways
to pair it: the Bluetooth® EASYPAIR™
Method and the NFC™ way. EASYPAIR™
works for everybody. NFC™ people —
you know who you are.
EASYPAIR™METHOD
STEP 1
Turn on Bluetooth and NFC on your device.
STEP 2
Tap your device tothe topof the right soundengine.
Abracadabra.Thedevicetellsyouwhenyou’reconnected.
NOTE
The above works for most devices, but not all
NFC readers are located in the same place or
functionthesameway.Seeyourdevice’suser
guide for all the details.
STEP 4
When thedeviceand TRACKS
AIR are connected, you’llget a
pairingcompletetone.
STEP 1
Turn on Bluetooth®on
your device.
STEP 2
Turn on TRACKS AIR andit
will automatically go into
pairingmode.
STEP 3
Goto theBluetooth menu
on your device topair and
connect.
NFC METHOD
It seems obvious,butyou musthavean NFCBluetooth-
enableddeviceinordertousetheNFCmethod. Ifyou
don’thaveit,usetheEasypairMethod.
EN USER GUIDE CONNECT
98

NOTE
Some features may work dierently depending on your phone/type of service.
YOU WANT TO
Playorpause
Skiptothenexttrack
Skip to previous
track
YOU WANT TO
Take a call
Declinea call
Make avoice
dialcall
Mute or unmute
acall
Enda call
Take a second
incomingcall
Declineasecond
incomingcall
Hearremaining
musicplaytimeor
batterstatus
PRESS
Themulti-functionbuttononce.
Themulti-functionbuttontwice.
Pressthe multi-function button
threetimes.
PRESS
Themulti-functionbutton.
Hold avolumebutton until youheara
tone.
Hold the music/call button until you hear
atone.
Holdboth volumebuttonsatthesame time,
until you hear “mute on” or “mute o”
Themulti-functionbutton.
Themulti-functionbutton.
Usethephonekeypad.
Thevolumebuttonswhileinstandby.
WIRED MODE
Nowwhatif you preferto stay wired? Friend, you can.
Takethe single button cablewith mic (included)and
plug the jacks into the respective sound engines. Not
surprisingly, L goes into the left one, R goes into the
rightone.Pushallconnectorsinuntilyouhear a“click.”
NOTE
Inwired mode,theBluetoothconnection
automatically switches o to save your battery.
NOTE
Usingamobile device or accessory while driving can be distractingandmaybe
illegal. Always follow the lawsof your stateanddrivesafely. Bothhandson the
wheel.Ten and two. Eyes ontheroad.
BASICS
MUSIC — SOUND ENGINE CONTROLS
CALLS — SOUND ENGINE CONTROLS
EN USER GUIDE
1110 BASICS

13
ADVANCED STUFF
For Smarties
SECOND DEVICE /
MULTI-POINT CONNECTION
Do you use two phones? Do you use a tablet and a
phone? Are you double jointed?
You can connect up to two devices to yourheadset for
music and calls. As long as multi-point is enabled (see
SETTINGSonpage13), pair bothdevicesandthen you
can switch backand forthbetweendevices seamlessly,
whetheryou’replayingmusic or managingcalls.
Justfollowtheinstructionsunder“Connect”onpage
8for each device. To connect both devices, just turn
themon.
MUSIC
Selecta music sourceby pressingplay on thatdevice.
If you wanttoswitch to yoursecondpaired device for
music, just hit playonthat device.
SETTINGS
To hear settings, press and hold the power and
multi-function button. To change them, just follow
the voice prompts.
Factory Reset
(CAUTION “Reset”erasesallpaireddevicesstoredinyourheadset.)
Voice interface on/off
Multi-point on/off
Wide-band audio on/off
(NOTE Use forincreasedclarity andrichersound.Notall devicesorcarrier
networkssupportWide-band.)
NOTIFICATION LIGHT
The easy way to check your headset
NOTE
Your headsetwill onlystream fromonemusic
sourceat a time.
IF THE
LIGHT SHOWS...
Fadingblue
Flashingblue
Steadyblue
Flashingred
Flashing green
SteadyGreen
IT MEANS...
Turning on or o
Inpairingmode
Deviceconnected
Charginglow powerbattery
Chargingmediumpowerbattery
Battery fully charged
EN USER GUIDE
1312 ADVANCED STUFF

CONTACT
Confused?Perplexed?Adrift? We’ve got answers and
we’re standing by.
Give Us a Shout
We’re here to help.
SUPPORT
The following are a set of resources to ensure you
get the most out of your SOL REPUBLIC product.
If you are experiencing issues at any time, please
visit SOLREPUBLIC.COM/SUPPORT, contact
us on Twitter (@SOLREPUBLIC), or call us at
8 7 7. 4 0 0 . 0 31 0
To acquire a printable version of this warranty,
please visit SOLREPUBLIC.com/warranty
Forcustomerserviceinquiries,pleaseemail
[e-mail]
FR
Manuel d’utilisation
TRACKS AIR
Avec le nouveau casque sans l TRACKS AIR Bluetooth,
vous êtes libre de circuler dans votre maison comme
bon vous semble. Des appels au son cristallin, des
commandes simples au creux de votre main, un
son haute-fidélité dans vos oreilles. Voilà ce qu’on
appelle l’indépendance.
BONJOUR,
AMOUREUXDE LIBERTÉ
APERCU
ASSEMBLAGE 16
LES COMPOSANTS 18
CONNEXION 20
LES BASES 22
POUR ALLER PLUS LOIN 24
CONTACTEZ-NOUS 26
NOTEZ
La batterieestconçue pour fonctionnerpendanttouteladuréedeviede
votreappareil.Iln’ya aucunbesoinde la retirerou même d’ytoucher.Si
voustentezd’enleverouderemplacerlabatterie,votregarantieseraannulée
etvousrisquezdevousblesseretd’endommagervotreappareil.
ATTENTION
Avant toute utilisation du casque Tracks Air, veuillezlire ledocument
relatifauxinformationsdesécurité,deréglementationetjuridiques.
14 EN USER GUIDE

ASSEMBLAGE
Commençons l’assemblage.
Arceau PowerTrack™
ÉcouteursA2 sans l™
Câbleboutonetmicrophone
Câbled’alimentationUSB
Etuidetransport
INSTRUCTIONS
Il y a des fentes situées sur les écouteurs. Insérez
les extrémités de l’arceau PowerTrack™ dans ces
fentes et faites-les glisserlégèrementvers lehaut.
Assurez-vous que le L (gauche) et R (droite) qui se
trouvent sur les écouteurs correspondent aux L et R
de l’arceau PowerTrack™. Posez les écouteurs sur vos
oreilles puis réglez les afin de trouver une position
confortable. Pour un son optimal, assurez-vous
que le L et R se trouvent sur la bonne oreille.
Arceau PowerTrack™
Fentedel’écouteur
Écouteur
1716 MANUEL D’UTILISATIONFR ASSEMBLAGE

LES COMPOSANTS
... jetons un coup d’œil.
ALIMENTATION
Avant toute chose : chargez votre Tracks
Air. Branchez la petite extrémité de l’USB
dans le port micro USB situé sur l’Ecouteur
Droit. Le casque est complètement chargé
lorsque le voyant d’état passe au vert xe.
Volume
Bouton marche/arrêt
Microphone
Emplacementdu
lecteur nfc
Bouton marche/
arrêt
Voyant
d’état
NOTEZ
Le NFC est uniquement situé
surl’EcouteurDroit.
Touchemulti-fonctions
Prisejack
Microphone
Portd’alimentationmicroUSB
1918 MANUEL D’UTILISATIONFR LES COMPOSANTS
