Motorola Moto Hint Installation instructions

en
moto hint
let’s get started
16 JULY 2014

16 JULY 2014

1en Charging
Charging
Note: Fully charge your headset
before use.
Wireless Charging
Wired Charging
micro USB
Charge the case and headset by
plugging in the charging cable.
Insert headset and close case to begin
charging. Headset is "on" when
removed from the case. A fully charged
case can recharge your headsettwice.
16 JULY 2014

2Wearing en
Wearing
Twist your headset to
make it t comfortably.
Fit
Remove the headset from the case
and carefully place in your ear.
Adjust
Connect and go
Followvoice prompts to
connect to your phone.
16 JULY 2014

3en Talking
Talking
Call / Voice Touch area
Back microphone
Front microphone
Touch to answer/ignore a call
or start voice commands.
16 JULY 2014

4Talk i n g e n
Incoming call
Answer Say “answer”
or touch
headset.
Ignore Say “ignore”.
Call options
Voice
command Touch headset. Say a
command,like
“Call Francis
Martin,
mobile”. (To
voice dial on a
second phone
touch and
hold headset.)
Note: This
feature is
phone
dependent.
End call Touch
headset.
Change volume Use your
phone.
16 JULY 2014

5en Talking
Take headset out of ear to:
•Transfer a call to your phone.
•Pause music.
Put headset in ear to:
•Answer an incoming call.
•Transfer a call to headset.
•Restart paused music.
16 JULY 2014

6Moto Voice en
Moto Voice
Tell your Moto Hint headset what you
want. Get directions, check
voicemail, play your favorite song, or
start a search using Moto Voice.
•If you have Moto Voice on your
phone and have trained it with
your launch phrase, you’re ready
to start using voice control.
•If you need to setup Moto Voice,
go to the Moto application on
your phone.
Note: You'll need the Moto Voice
feature on your Moto X or Droid
phone to use voice control on your
Moto Hint. If your phone doesn't
have Moto Voice, the headset still
supports voice commands (see
page 4).
16 JULY 2014

7en Lighting
Lighting
Headset light indicator
Note: You will hear a prompt when
the battery is low
.
In-ear Off.
Remove from case Turns on
briefly and
shows the
battery
level.
Light color Talk time
White More than
30 minutes
left.
Red Less than
30 minutes
left.
16 JULY 2014

8Lighting en
Charge case light indicator
Wired charging of case and
headset
Headset in case Headset and
case are
charging.
Case Case
charging.
Light Charge status
Blinks white Charging.
Solid white Fully charged.
16 JULY 2014

9en Lighting
Notes:
•To check if charging is complete
open and shut the case.
•Lights turn off to save power.
Headset will continue to charge
until fully charged.
Wireless charging of headset
Headset in case Charging.
Light Charge status
Blinks white Charging.
Solid white Fully charged
headset.
16 JULY 2014

10 Cleaning en
Cleaning
Pull off the ear gel and inspect the
opening for blockages. Remove any
unwanted materials from the
opening. Push the ear gel back on to
the headset.
16 JULY 2014

11en Second device
Second device
Do you use two phones? Or a phone
and a tablet? Connect with both of
them.
1Pair each device with the headset
as normal. You don’t have to turn
off the first device to pair with the
second one, as long as it’s done
within five minutes of turning on
the headset.
2Once paired, to connect with
both devices simply turn them on.
You’ll hear “device
(number) connected” as each
device connects with your
headset.
Notes:
•Two phones connected: If you are
on a call and you receive a call on
the other phone. Touch the
headset to switch calls. Touch and
hold the headset to return to
original call.
•Two phones connected, not on a
call: Touch the headset to activate
voice recognition on the first
phone. Touch and hold it to
activate voice recognition on the
second phone.
16 JULY 2014

12 Settings en
Settings
Touch and hold the Call / Voice
Touch area of the headset for 8
seconds, and then release. Headset
will announce that it is in the "Settings
Menu". Follow the voice prompts to
turn features on or off:
• Ear detect: Sensor for audio
detect when in ear.
•MotoVoice:Always on voice
detection.
• Voice prompts: Voice dial calls,
and more.
• Caller ID alert: Hear caller ID for
incoming calls.
•Wide-bandaudio:Use HD Audio
Plus for increased clarity and
richer sound.
•Voiceanswer:Speak to answer
incoming calls.
• Pass through audio: Allows
ambient sound though headset.
• Restore factory settings: Reset
default settings on your headset.
Caution: This erases all pairing
information stored on the
headset.
16 JULY 2014

13en Get what you need
Get what you need
Support: Visit
www.motorola.com/support or
contact the Motorola Customer
Support Center at: 0800 666 8676
(Argentina), 800-201-442 (Chile),
01-800-700-1504 (Colombia),
01 800 021 0000 (México),
0800-100-4289 (Venezuela) o al
0-800-52-470 (Perú).
16 JULY 2014

14 Safety, Regulatory & Legal en
Safety, Regulatory & Legal
For product safety information, visit:
www.motorola.com/hintlegalguide .
Caution About High
Volume Usage
Warning: Exposure to loud noise from any source
for extended periods of time may affect your
hearing. The louder the sound, the less time is
required beforeyour hearing could be affected. To
protect your hearing:
• Limit the amount of time you use headsets or
headphones at high volume.
• Avoid turning up the volume to block out noisy
surroundings.
• Turn the volume down if you can’t hear people
speaking near you.
If you experience hearing discomfort, including
the sensation of pressure or fullness in your ears,
ringing in your ears, or muffled speech, you should
stop listening to the device through your headset
or headphones and have your hearing checked.
Allergens
Glass Parts
Motorola Mobility avoids using known allergens in
our products. From time to time, trace amounts of
an allergen may be added during manufacture of a
device or device component that could cause
discomfort for some individuals. This approach is
common for many types of products. We
recommend that you monitor any products that
may be in prolonged contact with your skin, and
remove them if you experience skin irritation.
16 JULY 2014

15en Safety, Regulatory & Legal
European Union
Directives Conformance
Statement
EU Conforma nce
The following CE compliance information is
applicable to Motorola products that carry one of
the following CE marks:
Hereby, Motorola declares that this product is in
compliance with:
• The essential requirements and other relevant
provisions of Directive 1999/5/EC
• All other relevant EU Directives
For products that support Wi-Fi 802.11a (as defined
in your product information): This device is
restricted to indoor use when operating in the 5.15
to 5.25 GHz (802.11a) Wi-Fi frequency band.
The following gives an example of a typical Type
name:
You can view your product’s Declaration of
Conformity(DoC) to Directive 1999/5/EC (to
R&TTE Directive) at www.motorola.com/rtte
(in English only). To find your DoC, enter the Type
name from your product’s label in the “Search” bar
on the website.
Regulatory authorities within the EU may obtain compliance information
by writing to: Product Safety andCompliance, Motorola Mobility UK Ltd.,
Redwood, Crockford Lane, Chineham Business Park,Basingstoke,
RG24 8WQ, UNITED KINGDOM.
0168
Type
Name
16 JULY 2014

16 Safety, Regulatory & Legal en
FCC Notice to Users
FCC Notice
The following statement applies to all products
that bear the FCC logo and/or FCC ID on the
product label.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. See 47 CFR
Sec. 15.105(b). These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and the receiver.
• Connect the equipment to an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation. See 47 CFR Sec.
15.19(a)(3).
Motorola has not approved any changes or
modifications to this device by the user. Any
changes or modifications could void the user’s
authority to operate the equipment. See 47 CFR
Sec. 15.21.
For products that support Wi-Fi 802.11a (as defined
in product information): In the United States, do not
use your device outdoors while connected to an
802.11a Wi-Fi network. The FCC prohibits such
16 JULY 2014

17en Safety, Regulatory & Legal
outdoor use since frequencies 5.15-5.25 GHz can
cause interference with Mobile Satellite Services
(MSS). Public Wi-Fi access points in this range are
optimized for indoor use.
Industry Canada Notice to
Users
Industry Canada Notice
This device complies with Industry Canada
licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) This
device may not cause interference and (2) This
device must accept any interference, including
interference that may cause undesired operation of
the device. See RSS-Gen, Section 7.1.3. This
device complies with ICES-003 requirements for
Class B ITE (Information Technology Equipment).
CAN ICES-3 (B)/NMB-3(B)
Motorola Limited
Warranty
War ra nty
What Does this Warranty Cover?
Subject to the exclusions contained below,
Motorola Mobility LLC warrants its mobile
telephones (“Products”), Motorola-branded or
certified accessories sold for use with these
Products (“Accessories”), and Motorola software
contained on CD-ROMs or other tangible media
and sold for use with these Products (“Software”)
to be free from defects in materials and
workmanship under normal consumer usage for
the period(s) outlined below. This limited warranty
is a consumer's exclusive remedy, and applies as
follows to new Motorola Products, Accessories,
and Software purchased by consumers, which are
accompanied by this written warranty:
16 JULY 2014

18 Safety, Regulatory & Legal en
Products and Accessories
Exclusions (Products and Accessories)
Normal Wear and Tear. Periodic maintenance,
repair and replacement of parts due to normal
wear and tear are excluded from coverage.
Batteries. Only batteries whose fully charged
capacity falls below 80% of their rated capacity and
batteries that leak are covered by this limited
warranty.
Abuse & Misuse. Defects or damage that result
from: (a) improper operation, storage, misuse or
abuse, accident or neglect, such as physical
damage (cracks, scratches, etc.) to the surface of
the product resulting from misuse; (b) contact with
Products Covered Length of
Coverage
Products and
Accessories as
defined above,
unless otherwise
provided for below.
One (1) year from
the date of purchase
by the first consumer
purchaser of the
product unless
otherwise provided
for below.
Decorative
Accessories and
Cases. Decorative
covers, bezels, and
cases.
Limited lifetime
warranty for the
lifetime of ownership
by the first consumer
purchaser of the
product.
Monaural Headsets.
Ear buds and boom
headsets that
transmit mono sound
through a wired
connection.
Limited lifetime
warranty for the
lifetime of ownership
by the first consumer
purchaser of the
product.
Products and
Accessories thatare
Repaired or
Replaced.
The balance of the
original warranty or
for ninety (90) days
from the date
returned to the
consumer, whichever
is longer.
16 JULY 2014
