Motorola SURFboard SBV5122 Assembly instructions

SURFboard®SBV5122
Digital Voice Modem
To view the SBV5122 Digital Voice Modem User Guide, please visit the Motorola website at:
http://broadband.motorola.com/consumers/support/
Contact your VoIP
provider before
connecting your
Motorola SBV5122
Digital Voice Modem
to your existing
telephone wiring.
Connect each TEL port
to a telephone only,
never to a traditional
phone service.
Install Sheet

SURFboard®SBV5122
Digital Voice Modem
Install Sheet
Troubleshooting
The Problem The Solution
Green POWER light is OFF Check that the SBV5122 Digital Voice Modem is plugged into the AC adapter and wall outlet.
Cannot receive or send data If you have cable TV, check that your TV is working and the picture is clear.
If you cannot receive your regular TV channels, your data service will not function.
Check the coaxial cable connection to the SBV5122 Digital Voice Modem and wall outlet.
Hand-tighten if necessary.
Check that the Ethernet cable is properly connected to the SBV5122 Digital Voice Modem and your
computer.
Check the IP address by following the steps in “Verifying the IP Address” in the User Guide. On computers
using UNIX®or Linux®, you must have Adobe Acrobat Reader installed before opening the User Guide. Call
your cable provider if you need an IP address.
Check the lights on the front panel. Note the first light from top to bottom that is off. This light indicates
where the error occurred as described in Front-Panel Lights and Error Conditions in the User Guide.
This information is to help you quickly solve a problem. Before calling your service provider, try unplugging
and plugging in the cable modem power cord in the AC wall outlet to restart the cable modem.
