Operating Manual
motrona GmbH, Zeppelinstraße 16, DE - 78244 Gottmadingen, Tel. [phone], Fax [phone], [email protected], www.motrona.de
touchMATRIX®Indicator PN350
PROFINET display device with touch screen and graphic display
Product features:
•Multi-function display with PROFINET interface
•Operating modes for displaying two process values and links of the two values
(1+2, 1-2, 1x2, 1:2)
•PROFINET IO Device Conformance Class B
•Dual Port Ethernet with integrated switch
•Bright and high-contrast display with event dependent color variations
•Emulation of a 7-segment display inclusively icons and units
•Intuitive and easy parameterization by plain text and touch screen
•3.78 x 1.89 inch (96 x 48 mm) norm panel housing and IP65 protection
•Optional switching outputs
Available options:
PN350: Basic unit with PROFINET-interface
•Option AC: Power supply 115 … 230 VAC
•Option AO: 16 bit analog output, 4 control outputs, serial RS232 interface
•Option AR: 16 bit analog output, 4 control outputs, serial RS485 interface
•Option CO: 4 control outputs, serial RS232 interface
•Option CR: 4 control outputs, serial RS485 interface
•Option RL: 2relay outputs
Options can be combined

Pn350_01a_oi_e.docx / Mai-23 Seite 2 / 49
Die deutsche Beschreibung ist verfügbar unter:
https://www.motrona.com/fileadmin/files/bedienungsanleitungen/Pn350_d.pdf
The English description is available at:
https://www.motrona.com/fileadmin/files/bedienungsanleitungen/Pn350_e.pdf
La description en français est disponible sur:
https://www.motrona.com/fileadmin/files/bedienungsanleitungen/Pn350_f.pdf
The operator software OS (freeware) is available at:
https://www.motrona.com/en/support/software.html
Version:
Description:
PN350_01a_oi/TJ/mbo/May 23
First Version
Legal notices:
All contents included in this manual are protected by the terms of use and copyrights of motrona
GmbH. Any reproduction, modification, usage or publication in other electronic and printed media
as well as in the internet requires prior written authorization by motrona GmbH.

Pn350_01a_oi_e.docx / Mai-23 Seite 3 / 49
Table of Contents
Safety Instructions and Responsibility.......................................................................... 5
General Safety Instructions.............................................................................................................5
Use According to the Intended Purpose..........................................................................................5
Installation .......................................................................................................................................6
EMC Guidelines ...............................................................................................................................7
Cleaning, Maintenance and Service Notes.....................................................................................7
Introduction.................................................................................................................. 8
Operation Mode...............................................................................................................................8
Function Diagram.............................................................................................................................9
Electrical Connections................................................................................................ 10
DC Power Supply ...........................................................................................................................10
Auxiliary Voltage Output................................................................................................................10
PROFINET Interface........................................................................................................................11
LEDs .......................................................................................................................................... 11
PROFINET-Configuration........................................................................................................... 11
Process Data .............................................................................................................................12
Acyclic Data Exchange .............................................................................................................12
Control Inputs.................................................................................................................................13
Analog Output (Option AO/AR)......................................................................................................13
Serial Interface (Option AO/AR/CO/CR)........................................................................................14
Control Outputs (Option AO/AR/CO/CR) .......................................................................................14
AC Power Supply (Option AC)........................................................................................................15
Relay Outputs (Option RL)..............................................................................................................15
Display and Touch Screen .......................................................................................... 16
Screen Structure for Parameterization..........................................................................................16
Screen Structure in Operation.......................................................................................................17
Error Messages..............................................................................................................................18
Parameter / Overview –Menu Structure.................................................................... 20
General Menu ................................................................................................................................22
Fieldbus Properties ........................................................................................................................23
Linkage Properties .........................................................................................................................27
Preselection Values .......................................................................................................................28
Preselection 1 Menu......................................................................................................................29
Preselection 2 Menu......................................................................................................................31
Preselection 3 Menu......................................................................................................................32
Preselection 4 Menu......................................................................................................................33
Serial Menu ...................................................................................................................................34
Analog Menu .................................................................................................................................36
Command Menu.............................................................................................................................37
Display Menu.................................................................................................................................39
Appendix.................................................................................................................... 41
Data Readout via Serial Interface .................................................................................................41
Parameter/ Indices and Serial Codes............................................................................................42
Commands: ...............................................................................................................................45
Status Words:...........................................................................................................................45

Pn350_01a_oi_e.docx / Mai-23 Seite 4 / 49
Variables (Actual values):......................................................................................................... 46
Dimensions ....................................................................................................................................47
Technical Specifications................................................................................................................48

Pn350_01a_oi_e.docx / Mai-23 Seite 5 / 49
Safety Instructions and Responsibility
General Safety Instructions
This operation manual is a significant component of the unit and includes important rules and hints
about the installation, function and usage. Non-observance can result in damage and/or impairment
of the functions to the unit or the machine or even in injury to persons using the equipment!
Please read the following instructions carefully before operating the device and observe all safety
and warning instructions! Keep the manual for later use.
A pertinent qualification of the respective staff is a fundamental requirement in order to use this
manual. The unit must be installed, connected and put into operation by a qualified electrician.
Liability exclusion: The manufacturer is not liable for personal injury and/or damage to property and
for consequential damage, due to incorrect handling, installation and operation. Further claims, due to
errors in the operation manual as well as misinterpretations are excluded from liability.
In addition the manufacturer reserves the right to modify the hardware, software or operation manual
at any time and without prior notice. Therefore, there might be minor differences between the unit
and the descriptions in operation manual.
The raiser respectively positioner is exclusively responsible for the safety of the system and
equipment where the unit will be integrated.
During installation or maintenance all general and also all country- and application-specific safety
rules and standards must be observed.
If the device is used in processes, where a failure or faulty operation could damage the system or
injure persons, appropriate precautions to avoid such consequences must be taken.
Use According to the Intended Purpose
The unit is intended exclusively for use in industrial machines, constructions and systems. Non-
conforming usage does not correspond to the provisions and lies within the sole responsibility of the
user. The manufacturer is not liable for damages which have arisen through unsuitable and improper
use.
Please note that device may only be installed in proper form and used in a technically perfect
condition (in accordance to the Technical Specifications). The device is not suitable for operation in
explosion-proof areas or areas which are excluded by the EN 61010-1 standard.

Pn350_01a_oi_e.docx / Mai-23 Seite 6 / 49
Installation
The device is only allowed to be installed and operated within the permissible temperature range.
Please ensure an adequate ventilation and avoid all direct contact between the device and hot or
aggressive gases and liquids.
Before installation or maintenance, the unit must be disconnected from all voltage-sources. Further it
must be ensured that no danger can arise by touching the disconnected voltage-sources.
Devices which are supplied by AC-voltages must be connected exclusively by switches, respectively
circuit-breakers with the low voltage network. The switch or circuit-breaker must be placed as near as
possible to the device and further indicated as separator.
Incoming as well as outgoing wires and wires for extra low voltages (ELV) must be separated from
dangerous electrical cables (SELV circuits) by using a double resp. increased isolation.
All selected wires and isolations must be conformed to the provided voltage- and temperature-ranges.
Further all country- and application-specific standards, which are relevant for structure, form and
quality of the wires, must be ensured. Indications about the permissible wire cross-sections for wiring
are described in the Technical Specifications.
Before first start-up it must be ensured that all connections and wires are firmly seated and secured
in the screw terminals. All (inclusively unused) terminals must be fastened by turning the relevant
screws clockwise up to the stop.
Overvoltages at the connections must be limited to values in accordance to the overvoltage
category II.

Pn350_01a_oi_e.docx / Mai-23 Seite 7 / 49
EMC Guidelines
All motrona devices are designed to provide high protection against electromagnetic interference.
Nevertheless you must minimize the influence of electromagnetic noise to the device and all connected
cables.
Therefore the following measures are mandatory for a successful installation and operation:
•Use shielded cables for all signal and control input and output lines.
•Cables for digital controls (digital I/O, relay outputs) must not exceed a length of 30 m and are
allowed for in building operation only
•Use shield connection clamps to connect the cable shields properly to earth
•The wiring of the common ground lines must be star-shaped and common ground must be
connected to earth at only one single point
•The device should be mounted in a metal enclosure with sufficient distance to sources of
electromagnetic noise.
•Run signal and control cables apart from power lines and other cables emitting electromagnetic
noise.
Please also refer to motrona manual “General Rules for Cabling, Grounding, Cabinet Assembly”. You can
download that manual by the link
https://www.motrona.com/en/support/general-certificates.html
Cleaning, Maintenance and Service Notes
To clean the front of the unit please use only a slightly damp (not wet!), soft cloth. For the rear no
cleaning is necessary. For an unscheduled, individual cleaning of the rear the maintenance staff or
assembler is self-responsible.
During normal operation no maintenance is necessary. In case of unexpected problems, failures or
malfunctions the device must be shipped for back to the manufacturer for checking, adjustment and
reparation (if necessary). Unauthorized opening and repairing can have negative effects or failures to
the protection-measures of the unit.

Pn350_01a_oi_e.docx / Mai-23 Seite 8 / 49
Introduction
This series of display unit is suitable for PROFINET and panel mounting.
Two process data values transmitted by the PROFINET controller can be scaled, linked and displayed.
Due to the intuitive operation, the extensive functions and options, it can be used universally.
Basic knowledge of the function of PROFINET IO is required to commission the PROFINET display
device and to understand these operating instructions.
Operation Mode
All functions are can be configured in the parameter menu.
Optionally the two process data values or the linked value can be displayed.
The type of link is set via the operating mode.
The following operating modes can be set:
•VALUE1 + VALUE2:
The linked value is the sum of the two process data values.
•VALUE1 –VALUE2:
The linked value is the difference of the two process data values.
•VALUE1 x VALUE2:
The linked value is the product of the two process data values.
•VALUE1 / VALUE2:
The linked value is the quotient of the two process data values.

Pn350_01a_oi_e.docx / Mai-23 Seite 9 / 49
Function Diagram

Pn350_01a_oi_e.docx / Mai-23 Seite 10 / 49
Electrical Connections
The terminal screws should be tightened with a slotted screwdriver (blade width 2mm).
DC Power Supply
The unit accepts DC supply from 18 to 30 V at the terminals 1 and 2. The power consumption depends
on the level of the supply voltage with approx. 100 mA and the additional current required at the
Auxiliary Voltage Output.
All GND terminals are internally interconnected.
Auxiliary Voltage Output
Terminal 3 and 4 provide an auxiliary output for supply of sensors and encoders.
The output voltage depends on the power supply.
DC version
AC version
The encoder voltage is approx. 1 V lower than
the power supply voltage at terminal 1 and 2
and should be loaded with max. 250 mA
The encoder voltage is 24 VDC (± 15%) and
should be loaded with max. 150 mA up to 45
degrees Celsius. At higher temperature the
maximum output current is reduced to 80 mA.

Pn350_01a_oi_e.docx / Mai-23 Seite 11 / 49
PROFINET Interface
The PROFINET interface provides 2 RJ45 Ethernet connectors (Port 0 and 1) with an integrated switch
for full duplex communication up to 100 Mbit/s.
LEDs
Both ports have a yellow and a green status LED:
Green ("LINK") is on when an Ethernet connection has been established via the port.
Yellow ("ACTIVITY") flickers when data is being sent or received through the port.
Two red PROFINET status LEDs are located on the left side of the device behind the ventilation slots:
LED 0: off: Normal operation
flashing: Device identification by PROFINET service“DCP Signal“
on: Alarm pending (see error message on display)
LED 1: off: PROFINET communication running
flashing: Device has finished initialization, Ethernet link established,
Profinet communication not yet running.
on: Temporarily after power on (for some seconds): Initialization
Permanently: No Ethernet connection or device faulty.
These LEDs are not necessary for normal operation but may be helpful during commissioning.
PROFINET-Configuration
The PROFINET interface is described in the corresponding GSDML file "GSDML-V2.43-MOTRONA-
PN350-REPNS-xxxxxxxx".
The device has one single slot, to which the "PN350" module is dedicated. The module has a single
subslot with a fixed submodule.

Pn350_01a_oi_e.docx / Mai-23 Seite 12 / 49
Process Data
With the cyclic PROFINET communication, the PROFINET IO controller sends 9 bytes of process output
data to the PN350:
•Process Data Value 1, 4 bytes
•Process Data Value 2, 4 bytes
•Output Set Value, 1 byte
Process Data Value 1 and Process Data Value 2 can be scaled and provided with units using the
parameters in the "Fieldbus Properties" menu (chapter 5.2).
In addition, a so-called "Linkage value" is calculated from the two process data values. The linkage
value can be scaled separately and also provided with units. The type of link (+, -, x or /) is set with
the "Operational Mode" parameter in the General menu (chapter 5.1), while the scaling is set by the
parameters in the "Linkage Properties" menu (chapter 5.3).
The three scaled values can then optionally be displayed on the display, see sections “Display during
operation” (chapter 4.2) and “Display menu” (chapter 5.12). The digital control outputs and the analog
output can also be controlled by the three scaled values.
With the Output Set Value, you can switch directly those outputs that are not assigned to any
preselection switching condition (see parameter "Output Target ..." in chapter 5.5 ff). Bits 0…3 of
Output Set Value represent the Ctrl outputs Out 1…4 while bits 4 and 5 represent the relays Rel. 1
and Rel. 2.
The PN350 sends 17 bytes of process input data to the PROFINET IO controller:
•The scaled display value 1, 4 byte
•The scaled display value 2, 4 byte
•The scaled linkage value, 4 byte
•The actual value of the control inputs (Digital Input value), 4 Byte:
In this status value, bits 0…4 represent the inputs Ctrl. In 1…4.
(Bits 5…31 are not used and are fixed at 0)
•The actual value of the control outputs (Digital Output Value), 1 byte:
In this status byte, bits 0…3 represent the outputs Ctrl. Out 1…4 and bits 4 and 5 the relays Rel.
1 and Rel. 2.
Acyclic Data Exchange
With the acyclic PROFINET communication (Record Data Services), all device parameters of the PN350
can be accessed via slot 1 / subslot 1. All parameter values are signed 32-bit values (4 bytes). The
index of each individual register you can find in the parameter tables in Chapter 6.2.

Pn350_01a_oi_e.docx / Mai-23 Seite 13 / 49
Control Inputs
Five control inputs with HTL-PNP characteristics are available at terminals 5, 7, 10, 11 and 12
Three of these inputs (Ctrl.In 1…3) are configurable in the COMMAND MENU and can be used for
externally triggered functions such as switching the display, locking the touch screen or enabling the
latching of control and relay outputs.
Wiring of the control inputs:
Open control inputs are always "LOW".
The input stages are designed for electronic control signals.
Analog Output (Option AO/AR)
A 16 bit analog output is available at terminal 13 and 14 / 15
This output can be configured and scaled in the ANALOG MENU.
The following configuration is possible:
•Voltage output: -10 … +10 V
•Current output: 0 … 20 mA
•Current output: 4 … 20 mA
The analog output is proportional to the reference source and is referenced to potential AGND.
AGND and GND are internally interconnected.
Important:
A parallel operation with voltage and current output at the analog output is not allowed!

Pn350_01a_oi_e.docx / Mai-23 Seite 14 / 49
Serial Interface (Option AO/AR/CO/CR)
A serial interface (RS232 or RS485) is available at terminal 16, 17 und 18.
This interface can be configured in the SERIAL MENU.
The serial interface RS232 or RS485 can be used:
•for easy setup and commissioning of the units
•to modify settings and parameters during operation
•to read out internal states and actual measuring values by PC or PLC
The following drawing shows the connection to a PC by using a standard Sub-D-9 connector:
Connection of the RS232 interface:
Connection of the RS485 interface:
Control Outputs (Option AO/AR/CO/CR)
Four control outputs are available at terminal 20, 21, 22 and 23.
Switching conditions can be set in the PRESELECTION MENU. The output Ctrl. Out1 –4 are fast PNP
outputs with a switching capability of 5 –30 Volt / 200 mA per channel. The switching states is
displayed (display with unit and status bar) as C1 … C4.
The switching voltage of the outputs must be applied to input terminal 19 (COM+).
In case of switching inductive loads, it is advisable to use external filtering of the coils.

Pn350_01a_oi_e.docx / Mai-23 Seite 15 / 49
Wiring of the control outputs:
AC Power Supply (Option AC)
The unit accepts AC supply from 115 to 230 V at the terminals 24 and 25. The power consumption
depends on the level of the supply voltage with approx. 3VA and the additional current required at the
auxiliary voltage output.
Devices with option AC can also be supplied with a DC voltage between 18 and 30 VDC at terminals 1
and 2.
Relay Outputs (Option RL)
Two relay outputs with potential-free changeover contacts are available at terminal 27, 28, 28, 30, 31,
32. Switching conditions can be set in the PRESELECTION MENU. The switching state is displayed
(display with unit and status bar) as K1 and K4.
AC-switching capacity max. 250 VAC/ max. 3 A / 750 VA
DC-switching capacity max. 150 VAC/ max. 2 A / 50 W
Wiring of the relay outputs:

Pn350_01a_oi_e.docx / Mai-23 Seite 16 / 49
Display and Touch Screen
Screen Structure for Parameterization
The parameter menus and the parameters are described in chapter 5.
Start setup procedure:
To edit the parameters,
press the touch screen for 3 seconds.
Menu selection:
Select the parameter menu via arrow buttons
and confirm with “OK”.
The menu selection can be terminated
with „C“.
Parameter selection:
Select the parameter via arrow buttons and
confirm with „OK“.
The parameter selection can be terminated with
„C“.
Parameter editing:
Edit the parameter via arrow button up and
down, shift cursor via left and right and save
with „OK“.
The parameter editing can be terminated with
„C“.
Parameter changes becomes active only after closing the menu selection.

Pn350_01a_oi_e.docx / Mai-23 Seite 17 / 49
Screen Structure in Operation
During operation, either the two process data values and/or the linked value can be displayed.
The values to be displayed are selected in the display menu.
The following displays are available:
Display of a value with unit and status bar
To switch to the next display,
press the touch screen.
Control or Relay status are only displayed with
Option CO, CR, AO, AR or RL.
Two-line display of two values without units
To switch to the next display, press the top of
the screen.
Two-line display of two values with units
To switch to the next display, press the top of
the screen.
Large display (4-digits)
To switch to the next display, press the top of
the screen.
This is only possible with activated parameter
„LARGE DISPLAY“.
Display with command keys
To switch to the next display, press the top of
the screen or “SKIP”.

Pn350_01a_oi_e.docx / Mai-23 Seite 18 / 49
Continuation “Screen Structure in Operation“:
Display for quick start for enter preselection
values (PRESELECTION VALUES)
To switch to the next display, press the top of
the screen or “SKIP”.
This is only possible with option CO, CR, AO,
AR or RL.
Display with minimum and maximum values
To switch to the next display, press the top of
the screen or “SKIP”.
If there is no valid display value because the cyclic PROFINET data exchange has not yet started,
dashes ("--------") are displayed instead of the respective display value.
Error Messages
ERROR: FB VALUE 1 OUT OF RANGE
The value range of process data value 1 has been
exceeded.
ERROR: FB VALUE 2 OUT OF RANGE
The value range of process data value 2 has been
exceeded.
ERROR: LINK.RESULT OUT OF RANGE
The value range of the linked display value has
been exceeded

Pn350_01a_oi_e.docx / Mai-23 Seite 19 / 49
Continuation “Error Messages“:
ERROR: LARGE DI. OUT OF RANGE
The value range of the large display has been
exceeded
All error messages are displayed flashing.
A corresponding diagnostic alarm is sent via PROFINET for each error message
The error messages described are automatically reset as soon as the corresponding
display value is back in the displayable range.

Pn350_01a_oi_e.docx / Mai-23 Seite 20 / 49
Parameter / Overview –Menu Structure
The parameterization of the device is realized via the serial interface with a PC and the operating
software OS. The link to the free download can be found on page 2.
This section provides an overview of the menus and their parameters. The menu names are printed
bold and the associated parameters are listed under the menu name.
Menu / Parameter
GENERAL MENU
OPERATIONAL MODE
ENCODER SUPPLY
PIN PRESELECTION
PIN PARAMETER
FACTORY SETTINGS
FIELDBUS PROPERTIES
IN1 FACTOR
IN1 DIVIDER
IN1 ADDITIVE VALUE
IN1 DECIMAL POINT
IN1 SCALE UNIT
IN2 FACTOR
IN2 DIVIDER
IN2 ADDITIVE VALUE
IN2 DECIMAL POINT
IN2 SCALE UNIT
(FB VALUE IN 0)*
(FB VALUE IN 1)*
(FB VALUE IN 2)*
(FB VALUE IN 3)*
(FB VALUE OUT 0)*
(FB VALUE OUT 1)*
(FB VALUE OUT 2)*
(FB VALUE OUT 3)*
LINKAGE PROPERTIES
FACTOR
DIVIDER
ADDITIVE VALUE
DECIMAL POINT
SCALE UNIT
*) Not visible in the menu
Menu / Parameter
PRESELECTION VALUES
PRESELECTION 1
PRESELECTION 2
PRESELECTION 3
PRESELECTION 4
PRESELECTION 1 MENU
SOURCE 1
MODE 1
HYSTERESIS 1
PULSE TIME 1
OUTPUT TARGET 1
OUTPUT POLARITY 1
OUTPUT LOCK 1
START UP DELAY 1
EVENT COLOR 1
PRESELECTION 2 MENU
SOURCE 2
MODE 2
HYSTERESIS 2
PULSE TIME 2
OUTPUT TARGET 2
OUTPUT POLARITY 2
OUTPUT LOCK 2
START UP DELAY 2
EVENT COLOR 2
PRESELECTION 3 MENU
SOURCE 3
MODE 3
HYSTERESIS 3
PULSE TIME 3
OUTPUT TARGET 3
OUTPUT POLARITY 3
OUTPUT LOCK 3
START UP DELAY 3
EVENT COLOR 3
