Movement RTS User manual

INSTRUCTION MANUAL
PLEASE READ THIS MANUAL CAREFULLY
BEFORE USING THE EQUIPMENT AND KEEP IT FOR FUTURE REFERENCE

EXPLANATION OF SYMBOLS
03
CAUTION!
A statement proceeded with the word "CAUTION" contains information that
should be followed in order to avoid some damage to the product.
Keep this Manual to consult in the future.
MAX
150kg
This sticker indicates some caution when using the equipment:
- Do not exceed the maximum capacity of use of 150kg;
-Do not allow children to approach or use the equipment;
-Read and understand the user's instruction manual;
- Danger to use equipment improperly, may cause harm to the user.
Risk of serious injury to the user or third parties if hands are placed on the
pedals of the equipment in use.
- Risk of crushing. Do not place your hand between the movable arm and
the handrail.

INDEX
INTRODUCTION............................................................................................................05
SAFETY INFORMATION.................................................................................................08
GETTING KNOW THE EQUIPMENT.................................................................................11
EQUIPMENT ASSEMBLY.................................................................................................15
OPERATIONAL INSTRUCTIONS......................................................................................39
MAINTENANCE.............................................................................................................51
WARRANTY...................................................................................................................55

INTRODUCTION
05
WELCOME TO MOVEMENT!
Congratulations, now you are part of the world of MOVEMENT!
With the goal of offering products, services and innovative solutions that meet
the needs of leisure, well-being and comfort, waking people up to a more
pleasurable and healthy life, Brudden Equipment Ltd has created the
MOVEMENT brand.
Established to develop and produce gym equipment, the Movement logo
stands out in the Brazilian market for its tradition of practicality and durability,
which makes Brudden a quality icon in the sports equipment market.
With a lot of investment in research and development having worked with
renown institutions, such as the School of Physical Education and Sports from
the University of São Paulo - EEFE/USP, Movement has been promoting
improvements in people's quality of life for those from all walks of life that have
the most different profiles and habits. It also has a strong presence in:
households, Townhouses, Gyms, Clubs, Hotels, Clinics, Companies, and
Organizations.
The quality in equipment extends to services provided by its broad service
network and Authorized Points distributed throughout the country, bringing
Movement closer to you and your family for a more profitable and practical life
for our investors and a more enjoyable and healthier life for those who train on
our equipment.
To confirm the MOVEMENT Warranty, register your equipment on the website
at www.movement.com.br/garantia.
The registration is free, fast and practical. It will allow for a greater coverage of
your investment, facilitating our communication and speeding up eventual
service orders or technical assistance.
According to the instruction , the absence of registration will harm yourguide
warranty right. For more information, see page 56 of this manual.
Access our website and check to see more on what our company offers to
improve the quality of your life.

SAFETY INFORMATION

SAFETY INFORMATION
08
DANGER!
•Improper use of this piece of equipment can turn it into a danger object
which may cause serious injuries or even death to the user. For this reason it is
of the utmost importance that the user read and understand this Manual.
•Before using the equipment, read this Manual carefully, making sure it is
correctly installed and used, otherwise serious injury or death will occur.
•It is the buyer's sole for the MOVEMENT's products to readRESPONSIBILITY
the instructions and the equipment's sticker warnings. It is also theguide
buyer's responsibility to instruct end users on the correct use of the
equipment.
•The users must be supervised by a qualified professional, and it is up to the
buyer to instruct them correctly. The use of equipment contrary to that which
has been indicated in this Manual, may cause accidents to the users.
•This equipment has not been designed for people with physical, sensory or
mental disorders or for those who lack experience or knowledge unless they
have received instructions in relation to the use of the equipment and they
are under the supervision of an instructor.
•UNDERSTANDING each warning sticker is important. If you have any queries,
contact our central customer service line on 0800 772 40 80.
•NEVER allow two people to use the equipment at the same time.
•Do not allow third parties to be near the equipment. Risk of accidents
•Never place your hand and arm between the elliptical pedals and the fairing
and between the movable arms and the handrail when the equipment is
being used, whether it is for the user or for third parties.
•Keep both the floor surrounding the elliptical, and the seat and the pedals
always dry and clean, avoiding slips and falls that may result in serious
injuries.
•To enter the equipment use the handrail support.

SAFETY INFORMATION
09

GETTING TO KNOW THE EQUIPMENT

GETTING KNOW THE EQUIPMENT
OBJECTIVE
The elliptical RTS is intended for the physical conditioning of the user through
movements on the elliptical. The RTS elliptical has an electric motor that regulates the
resistance, so that the exercise is executed with high performance.
This equipment consists of the following main components:
12
Display
Movable Handlebar
Movable Handlebar
Heart rate
monitor / Handlebar
Front Fairing
Pedal
Heart rate
monitor / Handlebar
Bottle holder
Rear Fairing Handrail
Handrail
Handrail Fairing
Pendulum
Pendulum
167 cm
180,5 cm 78,5 cm
MAX
150kg

EQUIPMENT TECHNICAL SHEET
13
GETTING TO KNOW THE EQUIPMENT
MULTIFUNCTIONAL MODULE
TRAINING PROGRAMS
FACILITIES
HEART RATE
STRUCTURE
USE CAPACITY
WEIGHT
LANGUAGES
RESISTANCE SYSTEM
RESISTANCE LEVELS
MAXIMUM LOAD
USER HEIGHT
TRANSPORT
WARRANTY
POWER
6 LCD windows with backlight
7 training programs
1.5 to 2.0 meters
Accessories compartment and cup holder
Heart and Thoracic Belt Sensors
Steel frame with electrostatic powder
coating
150 kg
180,5 X 78,5 X 167,0 cm
146 kg
Portuguese
Magnetic
24 levels
Front base with wheels
See warranty chapter
Self-Powered System
Minimum load of 9,2 Watts at 25 RPM
Maximum load of 521,4 Watts at 120 RPM
STEP DIMENSIONS 52,5 X 15,3 cm

EQUIPMENT ASSEMBLY

EQUIPMENT ASSEMBLY
ICONS
50% 100%
Do not give
final tightening
of the screws
Give the final
tightening
of the screws
16
Assemble with
two or more
people
Assemble with two
or more people
Allen no.5
Allen no.8
Allen no.10
Threaded lock
average torque
Fixed wrench 13
Fixed wrench 17
Fixed wrench 19
Screwdriver
Philips
Diameter [mm] Torque [N.m]
M6
M8
M10
9-12
22-29
45-58
In order to assemble the equipment
the following tools are needed:
M12 78-102

EQUIPMENT ASSEMBLY
17
DESCRIPTION
A - Left Movable Handlebar
DESCRIPTION
B - Right Movable Handlebar
DESCRIPTION
C - Left handrail
DESCRIPTION
E - Front fairing
DESCRIPTION
G - Rear fairing
DESCRIPTION
H - Pendulum
DESCRIPTION
I - Side fairing
DESCRIPTION
F - Electronic module support
DESCRIPTION
L - Left Pedal
DESCRIPTION
M - Right Pedal
DESCRIPTION
D - Right handrail
DESCRIPTION
J - Left Pedal support
DESCRIPTION
K - Right support
DESCRIPTION
N - Limiter
LIST OF COMPONENTS - RTS

EQUIPMENT ASSEMBLY
18
PARTS LIST
DESCRIPTION
A - Left Movable Handlebar
ICONS
Assemble with
two or more
people
ICONS
A
SELF-ADJUSTING
BAERING
To avoid damaging the bearings
of the movable arm during assembly.
OBS: Unstable piece
Self-adjusting
bearings
maintenance table
pg. 53
ATTENTION!
CAUTION!
Assemble with
two or more
people
STEP 1 - RTS

EQUIPMENT ASSEMBLY
19
PARTS LIST
DESCRIPTION
1 - Screw Cab. Cil.
Hext. Int. - M10X80 1x
DESCRIPTION
2 - Screw Cab.
Hexagonal - M10X60 2x
DESCRIPTION
3 - Spacer 2x
DESCRIPTION
4 - Nut Hex. Insert.
Nylon. - M10 2x
100%
ICONS
Assemble with
two or more
people
TOOLS
Fixed
Wrench 17
Allen
Wrench no.8
DESCRIPTION
C - Left handrail
ATTENTION!
Make sure the spacers (Item 3)
are mounted to prevent damage
to the equipment
Medium torque
thread lock
QTY.
QTY.
QTY. QTY.
STEP 2 - RTS
4
3
1
C
2
TORQUE
SCREW TORQUE 45-58 N.m
1
SCREW TORQUE 45-58 N.m
2

EQUIPMENT ASSEMBLY
20
DESCRIPTION
B - Right Movable Handlebar
ICONS
Assemble with
two or more
people
B
SELF-ADJUSTING
BAERING
To avoid damaging the bearings
of the movable arm during assembly.
OBS: Unstable piece
Self-adjusting
bearings
maintenance table
pg. 53
ATTENTION!
CAUTION!
STEP 3 - RTS
