Moxa Technologies AWK-3252A Series User manual

P/N: 1802032520010
*1802032520010*
AWK-3252A Series
Quick Installation Guide
Moxa AirWorks
Version 1.0, December 2021
Technical Support Contact Information
www.moxa.com/support

2021 Moxa Inc. All rights reserved.

- 2 -
Overview
The AWK-3252A Series is an industrial-grade AP/bridge/client with IEEE
802.11ac Wave 2 technology. This Series features concurrent dual-band
Wi-Fi data transmissions up to 400 Mbps (2.4 GHz mode) and 867 Mbps
(5 GHz mode) simultaneously, meeting the speed and flexibility
requirements for industrial applications. In addition, the built-in dual
band pass filter and the wide-temperature design ensure the reliability
and continuous operation in harsh environments. The dual redundant
DC power inputs enhance availability while PoE support provides more
flexibility for powering end devices and simplifying field-site
deployments. Meanwhile, backwards compatibility with 802.11a/b/g/n
makes the AWK-3252A the ideal solution for constructing a versatile
wireless data transmission system.

- 3 -
Panel Layout of the AWK-3252A
1. Grounding screw (M5)
2. Terminal blocks for PWR1,
PWR2, relay, DI 1 and DI 2
3. Reset button
4. Antenna connector A
5. System LEDs: PWR1, PWR2,
PoE, 2.4GHz, 5GHz, SYSTEM
6. USB host (type A for ABC-02)
7. Console port (RS-232, RJ45)
8. LAN1 (PoE), LAN 2 ports
(10/100/1000BaseT(X) ports,
RJ45)
9. Antenna connector B
10. Model name
11.
Screw holes for wall-
mounting
kit
12.
DIN-rail mounting kit
13.
Cable holder screw

- 4 -
Mounting Dimensions
DIN-Rail Mounting
When shipped, the metal DIN-rail mounting kit is fixed to the back
panel of the AWK-3252A. Mount the AWK-3252A on to a corrosion-free
mounting rail that adheres to the EN 60715 standard.
STEP 1:
Insert the upper lip of the DIN
-rail
kit into the
mounting rail.
STEP 2:
Press the
AWK-3252A towards the
mounting rail until it snaps into
place.

- 5 -
To remove the AWK-3252A from the DIN rail, do the following:
STEP 1:
Pull down the latch on the DIN
-
rail kit with a screwdriver.
STEP 2 & 3:
Slightly pull the
AWK-3252A
forward and lift it up to remove
it from the mounting rail.
Wall Mounting (Optional)
For some applications, it may be more convenient to mount the AWK-
3252A to a wall, as illustrated below.
STEP 1:
Remove the aluminum DIN-
rail attachment plate from
the
AWK-3252A, and then
attach the wall
-mounting
plates with M3 screws, as
shown in the adjacent
diagrams.
STEP 2:
Mounting the
AWK-3252A to a wall requires 3 screws.
Use
the AWK-3252A device, with wall-mounting plates
attached, as a guide to mark the correct locations of
the 3 screws. The heads of the screws should be less
than 6.0 mm in diameter, and the
shafts should be less
than 3.5 mm in diameter, as shown in the figure on the
right.
Do not drive the screws in all the way—leave a space of about 2 mm to
allow room for sliding the wall-mounting panel between the wall and
the screws.
NOTE
Test the screw head and shank size by inserting the screws
into
one of the keyhole shaped apertures of the w
all-mounting
plates before they are fixed to the wall.

- 6 -
STEP 3:
Once the screws are fixed into the
wall, insert the four screw heads
through the large opening of the
keyhole
-shaped apertures, and then
slide the
AWK-3252A downwards, as
indicated to the ri
ght. Tighten the
three screws for added stability.
WARNING
•
This equipment is intended to be used in a Restricted
Access Location, such as a dedicated computer room
where
only authorized service personnel or
users can gain access.
Such personnel must be instructed about the fact that the
metal chassis of the equipment is extremely hot and may
cause burns.
•
Service personnel or users have to pay special attention
and take special precautions before handling this
equipment.
•
Only authorized, well-trained professionals should be
allowed to access the restricted access location. Access
should be controlled by the authority responsible for the
location with lock and key or a security identity system.
•
External metal parts are hot!! Pay special attention or
use special protection before handling the equipment.
Wiring Requirements
WARNING
Safety First!
Be sure to disconnect the power cord before installing and/or
wiring your
AWK-3252A.
Calculate the maximum possible current in each power wire
and common wire. Observe all electrical codes that dictate the
maximum current allowed for each wire size. If the
current
goes above the maximum ratings, the wiring could overheat,
causing serious damage to your equipment.
Read and Follow These Guidelines:
•Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the crossing point.
NOTE
Do not run signal or communications wiring and power wiring in
the same wire co
nduit. To avoid interference, wires with
different signal characteristics should be routed separately.

- 7 -
•You can use the type of signal transmitted through a wire to
determine which wires should be kept separate. The rule of thumb
is that wiring that shares similar electrical characteristics can be
bundled together.
•Keep input wiring and output wiring separated.
•For future reference, you should label the wiring used for all of your
devices.
ATTENTION
This product is intended to be supplied by a Listed Power Unit
marked “Class 2” or “LPS” and rated O/P: 22 W
ATTENTION
Make sure
the external power adapter (includes power cords
and plug assemblies) provided with the unit is certified and
suitable for use in your country.
ATTENTION
DO NOT
use a PoE Injector. Instead, use an IEEE 802.3af or
IEEE 802.3at compliant PSE (Power Sourcing Equipment) for
PoE (Power over Ethernet) devices.
Grounding the AWK-3252A
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from
the ground screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well
-grounded
mounting surface,
such as a metal panel. The potential
difference between any two
grounding points must be zero. If
the potential difference is NOT zero, the product could be
permanently damaged.
Installations with Cable Extended Antennas for Outdoor
Applications
If an AWK device or its antenna is installed in an outdoor location,
proper lightning protection is required to prevent direct lightning strikes
to the AWK device. In order to prevent the effects of coupling currents
from nearby lightning strikes, a lightning arrester should be installed as
part of your antenna system. Ground the device, antenna, as well as
the arrester properly to provide maximum outdoor protection for the
device.

- 8 -
Arrester Accessories
•SA-NMNF-02: Surge arrester, N-type (male) to N-type (female)
•SA-NFNF-02: Surge arrester, N-type (female) to N-type (female)
Terminal Block Pin Assignment
The AWK-3252A comes with a 10-pin terminal block located on the top
panel of the device. The terminal block contains dual power inputs, a
relay output, and dual digital inputs. Refer to the following figure and
table for the detailed pin assignment.
Pin
Definition
1
DC Power Input 1
2
3
DC Power Input 2
4
5
Relay Output
6
7
Digital Input 1
8
Digital Input GND
9
Digital Input 2
10
Digital Input GND
Wiring the Redundant Power Inputs
The top two pairs of contacts of the 10-contact terminal block
connector on the AWK-3252A’s top panel are used for the AWK-3252A’s
two DC inputs. The top view of the terminal block connector is shown
below.

- 9 -
STEP 1: Insert the negative/positive DC wires
into the
+/- terminals.
STEP
2: Insert the plastic terminal block
connector prongs into the terminal block
receptor, which is
located on the AWK-3252A’s
t
op panel.
NOTE
Input Terminal Block (CN1) is suitable for wire size range of 16-
28 AWG (1.318-0.0804 mm²).
ATTENTION
If the
AWK-3252A
is connected to a motor or other similar type
of equipment, be sure to use power isolation protection. Before
connecting the
AWK-3252A to the DC power inputs, make sure
the DC power source voltage is stable.
Wiring the Relay Contact
The AWK-3252A has one relay output, which consists of the two
contacts of the terminal block on the AWK-3252A’s top panel. Refer to
the previous section for detailed instructions on how to connect the
wires to the terminal block connector, and how to attach the terminal
block connector to the terminal block receptor. These relay contacts are
used to indicate user-configured events. The two wires attached to the
Relay contacts form an open circuit when a user-configured event is
triggered. If a user-configured event does not occur, the Relay circuit
will be closed.
Wiring the Digital Inputs
The AWK-3252A has two sets of digital inputs—DI1 and DI2. Each DI
comprises two contacts of the 10-pin terminal block connector on the
AWK-3252A’s top panel. Refer to the “Wiring the Redundant Power
Inputs” section for detailed instructions on how to connect the wires to
the terminal block connector, and how to attach the terminal block
connector to the terminal block receptor.
Cable Holder Installation
Attach the cable holder to the bottom of the AWK-3252A to keep
cabling neat and avoid accidents that result from untidy cables.

- 10 -
STEP 1: Screw the cable holder onto the bottom
of the
AWK-3252A.
STEP 2:
After mounting the AWK-3252A
and plugging in the LAN cable,
tighten the cable along the device and wall.
Communication Connections
10/100/1000BaseT(X) Ethernet Port Connection
The 10/100/1000BaseT(X) ports located on the AWK-3252A’s front
panel are used to connect to Ethernet-enabled devices.
MDI/MDI-X Port Pinouts
Pin
1000BaseT
MDI/MDI-X
10/100BaseT
(X)
MDI
10/100BaseT
(X)
MDI-X
1
TRD(0)+
TX+
RX+
2
TRD(0)–
TX-
RX-
3
TRD(1)+
RX+
TX+
4
TRD(2)+
--
--
5
TRD(2)-
--
--
6
TRD(1)-
RX-
TX-
7
TRD(3)+
--
--
8
TRD(3)-
--
--
RS-232 Connection
The AWK-3252A has one RS-232 (8-pin RJ45) console port located on
the front panel. Use either an RJ45-to-DB9 or RJ45-to-DB25 cable to
connect the AWK-3252A’s console port to your PC’s COM port. You may
then use a console terminal program to access the AWK-3252A for
console configuration.

- 11 -
Pin
Description
1
DSR
2
NC
3
GND
4
TXD
5
RXD
6
NC
7
NC
8
DTR
LED Indicators
The front panel of the AWK-3252A contains several LED indicators. The
function of each LED is described in the table below:
LED
Color
State
Description
Front Panel LED Indicators (System)
PWR1 Green
On
Power is being supplied from
power input 1.
Off Power is not being supplied
from power input 1.
PWR2 Green
On
Power is being supplied from
power input 2.
Off
Power is not being supplied
from power input 2.
PoE Amber
On Power is being supplied via
PoE.
Off Power is not being supplied
via PoE.
SYS
Red On
System initialization failure,
configuration error, or
system error. Refer to the
AWK-3252A User’s Manual
for more details.
Green On System startup completed
and is operating normally.
2.4G
Green
On
Client/Client-Router/Slave
has established a Wi-Fi
connection to an AP/Master
with a SNR value of 35 or
higher.
Blinking
Data is being transmitted
over the 2.4 GHz band.
Amber
On
Client/Client
-Router/Slave
has established a Wi
-Fi
connection to an AP/Master
with a SNR value of less than
35.
Blinking
Data is being transmitted
over the 2.4 GHz band.
5G Green
On
Established a Wi-Fi
connection to an AP/Master
with a SNR value of 35 or
higher.

- 12 -
Blinking
Data is being transmitted
over the 5 GHz band.
Amber
On
Established a Wi-Fi
connection to an AP/Master
with a SNR value of less than
35.
Blinking
Data is being transmitted
over the 5 GHz band.
LAN LED Indicators (RJ45 Port)
LED
Color
State
Description
LAN 1
Green
On
LAN port’s 1000 Mbps link is active.
Blinking
Data is being transmitted at 1000
Mbps.
Off LAN port’s 1000 Mbps link is
inactive.
Amber
On LAN port’s 10/100 Mbps link is
active.
Blinking
Data is being transmitted at 10/100
Mbps.
Off
LAN port’s 10/100 Mbps link is
inactive.
LAN 2
Green
On
LAN port’s 1000 Mbps link is active.
Blinking
Data is being transmitted at 1000
Mbps.
Off
LAN port’s 1000 Mbps link is inactive.
Amber
On
LAN port’s 10/100 Mbps link is active.
Blinking
Data is being transmitted at 10/100
Mbps.
Off
LAN port’s 10/100 Mbps link is
inactive.
Specifications
Input Current
2 A @ 12 VDC; 0. 5 A @ 48 VDC
Input Voltage 12 to 48 VDC, redundant dual power inputs,
48 VDC Power over Ethernet
Power Consumption
22 W (max.)
Operating Temperature Standard Models: -25 to 60°C (-13 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to
167°F)
Storage Temperature
-40 to 85°C (-40 to 185°F)
NOTE
To meet the standard for IP30 protection, all unused ports
should be covered with the protective caps.

- 13 -
ATTENTION
The
AWK-3252A
is NOT a portable mobile device and should be
located at least 20 cm away from the human body.
The
AWK-3252A is NOT designed for the general public. To
en
sure that your AWK-3252A wireless network is safe and
configured correctly, consult a well
-trained technician to assist
with the installation process.
ATTENTION
Use the
appropriate antennas for your wireless setup: Use 2.4
GHz antennas when the
AWK-3252A is configured for IEEE
802.11b/g/n.
Use 5 GHz antennas when the AWK-3252A is
configured for
IEEE 802.11a/n/ac
. Make sure that the antennas
are
located in an area with a lightning and surge protection
system installed.
ATTENTION
This device complies with part 15 of the FCC Rules.
Operation i
s
subject to the following
two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
ATTENTION
Do not locate the antenna near overhead power lines or other
electric light or power circuits, or where it can come into
contact with such circuits. When installing the antenna, take
extreme care not
to come into contact with such circuits,
because they may cause serious injury or death. For proper
installation and grounding of the antenna, refer to national and
local co
des (for example, U.S.: NFPA 70; National Electrical
Code (NEC) Article 810;
Canada: Canadian Electrical Code,
Section 54).
NOTE
For installation flexibility, either the antenna 1 or antenna 2
may be selected for use. Make sure the
antenna connection
matches the antenna
s configured in the AWK-3252A web
interface.
To protect the connectors and RF module, all radio ports should
be terminated by either an antenna or a terminator.
We
strongly recommend using resistive terminators for terminating
the unused antenna ports.

APPENDIX
Federal Communication Commission Interference
Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, maycause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution
To assure continued compliance, (example - use only shielded interface cables when connecting to
computer or peripheral devices) any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
IMPORTANT NOTE
This device is restricted to mobile configuration. To comply with FCC RF exposure compliance
requirements, the antenna used for this transmitter must be installed to provide a separation distance
of at least 50 cm from all persons and must not be co-located or operating in conjunction with any other
antenna or transmitter. This device must not be co-located or operating in conjunction with any other
antenna or transmitter
CAUTION
Any changes or modifications not expressly approved by the grantee of this device could void the user's
authority to operate the equipment.
Information for the OEMs and Integrators
The following statement must be included with all versions of this document supplied to an
OEM or integrator, but should not be distributed to the end user.
1) This device is intended for OEM integrators only.
2) Please see the full Grant of Equipment document for other restrictions.
This radio transmitter FCC ID: SLE-WAPC003 has been approved by FCC to operate with the antenna

types listed below with the maximum permissible gain and required antenna impedance for each
antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum
gain indicated for that type, are strictly prohibited for use with this device.
Professional installation
This is a specific product that requires professional installation and configuration, must be performed by
trained technical engineers to install the antenna, please contact Moxa for furtherinformation.
The availability of some specific channels and / or operational frequency bands are country dependent
and are firmware programmed at factory to match the intended destination. The firmware setting is not
accessible by the end user.
Antenna List
Item
Manufacturer
Model name
Type
2.4GHz Gain
5GHz Gain
1
MOXA
ANT-WDB-ANM-0306
Dipole
3.80 dBi
6.3 dBi
2
MOXA
ANT-WDB-ANM-0502
Dipole
4.62 dBi
1.41 dBi
3
MOXA
ANT-WDB-ARM-02
Dipole
2.04 dBi
0.81 dBi
4
MOXA
ANT-WDB-ARM-0202
Dipole
1.80 dBi
1.8 dBi
5
MOXA
ANT-WSB-AHRM-05-1.5m
Dipole
5.00 dBi
-
6
MOXA
MAT-WDB-CA-RM-2-0205
Dipole
2.50 dBi
5.7 dBi
7
MOXA
MAT-WDB-DA-RM-2-0203-1m
Dipole
2.45 dBi
2.72 dBi
8
MOXA
MAT-WDB-PA-NF-2-0708
Panel
7.63 dBi
8.77 dBi
9
MOXA
ANT-WDB-PNF-1011
Panel
10.33 dBi
12.04 dBi
10
MOXA
ANT-WDB-ONM-0707
Dipole
7.10 dBi
7.6 dBi
11
MOXA
ANT-WDB-ONF-0709
Dipole
7.40 dBi
8.87 dBi
12
MOXA
ANT-WSB5-PNF-16
Panel
-
16.94 dBi
13
MOXA
ANT-WSB-PNF-12-02
Panel
12.34 dBi
-
maximum conduct output power:
Antenna TYPE: Dipole: 2.4G : 0.7211W, 5G: 0.4819W
Antenna TYPE: Panel: 2.4G: 0.6194W, 5G: 0.4819W

Canada, Innovation, Science and Economic Development
Canada (ISED) Notices
CAN ICES-003 (A)/NMB-003(A)
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two
conditions:
This device may not cause interference.
This device must accept any interference, including interference that may cause undesired operation of
the device.
Avis du Canada, Innovation, Sciences et Développement économique Canada (ISED)
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR
d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
(1) L’appareil ne doit pas produire de brouillage;
(2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible
d’en compromettre le fonctionnement.
Radio Frequency (RF) Exposure Information
The radiated output power of the Wireless Device is below the Innovation, Science and Economic
Development Canada (ISED) radio frequency exposure limits. The Wireless Device should be used in
such a manner such that the potential for human contact during normal operation is minimized.
This device has also been evaluated and shown compliant with the ISED RF Exposure limits under
mobile exposure conditions. (antennas are greater than 50 cm from a person's body).
Informations concernant l'exposition aux fréquences radio (RF)
La puissance de sortie rayonnée du dispositif sans fil est inférieure aux limites d'exposition aux
radiofréquences d'Innovation, Sciences et Développement économique Canada (ISED). Le dispositif
sans fil doit être utilisé de manière à minimiser le potentiel de contact humain pendant le
fonctionnement normal.
Cet appareil a également été évalué et montré conforme aux limites d'exposition RF ISED dans des
conditions d'exposition mobiles. (Les antennes sont à plus de 50 cm du corps d'une personne).
This radio transmitter IC: 9335A-WAPC003 has been approved by Innovation, Science and Economic
Development Canada to operate with the antenna types listed below, with the maximum permissible
gain indicated. Antenna types not included in this list that have a gain greater than the maximum gain
indicated for any type listed are strictly prohibited for use with this device.
Cet émetteur radio IC: 9335A-WAPC003 a été approuvé par Innovation, Sciences et Développement
économique Canada pour fonctionner avec les types d'antennes énumérés ci‐dessous avec le gain
maximal admissible et impédance d'antenne requise pour chaque type d'antenne indiqué. Types
d'antennes n'est pas inclus dans cette liste, ayant un gain supérieur au gain maximal indiqué pour ce

type, sont strictement interdits pour une utilisation avec cet appareil.
Caution:
i.) the device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for
harmful interference to co-channel mobile satellite systems;
Mise en garde:
i.) le dispositif destiné à fonctionner dans la bande 5150–5250 MHz est destiné uniquement à une
utilisation en intérieur afin de réduire le risque de brouillage préjudiciable causé par les systèmes
mobiles à satellites dans le même canal;
Caution:
i.) the device for operation in the band 5250–5350 MHz is "for indoor use only".
Mise en garde:
i.) le dispositif destiné à fonctionner dans la bande 5250–5350 MHz est "pour usage intérieur
uniquement".
The user manual for LE-LAN devices shall contain instructions related to the restrictions mentioned in
the above sections, namely that:
i. the device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for
harmful interference to co-channel mobile satellite systems;
ii. for devices with detachable antenna(s), the maximum antenna gain permitted for devices in the bands
5250-5350 MHz and 5470-5725 MHz shall be such that the equipment still complies with the e.i.r.p. limit;
iii. for devices with detachable antenna(s), the maximum antenna gain permitted for devices in the band
5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p. limits as appropriate; and
iv. where applicable, antenna type(s), antenna models(s), and worst-case tilt angle(s) necessary to
remain compliant with the e.i.r.p. elevation mask requirement set forth in section 6.2.2.3 shall be clearly
indicated
