MGate 5102-PBM-PN
Quick Installation Guide
Version 3.1, November 2019
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll
-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa China (Shanghai office):
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe:
Tel:
[phone]
Fax:
[phone]
Moxa Asia-Pacific:
Tel:
[phone]
Fax:
[phone]
Moxa India:
Tel:
[phone]
Fax:
[phone]

2019 Moxa Inc. All rights reserved.

- 2 -
Overview
The MGate 5102-PBM-PN is an industrial Ethernet gateway for
PROFIBUS-to-PROFINET network communication.
Package Checklist
Before installing the MGate 5102-PBM-PN, verify that the package
contains the following items:
•1 MGate 5102-PBM-PN gateway
•RJ45 to DB9 cable (for console use)
•Quick installation guide (printed)
•Warranty card
Please notify your sales representative if any of the above items are
missing or damaged.
Optional Accessories(can be purchased separately):
•CBL-F9M9-150: DB9-female-to-DB9-male serial cable, 150 cm
•CBL-F9M9-20: DB9-female-to-DB9-male serial cable, 20 cm
•CBL-RJ45SF9-150: RJ45-to-DB9-female shielded serial cable, 150
cm
•ADP-RJ458P-DB9F: DB9-female-to-RJ45 connector
•A-ADP-RJ458P-DB9F-ABC01: DB9-female-to-RJ45-connector
•Mini DB9F-to-TB: DB9-female-to-terminal-block connector
Hardware Introduction
LED Indicators
LED
Color
Function
PWR1
Green
Power is on
Off
Power is off
PWR2
Green
Power is on
Off
Power is off
Ready
Green
Steady on: Power is on, and the MGate is functioning
normally
Blinking: The MGate has been located by the MGate
Manager’s Location function
Red
Steady on: Power is on, and the MGate is booting up
Blinking: Indicates an IP conflict, or the DHCP or
BOOTP server is not responding properly
Fast blinking: microSD card failed
Off
Power is off or fault condition exists
COMM
Green
Steady on: Data exchange with all slaves
Blinking: Data exchange with at least one slave
Red
Bus control error
Off
No data exchange
CFG
Green
PROFIBUS configuration OK
Off
No PROFIBUS configuration
TOK
Green
Gateway holds the PROFIBUS token
Off
Gateway is waiting for the PROFIBUS token

- 3 -
LED
Color
Function
PBM
Green
Steady on: PROFIBUS master is in OPERATE mode
Blinking: PROFIBUS master is in CLEAR mode
Red
PROFIBUS master is in STOP mode
Off
PROFIBUS master is offline
PN Green
Steady on: PROFINET I/O is connected and controller
is in RUN mode
Blinking: PROFINET I/O is connected but controller is
in STOP mode
Off
No connection with I/O Controller
Ethernet
Amber
Steady: 10 Mbps, no data is transmitting
Blinking: 10 Mbps, data is transmitting
Green
Steady: 100 Mbps, no data is transmitting
Blinking: 100 Mbps, data is transmitting
Off
Ethernet cable is disconnected
Dimensions
Reset Button
The reset button is used to load factory defaults. Use a pointed object
such as a straightened paper clip to hold the reset button in for five
seconds. Release the reset button when the Ready LED stops blinking.
Hardware Installation Procedure
1. Connect the power adapter. Connect the 12-48 VDC power line or
DIN-rail power supply to the MGate 5102-PBM-PN’s terminal block.
Make sure the adapter is connected to an earthed socket.
2. Use a PROFIBUS cable to connect the unit to a PROFIBUS slave
device.
3. Connect the unit to the PROFINET I/O controller.
4. The MGate 5102-PBM-PN is designed to be attached to a DIN rail or
mounted on a wall. For DIN-rail mounting, push down the spring and
properly attach it to the DIN rail until it “snaps” into place. For wall
mounting, install the wall-mount kit (optional) first and then screw
the device onto the wall.

- 4 -
Wall or Cabinet Mounting
Two metal plates are provided for mounting the
unit on a wall or inside a cabinet. Attach the plates
to the unit’s rear panel with screws. With the plates
attached, use screws to mount the unit on a wall.
The heads of the screws should be 5 to7 mm in
diameter, the shafts should be 3 to 4 mm in
diameter, and the length of the screws should be
more than 10.5 mm.
For each screw, the head should be 6 mm or less in diameter, and the
shaft should be 3.5 mm or less in diameter.
The following figure illustrates the two mounting options:
Software Installation Information
To install MGate Manager, please download it from Moxa's website at
http://www.moxa.com.
For detailed information about MGate Manager, refer to the MGate
5102-PBM-PN User's Manual, which can be downloaded from Moxa’s
website at http://www.moxa.com.
Default IP address: 192.168.127.254
Default account: admin
Default password: moxa
Pin Assignments
PROFIBUS Serial Port (female DB9)
PIN
Signal Name
1
N.C.
2
N.C.
3
PROFIBUS D+
4
RTS
5
Signal common
6
5V
7
N.C.
8
PROFIBUS D-
9
N.C.

- 5 -
Power Input and Relay Output Pinouts
V2+ V2- V1+ V1-
Shielded
Ground
DC
Power
Input 2
DC
Power
Input 2
N.O. Common N.C.
DC
Power
Input 1
DC
Power
Input 1
Specifications
Power Input
12 to 48 VDC
Power Consumption
(Input Rating)
12 to 48 VDC, 430 mA (max.)
Operating Temperature
Standard Models: 0 to 60°C (32 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to
167°F)
Storage Temperature
-40 to 85°C (-40 to 185°F)
ATEX and IECEx Information
1. DEMKO Certification number: 13 ATEX 1304499X
IEC Certification Number: IECEx UL 13.0031X;
2. Ambient Temperature Range:
0 to 60°C (for models without the -T suffix)
-40 to 75°C (only for models with the -T suffix)
3. Certification String: Ex nA nC IIC T3 Gc
4. Standards Covered: EN 60079-0:2012+A11:2013;
EN 60079-15:2010; IEC 60079-0 Ed.6; IEC 60079-15 Ed.4.
5. The conditions of safe usage:
a. The Ethernet Communications Devices are intended for mounting
in a tool-accessible IP54 enclosure and used in an area of not
more than pollution degree 2 as defined by IEC 60664-1.
b. Conductors suitable for use in an ambient temperature greater
than 85°C must be used for the power supply terminal.
c. A 4 mm2conductor must be used when a connection to the
external grounding screw is utilized.
d. Provisions shall be made, either in the equipment or external to
the equipment, to prevent the peak-rated voltage being
exceeded by transient disturbances of more than 140%.
Terminal Block (Plug mated with Socket): rated 300 V, 10 A, 105°C,
12-28 AWG (0.0804 mm2 - 3.31 mm2) wire size, torque value 4.5 lb-in
(0.509 N-m). The input terminal cable size 14 AWG ( 2.1 mm2).

- 6 -
ATTENTION
For installations in hazardous locations (Class 1, Division 2):
These devices are to be installed in an enclosure with a
tool-removable cover or door, suitable for the environment.
NOTE
This equipment is suitable for use in Class 1, Division 2, Groups A,
B, C, D, or nonhazardous locations only.
WARNING
EXPLOSION HAZARD
Do not disconnect equipment unless the power has been switched
off, or the area is known to be nonhazardous.
WARNING
EXPLOSION HAZARD
Substitution of any components may impair suitability for Class 1,
Division 2.
WARNING
EXPOSURE TO SOME CHEMICALS
MAY DEGRADE THE SEALING
PROPERTIES OF MATERIALS USED IN THE FOLLOWING DEVICE:
Sealed Relay Device U21.
