AIG-300 Series
Quick Installation Guide
Advanced IIoT Gateways with Arm® Cortex™-A7 dual-core 1
GHz processor, 1 CAN port, 4 DIs, 4 DOs, ThingsPro Edge
software, -40 to 70°C operating temperature
Version 1.2, December 2021
Technical Support Contact Information
www.moxa.com/support
2021 Moxa Inc. All rights reserved.

- 2 -
Package Checklist
Before installing the device, verify that the package contains the
following items:
•AIG-300 Series advanced IIoT gateway
•Power jack
•DIN-rail mounting kit
•Quick installation guide (printed)
•Warranty card
IMPORTANT!
The console cable is not included in the package; you need to
purchase it separately. Notify your sales representative if any of
the above items are missing or damaged.
Panel Views
The following figures show the panel layouts of the AIG-300 Series:
AIG-301-T-AZU-LX
Top Panel

- 3 -
Front Panel
Bottom Panel
AIG-301 US, EU, AP, and CN Models
NOTE
The CN model does not come
preinstalled
with the LTE module.
Contact Moxa’s distributor in China for more information.
Top Panel

- 4 -
Front Panel
Bottom Panel View
LED Indicators
LED Name
Status
Function
PWR1/PWR2
Green
Power is on
Off
No power is supplied
SIM
Green
SIM2 in use
Yellow
SIM1 in use
USR Green/Yellow Green: System is operating normally
Yellow: System is initializing and running
the initial boot-up process
L1/L2/L3 Yellow
Cellular signal strength
L1+L2+L3: Strong
L2+L3: Normal
L3:Weak
W1/W2/W3
Yellow
WLAN signal strength
W1+W2+W3: Strong
W2+W3: Normal
W3: Weak
LAN1/LAN2
(RJ45
connector)
Green
Steady on
1000 Mbps Ethernet link
Blinking
Data is being transmitted
Yellow
Steady on
100 Mbps Ethernet link
Blinking
Data is being transmitted
Off
No Ethernet connection or 10 Mbps
Ethernet link

- 5 -
Mounting Instructions
DIN-rail Mounting
The aluminum DIN-rail attachment plate is already attached to the
product’s casing. To mount the device on to a DIN rail, make sure that
the stiff metal spring is facing upwards and follow these steps.
1.
Pull down the bottom slider of
the DIN-rail bracket located at
the back of the unit
2.
Insert the top of the DIN rail
into the slot just below the
upper hook of the DIN-rail
bracket.
3.
Latch the unit firmly on to the
DIN rail as shown in the
illustrations below.
4.
Push the slider back into place.
Wall Mounting (optional)
The device can be mounted on to a wall using a wall-mounting kit. The
optional wall-mounting kit should be purchased separately.
Follow these steps to mount the device on to a wall:
Step 1
Use four screws to fasten the wall
-
mounting brackets on the left panel
of the device.
Step 2
Use another four screws to mount
the
device on to a wall or in a
cabinet.

- 6 -
IMPORTANT!
The diameter of the screw heads
should be greater than 7 mm
and less than 14 mm; the diameter of the shafts should be less
than 3 mm. The length of the screws should be greater than 6
mm.
NOTE
•Test the screw head and shank size by inserting the screws
into one of the keyhole shaped apertures of the wall-
mounting plates before attaching the plate to the wall.
•
Do not drive the screws in all the way—leave a space of
about 2 mm to allow room for sliding the wall mount panel
between the wall and the screws.
Wiring Requirements
•Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the intersection point.
•You can use the type of signal transmitted through a wire to
determine which wires should be kept separate. The rule of thumb
is that wiring that shares similar electrical characteristics can be
bundled together.
•Keep input wiring and output wiring separate.
•When necessary, it is strongly advised that you label wiring to all
devices in the system.
NOTE
Do not run signal or communication wiring and power wiring in
the same wire conduit. To avoid interference, wires with
different signal characteristics should be routed separately.
Grounding Requirements
There is a grounding connector located on the top panel of the device.
Connect it to an appropriate grounded metal surface. Grounding and
wire routing help limit the effects of noise due to electromagnetic
interference (EMI).
Connecting the Power Supply
C
onnect the power jack (in the package)
to
the DC terminal block (located on the
top
panel), and then connect the power
adapt
er. It takes about 3 minutes for the
system to boot up. Once the system is
ready, the
Power LED will light up. Both
m
odels support dual power inputs for
redundancy.
Use wires with 12 to 26 AWG wire size to connect to V+, V-, and GND.

- 7 -
The wire size of the power input and the earthing conductor should be
the same. Remove 8 to 9 mm of the DC wires’ protective cover and use
a torque of 4.5lb-in/0.51Nm to connect the wire. The max. wire
temperature should not exceed 100°C. The terminal blocks do not
accommodate more than one conductor wire per clamping point.
WARNING
EXPLOSION HAZARD!
Do not disconnect equipment unless the power has been
removed or the area is known to be non-hazardous.
WARNING
•
This product is intended to be supplied by a UL Listed
power adapter or DC power source whose output meets
SELV/LPS. The power source must be rated 12 to 48 VDC,
minimum 1 A, and minimum TMA = 85°C.
•
The power adapter should be connected to a socket outlet
with an earthing connection.
If you need further
information or assistance, contact a Moxa
representative.
Wiring the I/Os
There are four digital inputs and four digital
outputs on the top panel. Refer to the figure
on the left for detailed pin definitions.
Use wires with 16 to 28 AWG wire size
to
connect to DI, DO, and GND.
The
exposed conductor wire
length should be
7
-8 mm and the max. wire temperature
should not exceed 100°C. The terminal blocks
do not accommodate more than one
conductor wire per clamping point.
DI Dry Contact
DO Channel (Sink Type)

- 8 -
Communication Connections
Connecting to the Network
The two 10/100/1000 Mbps Ethernet ports (LAN 1 and LAN 2) use RJ45
connectors. Refer to the figure to the
Pin
10/100 Mbps
1000 Mbps
1
Tx+
TRD(0)+
2
Tx-
TRD(0)-
3
Rx+
TRD(1)+
4
–
TRD(2)+
5
–
TRD(2)-
6
Rx-
TRD(1)-
7
–
TRD(3)+
8
–
TRD(3)-
Connecting to Serial Ports
The two serial ports (P1 and P2) use DB9 interface. Each port can be
configured by software for RS-232, RS-422, or RS-485. The pin
assignments for the ports are shown in the following table:
Pin RS-232
RS-422/
RS-485 4w
RS-485 2w
1
–
TxD-(A)
–
2
RxD
TxD+(B)
–
3
TxD
RxD+(B)
Data+(B)
4
DTR
RxD-(A)
Data-(A)
5
GND
GND
GND
6
DSR
–
–
7
RTS
–
–
8
CTS
–
–
Inserting the microSD Card
The device comes with a micro-SD slot for storage expansion. The
microSD slot is located at the lower part on the front panel. To install
the card, remove the screw and the protection cover to access the slot
and insert the microSD card into the slot.
You will hear a click when the card is in place. To remove the card,
push the card in before releasing it.
Connecting to the Console Port
The console port is an RS-232 port located on the top panel, and can be
connected to a 4-pin pin header cable. You can use this port for
debugging or firmware upgrade.

- 9 -
Pin
Signal
1
TxD
2
RxD
3
NC
4
GND
Connecting a USB Device
The device comes with a USB port located on the lower part of the front
panel, allowing users to connect to a device with an USB interface. The
USB port uses a type-A connector.
Connecting a CAN Device
A CAN port with a DB9 interface is located on the bottom panel. Refer
to the figure below for detailed pin definitions.
Pin
Definition
1
–
2
CAN_L
3
CAN_GND
4
–
5
(CAN_SHLD)
6
(GND)
7
CAN_H
8
–
9
(CAN_V+)
Inserting a SIM Card
The device comes with two SIM card slots to install up to two SIM cards
for cellular communication.
Step 1
Remove the screw on the SIM card
holder
cover located on the bottom
panel of the
device.
Step 2
Insert the SIM card into the
socket. Make sure you insert
it in
the right direction. To remove the
SIM card, press the SIM card in to
release and then pull out the SIM
card.
Connecting the Antennas
There are two cellular antenna
connectors (C1 and C2) on the front
panel of the device. In addition, a
GPS connector is provided for the
GPS module. All three are SMA type
connectors. Connect the antennas to
these connectors as indicated.

- 10 -
The device also comes with two Wi-Fi
antenna connectors (W1 and W2) on
the top panel of the device. Connect
the antennas on the connectors as
shown below. Both W1 and W2
connectors are of RP
-SMA type.
NOTE
The optional Wi-Fi wireless module is not included in the
product package and must be purchased separately. Refer to
the AIG
-300 Series hardware manual, which can be
downloaded from
https://www.moxa.com, to install the Wi-Fi
module for the device.
Connecting the Device to a PC
You can use a PC to access the AIG-300 Series by one of the following
methods:
A. Access the web console of ThingsPro Edge via LAN 2 by
https://192.168.4.127:8443/.
Default Username : admin
Password: admin@123.
B. Using SSH over the network.
Refer to the following IP addresses and login information:
Default IP Address
Netmask
LAN 1
DHCP
LAN 2
192.168.4.127
255.255.255.0
Login: moxa
Password: moxa
NOTE
For security reasons the SSH port is disabled by default. You
can enable it via the ThingsPro Edge web console.
Troubleshooting
Reboot
To reboot the device, press the Function (FN) button for 1 second.
Reset to Default
Press and hold the Function (FN) button between 7 to 9 seconds to
reset the device to the factory default settings. When the reset button
is held down, the USR LED will blink once every second and become
steady after 7 to 9 seconds. Release the button within this period to
load the factory default settings.
Real-time Clock
The real-time clock is powered by a lithium battery. We strongly
recommend that you do not replace the lithium battery without the help

- 11 -
of a Moxa support engineer. If you need to change the battery, contact
the Moxa RMA service team.
ATTENTION
There is
a risk of explosion if the battery is replaced with an
incorrect type of battery.
ATTENTION
•
These devices are open-
type devices that are to be installed
in an enclosure with tool removable cover or door, suitable
for the environment.
•
This equipment is suitable for use in Class I, Division 2,
Groups A, B, C, and D or non-hazardous locations only.
•
ANTENNAS INTENDED FOR USE IN CLASS I, DIVISION 2
HAZARDOUS LOCATIONS MUST BE INSTALLED WITHIN THE
END-USE ENCLOSURE. FOR REMOTE MOUNTING IN AN
UNCLASSIFIED LOCATION, ROUTING AND INSTALLATION
OF THE ANTENNAS SHALL BE IN ACCORDANCE WITH
NATIONAL ELECTRICAL CODE REQUIREMENTS (NEC/CEC)
Sec. 501.10 (b).
•
The “USB, RS-232/422/485 serial ports, CAN, LAN1, LAN2,
and Console ports, and the Reset button” may only be
accessed at non-hazardous locations for equipment set-up,
installation, and maintenance. These ports and their
associated interconnecting cables must remain inaccessible
within hazardous locations.
Product Specifications
Input Current
0.4 A @ 12 VDC (AIG-301-AZU-LX/T-AZU-LX)
0.5 A @ 12 VDC (AIG-301-CN-AZU-LX/T-CN-
AZU-LX)
0.7 A @ 12 VDC (AIG-301-US-AZU-LX/T-US-
AZU-LX, AIG-301-EU-AZU-LX/T-EU-AZULX,
AIG-301-AP-AZU-LX/T-AP-AZU-LX)
Input Voltage
12 to 48 VDC
Power Consumption
4.8 W (AIG-301-AZU-LX/T-AZU-LX)
6.0 W (AIG-301-CN-AZU-LX/T-CN-AZU-LX)
8.4 W (AIG-301-US-AZU-LX/T-US-AZU-LX,
AIG-301-EU-AZU-LX/T-EU-AZU-LX, AIG-301-
AP-AZU-LX/T-AP-AZU-LX)
Operating
Temperature
Standard Temp. Models:
-20 to 70°C (-4 to 158°F) (AIG-301-US-AZU-
LX, AIG-301-EU-AZU-LX, AIG-301-AP-AZULX,
AIG-301-CN-AZU-LX)
-20 to 85°C (-4 to 185°F) (AIG-301-AZU-LX)
Wide Temp. Models:
-40 to 70°C (-40 to 158°F) (AIG-301-T-US-
AZU-LX, AIG-301-T-EU-AZU-LX, AIG- 301-TAP-
AZU-LX, AIG-301-T-CN-AZU-LX)
–40 to 85°C (-40 to 185°F) (AIG-301-T-AZU-
LX)

- 12 -
Storage Temperature
(package included)
-40 to 85°C (-40 to 185°F)
The latest specifications for Moxa's products can be found at
https://www.moxa.com.
ATEX and C1D2 Specifications
Model
UC-8210-T-LX, UC-8210-T-LX-S, UC-8220-T-LX
UC-8210-LX, UC-8210-LX-S, UC-8220-LX
Rating
Input: 12 to 48 VDC; 1.0 to 0.25 A
ATEX Information
II 3 G
Certificate Number: DEMKO 19 ATEX 2302X
Certification String: Ex ec IIC T4 Gc
Ambient Range:
-40°C ≦Tamb ≦85°C (UC-8210-T-LX, and
UC-8210-T-LX-S models)
-40°C ≦Tamb ≦70°C (UC-8220-T-LX
model)
-20°C ≦Tamb ≦85°C (UC-8210-LX and UC-
8210-LX-S models)
-20°C ≦Tamb ≦70°C (UC-8220-LX model)
Rated Cable Temp
≧
100°C
C1D2 Information
Temperature Code (T-code): T4
Manufacturer’s
Address
No. 1111, Heping Rd., Bade Dist., Taoyuan
City 334004, Taiwan
Hazardous Location
Certification
EN IEC 60079-0:2018
EN IEC 60079-7:2015+A1:2018
Special Conditions of Use
•The equipment shall only be used in an area of at least pollution
degree 2, as defined in EN 60664-1.
•The equipment shall be installed in an enclosure that provides a
minimum ingress protection of IP 54 in accordance with EN 60079-
0 and is accessible only by the use of a tool.
