Moxa Technologies PT-7528 Manual

2013 Moxa Inc. All rights reserved.
P/N: 1802075280030
PT-7528 Series
(8/12/16/20-Port Fiber Models)
Hardware Installation Guide
Moxa PowerTrans Switch
First Edition, December 2013

- 2 -
Package Checklist
The Moxa PowerTrans switch is shipped with the following items. If any of
these items are missing or damaged, please contact your customer
service representative for assistance.
•1 Moxa PowerTrans switch
•USB cable (Type A male to Type B male)
•Protective caps for unused ports
•2 rackmount ears
•CD-ROM with user’s manual and SNMP MIB file
•Hardware installation guide
•Warranty card
Panel Layout
1. System status LEDs
2. Ethernet port LEDs
3. Fast Ethernet ports and port LEDs
4. Gigabit SFP slots
5. USB console port
6. 10-pin terminal block for power inputs, and relay output
7. Rack mounting kit
8. Grounding screw
9. USB storage port (ABC-02-USB-T)
10. Reset button
Note: The model shown above is the PT-7528-20MST-4TX-4GSFP-HV
switch. For other models, the layout of Ethernet ports is different.

- 3 -
Dimensions; unit = mm (in)
Rack Mounting
Use six screws to attach the PT switch to a standard rack.
Rack Mounting Kit
PT-7528 Side View
NOTE
Two additional rack-mount ears can be ordered as an option. Use
them to secure the rear of the chassis in high
-vibration
environments.

- 4 -
Wiring Requirements
WARNING
Safety First!
•
Be sure to disconnect the power cord bef
ore installing and/or
wiring your Moxa PowerTrans Switch.
•
Calculate the maximum possible current in each power wire
and common wire. Observe all electrical codes dictating the
maximum current allowable for each wire size.
•
If the current goes above the maximum ratings, the wiring
could overheat, causing serious damage to your equipment.
Grounding the Moxa PowerTrans Switch
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.
Wiring the Power Inputs
The PT-7528 switches support dual redundant power supplies: Power
Supply 1 (PWR1) and Power Supply 2 (PWR2). The connections for PWR1,
PWR2, and the RELAY are located on the terminal block. The front view of
the terminal block connectors are shown below.
Wiring the Relay Contact
Each PT-7528 switch provides two types of relay output, at the user’s
option. See below for detailed instructions on how to connect the wires to
the terminal block connector, and how to attach the terminal block
connector to the terminal block receptor.
Normal contact state
withou
t power applied
to device.
The relay contact is used to detect user-configured events. Two wires are
attached to the relay pins. The PT-7528 provides normal open and normal
closed circuits at the user’s option. For pin definitions, refer to the table
below:
Relay pin connection
Power on state
Event trigger
Pins 4 and 6
Closed circuit
Open circuit
Pins 8 and 6
Open circuit
Closed circuit

- 5 -
Wiring the Redundant Power Inputs
Each PT switch has two sets of power inputs: power input 1 and power
input 2.
STEP 1: Insert the dual set positive/negative DC wires into PWR1 and
PWR2 terminals (+ pins 1, 7; – pins 3, 9), or insert the L/N AC wires
into PWR1 and PWR2 terminals (L pins 1, 7; N pins 3, 9).
STEP 2: To keep the DC or AC wires from pulling loose, use a screwdriver
to tighten the wire-clamp screws on the front of the terminal block
connector.
Ethernet Ports
Fast Ethernet RJ45 Twisted-Pair Cabling
PT-7528 series switches are equipped with several 10/100BaseTX ports
for connecting to standard CAT-5 STP cables with RJ45 male connectors.
PT-7528 series switches feature auto-negotiation, auto-polarity, and
auto-crossover functions. For high EMC environment applications, we
suggest using shielded twisted-pair cables to avoid EMC interference to
retain compliance with the IEEE 1613 standard.
Gigabit Ethernet 1000BaseTX Cabling
The IEEE 802.3ab Gigabit Ethernet standard defines 1000 Mbps Ethernet
communications over distances of up to 100 meters using all 4 pairs in
category 5 (or higher) balanced unshielded twisted-pair cabling. For
wiring guidelines, system designers and integrators should refer to the
Telecommunications Industry Association (TIA) TIA/EIA-568-A wiring
standard that characterizes the minimum cabling performance
specifications required for proper Gigabit Ethernet operation. To ensure
reliable, error-free data communication, new and pre-existing
communication paths should be checked for TIA/EIA-568-A compliance.
•Data cable lengths should be as short as possible, ideally limited to 3
m (10 ft) in length. Copper data cables should not be used for
inter-building communications.
•Power and data cables should not be run in parallel for long distances,
and should be installed in separate conduits. Power and data cables
should intersect at 90° angles when necessary to reduce inductive
coupling.
•Optionally, shielded/screened cabling can be used. The cable shield
should be grounded at one single point to avoid the generation of
ground loops.

- 6 -
USB Console Connection
The PT-7528 series has one USB console port (type B connector), located
on the top panel. Use the USB cable (provided in the product package) to
connect the PT-7528’s console port to your PC’s USB port and install the
USB driver (available in the software CD) on your PC. You may then use
a console terminal program, such as Moxa PComm Terminal Emulator, to
access the PT-7528’s console configuration utility.
USB Console Port (Type B Connector) Pinouts
Pin
Description
1
D- (Data-)
2
VCC (+5V)
3
D+ (Data+)
4
GND (Ground)
USB Storage Connection
The PT-7528 series has one USB storage port (type A connector) on the
front panel. Use Moxa’s ABC-02-USB-T automatic backup configurator to
connect the PT-7528’s USB storage port for configuration backup,
firmware upgrade, or system log file backup.
ABC-02-USB Installation
Plug the ABC-02-USB into the USB storage port of the Moxa PT-7528
series. We suggest attaching the ABC-02-USB to a wall with an M4 screw.
USB Storage Port (Type A Connector) Pinouts
Pin
Description
1
VCC (+5 V)
2
D- (Data-)
3
D+ (Data+)
4
GND (Ground)
The Reset Button
Depress the Reset button for five continuous seconds to load the factory
default settings. Use a pointed object, such as a straightened paper clip or
toothpick, to depress the Reset button. When you do so, the STATE LED
will start to blink about once per second. Continue to depress the STATE
LED until it begins blinking more rapidly; this indicates that the button has
been depressed for five seconds and you can release the Reset button to
load factory default settings.
NOTE
DO NOT power off the switch when loading default settings.

- 7 -
LED Indicators
LED
Color
State
Description
STATE
GREEN
On
System has passed self-diagnosis test on
boot-up and is ready to run.
Blinking
•
1 blink every sec:
The switch is being reset
•1 blink every 2 sec:
The switch is connected to the
ABC-02-USB.
RED
On
The system failed self-diagnosis on
boot-up.
•
RAM Test Fail / System Info. Read Fail
/ Switch Initial Fail / PTP PHY Error.
(+
Green MSTR lit on : HW FAIL)
•FW Checksum Fail / Uncompress Fail.
(+ Green Coupler lit on: SW FAIL)
FAULT
RED
On
One of the following situations exists:
•The signal contact is open.
•ABC Loading/Saving Failure.
•The port has been disabled because
the ingress multicast and broadcast
packets exceed the ingress rate limit.
•Incorrect loop connection in a single
switch.
•Invalid Ring port connection.
Off
The system is operating normally.
PWR1
AMBER
On
Power is being supplied to the main
module’s power input PWR1.
Off Power is not being supplied to the main
module’s power input PWR1.
PWR2
AMBER
On
Power is being supplied to the main
module’s power input PWR2.
Off
Power is not being supplied to the main
module’s power input PWR2.
MSTR/
HEAD
GREEN
On
One of the following situations exists:
•The switch is set as the Master of the
Turbo Ring, or as the Head of the
Turbo Chain.
•POST H.W. Fail (+Stat on and Fault
blinking).
Blinking
One of the following situations exists:
•The switch has become the Ring
Master of the Turbo Ring.
•The switch has become the
Head of the
Turbo Chain after the Turbo Ring or
the Turbo Chain went down.
•The switch is set as a member of the
Turbo Chain and the corresponding
chain port is down.
Off
One of the following situations exists:
•The switch is not the Master of this
Turbo Ring.
•This switch is set as a member of the
Turbo Chain.

- 8 -
CPLR/
TAIL
GREEN
On
One of the following situations exists:
•The switch’s coupling function is
enabled to form a back-up path.
•The switch is set as the Tail of the
Turbo Chain.
•POST S.W. Fail (+Stat on and Fault
blinking)
Blinking
One of the following situations exists:
•Turbo Chain is down.
•The switch is a member of the Turbo
Chain and the corresponding chain
port is down.
Off
One of the following situations exists:
•This switch has disabled the coupling
function.
•This switch is a member of the
Turbo Chain.
FAULT +
MSTR/HEAD
+ CPLR/TAIL
Rotate
Blinking
Sequentially
ABC-02-USB is importing/exporting files.
STATE +
FAULT +
MSTR/HEAD
+ CPLR/TAIL
Blinking
2 blinks per sec: The switch is being
discovered/located by MXview.
Ports
1 to 24
GREEN
On
Port’s 100 Mbps link is active
Blinking
Data is transmitting at 100 Mbps
Off
Port’s link is inactive
AMBER
On
Port’s 10 Mbps link is active
Blinking
Data is transmitting at 10 Mbps
Off
Port’s link is inactive
M1
Ports
1 to 4
GREEN
On
Port’s highest speed link is active
Blinking
Data is transmitting at the highest speed
Off
Port’s link is inactive
AMBER
On
Port’s non-highest speed link is active
Blinking
Data is transmitting at non-highest
speed
Off
Port’s link is inactive

- 9 -
Specifications
Technology
Standards
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3z for 1000BaseX
IEEE 802.3x for Flow Control
IEEE 802.1D-2004 for Spanning Tree Protocol
IEEE 802.1w for Rapid STP
IEEE 802.1s for Multiple Spanning Tree Protocol
IEEE 802.1Q for VLAN Tagging
IEEE 802.1p for Class of Service
IEEE 802.1X for Authentication
IEEE 802.3ad for Port Trunk with LACP
Protocols
IGMP v1/v2, GMRP, GVRP, SNMPv1/v2c/v3, DHCP
Server/Client, BootP, TFTP, SNTP, SMTP, RARP,
RMON, HTTP, HTTPS, Telnet, SSH, Syslog, DHCP
Option 66/67/82, EtherNet/IP, Modbus/TCP, LLDP,
IEEE 1588 PTP V2, IPv6, NTP Server/Client, MMS
MIB
MIB-II, Ethernet-like MIB, P-BRIDGE MIB,
Q-BRIDGE MIB, Bridge MIB, RSTP MIB,
RMON MIB Groups 1, 2, 3, 9
Flow control
IEEE 802.3x flow control, back pressure flow control
Interface
Fast Ethernet
10/100BaseT(X) or 100BaseFX (SC/ST connector)
Gigabit Ethernet
10/100/1000BaseT(X), 1000BaseSX/LX/LHX/ZX
(SFP slot, LC connector)
Console Port
USB-serial console (Type B connector)
Storage port
USB storage port (Type A connector)
System LED
Indicators
STAT, PWR1, PWR2, FAULT, MSTR/HEAD, CPLR/TAIL
Alarm Contact
One relay output with current carrying capacity of
3 A @ 30 VDC or 3 A @ 240 VAC
Optical Fiber (100BaseFX)
Distance Multi-mode:
0 to 5 km, 1300 nm (50/125μm, 800 MHz*km)
0 to 4 km, 1300 nm (62.5/125μm, 500 MHz*km)
Single-mode:
0 to 40 km, 1310 nm (9/125μm, 3.5 PS/(nm*km))
Min. TX Output
Multi-mode: -20 dBm; Single-mode: -5 dbm
Max. TX Output
Multi-mode: -10 dBm; Single-mode: 0 dbm
RX Sensitivity
Multi-mode: -32 dBm; Single-mode: -34 dbm
Power
Input Voltage
WV: 24/48 VDC (18 to 72 V)
HV: 110/220 VDC/VAC (88 to 300 VDC and 85 to 264
VAC)
Input Current
Max. 1.428 A @ 24 VDC
Max. 0.735 A @ 48 VDC
Max. 0.313/0.167 A @ 110/220 VDC
Max. 0.586/0.382 A @ 110/220 VAC

- 10 -
Physical Characteristics
Housing
IP40 protection, metal case
Dimensions
(W x H x D)
440 x 44 x 325 mm (17.32 x 1.73 x 12.76 in)
Weight
4900 g
Installation
19” rack mounting
Standards and Certifications
Safety
UL 508
Power Automation
IEC 61850-3, IEEE 1613
Road Traffic
NEMA TS2
Rail Traffic
EN 50121-4
EMI
FCC Part 15 Subpart B Class A, EN55022 class A
Environmental Limits
Operating Temp.
-40 to 85°C (-40 to 185°F)
Cold start of min. 100 VAC at -40°C
Storage Temp.
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity.
5 to 95% (non-condensing)
Warranty
Warranty Period
5 years
Details
See www.moxa.com/warranty
Rack Mounting Instructions
1. Elevated Operating Ambient: If installed in a closed or multi-unit
rack assembly, the operating ambient temperature of the rack
environment may be greater than room ambient. Therefore,
consideration should be given to installing the equipment in an
environment compatible with the maximum ambient temperature
(Tma) specified by the manufacturer.
2. Reduced Air Flow: Installation of the equipment in a rack should
be such that the amount of air flow required for safe operation of the
equipment is not compromised.
3. Mechanical Loading: Mounting of the equipment on the rack
should be such that a hazardous condition is not achieved due to
uneven mechanical loading.
4. Circuit Overloading: Consideration should be given to the
connection of the equipment to the supply circuit and the effect that
overloading of the circuits might have on overcurrent protection and
supply wiring. Appropriate consideration of equipment nameplate
ratings should be used when addressing this concern.
5. Reliable Grounding: Reliable grounding of rack-mounted
equipment should be maintained. Particular attention should be
given to supply connections other than direct connections to the
branch circuit (e.g., use of power strips).
NOTE
The rackmount ears can be attached to the front or rear of the
PT-7528 switch.

- 11 -
Restricted Access Locations
•This equipment is intended to be used in Restricted
Access Locations, such as a computer room, with
access limited to SERVICE PERSONAL or USERS
who have been instructed on how to handle the
metal chassis of equipment that is so hot that
special protection may be needed before touching it. The location
should only be accessible with a key or through a security identity
system.
•External metal parts of this equipment are extremely hot!! Before
touching the equipment, you must take special precautions to protect
your hands and body from serious injury.
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll
-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa China (Shanghai office):
Tel:
[phone]
Fax:
[phone]
Moxa Europe:
Tel:
[phone]
Fax:
[phone]
Moxa Asia-Pacific:
Tel:
[phone]
Fax:
[phone]
