Moxa EtherDevice Switch
EDS-G205
Hardware Installation Guide
Second Edition, April 2009
©2009 Moxa Inc. All rights reserved.
Reproduction without permission is prohibited.
Fl.4, No.135, Lane 235, Pao-Chiao Rd. Shing Tien City, Taipei, Taiwan,
R.O.C.
TEL: [phone]
P/N: 1802002051011

- 2 -
Overview
The EDS-G205 series is equipped with 5 Gigabit Ethernet ports, making it an
ideal and economical solution for demanding, high bandwidth Gigabit Ethernet
applications. In addition, the built-in relay warning function alerts system
administrators when power failures or port breaks occur. The EDS-G205 series
includes 2 models: one with an operating temperature range of 0 to 60°C, and
the other one with extended operating temperature range of -40 to 75°C. These
2 models have passed a 100% burn-in test to ensure that they fulfill the special
needs of industrial automation control. The EDS-G205 series can be easily
installed with DIN-Rail mounting as well as distribution boxes.
NOTE Throughout this Hardware Installation Guide, we use EDS as an
abbreviation for Moxa EtherDevice Switch:
EDS = Moxa EtherDevice Switch
Package Checklist
Your EDS is shipped with the following items. If any of these items is missing
or damaged, please contact your customer service representative for assistance.
yMoxa EtherDevice™ Switch
yHardware Installation Guide
yMoxa Product Warranty booklet
Features
High Performance Network Switching Technology
y10/100/1000BaseT(X) (RJ45), auto negotiation speed, F/H duplex mode
yIEEE 802.3/802.3u/802.3ab.
yStore and Forward switching process type, 8K MAC address entries.
Industrial Grade Reliablity
yPower failure, port break alarm by relay output
yRedundant dual 12/24/48VDC power inputs
Rugged Design
yOperating temperature range of 0 to 60°C, or extended operating
temperature of -40 to 75°C for (-T) models
yIP30, rugged high-strength case
yDIN-Rail or panel mounting ability

- 3 -
Panel Layout of EDS-G205
6
7
5
2
8
9
2
2
1
1
10
12
12
13
11
3
4
ON DIP
12345
2
1
Front Panel View
Top Panel View
Rear Panel View
FAULT
1. Grounding screw
2. Terminal block for power input
(PWR1, PWR2) and relay output
3. Power input PWR1 LED
4. Power input PWR2 LED
5. Fault LED
6. TP port’s 10/10/1000 Mbps LED
7. Port number
8. 10/100/1000BaseT(X) Port
9. Model Name
10. DIP switches
11. Heat dissipation orifices
12. Screw hole for wall mounting kit
13. DIN-Rail Kit

- 4 -
Mounting Dimensions (unit = mm)
PWR2
PWR1
FAULT
DIN-Rail Mounting
The aluminum DIN-rail attachment plate should already be fixed to the back
panel of the EDS when you take it out of the box. If you need to reattach the
DIN-rail attachment plate, make sure the stiff metal spring is situated towards
the top, as shown in the figures below.
STEP 1:
Insert the top of the DIN-rail into the
slot just below the stiff metal spring.
STEP 2:
The DIN-rail attachment unit will
snap into place as shown below.
metal
spring
DIN-Rail
metal
spring
DIN-Rail
To remove the DIN-rail from the EDS, simply reverse Steps 1 and 2.
Wall Mounting (optional)
For some applications, you will find it convenient to mount the EDS on the
wall, as illustrated below.
STEP 1:
Remove the aluminum
DIN-rail attachment plate
from the EDS’s rear panel,
and then attach the wall
mount plates, as shown in
the figure. ⇒

- 5 -
STEP 2:
Mounting the EDS on the wall requires 4 screws. Use the
switch, with wall mount plates attached, as a guide to
mark the correct locations of the 4 screws. The heads of
the screws should be less than 6.0 mm in diameter, and
the shafts should be less than 3.5 mm in diameter, as
shown in the figure at the right.
6.0 mm
3.5 mm
NOTE Before tightening screws into the wall, make sure the screw head
and shank size are suitable by inserting the screw into one of the
keyhole-shaped apertures of the Wall Mounting Plates.
Do not screw the screws in all the way—leave about 2 mm to allow room for
sliding the wall mount panel between the wall and the screws.
STEP 3:
Once the screws are fixed in
the wall, insert the four screw
heads through the large parts
of the keyhole-shaped
apertures, and then slide the
EDS downwards, as indicated.
Tighten the four screws for
added stability.
⇒
Wiring Requirements
WARNING
Safety First!
Turn the power off before disconnecting modules or wires. The
proper power supply voltage is listed on the product label. Check
the voltage of your power source to make sure you are using the
correct voltage. Do NOT use a voltage greater than what is
specified on the product label.
These devices must be supplied by an AELV source as defined in
the Low Voltage Directive 2006/95/EC and 2004/108/EC.
WARNING
Safety First!
Calculate the maximum possible current in each power wire and
common wire. Observe all electrical codes dictating the
maximum current allowable for each wire size.
If the current goes above the maximum ratings, the wiring could
overheat, causing serious damage to your equipment.

- 6 -
You should also pay attention to the following items:
yUse separate paths to route wiring for power and devices. If power wiring
and device wiring paths must cross, make sure the wires are perpendicular
at the intersection point.
NOTE: Do not run signal or communications wiring and power wiring in
the same wire conduit. To avoid interference, wires with different signal
characteristics should be routed separately.
yYou can use the type of signal transmitted through a wire to determine
which wires should be kept separate. The rule of thumb is that wiring with
similar electrical characteristics can be bundled together.
yKeep input wiring and output wiring separated.
yIt is strongly advised that you label wiring for all devices in the system
when necessary.
Grounding Moxa EtherDevice Switch
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well-grounded
mounting surface, such as a metal panel.
Wiring the Alarm Contact
The Alarm Contact consists of the two middle contacts of the terminal block on
the EDS’s top panel. You may refer to the next section for detailed instructions
on how to connect the wires to the terminal block connector, and how to attach
the terminal block connector to the terminal block receptor.
In this section, we explain the meaning of the two contacts used to connect the
Alarm Contact.
FAULT
FAULT
Top View
Front View
FAULT: The two middle contacts of the
6-contact terminal block connector are used to
detect both power faults and port faults. The
two wires attached to the Fault contacts form
an open circuit when:
1. EDS has lost power from one of the DC
power inputs.
OR
2. The PORT ALARM DIP switch for one of
the ports is set to ON, but the port is not
connected properly.
If neither of these two conditions is satisfied,
the Fault circuit will be closed.

- 7 -
Wiring the Redundant Power Inputs
The top two contacts and the bottom two contacts of the 6-contact terminal
block connector on the EDS’s top panel are used for the EDS’s DC inputs. Top
and front views of one of the terminal block connectors are shown here.
Top View
Front View
STEP 1: Insert the negative/positive DC
wires into the V-/V+ terminals.
STEP 2: To keep the DC wires from
pulling loose, use a small flat-blade
screwdriver to tighten the wire-clamp
screws on the front of the terminal block
connector.
STEP 3: Insert the plastic terminal block
connector prongs into the terminal block
receptor, which is located on EDS’s top
panel.
ATTENTION
Before connecting the EDS to the DC power inputs, make sure
the DC power source voltage is stable.
Communication Connections
EDS-G205 Models have 5 10/100/1000BaseT(X) Ethernet ports
10/100/1000BaseT(X) Ethernet Port
Connection
The 10/100/1000BaseT(X) ports located on Moxa EtherDevice Switch’s front
panel are used to connect to Ethernet-enabled devices. Most users will choose
to configure these ports for Auto MDI/MDI-X mode, in which case the port’s
pinouts are adjusted automatically depending on the type of Ethernet cable
used (straight-through or cross-over), and the type of device (NIC-type or
HUB/Switch-type) connected to the port.
In what follows, we give pinouts for both MDI (NIC-type) ports and MDI-X
(HUB/Switch-type) ports. We also give cable wiring diagrams for
straight-through and cross-over Ethernet cables.
10 /100Base T(x) RJ45 Pinouts
MDI Port Pinouts MDI-X Port Pinouts 8-pin RJ45
Pin Signal Pin Signal
1 Tx+ 1 Rx+
2 Tx- 2 Rx-
3 Rx+ 3 Tx+
6 Rx- 6 Tx-
1 8

- 8 -
1000BaseT RJ45 Pinouts
Pin MDI MDI-X
1 BI_DA+ BI_DB+
2 BI_DA- BI_DB-
3 BI_DB+ BI_DA+
4 BI_DC+ BI_DD+
5 BI_DC- BI_DD-
6 BI_DB- BI_DA-
7 BI_DD+ BI_DC+
8 BI_DD- BI_DC-
1 8
RJ45 (8-pin) to RJ45 (8-pin) Straight-Through Cable Wiring
Straight-Through Cable
RJ45 Plug Pin 1
Switch Port
RJ45
Connector RJ45 Connecto
r
Tx+
Tx-
Rx+
Rx-
DD+
DD-
DC+
DC-
NIC Port
Cable Wiring Rx+
Rx-
Tx+
Tx-
DC+
DC-
DD+
DD-
3
6
1
2
4
5
7
8
3
6
1
2
4
5
7
8
RJ45 (8-pin) to RJ45 (8-pin) Cross-Over Cable Wiring
Cross-Over Cable
RJ45 Plug Pin 1
Switch Port
(NIC Port)
RJ45
Connector RJ45 Connector
Tx+
Tx-
Rx+
Rx-
(Rx+)
(Rx-)
(Tx+)
(Tx-) DC+
DC-
DD+
DD-
(DD+)
(DD-)
(DC+)
(DC-)
(Tx+)
(Tx-)
(Rx+)
(Rx-)
Switch Port
(NIC Port)
Cable Wiring
Rx+
Rx-
Tx+
Tx- (DC+)
(DC-)
(DD+)
(DD-)
DD+
DD-
DC+
DC-
3
6
1
2
4
5
7
8
1
2
3
6
7
8
4
5
Redundant Power Inputs
Both power inputs can be connected simultaneously to live DC power sources.
If one power source fails, the other live source acts as a backup, and
automatically supplies all of the EDS’s power needs.

- 9 -
Alarm Contact
The Moxa EtherDevice Switch has one Alarm Contact located on the top panel.
For detailed instructions on how to connect the Alarm Contact power wires to
the two middle contacts of the 6-contact terminal block connector, see the
Wiring the Alarm Contact section on page 6. A typical scenario would be to
connect the Fault circuit to a warning light located in the control room. The
light can be set up to switch on when a fault is detected.
The Alarm Contact has two terminals that form a Fault circuit for connecting to
an alarm system. The two wires attached to the Fault contacts form an open
circuit when (1) EDS has lost power from one of the DC power inputs, or (2)
one of the ports, for which the corresponding PORT ALARM DIP switch is set
to ON, is not properly connected.
If neither of these two conditions occurs, the Fault circuit will be closed.
DIP Switch Settings
ON DIP
12345
2
1
----
BSP
PORT
ALARM
ONOFF
P1
P2
P3
P4
P5
OFF ON
The default setting for each DIP switch is OFF. The
following table explains the effect of setting the
DIP switches to the ON positions.
DIP Switch Setting Description
ON Enables broadcast storm protection
BSP OFF Disables broadcast storm protection
ON Enables jumbo frame function
----
refers to Jumbo
Frame OFF Disables jumbo frame function
ON Enables the corresponding PORT Alarm. If the port’s link fails, the relay will form an
open circuit and the fault LED will light up.
PORT Alarm
OFF Disables the corresponding PORT Alarm.
The relay will form a closed circuit and the
Fault LED will never light up.
ATTENTION
To actively update DIP switch settings, power off and then power
on the EDS.

- 10 -
LED Indicators
The front panel of the Moxa EtherDevice Switch contains several LED
indicators. The function of each LED is described in the table below.
LED Color State Description
On Power is being supplied to power input
PWR1
PWR1 AMBER
Off Power is not being supplied to power input
PWR1
On Power is being supplied to power input
PWR2
PWR2 AMBER
Off Power is not being supplied to power input
PWR2
On When the corresponding PORT alarm is
enabled, and the port’s link is inactive.
FAULT RED
Off
When the corresponding PORT alarm is
enabled and the port’s link is active, or
when the corresponding PORT alarm is
disabled.
On TP port’s 10/100 Mbps link is active
Blinking Data is being transmitted at 10/100 Mbps
AMBER
Off TP Port’s 10/100 Mbps link is inactive
On TP port’s 1000 Mbps link is active
Blinking Data is being transmitted at 1000 Mbps
10/100/
1000M
GREEN
Off TP Port’s 1000 Mbps link is inactive
Auto MDI/MDI-X Connection
The Auto MDI/MDI-X function allows users to connect the EDS’s
10/100/1000BaseT(X) ports to any kind of Ethernet device, without paying
attention to the type of Ethernet cable being used for the connection. This
means that you can use either a straight-through cable or cross-over cable to
connect the EDS to Ethernet devices.
Triple Speed Functionality and
Switching
The EDS’s 10/100/1000 Mbps RJ45 switched port auto negotiates with the
connected device for the fastest data transmission rate supported by both
devices. The EDS is a plug-and-play device, so software configuration is not
required at installation or during maintenance.
The half/full duplex mode for the RJ45 switched ports is user dependent and
changes (by auto-negotiation) to full or half duplex, depending on which
transmission speed is supported by the attached device.

- 11 -
Auto-Negotiation and Speed Sensing
The EDS’s RJ45 Ethernet ports independently support auto-negotiation for
transmission speeds of 10 Mbps, 100 Mbps, and 1000 Mbps, with operation
according to the IEEE802.3 standard.
This means that some nodes could be operating at 10 Mbps, while at the same
time, other nodes are operating at 100 Mbps or 1000Mbps.
Auto-negotiation takes place when an RJ45 cable connection is made, and then
each time a LINK is enabled. The EDS advertises its capability for using 10
Mbps, 100 Mbps, or 1000 Mbps transmission speeds, with the device at the
other end of the cable expected to advertise similarly. Depending on what type
of device is connected, this will result in agreement to operate at a speed of 10
Mbps, 100 Mbps, or 1000 Mbps.
If an EDS’s RJ45 Ethernet port is connected to a non-negotiating device, it will
default to 10 Mbps speed and half-duplex mode, as required by the IEEE802.3
standard.
Specifications
Specifications and Pin Assignments
Technology
Standards IEEE 802.3 for 10BaseT,
IEEE 802.3u for 100BaseT(X),
IEEE 802.3ab for 1000BaseT,
Interface
RJ45 Ports 10/100/1000BaseT(X) auto negotiation speed
LED Indicators PWR1, PWR2, FAULT, 10/100M/1000M
DIP Switch Port break alarm, broadcast storm protection
Alarm Contact One relay output with current carrying capacity of
1A @ 24 VDC
Power
Input Voltage 12/24/48 VDC (9.6 to 60 VDC)
Input Current @ 24VDC 0.2A
Connection One removable 6-pin terminal block
Overload Current
Protection Present
Reverse Polarity
Protection Present
Mechanical
Casing IP30 protection, metal case
Dimension (W x H x D) 35 x 130 x 105 mm (1.37 x 4.05 x 4.13 in)
Weight 290g
Installation DIN-rail, Wall Mounting (optional kit)
Environmental
Operating Temperature 0 to 60oC (32 to 140oF)
-40 to 75oC (-40 to 167oF) for -T models
Storage Temperature -40 to 85oC (-40 to 185oF)
Ambient Relative
Humidity 5 to 95% (non-condensing)

- 12 -
Regulatory Approvals
Safety UL508(Pending)
Hazardous Location UL/cUL Class I, Division 2, Groups A, B, C, and D;
ATEX Class I, Zone 2, Ex nC nL IIC T4 (Pending)
EMI FCC Part 15, CISPR (EN55022) class A
EMS EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 3
EN61000-4-5 (Surge), Level 3
EN61000-4-6 (CS), Level 3
EN61000-4-8
EN61000-4-11
EN61000-4-12
Shock IEC60068-2-27
Free Fall IEC60068-2-32
Vibration IEC60068-2-6
WARRANTY 5 years
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll-free: 1-888-669-2872
Tel: [phone]
Fax: [phone]
Moxa China (Shanghai office):
Toll-free: 800-820-5036
Tel: [phone]
Fax: [phone]
Moxa Europe:
Tel: [phone]
Fax: [phone]
Moxa Asia-Pacific:
Tel: [phone]
Fax: [phone]
