MrHeater MH12HB Assembly instructions

2017 32097 CAN-CB
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed
space such as a camper, tent, car or
home.
DANGER: FOR YOUR SAFETY
If you smell gas:
1. Do not attempt to light appliance.
2. Extinguish any open flame.
3. Disconnect from fuel supply.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
PORTABLE PROPANE HEATER FOR
RECREATIONAL, COMMERCIAL AND
EMERGENCY INDOOR USE
PORTABLE HUNTING BUDDY
RADIANT HEATER
READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe
place for future reference. Do not allow anyone who has not read these instructions to assemble,
light, adjust or operate the heater.
MH12HB
www.mrheater.com 800-251-0001
Model #
LANGUAGES INCLUDED:
Use only Mr. Heater branded accessories
(See page 9 for WARNING information)

2
Mr. Heater | Portable Propane Heater
SPECIFICATIONS
this appliance may vary.
GAS TYPE ......................................................PROPANE
INPUT BTU/HR. .....................................6,000 / 12,000
TOP .......................................................................
....................................................................
SIDES ......................................................................
REAR .......................................................................
CONTENTS
General Safety Instructions ............................................... 2
.......................................................... 3
General Information .......................................................... 4
Operating with Disposable Propane Cylinders ...................4
Operating With Hose Connected to Remote Cylinder ........ 5
Pulse Ignition/Battery Innstallation....................................6
Maintenance..................................................................... 6
Troubleshooting ................................................................ 7
...........................................................................8
Parts Ordering Information ...............................................9
Service Information ........................................................... 9
Due to high temperatures, the appliance should be lo-
cated out of traffic and away from combustible materials.
Children and adults should be alerted to the hazard of
high surface temperatures and should stay away to avoid
burns or clothing ignition.
Young children should be carefully supervised when they
are near the appliance.
Do not place clothing or other flammable material on or
near the appliance.
Do not operate heater in any moving vehicle.
This heater is for outdoor use only.
When using a remote hose connection do not regulate or
reduce propane tank supply pressure to heater!
Regulator in heater must always be in place during operation.
Any safety screen or guard removed for servicing the ap-
pliance must be replaced prior to operating the heater.
The appliance should be inspected before each use.
-
partments, burner and circulating air passageways of
the appliance must be kept clean, see MAINTENANCE.
DO NOT use this heater if any part has been under
water. Immediately call a qualified service technician to
inspect the heater and to replace any part of the control
system and any gas control, which has been under wa-
ter.
When used without adequate combustion and ventilation
GENERAL SAFETY INSTRUCTIONS
THIS IS A HEATING APPLIANCE. DO NOT OPERATE
THIS APPLIANCE WITHOUT THE FRONT WIRE GUARD
INSTALLED. DO NOT ATTEMPT TO WARM OR COOK
FOOD ON THIS HEATER.
Do not use non-approved attachments on this heater.
WARNING:
Every time hose or tank is connected to unit, connection must be checked for leaks in one or more ways: Apply soapy
water to connection, look for bubbles, listen for hiss of escaping gas, feel for extreme cold, smell for rotten egg odor. Do
not use if leaking!
THE STATE OF CALIFORNIA REQUIRES THE FOLLOWING WARNINGS:
WARNING: Combustion by-products produced when using this product contain carbon monoxide, a chemical
known to the State of California to cause cancer and birth defects (or other reproductive harm).
WARNING:
Early signs of carbon monoxide poisoning resemble the
flu, with headache, dizziness and/or nausea. If you have
these signs, heater may not be working properly. Get
fresh air at once! Have heater serviced.
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or
other reproductive harm.
WARNING:
Any changes to this heater or its controls can be
dangerous.
NOTICE:
CAUTION:
Some carpets or linoleum surfaces may discolor if heater is
placed directly on these floor coverings.
INFORMATION)

3
Mr. Heater | Portable Propane Heater
ODOR FADE WARNING
WARNING
not be obstructed.
support the combustion air requirements of the
heater being used.
manual, heater dataplate, or contact the factory
to determine combustion air ventilation
requirements of the heater.
improper combustion.
monoxide poisoning leading to serious injury or
death. Symptoms of carbon monoxide poisoning
can include headaches, dizziness and difficulty
in breathing.
FUEL GAS ODOR
GAS ODOR IS YOUR SIGNAL TO GO INTO IMMEDIATE
ACTION!
Do not operate any electrical switches. Do not pull
any power supply or extension cords. Do not light
matches or any other source of flame. Do not use your
telephone.
area immediately.
valves, or the main fuel supply valve located at the
meter if you use natural gas.
low areas. When you have reason to suspect a propane
leak, keep out of all low areas.
supplier and your fire department. Do not re-enter the
building or area.
declared safe by the firefighters and your fuel gas
supplier.
firefighters check for escaped gas. Have them air out
the building and area before you return. Properly trained
service people must repair any leaks, check for further
leakages, and then relight the appliance for you.
smell the odor of the man-made chemical added to
can smell the odorant in these fuel gases.
than happy to give you a scratch and sniff pamphlet.
Use it to become familiar with the fuel gas odor.
around an odor for a period of time can affect your
sensitivity to that particular odor. Odors present in
animal confinement buildings can mask fuel gas odor.
through the soil can filter the odorant.
may be more odor at lower levels.
If you
continue to detect any gas odor, no matter how small,
treat it as a serious leak. Immediately go into action as
discussed previously.
REMEMBER!
light heater, perform service or repairs, or make any
system.
joints; i.e. hose, connections, etc., is a good safety
practice under any conditions. If you smell even a small
air, this heater may give off excessive CARBON MONOX-
IDE, an odorless, poisonous gas.
Some people - pregnant women, persons with heart or
lung disease, anemia, those under the influence of alco-
hol, those at high altitudes - are more affected by carbon
monoxide than others.
When heater is placed on the ground, make sure the
ground is level and keep any objects at least 24 inches
from the front of the heater. THIS HEATER IS EQUIPPED
CAUSE THE HEATER TO TIP OVER. NEVER OPERATE THE
Heater must not be exposed to flammable vapors or
liquids during lighting or operation.

4
Mr. Heater | Portable Propane Heater
GENERAL INFORMATION:
When the heater is cold, it will take a few minutes for
the burner tile to turn bright orange. This is normal and
the heater is working properly. If burner tile is visibly
flaming, turn heater off and call a qualified service tech-
nician.
The heater is to be used outdoors, but may experi-
ence nuisance shutoffs due to certain wind conditions.
When the unit is lit, there should be about a quarter
inch border around the tile that will not turn bright
orange. This is normal.
When operating the heater for the first time, the top
area of the reflector may discolor. This is also normal
and is no reason for concern.
with a special high-temperature resistant paint. When
the heater is used for the first time, the grill may give
off noticeable smoke or fumes. This is normal and will
not occur during subsequent uses. The fumes are not
harmful.
Operating time will vary depending on the heater
setting and the supply cylinder size. Up to 1.5 to 3.5
hours on a 1 lb. cylinder. Up to 36 to 72 hours on a 20
reduced when operating continuously at temperatures
these conditions.
When moving heater when lit or bumping heater setting
it down, the tip over switch may shut off heater. If this
happens, re-light.
Do not leave this appliance unattended while it is in
operation.
LIGHTING / OPERATING
INSTRUCTIONS FOR USE WITH
DISPOSABLE 1 LB. PROPANE
CYLINDERS:
WARNING: Always inspect propane cylinder and heater propane
connections for damage, dirt, and debris before attaching
propane cylinder. Do not use if head of cylinder is damaged,
punctured or deteriorated.
TOUCH. NEVER SMOKE
WHEN ATTACHING OR
REMOVING PROPANE
REMOTE CONNECTIONS!
cylinders marked in
accordance with the
U.S. Dept. of Trans-
portation (DOT).
Use only 16.4 oz.
(1 lb.) disposable
cylinders that mate
with No. 600 valve
connection.
Heater and attached
cylinder must be in
an upright position
during operation.
Make sure four-po-
sition Control Knob
door, swivel regula-
tor outward for easy
tank installation.
Screw 1 lb. dispos-
cylinder clockwise
(from bottom) into
portable heater until
-
ure 2. DO NOT use
thread sealant on
this connection.
Check cylinder con-
nection for leaks
with soapy water at
the threaded con-
nection under the
domed plastic cover
where the cylinder
screws into the regu-
lator. SEE
-
TIC ADDESS Door.
Close access door.
Turn Control Knob
counterclockwise to
depress the pulse ig-
nition button located
in the accessory com-
partment (see pg 7).
HI
LO
PILOT
OFF

Mr. Heater | Portable Propane Heater
After pilot lights, hold down for 30 -60 seconds and
then release knob. Knob should return to fully extended
bright orange.
After burner tile has turned bright orange, adjust heat
output by turning Control Knob to desired position
To shut off heater, slightly push down and turn Control
CAUTION: After turning heater off, wire guard will
remain hot. Allow to thoroughly cool before storing.
Do not operate, store or remove cylinder near flam-
mable items or ignition sources.
HEATER WHEN NOT IN USE!
LIGHTING / OPERATING
INSTRUCTIONS FOR USE WITH HOSE
This Heater may be used with a remote refillable
-
doors and the Heater is used with Mr. Heater Hose No.
and fuel filter .
operate without the fuel filter as fuel contamination may
damage the heater.) Or use hose No. Buddy
series hose, fuel filter not required.
DANGER: NEVER bring a refillable propane cylinder
indoors. A fire or explosion can occur causing property
damage, serious injury or death!
Inspect the hose before each use of the heater. If there
is excessive abrasion or wear, or the hose is cut, replace
prior to using the heater with one of the Mr. Heater
The propane cylinder must include a listed overfilling
protection device as well as a collar to protect the cylin-
der valve.
Heater must be in an upright position during operation.
-
Swivel regulator outward for easy hose installation.
Screw hose connector into regulator on heater and
cylinder valve. Tighten all hose connections. DO NOT use
thread sealant on any of these connections.
filter to trap any oil substances when connect-
ed to a remote cylinder that can make heater inoper-
able.
Check all hose connections for leaks with soapy water at
the threaded connection under the domed plastic cover
where the hose connector screws into the regulator and
-
tion and depress the pulse light button located in the
accessory compartment. This may take longer to purge
air from the supply hose depending on the length of the
hose being used.
If pilot does not light, hold down the pilot button for ap-
proximately 30 seconds and depress pulse light button
again. Repeat until pilot lights.
After pilot lights, hold down for 30 -60 seconds and
then release knob. Knob should return to fully extended
heater slightly depress knob and gently turn to lock in
-
tion until burner tile turns bright orange.
After burner tile has turned bright orange, adjust heat
output by turning Control Knob to desired position
Do not try to adjust heating levels by using the
propane tank shut off valve.
CAUTION: After turning heater off, wire guard will
remain hot. Allow to thoroughly cool before storing.
When not in use, the gas must be turned off at the
to use up propane in supply line until heater shuts off.
from the heater, the heater and the cylinder must be
stored outdoors, in a well ventilated space, out of reach
of children, and must not be stored in a building, garage
or any other enclosed area.
Indoor storage of the heater is permissible only if the
cylinder is disconnected and removed from the heater.
Cylinders must be stored outdoors out of the reach of
children and must not be stored in a building, garage or
any other enclosed area.

Mr. Heater | Portable Propane Heater
The MH12HB has two storage compartments, with access
doors, on the left side of the heater. The pulse light
button is located in the forward compartment (Ref.A).
This compartment can also be used to store small tools or
spare fuel filters (not included).
The rear compartment (Ref.B) can be used to store a
spare 1# tank (not included).
PULSE IGNITION:
MAINTENANCE:
Always keep the heater area clear and free from combus-
tible materials, gasoline and other flammable vapors and
liquids.
Keep the vent areas (slots in the bottom and the top at the
front and rear of heater) clear at all times.
and without a noticeable flame. A blue flame that rolls out
at the top of the ceramic tile indicates an accumulation of
dust, lint or spider webs inside the casing assembly and
main burner assembly. If the pilot is yellow or the burner
has a noticeable flame, cleaning may be required. Use the
following procedure to inspect the casing assembly and
main burner assembly.
It is necessary to periodically check the burner orifice and
burner venturi tube to make sure they are clear of insects/
nests or spider webs that may accumulate over time. A
clogged tube can lead to a fire.
1 Allow heater to thoroughly cool before performing any
maintenance.
2 Remove disposable 1 lb. cylinder from heater or turn
hose from heater.
3 Remove (4) four screws that secure the rear cover to the
Heater.
4 Pivot cover outward from bottom. Release from 2 top
clips. Set aside.
5 Remove (4) four burner retaining screws and fuel line
from burner assembly. Remove burner assembly from
back of housing.
6 Inspect interior of housing for accumulation of dust, lint
or spider webs. If necessary, clean interior housing with
a vacuum cleaner or apply air pressure. Do not damage
any components within the housing assembly when you
are cleaning.
7 Inspect and clean main burner orifice (threaded into
orifice holder). Orifice holder is attached to the burner
assembly venturi with (2) two screws.
8 Inspect and clean pilot (mounted to bracket) by using a
vacuum or apply air pressure through the holes in the
WARNING: Never use needles, wires, or similar cylin-
drical objects to clean the pilot to avoid damaging the
calibrated orifice that controls the gas flow.
9 Apply air pressure (max. 30 psi.) into ceramic tile of
burner assembly and the venturi tube (ref. item #16) to
remove dust, lint or spider webs.
10 Reassemble main burner orifice holder onto the burner
assembly.
11 Reinstall burner assembly into the heater housing
12 Reinstall fuel line and check for leaks.
13 Install heater back cover.
B
Visually inspect the pilot flame and burner periodically dur-
ing use. The pilot flame should be blue in color (not yellow)
and will extend beyond the thermocouple. The flame will
A slight yellow flame may occur where the pilot flame
and main burner flame meet. The burner should be bright
orange (with a slight blue color around the border, a red-
orange haze that is visible on the ceramic tile is acceptable)

Mr. Heater | Portable Propane Heater
TROUBLESHOOTING INFORMATION:
If Spark electrode does not produce spark.
CHECK
Sensor).
If Spark electrode produces spark but pilot does not light.
CHECK
hose and filter where required and turn on valve at remote
cylinder.
MAINTENANCE.
If Pilot flame does not stay lit when knob is released.
CHECK
or held in long enough to purge air from lines.
MAINTENANCE.
If Main burner does not ignite.
CHECK
-
NANCE.
CHECK

8
Mr. Heater | Portable Propane Heater
ACCESSORIES:
ITEM # DESCRIPTION
(Recommended use with fuel
filter.)
(Recommended use with fuel
filter.)
(Recommended use with fuel
filter.)
10 ft. BUDDY-SERIES HOSE
required)
REPLACEMENT PARTS LIST:
1. 32098 Handle (Back)
3. 32129 Back Panel Assy
4. 32145 Pulse Igniter
5.
8. 32106 Accessory Compartment Base
10. 32134 Spare Bottle Bracket
11. 32128 Bottom Panel
12. 32135 Regulator Bracket
13. 32147 Regulator Assy
14. 32108 Handle Base
15. 32123 Knob Black
16. 32109 Right Side Housing
17. 32110 Right Door
18. 32403 Tip Over Switch
19. 32124 Control Valve Assy
20. 78422 Pilot Assy
21. 32052 Orifice Adapter
22. 32141 Orifice Assy
23. 32111 Heat Shield Assy
24. 32114 Ceramic Tile Clip
25. 32113 Burner Assy
26. 32112 Ceramic Tile
27. 32115 Reflector
28. 32137 ODS Bracket
29. 32116 Wire Guard
31. 32146 Tile Gasket*
*Part Not Shown
32147

Mr. Heater | Portable Propane Heater

Mr. Heater | Portable Propane Heater
PRODUCT REGISTRATION: Thank you for your purchase.
Please log in to http://www.egiregistration.com to register your product.
OPERATING INSTRUCTIONS
MH12HB
Model #
Mr. Heater and Portable Buddy are registered trademarks of Enerco Group, Inc.
© 2017, Enerco/Mr. Heater. All rights reserved
Mr. Heater, Inc. reserves the right to make changes at any time, without notice or obligation, in colors, specifications,
accessories, materials and models.
WARNING:
SERVICE AGENCY. MR. HEATER HOSES , AND
WARNING:
NEVER
NEVER USE HAND-MADE OR THIRD PARTY ACCESSORIES OR
DEATH TO YOU OR OTHERS.
PARTS ORDERING INFORMATION:
PURCHASING: Accessories may be purchased at any Mr. Heater local dealer or direct from the factory
FOR INFORMATION REGARDING SERVICE
www.mrheater.com
Please include the model number, date of purchase, and description of problem in all communication.
LIMITED WARRANTY
Mr. Heater, Inc. warrants its heaters and accessories to be free from defects in material and workmanship for a period of
1 year from date of purchase. Mr. Heater, Inc. will repair or replace this product free of charge if it has been proven to be
defective within the 1-year period, and is returned at customer expense with proof of purchase to Mr. Heater, Inc. within
including but not limited to using a heater for the cooking or warming of foods; or c) has been used with hand-made or
third party accessories or attachments.

LISEZ SOIGNEUSEMENT LES INSTRUCTIONS : lisez et observez toutes les instructions. Conservez les
APPAREIL DE
CHAUFFAGE PORTATIF
AU GAZ PROPANE À
USAGE RÉCRÉATIF
EXTÉRIEUR
Modèle #
2017 32097 CAN-CB
PRODUCTION DE MONOXYDE
DE CARBONE
Cet appareil produit du monoxyde de
carbone, un gaz inodore.
endroit fermé risque de causer la mort.
récréatif, une automobile ou une maison.
DANGER: POUR VOTRE SÉCURITÉ
Si vous percevez une odeur de gaz :
2. Éteignez toute flamme nue.
POUR VOTRE SÉCURITÉ
liquides ou vapeurs inflammables à proximité de
PORTABLE HUNTING BUDDY
RADIANT HEATER MH12HB
I
www.mrheater.com 800-251-0001
LANGUES INCLUSES:

Mr. Heater | Chauffage de Propane Portatif
SPÉCIFICATIONS
carburant pour cet appareil peut varier.
.................................................. MH12HB
TYPE DE GAZ ................................................PROPANE
PUISSANCE BTU/H..................................6,000/12,000
DESSUS ............................................................. 75 cm
DEVANT ............................................................ 60 cm
................................................................15 cm
....................................................................0
Instructions générales en matière de sécurité .......................2
Avertissement lié aux substances odorantes .........................3
Informations générales .........................................................3
.....4
distante ............................................................................ 5
Entretien ..............................................................................5
Dépannage ..........................................................................6
.....................................................................7
Informations sur la commande de pièces .............................8
Informations sur le service ....................................................9
Ne pas utiliser non accessoires approuves sur ce
chauffage.
doit être placé à distance des lieux de passage et des matéri-
aux combustibles.
-
avec une peinture résistante de-température-haute spéciale.
Quand le chauffage est utilisé pour la première fois, le gril
-
mal et ne se produira pas pendant les utilisations ultérieures.
Ne placez pas de vêtements ou de matière inflammable sur
-
vement.
Cet appareil de chauffage est conçu uniquement pour être
DE SÉCURITÉ
CET APPAREIL SERT AU CHAUFFAGE. NE LE FAITES PAS
FONCTIONNER SANS LA GRILLE PROTECTRICE INSTALLÉE
ALIMENTATION SUR CET APPAREIL.
AVERTISSEMENT :
AVERTISSEMENT :
REMARQUEZ :
AVERTISSEMENT :
sifflement produit par une fuite de gaz, à une sensa-
AVERTISSEMENT :
Toute modification de cet appareil de chauffage ou
de ses commandes constitue un danger.
AVERTISSEMENT :
de carbone ressemblent aux symptômes de la grippe
chauffage ne fonctionne peut-être pas correctement.
AVERTISSEMENT :
PRUDENCE:
chauffage est placé directement sur ces revêtements de plancher.
informations générales)
2

Mr. Heater | Chauffage de Propane Portatif
ODEUR DE GAZ COMBUSTIBLE
propane (liquéfié) ou de la bonbonne, ainsi que le robinet
du gaz naturel.
y a une fuite de gaz propane, éloignez-vous des endroits plus
bas.
que le personnel du service des incendies ou le fournisseur
aucun risque.
expérimenté doit colmater toute fuite, vérifier la présence
ODEUR DÉCELÉE
donc possible que certaines personnes ne puissent sentir la
substance odorante ajoutée au gaz propane (liquéfié) ou
au gaz naturel. Vous devez savoir si vous arrivez à déceler
gaz naturel. Pour ce faire, les détaillants de gaz propane
(liquéfié) locaux seront heureux de vous fournir un feuillet
comprenant une pastille à humer. Servez-vous de cette
combustible.
demeurez un certain temps dans un endroit où cette odeur
-
dernier.
-
système de commandes et de contrôle du gaz qui ont été
à la combustion et à la ventilation, il produira une quantité exces-
sive de MONOXYDE DE CARBONE, un gaz toxique et inodore.
Certaines personnes, notamment celles enceintes, celles affec-
davantage affectées par le monoxyde de carbone que les autres.
que ce dernier est de niveau. Gardez les objets à une distance
AVERTISSEMENT LIÉ AUX SUBSTANCES
ODORANTES
AVERTISSEMENT
locaux où demeurent des gens.
obstrué.
apport adéquat en air de ventilation.
le fabricant pour obtenir les renseignements relatifs
combustion.
insuffisant.
les maux de tête, les étourdissements et la difficulté
respiratoire.
3

Mr. Heater | Chauffage de Propane Portatif
différents niveaux. Étant donné que le gaz propane (liquéfié)
des niveaux inférieurs.
Si
une odeur de gaz persiste, même si elle est minime, agissez
immédiatement tel que décrit précédemment.
RETENIR!
Odeur du gaz combustible et Substance odorante, ci-dessus.
odeurs que dégagent le gaz propane (liquéfié) et le gaz
naturel.
réparation des appareils au gaz propane (liquéfié), ne tentez
raccords, du tuyau et autres éléments. Si vous décelez la
moindre odeur de gaz, COMMUNIQUEZ IMMÉDIATEMENT
INFORMATIONS GÉNÉRALES :
-
ture de la pièce, il faudra quelques minutes pour que le bloc
appelez un technicien qualifié.
vent.
-
mi-centimètre entourant le bloc qui ne devienne pas orangé.
Ceci est normal.
la surface supérieure du réflecteur se décolore. Ceci est aussi
attendez cinq minutes et allumez-le de nouveau.
DE FONCTIONNEMENT AVEC DES
AVERTISSEMENT : Vérifiez toujours les raccords de la bouteille et de
est endommagée ou percée,
ne vous en servez pas.
RACCORDANT OU EN
DISTANCE!
bouteilles de gaz propane
liquéfié conformes aux
normes du U.S. Dept. of
Transportation (DOT).
bouteilles jetables de 500
g (1 lb) munies du raccord
la bouteille doivent être en
position verticale pendant
le fonctionnement.
bouton de commande
à quatre positions est à
figure 1).
de réservoir facile. Vis 1
livre. le cylindre de réserves
disponible du GAZ DE
(du fond) dans le chauffage
mains; (voir figure 2).
NE
PAS utiliser du produit
d etancheite pour file-
tages sur cette liaison
-
neuse le raccord fileté situé
HI
LO
PILOT
OFF
carburant
4

Mr. Heater | Chauffage de Propane Portatif
-
ape de la bonbonne.
fonctionnement.
gaz propane liquéfié. Serrez tous les raccords de tuyau.
NE PAS
connexions.
situé sous le couvercle bombé en plastique, là où le raccord se visse
dans le régulateur, et celui situé à la bonbonne de gaz. VOYEZ
complètement pour enflammer le pilote et tenir depuis 30-60 sec-
revenir à la position complètement prolongée. Pour faire marcher le
chauffage, déprimez légèrement le bouton et tournez doucement
pour vous bloquer dans la position désirée.
-
ATTENTION : Une fois que le bloc a atteint cette couleur vive,
réglez la sortie de chaleur en tournant le bouton de commande à la
AVERTISSEMENT :
après avoir épuisé le gaz restant dans le tuyau, enfoncez légèrement
le bouton de commande et tournez-le dans le sens des aiguilles
bien aéré, hors de la portée des enfants et ne doit pas être remisé
dans un édifice, un garage ou tout autre endroit fermé.
-
remisées dans un édifice, un garage ou tout autre endroit fermé.
sous le couvercle
bombé en plastique,
là où la bouteille se
visse dans le régula-
teur. VOYEZ VEA
AVERTISSEMENT !
-
Volet étroit.
de commande dans
le sens contraire
montre à la posi-
enfoncez le bouton
page 7).
revenir à la position complètement prolongée. Pour faire marcher le
chauffage, déprimez légèrement le bouton et tournez doucement
pour vous bloquer dans la position désirée.
-
chaleur en tournant le bouton de commande à la position désirée
AVERTISSEMENT :
ET DE FONCTIONNEMENT AVEC
1 ou et le filtre
à combustible sont utilisés. Ce dernier doit être remplacé
matériels, des blessures graves et des pertes de vie risqueraient de se
produire.
ci-dessus.

Mr. Heater | Chauffage de Propane Portatif
El MH12HB tiene dos compartimientos del almacenamiento, con
las puertas de acceso, en el lado izquierdo del. El botón de la luz
del pulso está situado en el compartimiento delantero (Ref.A). Este
compartimiento se puede también utilizar para salvar las pequeñas
herramientas o los filtros de combustible de repuesto (no incluidos).
BA
Botón de la
ignición del pulso
Cuadro 5
ENTRETIEN :
inflammables.
bas) dégagés en tout temps.
flamme jaune apparaisse là où se rencontrent la flamme veilleuse et
un peu de bleu sur le contour; une brume rouge orangée visible sur le
bloc céramique est acceptable) sans flamme apparente. Une flamme
peut causer un incendie.
la pliant légèrement pour la sortir des trous du couvercle avant.
-
veilleuse, indiqués par les flèches de la figure 2, à gauche.
AVERTISSEMENT :
place contre le réflecteur.
12 Réinstallent la ligne du combustible et vérifient pour les fuites.
13 Installent le chauffage couvrent en arrière .

DÉPANNAGE :
fixer.
bouteille jetable ou raccordez le tuyau et ouvrez la
soupape de la bonbonne.
ou de la saleté : nettoyez-la (voir ENTRETIEN).
le bouton
le thermocouple : nettoyez la veilleuse (voir
ENTRETIEN).
remplacez-le.
ENTRETIEN).
de contrôle et le régulateur.
renseignements supplémentaires.
Mr. Heater | Chauffage de Propane Portatif

Mr. Heater | Chauffage de Propane Portatif
ACCESSOIRES:
DESCRIPTION
PROPANE 1,5 m (orientable
volant) (Utilisation recomman-
PROPANE 3,6 m (orientable
volant) (Utilisation recomman-
PROPANE 3,6 m (orientable
volant) (Utilisation recomman-
-
placer annuellement)
non exigé)
1. 32098 Traitement (arrière)
2. 32099 Traitement (avant)
3. 32129 Assemblée de panneau arrière
5. 32103 Porte gauche
6. 32104 Porte de filtre à essence
8. 32106 Base annexe de compartiment
9. 78436 Garniture de jambe
10. 32134 Parenthèse disponible de bouteille
11. 32128 Panneau inférieur
12. 32135 Parenthèse de régulateur
13. 32147 Assemblée de régulateur
14. 32108 Base de traitement
15. 32123 Molette, noir
17. 32110 Porte droite
18. 32403 Extrémité au-dessus de commutateur
19. 32124 Assemblée de soupape de commande
20. 78422 Assemblée pilote
23. 32111 Assemblée de bouclier thermique
24. 32114 Clip de carreau de céramique
26. 32112 Carreau de céramique
27. 32115 Réflecteur
29. 32116 Dispositif protecteur de fil
30. 32125 Panneau avant
31. 32146 Garniture de tuile*
* Partie non affichée
# DE
RÉF.
#
ART.
8
Orifice
O-ring, orifice

Mr. Heater | Portable Propane Heater

Mr. Heater | Portable Propane Heater
-
leurs, aux spécifications, aux accessoires, aux matériaux et aux modèles.
AVERTISSEMENT:
ET ,
AVERTISSEMENT:
ACHAT :
POUR OBTENIR DES INFORMATIONS SUR LE SERVICE
Appelez sans frais au 800-251-0001
www.mrheater.com
Nos heures de bureau sont de 8 h 00 à 17 h HE, du lundi au vendredi
avec nous..
GARANTIE LIMITÉE
Enerco Group Inc. garantit ses appareils de chauffage et ses accessoires contre les défauts de matériel et de main-
INSTRUCTIONS DE FONCTIONNEMENT
MH12HB
Modèle #
Mr. Heater and Portable Buddy are registered trademarks of Enerco Group, Inc.
© 2017, Enerco/Mr. Heater. All rights reserved
ENREGISTREMENT DU PRODUIT : Nous vous remercions pour votre achat.
Veuillez vous connecter à http://www.egiregistration.com pour enregistrer votre produit.
