Music Man BT-X63 User manual

1
BT-X63 5098 5099 / 0923
MusicMan®* User Manual
TWS In-Ear headphones with
charging case BT-X63
Before using the appliance for the first time, please
read the instructions for use and safety information
carefully.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capacities, or by persons lacking in
experience or knowledge, unless they are
supervised or instructed on the use of this device
by a person responsible for their safety. Children
should be supervised to ensure they do not play
with this device.
Keep this user manual for future reference or
product sharing carefully. Do the same with the
original accessories for this product. In case of
warranty, please contact the dealer or the store
where you bought this product.
Enjoy your product * Share your experience
and opinion on one of the well-known internet
portals.

2
BT-X63 5098 5099 / 0923
Features
•True Wireless Stereo (TWS) in-ear headphone
•Bluetooth V5.3
•Built-in microphone for phone calls
•Multi-functional touch buttons on both in-ear
headphone
•Charging case for up to 4 charges
•Automatic on/off function
Technical specifications
Bluetooth
version
V5.3
Bluetooth
Transmitting distance ~10m (open
space)
Frequency band 2.4GHz
Radiated transmission power
max. 2.5mW
Loudspeaker /
frequency /
impedance
2x 3mW / 20Hz-20kHz / 32Ω
Audio codec
A2DP / HFP / HSP / AVRCP
/ CVC
Playtime ~4h (middle volume)

3
BT-X63 5098 5099 / 0923
Charges with
charging box
4 times fully charged
Standby time ~300h inside case
Charging time
earphones
~1.5h
Battery
earphones
(each)
Built-in rechargeable 30mAh
lithium polymer battery 3.7V
/ charging via charging case
Charging time
case
~2h (5V/1A)
Battery
charging case
250mAh lithium polymer
battery 3.7V / charging via
USB type C
Operating
temperature
-10°C up to +50°C
Weight /
dimension
earphone
10.5g / (L)31.6 x (W)23.8 x
(H)22mm
Weight /
dimension
case
35.0g
/ (L)61 x (W)46 x
(H)24mm
Package
content
MusicMan® BT-X63,
charging case, USB Type-C
charging cable, 2 different
plug size caps, user manual

4
BT-X63 5098 5099 / 0923
Specifications are subject to change without notice
- please be sure to use the latest manual available
on the manufacturer's website.
Product overview
1
Ear
phone
2
Earphone cap
(changeable)
3
Indicator LED
earphone
4
Earphone charging
contact
5
Charging case
6
Indicator LED case
7
USB-C charging
interface
1
23
4
5
6
7

5
BT-X63 5098 5099 / 0923
Charge
Connect the charging box with the USB-C cable
and a USB power adapter* (*not included in the
delivery). Wait until the box is fully charged. The
charging box LED (6) turns blue.
Bluetooth connection
Pairing
Remove the BT-X63
earphones from the charging
box. The indicator on one
earphone will flash red and
blue quickly and the indicator
on the other earphone will
flash red slowly, indicating
they are ready to pair. Start
the Bluetooth pairing function
with your smartphone / tablet
or any other Bluetooth-enabled device. Click on
"MusicMan BT-X63" in the Bluetooth settings to
pair your device with the earphones.
Reset pairing
To pair with any other device, unpair the BT-X63
from the Bluetooth settings of your smartphone or
tablet.
MusicMan BT-X63

6
BT-X63 5098 5099 / 0923
Touch button settings
Listening to music
•Volume +: double tap the
earphone L to decrease
the volume.
•Volume -: double tap the
earphone R to increase
the volume.
•Previous: press the earphone L and hold for
about 1.5 seconds to play previous song.
•Next: press the earphone R and hold for about
1.5 seconds to play next song.
•Play/pause: quick tap earphone R or L to play or
pause music.
Phone calls
•Quick tap earphone R or L to answer call when
in use.
•Quick tap earphone R or L again to end call.
•Press earphone R or L and hold for about 1.5
seconds to reject call.
•Tap earphone R or L four times to redial last
phone number.
Voice control
Triple tap earphone R or L to activate voice
assistant.
L R
Touch area

7
BT-X63 5098 5099 / 0923
On/Off
On: Press the touch area and hold; or remove the
earbuds out of the charging box. LED turns red.
Off: Press the touch area and hold for about 3
seconds or put the earbuds into charging case.
LED flashes red three times.
Single use of one earphone
Take out the chosen earphone you want to use, it
will connect automatically to the last connected
BT-device.
Support
Service phone No. for technical support: 01805
012643*(14 cent/minute from German fixed-line
and 42 cent/minute from mobile networks).
Free Email: suppo[email protected]
The support hotline is available Mon-Fri from 9am
to 1pm & 2pm to 5pm.
Troubleshooting
If you cannot connect the headphone to your
phone, do as follows:
Ensure that the headphone is charged and in on
state. Ensure that the Bluetooth feature is
activated on your phone. Check that the
headphone is within 10m of your phone and that
there are no obstructions between the headphone

8
BT-X63 5098 5099 / 0923
and the phone, such as walls or other electronic
devices. The BT-X63 powers off or does not turn
on again could be either a low battery or a problem
with the power supply. Charge the BT-X63 and
check the battery status of the charging box. (We
suggest charging the BT-X63 all 2–3 month if it is
not in use)
Notes
●Wear the right size of ear caps to achieve the
best noise reduction performance and sound
quality. ●Noises are heard from the BT-X63 could
be a poor Bluetooth signal. To avoid noise, stay
within the Bluetooth range of ~10m. ●While the
earphones are charging, sounds can be heard
from the charging box. This is a normal fact of a
mini-transformer working at high frequency. Above
85% charge, the current consumption decreases
and the shrill noise disappears. ●Avoid prolonged
exposure to excessive volume that may cause
noise-induced hearing impairment. ●Turn the
volume down before putting on your headphones,
then adjust it to the right volume. ●Do not use
headphones while driving or riding your bike.
●Stay away from sharp edges, uneven surfaces,
metal parts, and anything that could damage the
headphones. ●Do not modify, repair or remove
headphones without professional guidance. ●Do

9
BT-X63 5098 5099 / 0923
not use corrosive or volatile liquid to clean the
earphone. ●Do not use headphones in dangerous
environments. ●This headphone contains small
parts, which may cause a choking hazard. Please
keep away from children and pets to prevent
accidents.
Care
Clean the device only with a dry or slightly damp,
lint-free cloth.
Do not use abrasive cleaners to clean the device.
Warnings
●Only charge the BT-X63 charging box through
the DC 5V USB-C port by using the provided USB-
C charging cable. You also can use an USB
charging adapter but ONLY up to DC 5V/1A. Do
not (!) charge the BT-X63 with more power! ●If the
BT-X63 fails to link to your mobile device or if it
fails to play music after being connected, the user
shall check if your mobile device supports SBC /
ACC. ●Do not disassemble the BT-X63, it may
result in short-circuit or damage. ●Battery warning:
Improper use of the battery may cause fire or
chemical burns. The battery may explode in case
of damage. The battery can only be charged using
an adapter especially provided for this product.
●Do not drop or shake the BT-X63, it may break

10
BT-X63 5098 5099 / 0923
internal circuit boards or mechanics. ●Keep the
BT-X63 in dry and ventilated environment. Avoid
high humidity and high temperature. Also,
batteries should not be exposed to excessive heat
or direct sunlight. ●This BT-X63 is not water-
resistant; keep it away from moisture. ●Keep the
BT-X63 away from little children.
To prevent possible hearing damage, do
not listen at high volume levels for long
periods.
Declaration of Conformity
The EU Declaration of Conformity can be
requested at the following address:
www.technaxx.de/ (in the lower bar
"Declaration of Conformity").
Disposal
Disposal of the packaging. Sort
packaging materials by type upon
disposal.
Dispose of cardboard and paperboard in
the waste paper. Foils should be
submitted for recyclables collection.

11
BT-X63 5098 5099 / 0923
Disposing of old equipment (Applies in the
European Union and other European countries
with separate collection (collection of recyclable
materials) Old equipment must not be disposed of
with household waste! Every consumer is required
by law to dispose of old devices that can no longer
be used separately from household waste, e.g. at
a collection point in his or her municipality or
district. This ensures that the old devices are
properly recycled and that negative effects on the
environment are avoided. For this reason,
electrical devices are marked with the symbol
shown here.
Batteries and rechargeable batteries
must not be disposed of in household
waste! As a consumer, you are required
by law to dispose of all batteries and rechargeable
batteries, whether they contain harmful
substances* or not, at a collection point in your
community/city or with a retailer, to ensure that the
batteries can be disposed of in an environmentally
friendly manner. * marked with: Cd = cadmium, Hg
= mercury, Pb = lead. Return your product to your
collection point with the fully discharged battery
installed inside!

12
BT-X63 5098 5099 / 0923
Made in China
Distributed by:
Technaxx Deutschland GmbH & Co. KG
Konrad-Zuse-Ring 16-18,
61137 Schöneck, Germany
