MuxLab 500044 User manual

© MuxLab Inc. 94-000787-A
8495 Dalton Rd, Montreal, Quebec, Canada. H4T 1V5
Tel: [phone] Fax: [phone]
Toll Free (North America): [phone]
E-mail: [e-mail] URL: www.muxlab.com
Specifications
Environment
Audio HiFi Muxlab Balun User
Device Targeted
Installation of multiple audio receiver using Muxlab Audio Balun
HiFi and Audio Matrix.
Compatible TX Unit
500210, 500028
Compatible RX Unit
500219, 500028
Compatible mounting
hardware
M500902, M500900, M500910, M500915
Cabling Requirement
Any 4-pair straight cable Cat5, 5E or 6 UTP.
Connectors
Four RJ45 connectors.
RJ45 Pin Configuration
Pin 1+2, 3+6 for audio
Maximum distance
Total distance (all length must be added): 3250ft (1km)
Temperature
Operating: -40° to 60°C (-40° to 140°F)
Storage: -40° to 85°C (-40° to 185°F)
Humidity
Maximum 95% (non-condensing)
Enclosure
ABS UL94HB fire retardant plastic
Dimensions
6 x 5.5 x 2.5 cm (2.4” x 2.25” x 1.0”)
Weight
50g (2 oz.)
Warranty
Lifetime
Order Information
M500044 Stereo Analog Audio Splitter
ANALOG STEREO AUDIO
SPLITTER 1X3
500044
Quick Installation Guide
Overview
The Analog Stereo Audio Splitter allows one analog source using either the Muxlab
analog audio balun (500028) or Muxlab Audio Matrix Switch (500210) to be connected
passively to up to three receivers using Muxlab’s Analog Audio Balun (500028) over
CAT 5e/6 cabling.
Applications
Installation of multiple audio receiver using Muxlab Audio Balun HiFi, Audio Matrix
and Balun Amplifier.
All manuals and user guides at all-guides.com

© MuxLab Inc. 2015
Installation
One splitter and up to 3 audio analog balun (500028) can be used to complete the
system via UTP cable.
Caution: Do not attempt to open the housing. There are no user-serviceable parts
inside the box. Opening the unit will void your warranty.
Do not connect the unit to a telecommunication outlet wired to unrelated
equipment. Making such a connection may damage the equipment and/or
the balun. Verify that the desired twisted pairs are not being used for
other LAN or telephone equipment.
1. Use a dedicated 4-pair Cat5e/6 cable between the source and the receiver balun. A patch
panel can also be used.
2. Verify the wiring is “straight-through”, has 4 twisted pairs and has the standard Ethernet
RJ45 plug.
3. Each connector (#1, 2, 3& 4) can be used for input or output. Only one source can
be used.
4. Cascading multiple units is not recommended.
5. At the destination point, connect the passive balun Audio receiver (or AV receiver)
or Muxlab Amplifier (500219).
Troubleshooting
The following tables describe some of the symptoms, probable causes and possible solutions regarding
the splitter:
Video Symptom
Probable Cause
Possible Solutions
No audio
No continuity
Check continuity on each pair.
Check if pairs are not swapped or reversed.
Check if the four pairs are present.
Equipment off
Check the audio source equipment.
Loss of Hi Frequency
Exceeded distance
Verify total cable length.
Hum or Buzz
Defective cable or
equipment incorrectly
connected or grounded.
Change cable or verify wiring interface.
Try grounding equipment on each side to
safety ground.
If you still can’t diagnose the problem, please call MuxLab Customer Technical Support at
877-689-5228 (toll-free in North America) or ([phone] (International).
