myPhone VENUM User manual

©
©©
© 2015 myPhone. All rights reserved. myPhone VENUM ENG
USER MANUAL
myPhone VENUM

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
2
Thank you for choosing myPhone FUN 4. This manual is intended
to guide you through the operation of the device. Full version of
Manual is available on http://www.myphone.pl/.
Without the prior ritten consent of myPhone no part of this
manual may be photocopied, reproduced, translated or
transmitted in any form or by any electronic or mechanical
means, including photocopying, recording or storing in any
storing system.

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
3
SAFETY
Read these simple guidelines. Not following them may be dangerous or illegal.
DO NOT RISK
Do not switch the telephone on when mobile phone use is prohibited or if it may cause
interference or danger.
SAFETY WHILE DRIVING
Do not use the device while driving.
RESTRICTED AREAS
Turn off your phone in aircraft as it can interfere with other devices onboard. It may also
interfere with medical equipment in hospitals or health care facilities. Obey all kinds of
prohibitions, regulations and warnings from medical personnel.
SAFETY ON SERVICE STATIONS
Switch off your mobile phone while refueling at a service station. Do not use it in the vicinity
QUALIFIED SERVICE
Only myPhone qualified servicer or authorized service center can repair this product.
Repairing the device by unqualified service or by unauthorized customer service center may
damage the device and void the warranty.
BATTERY AND ACESSORIES
Avoid exposing the battery to very low or very high temperatures (below 0°C / 32°F or above
40°C / 100°F). Extreme temperatures can affect the capacity and lifetime of the battery. Avoid
contact with liquids and metal objects as it may result in total or partial damage to the battery.
Battery should only be used for its intended purpose. Please do not destroy, damage or
dispose of the batteries in a fire - it can be dangerous and cause a fire. Worn or damaged
battery should be placed in a special container. Please do not open the battery. Overcharging
can cause damage. Therefore a single battery charge should not last longer than three days.
Fitting the battery of the wrong type may cause the explosion. Dispose of the battery as
instructed. Disconnect unused charger from the mains. If the charger cable is damaged it
should not be repaired but replaced with a new charger. Use only original myPhone
accessories which are included with the device.
WI-FI (WLAN)
The device is using non-harmonized frequency of wireless communication and is intended for
use in all European countries. In the European Union WLAN can be used without restriction
indoors. In France, the WLAN must not be used outdoors.

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
4
CHILDREN
The device is not a toy. The memory card and SIM card are so small that they could be
swallowed by a child. Keep the device and its accessories away from children.
INTERFERENCE
All wireless devices may cause interference that may affect the quality of work of other
equipment.
ATTENTION
To avoid damage to your hearing, do not use the device at high volume over an
extended period of time. Do not put enabled device directly to the ear.
Using the Manual
The device itself and screenshots included in this manual may differ from the actual
product. Accessories supplied myPhone FUN 4 may look different than the illustrations
in this guide.
The manual describes options in Android operating system. These descriptions may vary,
depending on the version of the operating system, hich ill be held by the user.
Important information
Most of the applications that can be installed on the device are mobile applications. The
operation of these applications may be different from their counterparts designed for
personal computers.
Applications installed on your device may vary depending on country, region and
hard are specifications. myPhone is not liable for performance issues caused by third-
party soft are.
myPhone is not responsible for irregularities that may occur hile editing the registry
settings and modifying the operating system soft are. Attempts to modify the system
can cause improper functioning of equipment and applications and be the reason of
voiding the arranty.

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
5
Trademarks
• Android, Google™, Google Maps™, Google Mail™, YouTube™,
Google Play™, Google Latitude™ and Google Talk™ logos are
trademarks of Google, Inc.
• racle and Java are registered trademarks of racle and / or its
affiliates.
• Wi-Fi® and the Wi-Fi logo are registered trademarks of the Wi-Fi
Alliance.
• All other trademarks and copyrights are the property of their
respective owners.
Producer
myPhone Sp. z o.o.
ul. Krakowska 119
50-428 Wrocław
Poland
helpline: ([phone]
E-mail: [email protected]
website: http://www.myphone.pl

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
6
Contents
Contents .................................................................................................................................... 6
Package contents .................................................................................................................... 7
Technical specifications ........................................................................................................ 7
1. Before the first start ........................................................................................................... 9
SIM car instalation ................................................................................................................ 9
Memory car instalation .............................................................................................. 9
Charging the battery .............................................................................................................. 9
2. Outer view .......................................................................................................................... 10
Keys .......................................................................................................................................... 11
Turning on/ turn off/ lock .................................................................................................... 12
3. Comunication ..................................................................................................................... 12
Making a phone call .............................................................................................................. 12
Text messages ........................................................................................................................ 13
4. Safety issues ....................................................................................................................... 13
Troubleshooting .................................................................................................................... 13
Screenshots ............................................................................................................................. 13
Memory car s ........................................................................................................................ 14
Protection of personal ata an other important information ................................. 14
Comments on the proper battery use .............................................................................. 14
Maintaining your phone ...................................................................................................... 15
Safety while listening to music/ making a phone calls ................................................. 15
Environment safety .............................................................................................................. 15
Proper isposal of use equipment .................................................................................. 16
Proper isposal of use batteries ...................................................................................... 16
Declaration of Conformity with European Union irectives ..................................... 16

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
7
Package contents
Before you start using your phone, make sure all of the follo ing items are included in
the box:
• Mobile phone myPhone VENUM
• Charger (adapter + USB cable)
• Headset HF
• user manual,
• arranty card.
Contact your dealer if any of the above items is missing or damaged.
myPhone FUN 4 set has a sticker ith the IMEI number on the package. Therefore it is
recommended to keep the packaging in case of any complaint. Keep the container out of
reach of children. When it is no longer needed dispose of container in accordance ith
local regulations.
Technical specifications
•
••
• Touch screen 5" an resolution of WVGA (800 x 480 px)
Modern display ith IPS technology provides an extremely deep colors and a ide
vie ing angle allo ing you to appreciate movies, photos and games in incredible, real
and juicy colors.
•
••
• Multi-Touch
The touch screen provides enjoyable ork ith myPhone FUN 4 - play, rite, dra ,
rotate images and maps - all this ith excellent quality of glass screen.
•
••
• 3G Network
All myPhone smartphones support 3G Net ork. This allo s you to make high-quality
voice calls, use internet, proceed video conferences, use location-based services and
vie mobile TV. With HSPA+ internet transfer reaches up to 21Mbps.
• Qua Core Cortex- A7 1.3 GHz Processor
Super-efficient quad-core processor ensures maximum efficiency of the phone.
Together ith 1GB of RAM is a great offer for the most demanding users. Games,
ebsites, e-mails - everything orks in the blink of an eye.
• Back camera 5 Mpx/Front camera 2 Mpx
The front ebcam allo s you to video chat and take pictures. The back camera is
capable of taking pictures and making movies of the highest quality, herever you
are.

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
8
•
••
• WiFi
myPhone VENUM is equipped ith WiFi technology, providing data transmission at
speeds compatible ith 802.11 b / g / n standards, so you can irelessly connect to
hot spots or to your home net ork. Receive, send, upload data, programs and files
ith no restrictions.
•
••
• Micro-B USB
With Micro-B USB 2.0 slot you can connect your smartphone to any computer.
•
••
• microSD car slot - up to 32GB
Problems ith memory capacity? 16 or 32 GB is not enough? myPhone VENUM does
not have such problems - use a removable microSD card, and do not orry about your
phone`s memory resources.
•
••
• Mini jack 3.5 mm
myPhone VENUM smartphone has a 3.5mm minijack slot. It enables you to connect
headphones or Hi-Fi set.
• An roi 5.1 Lollipop System
Extra-efficient system branded by Google - incredible opportunities are ithin your
hand - all applications are available at any time, the latest Gmail client or the bro ser
are just the beginning of hat you ill find in your myPhone VENUM smartphone -
the rest can be found in Google Play online store.
• Google Play
All myPhone smartphones have the ability to use applications located Google Play
online store. You need to register your individual Google account by giving your email
and pass ord. After registration and acceptance of the Rules, you can use all - free
and paid applications, available in Google Play.
• RAM: 1 GB
• 8 GB of internal memory
• Battery apa ity 2000 mAh
• Charger parameters:
- input: 100-240 V ~ , 50/60 Hz, 200 mA
- output: 5 V , 1000 mA
• Phone weight: 143 g

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
9
1. Before the first start
SIM car installation
myPhone VENUM is a mobile phone ith Dual SIM technology, hich allo s you to use
t o mobile net orks simultaneously. First slot supports SIM or microSIM adapter, hile
the second slot microSIM cards only. To insert the SIM card properly proceed as follo s:
•Turn off the phone, remove the back cover (undermine it ith fingernail using a
slot designed for this purpose. It is located in the lo er right corner of the phone)
and remove the battery.
•Insert the SIM card into the slot according to the dra ings underneath the seat.
Memory car installation
Use only memory cards compatible and approved by myPhone. Incompatible memory
cards may damage the device, the card itself and lead all data loss. Incompatibility of
memory card can be caused by incorrect card format (requires microSD format) or
unsupported card size (over 32GB). To properly insert a memory card proceed:
•Turn off the phone, remove the back cover (undermine it ith fingernail using a slot
designed for this purpose. It is located in the lo er right corner of the phone) and remove
the battery.
• Insert the memory card into the slot according to the dra ings underneath the seat.
Charging the battery
Before you turn on the phone for the first time the battery needs to be charged. Charge
the battery ith charger included in the set. The capacity of battery is 1800 mAh. In case
of problems ith battery - the device should be delivered to myPhone service center.
You should only use chargers and cables approved by myPhone. Unauthorized chargers
or cables can cause the battery explosion and damage your device. When the battery
becomes lo , lo battery indicator appears on display. To continue using the device,
recharge the battery. When the battery is completely discharged the phone can`t be
turned on even hen loading is in progress. To turn it on again the battery needs to be
loaded for fe minutes.
To charge the battery:
1. Connect micro-B USB (trapeze) into the appropriate slot in myPhone VENUM.
Improper connection of charger (USB cable) can damage your phone or AC
adapter. Any damages caused by misuse are not covered by the arranty.
2. Connect the charger to an AC outlet. Once you start charging an animated charging
icon should appear on the phone screen.
The device may heat up hile charging. This is normal and should not affect the
stability or performance.

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
10
3. When charging percentage on the display reaches 100, it ill mean that the battery is
full and you should finish loading.
4. Unplug the charger from mains and from the device.
If the device is not being charged properly, you should provide it ith the charger
to myPhone service center.
3. Outer view

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
11
Numer Symbol Funkcja
1 Touchscreen 5"
2 Camera lens 2Mpx
3 Speaker
4 Notification LED
5 Back key
6 Home key
7 Menu key
8 Camera lens 5 Mpx
9 Brightening LED
10 Headphones miniJack 3.5 mm
11 Multifunctional micro-B USB slot
12 Volume up/Volume do n
13 Turn on / Turn off / Lock
14 Microphone
15
Loudspeaker
Keys
Menu
• One short press activates the Advanced Options Menu, or Additional Options
Menu, eg. for desktop screen there are the follo ing options:
• Wallpaper
• Widgets
Home
• One short press takes you back to the main screen

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
12
• Press and hold it for about 2 seconds to see the list of currently opened
applications
Ba k
• Press the Back key to leave the application currently use / go to previous screen.
Turn on / Turn off / Lo k
• One short press locks / unlocks the touchscreen.
• Press and hold the key for about 2 seconds to:
o Turn on the phone (if it is turned off)
o If the phone is turned on – a Menu appears that enables you to shut do n
or restart your system, enable / disable Airplane Mode or proceed rapid
changes in sound profile.
Volume up/down key
• Press during a voice call to increase or decrease call volume.
• Pressing during an incoming call mutes the ringtone.
• Press on the Main Screen hile there is no active phone call to increase or
decrease the ringtone volume or change the sound profile phone to "silent" or
"only vibrations".
•
••
• Pressing the volume key in other applications controls the volume of music,
spoken directions or other sounds.
Turning the phone on/off
To turn on the phone press and hold for about 3 seconds Turn on / off key. To turn it off
press the same key for 3 seconds and select option: [Turn off].
3. Comunication
Making a phone call
To establish connection:
•Touch the „Phone” icon , located on the Main Screen or in Main Menu of
Android System.
•Enter a phone number you ant to call.
•Press the “handset” icon ith the name of SIM card on the bottom of the screen
to establish a voice call.

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
13
Text messages
The phone can be used to exchange text and multimedia messages ith other mobile
phones. It uses a "SMS / MMS" application located on the home screen or in the phone's
main menu to manage messages. Incoming and outgoing messages for the same contact
ill be recorded as a single conversation, so you can conveniently atch the entire
message history ith that contact.
4. Safety issues
Troubleshooting
If any problems ith the product occur e advise you to save your data, and then restart
the phone. If the problem persists read the follo ing tips and apply to the simple
suggestions in case of trouble ith a particular section of the unit.Karta pamięci SD -
spra dź czy jest ona popra nie zamonto ana odpo iednim gnieździe SD dla kart SD.
Jeśli to nie pomoże skorzystaj z innej karty pamięci SD.
• USB operation - check if your phone is properly connected to another device.
Check the form of a USB connection in phone settings (available in shortcut
notifications screen). If this doesn`t help, try another USB cable.
• Internet / Wi-Fi - check hether your phone is in Flight Mode (this mode prevents
you from using any ireless functionality). Check net ork coverage. Check
hether the Wi-Fi mode is enabled.
• Bluetooth - check the visibility options of Bluetooth devices you use. Make sure
that both devices are ithin range of the Bluetooth connection and that there are
Touch
the icon
to make a phone call

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
14
no obstacles bet een them interfering ith Bluetooth (some LCDs absorb
magnetic aves). Make sure that both devices have enough memory to exchange
files. Check hether the devices are in flight mode (flight mode disables the
Bluetooth).
• Sounds - make sure that the phone is not muted and check other sound settings.
Check if the cord in 3.5mm minijack socket is connected correctly. Some
minijack`s differ from the others, it also can be the reason - try a different cable.
• Photos and screenshots - check if the camera lens is not obscured. Make sure that
the device has enough memory on the SD card. Check the installation of the SD
memory card.
• Although the battery is charging, the battery status is lo - turn off all options,
such as Wi-Fi, Bluetooth, and then reduce the brightness of the screen (these
options consume the most of po er), then enable the Flight Mode. These simple
steps accelerate battery charging. It is recommended to charge the device ith
the charger, not via computer's USB port
If problems persists, contact your dealer.
Screenshots
While using your phone, it is possible to take a snapshot of your screen and save it in the
phone`s memory. To do this, simultaneously hold do n the On / Off and Volume keys.
The screenshot ill be saved in phone`s memory in the Pi tures 

 S reenshots folder.
Memory car s
• Do not remove the memory card, hile the information is being transferred to it
is in use. This may cause data loss or damage the card or your phone.
• Do not touch the golden contacts ith your fingers or metal objects. If the card
gets dirty, ipe it ith a soft cloth.
Protection of personal ata an other important information
•
••
•It is recommended to make regular backups of important data. myPhone is not
responsible for data loss.
•
••
•Before disposing of the device, erase all data ([Application Menu] 

 [Settings] 


[Backup and reset] 

 [Restore factory settings] 

 [Reset phone]). This ay you
can protect yourself from accessing your personal data by unauthorized persons.
•
••
•Refer to on-screen information hile do nloading applications. Be careful ith
applications that demand access to many functions or to a significant amount of
personal information.
•
••
•Regularly check your account on the issue of unauthorized or suspicious use. If
you discover traces of misuse of personal information, contact your service
provider to delete or change your account information.
•
••
•In the event of loss or theft of the phone, immediately change the pass ords for
accounts to protect your personal data.
•
••
•Try not to use applications from unkno n sources. Block the device using the
pattern, pass ord or PIN.
•
••
•Do not distribute copyright-protected data.

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
15
•
••
•Do not distribute copyrighted content ithout the permission of the copyright
holder. Failure to do so may result in copyright infringement. The manufacturer
is not liable for any consequences of illegal use of copyrighted material by phone
user.
Comments on the proper battery use
•
••
•The battery in this device can be charged via the USB port. But it is not
recommended form of charging the device during operation due to the lo
charging po er offered via the USB port - despite supplying po er the battery
can still be discharged. If you ant to charge the battery this ay, turn off the
device. If the battery is lo , charge it to continue using the device. If you ant to
extend battery life, let it discharge less than 20% of the full battery, then fully
charge it.
•
••
•If you are not using a charger, disconnect it from the phone. Overcharging ill
shorten battery life.
•
••
•The battery temperature affects the quality of charging. Before you start
charging, the battery can be cooled or heated so that its temperature is similar to
the standard conditions inside the place it ill be charged. If the battery
temperature exceeds 40 degrees, it can`t be recharged!
•
••
•Don`t use damaged battery!
•
••
•The battery life may be shortened if it is exposed to very lo or very high
temperatures. This causes a disruption in operation of the device, even if the
battery is charged properly.
Maintaining your phone
To extend the life of your device:
• Keep the device and its accessories a ay from children.
• Avoid contact ith liquids as it can cause damage to electronic components of the
device.
• Avoid very high temperatures; it may shorten life of electronic components or
melt plastic parts and destroy the battery.
• Do not attempt to disassemble the device. Unprofessional interference can
seriously damage or destroy your phone.
• Clean only ith dry cloth. Do not use a high concentration of acidic or alkaline
cleaners.
• Use only original accessories; violation of this rule may void your arranty.
• Packing materials can be recycled in accordance ith local regulations.

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
16
Safety while listening to music/ making a phone calls
This phone is capable of producing loud noises that can cause hearing damage. While
using the phone or speakers it is recommended to keep the device at a safe distance
from your ear and not listen to the sounds of high voice intensity for a long time.
Environment safety
Turn off the device in areas here using it is prohibited or here it may cause
interference or danger. The use of any equipment using radio aves causes interference
ith medical devices (e.g. a stethoscope, or pacemaker), if they are not properly secured
(if in doubt, consult your doctor or medical device manufacturer).
Attention
Statement
The
manufacturer is not responsible for
the consequences of situation caused by
improper use of equipment or failure to
comply ith these recommendations.
The soft are version can be improved
ithout prior notice.
Proper isposal of use equipment
The device is marked ith a crossed-bin, according to the European Directive 2012/19 /
EC on Waste Electrical and Electronic Equipment (Waste Electrical and Electronic
Equipment - WEEE). Products marked ith this symbol after a period of use should not
be disposed of or dumped ith other household aste. User is obliged to dispose of
aste electrical and electronic equipment by delivering it to a designated point at hich
such hazardous astes are recycled. Collecting this type of aste in enclosed places and
the actual process of their recovery help to conserve natural resources. Proper disposal
of aste electrical and electronic equipment has beneficial effects on human health and
environment. For information about here and ho to safely get rid of electrical and

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
17
electronic aste, user should contact their local government office, the aste collection
point or the point of sale here the equipment as purchased.
Proper isposal of use batteries
According to the EU directive 2006/66 / EC on the disposal of batteries, this
product is marked ith a crossed-bin symbol.
The symbol indicates that batteries used in this product should not be disposed of ith
normal household aste, but treated in accordance ith the Directive and local
regulations.
Do not dispose of batteries and accumulators ith unsorted municipal aste. Users of
batteries and accumulators must use the available net ork to receive those items that
they can return, recycle and dispose of. Within the EU, collection and recycling of
batteries and accumulators are subject to separate procedures. To learn more about
existing procedures in the area of recycling of batteries and accumulators, please
contact your local city office.
Declaration of Conformity with European Union irectives
myPhone Sp. z o.o declares that this product complies ith the essential
requirements and other provisions of European Directive 1999/5 / EC.

©
©©
© 2015 myPhone. Wszystkie prawa zastrzeżone. myPhone VENUM PL
18
