Myson TS4 User manual

Décor Radiator Series
Installation Guide MYSON
Revised 2/12

2
Décor Radiator Series
Table of Contents
MYSON
Information Symbols................................................................................3
Before You Begin.....................................................................................4
Rough-In...................................................................................................5
Connection Arrangements ......................................................................6
Mounting Details .....................................................................................7
TS4 Connection Options .........................................................................8
V10 Connection Options .........................................................................9
H11 2,3,4 Tube Connection Options ....................................................10
H11 6,8,10 Tube Connection Options ..................................................11
Conventional Wall Installation-Radiator ................................................12
Conventional Wall Installation-Baseboard ............................................13
Valve Installation...............................................................................14-15
System Start-Up & Maintenance ...........................................................16
Myson, Inc. Limited Warranty
Myson, Inc warrants the following products against defects in material and workmanship to the original owner
for the duration listed from date of installation or three months after date of shipment, whichever comes first.
The remedy in all cases shall be to repair or replace the product at Myson’s discretion upon verification of a
factory defect. If replacement is required, and an exact replacement product is no longer available, Myson
reserves the right to furnish a similar product of equal value.
NO REMOVAL, SHIPPING OR INSTALLATION EXPENSES ARE REIMBURSIBLE
The original purchaser is responsible for determining the suitability of the Myson product for their installation.
Installation and troubleshooting should be performed by a competent technician with knowledge of hydronic
heating and/or basic electricity.
Damages occurring during shipment, transit, storage or handling, abuse, neglect, accident, misapplication,
incorrect power line voltage, improper water source or connection, fire, flood or other Acts of God are not
covered. Freight damage claims MUST be made within 10 days of receipt from Myson. No Exceptions.
STEEL PANEL RADIATORS — SELECT, T6, DÉCOR, COLUMN AND BENCH
The duration of warranty for steel panel radiators is 5 Years.
What is covered:
• Painted finishes will not peel or flake from the surface of the radiator.
• The body of the radiator and its welded joints will not leak when the product is properly installed and
maintained according to Myson’s instructions.
What is not covered:
• Rust occurring from improperly sealed threaded connections or oxygen corrosion.
• Electrolytic corrosion caused by failure to flush the system properly after initial installation.

3
NOTE: You will see these symbols within the text of this manual, drawing your
attention to important information.
Myson products are designed to be installed by professional tradespeople.
Myson instructions are meant to be thorough; however it is assumed that the
installer has the appropriate technical knowledge related to building codes,
standard trade practices, and proper use of the tools of the trade. Should a
homeowner without such knowledge or skill take it upon him/herself to attempt
the installation, Myson will not be responsible for any damages, injuries or
unsatisfactory performance of the Myson product used.
Information following this symbol indicates that it is important for the correct
installation or use of the product. Failure to heed this information may affect the
performance or useful life of the product. Risk of property damage or personal
injury is low.
Information following this symbol must be followed without exception.
Failure to follow these directions could result in moderate property
damage or the possibility of personal injury.
Information following this sign must be carefully followed without exception.
Failure to do so could result in significant and extensive property damage or
serious personal injury or death.
Décor Radiator Series
Information Symbols MYSON

4
INSPECT FOR DAMAGE
NOTE: Inspect materials for concealed shipping damage. You only have 11 days to file a
freight claim. If items are damaged or missing, please call Myson at 1-800-698-9690.
INSPECTION FOR COMPLETENESS
Unpack the Décor Radiator carefully to avoid damage or loss of parts.
The Décor Radiator should come with the following parts:
• Wall brackets
• Plastic inserts for noise suppression
• Stainless steel solid plug
• Vent plug
INTRODUCTION
The Myson Décor Radiator will keep any room in comfort and style. We at Myson Inc. thank you
for your purchase of the Décor Radiator. Each radiator combines Myson’s compact design and
advanced steel construction with a durable baked epoxy/polyester enamel powder coat finish.
Myson’s sleek styling and thorough testing provides attractiveness and dependability. Myson’s
goal is to assure the highest performance, quality, reliability and outstanding customer service.
CAUTION
Step 1 Read this entire instruction manual thoroughly before beginning installation.
Step 2 To ensure full efficiency of your Myson Décor Steel Panel Radiator, please follow all
the instructions carefully observing the caution notes for each step.
Step 3 Failure to follow these instructions will invalidate the manufacturer’s warranty.
APPLICATION
Myson radiators are only for use in recirculating closed loop hydronic-heating systems. These
radiators are not recommended for gravity systems. Myson Décor Radiators are designed to work
with a maximum working pressure of 66 PSI and no more then 230 degrees F water temperature.
DO NOT USE STEAM IN THESE RADIATORS.
DESIGN AND LAYOUT CONDITIONS
Myson Décor Radiators should only be used with a recirculation pump closed loop hydronic
heating system. Please consult national and local codes for specific restrictions that may be
imposed on your installation. Position your radiator away from your circulator pump to avoid
either excess pressure that could force water out the air vent or excess suction that could draw air
into the system. The preferred positioning for the Décor radiator is below a window where it can
minimize downdrafts from glazed areas.
Myson Radiators may be hot to the touch. Generally the surface temperature is at 10-12
degrees Fahrenheit below system water temperature. Care must be taken to consider room
occupant’s ability to sense or understand that radiators may be hot. Should radiator surface or
system water temperature be an issue, please contact MYSON at 1-800-698-9690 for information
on the MYSON LST radiators. LST (Low Surface Temperature) Radiators can be a viable solution
where temperatures are a safety concern.
Décor Radiator Series
Before You Begin
MYSON

Rough-ins given are for MYSON TRV and Control Valves only. Valve specifications vary by
manufacturer. Myson will not be responsible for damage or repair of property for rough-in with
non-Myson Valves. Prior to committing pipe work behind finish floor or wall materials, consult
Myson for assistance at 1-800-698-9690.
Dimensions are in inches. All valves are by MYSON and are 1/2” thread engagement in a vertical
pattern. For two LKD valves, use LKD and TRV dimensions.
For the 2, 3 & 4 Tier Radiators only,
there is not sufficient room with the
standard mounting plates to pipe
through the wall and make the angle
into the radiator. You must order the
optional 1-1/8” Offset Mounting Plate
that appears on page 7 (Mounting
Details) to accomplish this.
5
Décor Radiator Series
Rough-in MYSON
H11060 23- 5/8" 24-1/4" 21-1/2" 27-7/8" 27-3/4"
H11090 35 7/16" 36 1/16" 33 5/16" 39 11/16" 39 9/16"
H11120 47 1/4" 47 11/16" 45 1/8" 51 1/2" 51 3/8"
H11150 59 1/16" 59 11/16" 56 15/16" 63 5/16" 63 1/16"
H11180 70 7/8" 71 1/16" 68 5/8" 75 1/8" 75"
H11210 82 5/8" 83 1/4" 80 1/2" 86 7/8" 86 3/4"
H11240 94 1/2" 95 1/8" 92 3/8" 98 3/4" 98 5/8"
H-060 23 5/8" 24 1/4" 27 7/8" 27 3/4"
H-080 31 1/2" 32 1/8" 35 3/4" 35 5/8"
H-100 39 3/8" 39 13/16" 43 5/8" 43 1/2"
H-140 55 1/8" 55 3/4" 59 3/8" 59 1/4"
H-180 70 7/8" 71 1/2" 75 1/8" 75"
H28100 39 3/8" 43 7/8" 43 3/4"
H28140 55 1/8" 59 3/8" 59 1/4"
H28180 70 7/8" 75 1/8" 74"
H28220 86 5/8" 90 7/8" 90-3/4"
6 18" 14 7/8"
8 24" 20 7/8"
10 30" 26 7/8"
8 12" 9 1/4"
11 17" 141/4"
13 20" 17 1/4"
16 25" 22 1/4"
18 28" 25 3/4"
21 33" 30 1/4"
3/8" 2-1/16"
1-1/16"
3-3/16"
1-5/16" 2-1/16"
1-15/16"
3-3/16"
1-5/16" 4-1/8"
4-5/16"
3-3/16"
15/16"
2-1/16"
1-3/4"
2-3/8"
D
CABB
2, 3 & 4 Tier 6, 8 & 10 Tier
D
B
C
A
MODEL Product Face Overall Rough-in LKD & FF LKD& TRV
Code Length Length at Bottom Valves Valves
H11
2,3,4 TUBES
H11 & H22 NO
6,8,10,TUBES BOTTOM
TAPPINGS
H28 NO
2,4 TUBES BOTTOM
TAPPINGS
V10
TS4
1 Panel 1 Convector fin 2 Panel 2 Convector fin Vertical Decor

R
S
P
VV
P
R
S
V
SR
P
RS
P
V
V
P
R
S
V
S
R
P
V
RP
V
SSR
R
P
P
PSS
R
AB
CD
EF
AB
6
FF or LKD
CONNECTIONS: Myson Décor Radiators come with four 1/2” connections located at the
top and the bottom of both sides on the radiator.
Preferred methods A and B
NOTE: Myson Radiators have British Standard Pipe Threads.
All Myson Radiators are shipped with nylon paint plugs. All plugs must be
removed and replaced by the appropriate plug, vent or valve. Failure to use
Myson supplied plugs may result in significant water damage!
Décor Radiator Series
Connection Arrangements
MYSON
PPlug VVent SSupply R Return
2-3-4 Tube Connection Arrangements
Tapping locations are on the bottom and side of the units.
NOTE: Plug ports not being used.
6-8-10 Tube Connection Arrangements
Tapping locations are on both sides of the units.
For alternate methods E and F, derate the radiation by 5%

4 Tubes
5-7/8"
Wall hanging
bracket
Wall Stud
Radator fins
1-1/2"
1/8"
2-7/16"
L
B5-7/8"
2 Tubes
5-7/8"
L
B5-7/8"
5-7/8"
L
B5-7/8"
3 Tubes
4 Tubes
5-7/8"
L5-7/8"
2 Tubes
5-7/8"
L
5-7/8"
5-7/8"
L
B5-7/8"
3 Tubes
B
BB
BB
B=L-11-3/4" B= L-11-3/4"
2
24" to 48" 51" to 96"
6,8,10 Tubes
5-7/8"
L
B
5-7/8"
6,8,10 Tubes
5-7/8"
L
5-7/8"
BB
B=L-11-3/4" B=L-11-3/4"
2
24" to 48" 51" to 96"
AA
A=L-7-1/2"
2
3-3/ 4" 3-3/4" 3-3/4" 3-3/4"
Type H L=39" Type H L=55" to 87"
Mounting with adjustable feet
3-1/2" to 4-3/4"
Wall Mounted
Standard mounting system for all models
H11
Radiator
H22
Radiator
H28
Pedestal
H11 Baseboard
1-7/8"
5/8"
Flexible Along All Fins
Extended Bracket Optional
1-1/2"
1/8"
2-7/16"
1-1/8"
offset
OPTIONAL 1-1/8" OFFSET
MOUNTING PLATE
Part # BBWB-O
7
Décor Radiator Series
Mounting Details MYSON

P
1-15/16"
2-1/8"
2-3/8" Min.
79"
5/8"
Vent Plug
Bottom Connections Bottom Connections
Mounting
Brackets
9/16"
1-3/8"
W
1-3/8"
1-5/8"
2-3/4"
VV
V = Vent (1/4 in BSP)
P
P = Blind Plug/Drain
L
c
L
cL c
= Water inlet
= Water outlet
01 02
8
MYSON
CONNECTIONS: Myson Radiators come with two 1/2” BSP connections located at the
bottom of both sides on the radiator. (01 is standard)
Décor Radiator Series
TS4 Connection Options
All Myson Radiators are shipped with nylon paint plugs. All plugs must be removed
and replaced by the appropriate stainless steel plug, vent or valve. Failure to use
Myson supplied plugs may result in significant water damage!
Optional tappings available
on special orders.

9
Décor Radiator Series
V10 Connection Options MYSON
CONNECTIONS: Myson Radiators come with two 1/2” BSP connections located at the
bottom of both sides on the radiator. (01 is standard)
All Myson Radiators are shipped with nylon paint plugs. All plugs must be removed
and replaced by the appropriate stainless steel plug, vent or valve. Failure to use
Myson supplied plugs may result in significant water damage!
Optional tappings available
on special orders.
= Water inlet
V = Vent (1/4 in BSP)
P = Blind Plug/Drain
= Water outlet
PVV P
01 02
15/16"
1-3/4"
2-3/8" Min.
79"
15/16"
Vent Plug
Bottom
Connections Bottom Connections
Mounting
Brackets
3/16" 3/16"
1-9/16"
W
1-9/16"
2-3/4"
2-1/16"
L
cL
cL
c

8
8
8
888
8
8
8
8
TRV thermostatic valve and LKD lockshield valve
2TRV1/2ANS
2TRV RS Remote sensor 2TRV RA Remote adjuster
2TRV1/2ANS
DCK12
2TRV1/2ANS
FF WAC
FF 16 WAC
LKD 16AN
TRV head with vertical
angle body head
TRV head with
straight body head
TRV head with inverted
angle body head
LKD 16AN
LKD 16AN
FF LAC
FF LAC
DAV12
DAV12DAV12
LKD 16AN
LKD 16SN
FF WAC Wheelhead angle valve & LKD lockshield valve
For best accuracy 2TRV2 head should be in a horizontal position
away from heat source. Remote Sensor or Adjuster heads are available
2 LKD lockshield valves
2 LKD straight lockshield valves2 Decorative manual angle valves
TRV thermostatic valve & FF LAC Lockshield angle valve
FF WAC Wheelhead angle & FFLAC lockshield angle valve.TRV thermostatic valve & Decorative manual angle valve
NOTE:
See Radiator Range Technical Specifications
for Mounting Details of Radiators.
Copper pipe
Copper pipe
Copper pipe Copper pipe
Copper pipe
10
Décor Radiator Series
H11 2, 3, 4 Tube Connection Options
MYSON
(FF LAC) Valve is set full open and white knob will not turn. Angle only.
(FF WAC) Valve white knob can turn to open or close the valve. Angle only.
(LKD) Manual valve, has chrome cap that can be removed exposing an adjustment screw to open or close the valve. Angle or straight.
(TRV) Valve is a non-electric thermostatic valve that modulates water flow in response to changes in room temperature and closes when set
temperature is achieved. NOTE: This valve will not turn on or shut off your heating system. Horizontal angle, vertical angle or straight pattern.
(DCK12) Pipe extension with compression fitting and escutcheon for use with the 2TRV1/2ANS valve.
(DAV12) Manual valve, adjust flow with Allen wrench. Valve comes with chrome pipe extension with compression fitting and escutcheon.
