Myson iVector S2 User manual

Installation
manual
iVector S2 | 2022-07-01
US


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
Installation manual
iVector S2 – VS and VSI models
We want to thank you for choosing one of our products. We are confident that you will be
happy with your selection because it represents the state of the art in the technology of
climate control. By following the suggestions contained in this manual, the product you have
purchased will operate without problems giving you optimum room temperatures with
minimum energy costs.
This unit complies with North America Standards:
• UL1995
• CSA C22.2 No. 236-15
CONFORMITY
The following symbols provide the necessary guidance for correct, safe use of this product.
SYMBOLS
Safety pictograms
These symbols may appear in the manual or on the product
WARNING / CAUTION HOT SURFACE
Signals that an appropriate safety instruction
should be followed or caution to a potential
hazard.
Signals that the parts of the product could be
hot and should not be touched without great
care.
DANGEROUS VOLTAGES PROTECTIVE EARTH
Indicates hazards arising from dangerous
voltages.
Identifies any terminal intended for connection
to an external conductor for protection against
electric shock in case of a fault, or the terminal
of a protective earth electrode.
HEAVY REFER TO MANUAL
Indicates that this product is heavy, and provision
should be made for safe lifting and handling.
Refer to relevant instructions within the product
manual.
The iVector S2 is available with casing (VS model) or
without casing (VSI model), in 5 different lengths.
VS models can be mounted vertically on the wall or
horizontally on the ceiling, with the option for integral
controls (not ceiling), remote mounted controls or 0-10V
option with BMS input or 0-10V remote control input.
All units are available in 2 or 4 pipe options, and all units
are supplied with pre-fitted valves.
VSI models can be mounted vertically (recessed wall
mounting) or horizontally (recessed ceiling mounted), with
the option for remote mounted control or 0-10V option
with BMS input or 0-10V remote control input.


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
Safety and General Information
1.1 Safety information 6
1.2 General information 7
1.3 Product range 7
1.4 Technical data 8
1.5 Dimensions 8-9
Installation
2.1 Positioning the unit 10
2.2 Installation clearances 10
2.3 Side opening 11
2.4 Vertical floor or wall installation 11
2.5 Horizontal or ceiling installation (VS, VSI) 12
2.6 Mounting front grille safety support (VS) 12
2.7 Air intake grille fixing 13
2.8 Water connections 13
2.9 Condensate discharge 14
2.10 Filling and venting the system 15
2.11 Electrical connections 16
2.12 Maintenance 16
2.13 Cleaning the outer casing 16
2.14 Cleaning the air filter 16
Faults and Troubleshooting
3.1 Troubleshooting 18
3.2 Fault-finding guide 18
Instructions 2-way valve
4.1 Warnings 19
4.2 2-way valve parts list 19-21
4.3 Return valve pre-setting screw adjustment 22-23
4.4 Valve Insulation 24
Control Panel connection and setup
5.1 Connection and setup of onboard control panel 25
5.2 Cooling mode additional functionality 25
5.3 Night time heating additional functionality 25
5.4 2 pipe & 4 pipe models with integrated control 26
5.5 2 pipe & 4 pipe models with remote-mounted control 27
5.6 Connection of multiple units using remote-mounted thermostat 28
5.7 LED Indications (A) 2 pipe & 4 pipe models with remote-mounted thermostat 28
5.8 Remote-control panel mounting 29
5.9 Wiring connection to remote-mounted control 30
5.10 Presence detection sensor input connection – units with remote-mounted control 30
Contents


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
Onboard and remote control setup menu
6.1 Setup menu 31-32
0-10V Models
7.1 0-10V fan control 33
7.2 Connection diagram with 0-10V DC thermostats / signals 33
7.3 Fan speed regulation 33
User instructions
. Onboard and remote-mounted control operation 34
. Display 34
. Key function 34
. Activation 35
. Heating / cooling operation modes setting 35
. Stand-by 35
. Temperature selection 35
. Automactic operation 36
. Silent operation 36
. Night-time operation 36
. Operation at maximum fan speed 36
. Key lock 36
. Reduce brightness to minimum 36
. Room temperature probe regulation offset 37
. Switching off for longer periods 37
Contents (continued)


iVector S2
Installation manual
iVector S2 • 2022-07-01
US Safety and general information
1.1 Safety information
This appliance MUST NOT be installed
in a bathroom or other similar high
humidity areas.
This appliance MUST be earthed.
This appliance must be installed by a
qualified installer.
The electrical installation must comply
with local or national wiring
regulations and should be carried out
by a qualified electrician.
This appliance can be used by
children aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
For the correct installation of this
product, it is essential that fixing
is carried out in such a way that
it is suitable for intended use and
predictable misuse. A number of
elements need to be taken into
consideration including the fixing
method used to secure it to the
surface, the type and condition of
the surface itself, and any additional
potential forces or weights that may
happen to be applied to the unit, prior
to finalising installation.
This product must not be installed
immediately below a socket outlet.
This product must not be installed in
areas where excessive dust exists.
This product can be hot when in
use, and as such, presents a risk of
burns to users on prolonged contact.
The temperature of the product
is dependent on system water
temperature, as set by the installer or
end user. Installers and users should
ensure that those who may come into
close proximity to the product are
aware of the risk of burns.
The imbedded iVector S2 VSI series do
not have a grille or covering plate. The
installer must provide safety guards
and air inlet/outlet grills to prevent
accidental contact with the device.
DO NOT cover or obstruct the air inlet
or outlet grilles.
Isolate electrical supply before
carrying out any cleaning or
maintenance activities.
This instruction leaflet is an integral
part of the appliance. The installer
MUST ensure it is left with the end
user.
All repair and maintenance activities
must be performed by suitably
qualified personnel.


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
1.2 General information
Before proceeding with the installation, unpack the
product and make sure that all the components are
present, and that there is no concealed shipping damage.
Components include:
• unit
• instruction manual
• template
• accessories/mounting kit
This appliance has been designed both for heating and /
or cooling applications and must be installed for this use
only. The installation must take into consideration stated
performance characteristics.
Check the location where the product is to be installed, the
surface must be flat and the specified product clearances
available. If fitted to a wood framed construction, there
may be an adverse effect on sound levels especially
at higher fan speeds. If the product is to be used for
cooling applications, the disposal of condensate must be
considered.
If the appliance is not used for a long period
of time, it is recommended that the product is
electrically isolated, and the connecting valves are
closed. Frost prevention measures must be taken
including use of anti-freeze if appropiate.
Avoid prolonged physical contact with the direct
air flow.
Do not leave the room closed for long periods.
Periodically open the windows to ensure fresh air
exchange.
In the event of a water leak, isolate the electrical supply
and close connecting valves. Contact the installer.
The manufacturer accepts no responsibility, either
contractual or for consequential loss, for any damage
caused to persons, animals of property as a result of
incorrect installation, alteration, maintenance or improper
use.
To ensure that the installation is carried out correctly and
that the unit will perform as designed, carefully follow the
instructions in this manual. Failure to follow the instructions
can not only cause malfunctions of the appliance but
will also invalidate the warranty and hence PG shall not
respond for any damage to persons, animals or property.
All IP units contained in this document are converted from
SI equivalent – all IP units nominal.
1.3 Product range
The iVector S2 is available with casing (VS model) or
without casing (VSI model), in 5 different lengths.
VS models can be mounted vertically on the wall or
horizontally on the ceiling, with the option for integral
controls (not ceiling), remote mounted controls or 0-10V
option with BMS input or 0-10V remote control input.
All units are available in 2 or 4 pipe options, and all units
are supplied with pre-fitted valves.
VSI models can be mounted vertically (recessed wall
mounting) or horizontally (recessed ceiling mounted), with
the option for remote mounted control or 0-10V option
with BMS input or 0-10V remote control input.
1.4 Technical data
2 PIPES
Technical Data (DC) Model VS VS 7-2P VS 9-2P VS 11-2P VS 13-2P VS 15-2P
Model VSI VSI 7-2P VSI 9-2P VSI 11-2P VSI 13-2P VSI 15-2P
Length VS mm (inch)  ()  ()  ()  ()  ()
Length VSI mm (inch)  ()  ()  ()  ()  ()
Heat exchanger water content VS/VSI L (US Gal) . (.) . (.) . (.) . (.) . (.)
Maximum working pressure bar (psi)  ()  ()  ()  ()  ()
Maximum inlet water temperature °C (°F)  ()  ()  ()  ()  ()
Minimum inlet water temperature °C (°F)  ()  ()  ()  ()  ()
Water connections Eurocone /" Eurocone /" Eurocone /" Eurocone /" Eurocone /"
Power supply V/ph/Hz // // // // //
Maximum current A. . . . .
Maximum power W    
Weight VS kg (lbs)  ()  ()  ()  ()  ()
Weight VSI kg (lbs)  ()  ()  ()  ()  ()
IP units are converted from SI equivalent – all IP units nominal


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
1.5 Dimensions
37.5 (1-1/2)
80 (3-5/32)
131 (5-5/32)
579 (22-3/4)
449 (17-11/16)
206 (8-1/8)
102 (4)
83 (3-1/4)
G3/4"EK
G3/4"EK
A
a1
a2 ∅ 14 (1/2)
iVector S2 / Vido S2
2 PIPES – VS
DimensionsModel VS 7-2P VS 9-2P VS 11-2P VS 13-2P VS 15-2P
Amm 735935113513351535
a1 mm 210 310 410 510 610
a2 mm 254 354 454 554 654
126 (4-15/16)
A73.5 (2-9/16)73.5 (2-9/16)
18.5 (3/4)
468.5 (18-7/16)
228 (9)
G3/4“EK
180.5 (7-3/32)
14 (1/2)
99.5
(3-15/16)G3/4“EK
194.5 (7-5/8) 316 (12-7/16)
65.5
(2-9/16)
576 (22-21/32)
14 (1/2)
468.5 (18-7/16)
228 (9)
79.5 (3-1/8)
37.5 (1-1/2)
∅ 14 (1/2)
83.2 (3-9/32)
116 (4-9/16)
83.5 (3-9/32)
4 PIPES
Technical Data (DC) Model VS VS 7-4P VS 9-4P VS 11-4P VS 13-4P VS 15-4P
Model VSI VSI 7-4P VSI 9-4P VSI 11-4P VSI 13-4P VSI 15-4P
Length VS mm (inch)  ()  ()  ()  ()  ()
Length VSI mm (inch)  ()  ()  ()  ()  ()
Cooling coil water content L (US Gal) . (.) . (.) . (.) . (.) . (.)
Heating coil water content L (US Gal) 0.16 (0.04) 0.27 (0.07) 0.38 (0.10) 0.49 (0.13) 0.6 (0.16)
Maximum working pressure bar (psi)  ()  ()  ()  ()  ()
Maximum inlet water temperature °C (°F)  ()  ()  ()  ()  ()
Minimum inlet water temperature °C (°F)  ()  ()  ()  ()  ()
Water connections Eurocone /" Eurocone /" Eurocone /" Eurocone /" Eurocone /"
Power supply V/ph/Hz // // // // //
Maximum current A. . . . .
Maximum power W    
Weight VS kg (lbs)  ()  ()  ()  ()  ()
Weight VSI kg (lbs)  ()  ()  ()  ()  ()
2 PIPES – VS
Dimensions Model VS 7-2P VS 9-2P VS 11-2P VS 13-2P VS 15-2P
Amm (inch)  ()  ()  ()  ()  ()
a1 mm (inch) 210 (9) 310 (13) 410 (17) 510 (20) 610 (24)
a2 mm (inch) 254 (10) 354 (14) 454 (18) 554 (22) 654 (26)
2 PIPES – VSI
Dimensions Model VSI 7-2P VSI 9-2P VSI 11-2P VSI 13-2P VSI 15-2P
Amm (inch) 378 (14-7/8) 578 (22-3/4) 778 (30-5/8) 978 (38-1/2) 1178 (46-3/8)
2-pipe inset unit shown without factory-fitted valves. For more details see section 4 below.
IP units are converted from SI equivalent – all IP units nominal


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
80 (3-5/32)
131 (5-5/32)
639 (25-5/32)
83 (3-1/4)
G3/4"EK
102 (4)
230 (9-1/16)
206 (8-1/8)
394 (15-1/2)
536 (21-3/32)
491 (19-5/16)
37,5 (1-1/2)
76 (3)
418 (16-7/16)
560 (22-1/16)
79 (3-1/8)
54 (2-1/8)
∅14 (1/2)
G3/4"EK
a2
A
a1
4 PIPES – VS
DimensionsModel VS 7-4P VS 9-4P VS 11-4P VS 13-4P VS 15-4P
Amm 735935113513351535
a1 mm 210 310 410 510 610
a2 mm 254 354 454 554 654
iVector S2 / Vido S2
4 PIPES – VS
Dimensions Model VS 7-4P VS 9-4P VS 11-4P VS 13-4P VS 15-4P
Amm (inch)  ()  ()  ()  ()  ()
a1 mm (inch) 210 (9) 310 (13) 410 (17) 510 (20) 610 (24)
a2 mm (inch) 254 (10) 354 (14) 454 (18) 554 (22) 654 (26)
4 PIPES – VSI
Dimensions Model VSI 7-4P VSI 9-4P VSI 11-4P VSI 13-4P VSI 15-4P
Amm (inch) 378 (14-7/8) 578 (22-3/4) 778 (30-5/8) 978 (38-1/2) 1178 (46-3/8)
126 (3-15/16)
636 (25-1/16)
228 (9)
468 (18-7/16)
98,5
(3-7/8)
515 (20-1/4)
558 (22)
73,5 (2-7/8)
65 (2-9/16) 72 (2-13/16) 55,5 (2-3/16)
A
30 (1-3/16)
73,5 (2-7/8)
30 (1-3/16)
125,6
(415/16)
316
(12-7/16)
194,4
(4-21/32)
∅ 14 (1/2)
37 (1-7/16)
80 (3-5/32)
41 (1-5/8)
76 (3)
99,5
(3-15/16) G3/4“EK G3/4“EK
G3/4“EK
G3/4“EK
Heating circuit in
Heating circuit out
Cooling circuit in
Cooling circuit out
4-pipe inset unit shown without factory-fitted valves. For more details see section 4 below.


iVector S2
Installation manual
iVector S2 • 2022-07-01
US Installation
2.1 Positioning the unit
2.2 Installation clearances
The figure below indicates the minimum clearance
between the surface-mounted unit and any adjacent
furniture.
20 mm (7/8“) 20 mm (7/8“) 400 mm (15-3/4“)
80 mm (3-5/32“)
140 mm (5-1/2“)
2100 mm (8‘ - 6“)
This unit must not be installed in a bathroom, in damp
areas or places with possible contact with water.
Avoid installing the unit:
· in positions subject to exposure to direct sunlight;
· in proximity to sources of heat;
· in places with oil fumes
· in places subject to high frequency radio waves
The following instructions refer to units with standard
water connections on the left hand side.
Make sure that:
· the surface on which the unit is to be installed is strong
enough to support the weight;
· the installation does not interfere with existing pipes or
electric wires ;
· the surface is perfectly flat;
· that the air inlet and outlet are free of obstructions;
· the installation surface is preferably near an external
wall to allow the discharge of the condensate outside;
· in case of ceiling installation (VS or VSI version) the
airflow is not directed towards room occupants


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
2.3 Side opening
• On the left-hand side, lift the cover that protects the
screw, loosen the screw that fixes the left panel,
then move it slightly to the left and lift it up.
• On the opposite side, lift the cover that protects the
screw and unscrew it.
• Move the side panel slightly to the right and lift it out.
ACover CLeft panel
BFixing screws DRight panel
B
AD
A
B
C
2.4 Vertical floor or wall installation
When mounting on the floor with support feet, refer to
the product instructions supplied, and the instructions
supplied with the support feet.
Do not over-tighten the screws, check alignment with
a spirit level and make final adjustment. Mark the
lower fixing points, remove unit, then drill and plug
mounting surface. Fully tightening the bracket screws,
refit unit, check alignment and stability then secure
using bottom screw fixings.
Use the paper template provided to trace the position
of the bracket fixing holes on the the mounting
surface. Drill the holes, insert the mounting plugs or
other suitable fixing and secure the 2 brackets.
NOTE: take care to ensure correct orientation of
the mounting brackets. These should be fixed with
small tabs pointing towards the fixing surface.
AMounting plugs BBrackets
A AB
B


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
AMounting plugs CScrews
BBrackets DDrainage pipe
2.5 Horizontal or ceiling installation (VS, VSI)
ceiling
A A
B
B
C
D
2.6 Mounting front grille safety support (VS)
When the unit is installed horizontally the inlet
grille must be attached to the chassis using the
two tie straps supplied in the accessory bag. This
prevents the grille from falling and ensures safe filter
replacement.
Separate the two tie straps then;
• Remove the front grille and completely unscrew the
spring-loaded fixing screws.
• Fix one end of each tie to the chassis using the
spring-loaded fixing screws.
• Fix the other end of each tie to the grille using the
supplied screws.
• Refit the grille.
ATies CScrew fixing
BSpring-loaded screws
A
A
B
C
Using the paper template provided, trace on the ceiling the
position of the two fixing brackets and the two rear screws.
Using a suitable drill, make the holes and insert the
mounting plugs (2 for each bracket). Fix the two brackets. Do
not over-tighten the screws. Position the unit on the two
brackets, keeping it in position and then fix the two screws
into the rear toggle bolts, one on each side.
Make sure that there is sufficient inclination of the
unit towards the drainage pipe to facilitate the water
drainage. Additional washers or spacers may be
needed.
Fully tighten all 6 fixing screws.
For installation of the VS versions, horizontal condensation
collection tray accessory kits are available.
Carefully check the inclination of the condensate
pipe. Any backflow can cause water leakage.


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
2.7 Air intake grille fixing
If the inlet grille is accidentally removed or left loose
the fan will stop and the grille safety alarm will
activate. To prevent this from happening the grille
can be secured using the 2 screws provided (type TC
4,2x9,5 mm).
Fit the grille and secure by fitting the 2 fixing screws
into the dedicated holes located on the grille's fixing
bars as shown below.
AInsert grille tab into lower bracket slot CCorrect position of grille tab
BFixing screws
AB
C
Front View
2.8 Water connections
The system should be designed and installed
following best practice by a qualified installer. The
choice and sizing of the pipework should take into
account the number and size of the units installed,
and the performance characteristics of each unit.
Undersized pipes can cause malfunction of the units.
The water connection pipes and joints must be
thermally insulated.
Partially insulating the pipes should be avoided and
the insulation should not be over-tightened.
A suitable thread sealant should be used. The use of
Teflon thread sealant is advised when there is anti-
freeze in the hydraulic circuit.
After making the water connections check for leaks
and cover the connections with insulating material.
MINIMUM PIPELINE DIAMETERS
Model
VS 7-2P
VS 9-2P
VS 11-2P
VS 13-2P
VS 15-2P
VSI 7-2P VSI 9-2P VSI 11-2P VSI 13-2P VSI 15-2P
VS 7-4P
VS 9-4P
VS 11-4P
VS 13-4P
VS 15-4P
VSI 7-4P
VSI 9-4P
VSI 11-4P
VSI 13-4P
VSI 15-4P
Minimum
Pipeline diameters mm (inch) 14 (1/2) 14 (1/2) 16 (1/2) 18 (3/4) 20 (3/4)


iVector S2
Installation manual
iVector S2 • 2022-07-01
US 2.9 Condensate discharge
The condensate discharge pipes must be suitably
sized (minimum inside pipe diameter 16 mm / 1/2")
and the pipeline positioned so that it keeps a constant
inclination, never less than 1%. In a vertical installation,
the discharge pipe is connected directly to the
discharge tray, positioned underneath the water
connections. In a horizontal installation the discharge
tube is connected to the one already present in the unit.
For installation of the VS versions in a horizontal
position, horizontal condensation collection tray
accessory kits are available.
• If possible, the condensate pipework should be
directed into a rainwater discharge.
• When discharging directly into the main drains, it is
essential to make a siphon to prevent bad odours coming
up the pipe into the room.The curve of the siphon must be
lower than the condensation collection bowl.
• If the condensate needs to be discharged into
a container, the container must be open to the
atmosphere and the tube must not be immersed in
water so that the normal outflow is not restricted.
• If there is a height difference that could interfere with
the outflow of condensate, a pump must be fitted:
• In a vertical installation mount the pump under the
lateral drainage tray.
• In a horizontal installation the pump position must be
decided according to the specific requirements.
Such pumps are readily available.
On completion of the installation, it is advisable to
check the correct outflow of the condensate by slowly
pouring about 0.5 l (0.5 quarts) of water into the
collection tray in about 5-10 minutes.
Condensate discharge pipe connection – vertically mounted units
Check that the condensate collection tray is present
and is correctly installed.
Connect the discharge pipe (B) to condensate collection
tray (A).
ADischarge fitting CInternal discharge point
BCondensate pipework DCondensate collection tray
B
ø14 mm / 1/2"
A
C
D
A
B
ø14 mm /
1/2"
Condensate discharge pipe connection – horizontally mounted units
To mount the horizontal condensate tray on the VS
units refer to the instructions supplied with accessory kits.
• Check that the "L" pipe (A) and the flexible rubber
hose are correctly connected to the condensate tray.
• Slide in the side of the unit keeping the pipe in position
up against the front grille.
• Fully close the side checking that the pipe remains
tight in the special groove on the side.
N.B. for a horizontal installation carefully note the
following precautions:
• Make sure that the unit is installed perfectly level
or with a slight inclination towards the condensate
discharge point.
• Carefully insulate the flow and return pipes to the unit
to prevent any drops of condensate falling outside the
drip tray.
• Insulate the condensate discharge pipe (B) along its
complete length.


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
2.10 Filling and venting the system
When starting up the system, make sure that the return
valve is open. Refer to section 4.3 for correct setting.
If there is no electric power and the valve actuator has
not already been powered up, use the special tool, press
the valve actuator and use the tool to keep it open.
• Open all the shut off valves (manual or automatic).
• Start to slowly fill the system.
• For units installed in a vertical position, open the
highest vent of the heat exchanger; for appliances
installed in a horizontal position, open the highest
positioned vent; for the 4-pipe versions open the
highest vents on both heat exchangers. Vents can be
opened using a screwdriver.
• When water starts coming out of the air vents, close
them and continue filling the system until reaching
the nominal system pressure.
• Check for leaks.
It is advisable to repeat these operations after the
appliance has been running for a few hours and to
periodically check the system pressure.
AVenting of the heat exchange
AA
Warning: Commissioning instructions – opening the valve actuator (where used)
Remove the 'red plastic' clip from the valve actuator
before starting the system.
AValve actuator CRed plastic clip
BValve
C
A
B


iVector S2
Installation manual
iVector S2 • 2022-07-01
US 2.11 Electrical connections
Electrical connection must be made by a qualified
electrician in accordance with local and national wiring
regulations.
The unit must be connected to the mains supply using a
switched fused spur having 3 mm / 1/8" separation on all
poles.
This appliance must be earthed.
• Switch off electrical supply before making
electrical connections.
• Remove control box cover.
• Make electrical connections to pcb.
• Secure power supply cables using strain relief
clamps attached to the control box.
• Refit control box cover.
2.12 Maintenance
Routine maintenance is essential to keep this product in a
safe and reliable working condition. End user maintenance
activities should be limited to cleaning of the outer casing
and cleaning of the air filter at appropriate intervals.
Any other repair or maintenance activity should be
carried out by a qualified installer.
2.13 Cleaning the outer casing
Disconnect electrical supply before carrying out
any cleaning or maintenance activities.
Do not use abrasive cloths or abrasive or
corrosive detergents to avoid damaging the
painted surfaces.
Wait until the parts have cooled down to avoid the risk
of burns. When necessary, clean the outer surfaces
of the iVector S2 with a soft damp cloth.
2.14 Cleaning the air filter
To maintain air flow levels through the unit, air filters
should be cleaned at regular intervals. The frequency
of cleaning should take into consideration the
concentration of impurities in the local environment
and duration of operation. Filter cleaning should also
be considered after a period of inactivity.
Removing the filter
• Remove the front grille by lifting it slightly and turn it
until it comes completely out of its seat.
• Remove the filter by pulling horizontally outwards.
ALift front grille CFilter exposed
BRotate grille forward DRemove filter
AB
CD


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
ABB C
Cleaning the filter
• Remove any dust with a vacuum cleaner.
• Wash the filter with clean running water. Do not use
detergents or solvents.
• Leave to dry.
• Re-fit the filter taking care to insert the lower back
edge into its seat.
Never use the unit without filters
The appliance is fitted with a safety switch that
prevents operation of the fan with the front
grille missing or out of position.
After refitting the filter, check that the grille is
correctly mounted.
AFilter CFilter locating channel
BLower edge
• To refit the grille, insert the two lugs into the lower
slots, rotate it and attach to the upper chassis slots.
ATabs BSlots
A
B
Energy saving tips
• Always keep the filters clean and as far as possible
keep the doors and windows closed in the room being
conditioned when the unit is in use.
• Limit where possible the effect of direct sun rays in
the rooms being conditioned (use curtains, shutters
etc.)


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
3.1 Troubleshooting
In the event of a water leak or malfunction
immediately cut off the power supply and close
the system valves to the unit.
• the fan does not activate even if there is hot or cold
water in the hydraulic circuit.
• the appliance leaks water during the heating function.
• the appliance leaks water only during the cooling
function.
• the appliance makes an excessive noise.
• condensate forms on the front panel.
Should one of the following faults occur,
contact a qualified installer. DO NOT intervene
personally.
Faults and Troubleshooting
3.2 Fault-finding guide
These operations must be carried out by a qualified installer or by a specialised service centre.
EFFECT CAUSE SOLUTION
A delayed fan start up following set
temperature change or change of function.
The unit valves need time to open and as
a result the hot or cold water takes time to
circulate in the appliance.
Wait for 2 or 3 minutes for the unit valves
to open.
The fan does not function No hot or cold water in the system. Check that the boiler or chiller are
functioning correctly.
The fan does not activate even if there is
hot or cold water in the hydraulic circuit.
The hydraulic valve remains closed
Remove the valve actuator
and check if water circulation is restored.
Check the valve actuator by powering
it from a separate 230V (120V Canada/
US) source. If it activates then check the
electronic control.
The fan motor is blocked or burnt out. Replace motor.
The micro-switch that stops the fan when
the filter grille is opened does not close
correctly.
Check correct fitting of grille and that the
micro-switch contact is activated.
The electrical connections are not correct. Check the electrical connections.
The appliance leaks water during the
heating function.
Leaks in the hydraulic connections of the
system.
Check the leak and fully tighten the
connections.
Leaks in the valve unit. Check the condition of the gaskets.
Condensation forms on the front panel. Front panel insulation damaged or
detached.
Check the correct positioning of the
thermo-acoustic insulation, paying attention
to insulation in the front above the heat
exchanger.
There are drops of water on the air outlet
grille.
In situations of high humidity (>60%)
condensation could form, especially at the
minimum fan speeds
As soon as the humidity starts falling the
phenomenon disappears. In any case the
presence of a few drops of water in the
appliance does not indicate a malfunction.
The appliance leaks water only during the
cooling function.
The condensate tray is blocked. Slowly pour a bottle of water into the low
part of the heat exchanger to check the
drainage; if necessary, clean the tray and/
or increase the inclination of the drainage
pipe.
The condensation discharge does not need
an inclination for correct drainage.
The connection pipes and the valve unit are
not insulated well. Check the insulation of the pipes.
The appliance makes a strange noise.
The fan fouling adjacent parts. Check if the filters are clogged and clean if
necessary
The fan is unbalanced. An unbalanced fan can cause excessive
vibrations in the unit; replace the fan.
Check if the filters are clogged and clean
them if necessary.
Clean the filters.


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
Instructions 2-way valve
4.1 Warnings
These instructions relate to the valve kits
supplied with the unit. The general instructions
and basic safety rules detailed in this manual
should be followed.
For correct operating performance of this unit,
the flow and return pipework must be correctly
fitted according to the detail provided in these
instructions.
4.2 2-way valve parts list
• 1x automatic valve with thermoelectric head for VS
and VSI models
• 1x return with presetting for correct balancing of the
system.
• 1x Connection 3/4" Eurocone extention pipe (for use
with pipe connection from floor)
• Insulation pieces are supplied loose when the product
is supplied. These should be fitted to the flow and
return valves once the pipework connections have
been made.
Pipe connection from floor – with optional 3/4” EK extension
AValve actuator
(optional Canada/US)
D3/4" Eurocone extension (optional – supplied
as accessory)
B2-way valve EFloor penetration opening
CReturn valve connection
A
C
B
D
E
E
27 mm
15 mm79 mm
53 mm
1”
3/4”3-1/4”
2”
PLEASE NOTE: valves are factory fitted but not
tightened. For floor connections extension piece D
(or similar) must be used to clear outside edge of
condensate tray.


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
A
C
B
D
21 (13/16)
527 (20-3/4)
152 (13)
69 (2-3/4)
311 (12-1/4)
500.2 (19-11/16)
Pipe connection from wall – with optional 90° elbow fitting
AValve actuator B2-way valve
C90° elbow fitting (optional – supplied as
accessory)
DReturn valve connection
PLEASE NOTE: valves are factory fitted but not
tightened. For through-the-wall connections 90°
elbow C or similar should be used.
