NAPCO GEMINI C Series Installation manual

G E M C -255
G E M C -128
G E M C -96
G E M C -32
COMMERCIAL / RESIDENTIAL
GEMINI C-Series CONTROL PANELS / COMMUNICATORS
Programming the Gemini C-Series Control Panels with
the GEMC-FK1 Fire Keypad
or the GEMC-BK1 Burglary Keypad for Burglary Only systems
WIRELESSHARDWIRE
GEMC-FK1 Keypad GEMC-BK1 Keypad
SYSTEM NORMAL
11/02/28 12:05 AM
SYSTEM READY
11/02/28 12:05 AM
Publicly traded on NASDAQ Symbol: NSSC
WI1673ELF-2 (Vol 2) 2/23
© NAPCO 2023
KEYPAD
PROGRAMMING
INSTRUCTIONS
VOLUME 2

THIS MANUAL INCLUDES FEATURES WHICH ARE ONLY AVAILABLE IN CONTROL PANEL
FIRMWARE VERSION 90.69 OR GREATER, AND REFLECTS THE FEATURES FOUND IN
PCD-WINDOWS QUICKLOADER DOWNLOAD SOFTWARE VERSION 6.4.8 OR GREATER.
NAPCO Security Technologies, Inc.,
333 Bayview Avenue, Amityville, New York 11701
For Sales and Repairs, call toll free: [phone]
For direct line to Technical Service, call toll free: [phone]
http://www.napcosecurity.com
Warning: The use of non-NAPCO wireless devices with this control panel has not been evaluated by UL and voids
the UL listing. In addition, the performance of these devices can not be guaranteed as compatible with NAPCO
control panels. For systems that include CO detectors, the system must be monitored by a central station.
IMPORTANT NOTE
The Gemini C-Series combination Fire and Burglary control panels are normally programmed with the GEMC-FK1
Fire keypad. However, the control panel can also operate as a "Burglary Only" panel (following the procedure de-
tailed in the section "BASIC OPERATION, Burg-Only Systems"), and may be programmed with the GEMC-BK1
keypad. In programming mode, the key locations used to program with the
GEMC-BK1 keypad are identical to the GEMC-FK1 keypad, however only
the button labels are different. Compare the images of the two keypads on
the cover of this volume. Note that the GEMC-FK1 keypad buttons "NEXT",
"PRIOR", "ACK." and "SILENCE" are labeled "INTERIOR", "INSTANT",
"G", and "BYPASS" on the GEMC-BK1 Burglary keypad, respectively.
These button equivalents are also expressed in the table at right:
GEMC-FK1 GEMC-BK1
NEXT INTERIOR
PRIOR INSTANT
ACK. G
SILENCE BYPASS

NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
NAPCO Security Group
Programming Instructions, Volume 2 Page 71
TABLE OF CONTENTS
Refer to accompanying Gemini C-Series Control Panel Installation Instructions (WI1653) for installation information.
Volume 1
Remote Downloading Rules ....................................................4-11
Locked / Unlocked Quickloader Account.................................4
How To "Lock" / How To "Unlock" ...........................................5
Locked Account Mismatch ........................................................6
Mismatch While Establishing a Telco Connection .................7
Download Initiated Mismatch ....................................................8
"Error Check Required" Keypad Trouble.................................9
Enable Programming Keypad Function Menu Selection........9
30-Minute "Download Window" ..............................................10
PC Preset Support....................................................................11
Basic Operation ............................................................................12
Security, Program & User Codes ................................................15
No Code.....................................................................................15
Master Security Code...............................................................15
Dealer Keypad Program Code.................................................15
Fire User Codes & Burg User Codes ......................................15
Download Security Code .........................................................15
Ambush Code ...........................................................................15
Control Panel Programming Options .........................................16
A: Downloading From A Computer........................................16
Local Downloading From A Computer ...........................16
TCP/IP From A Computer.................................................16
Remote Downloading From A Computer .......................16
Function Mode With A Computer....................................16
Callback Method With A Computer.................................16
B: Easy Menu-Driven Program Mode (Using The Keypad)..16
C: Direct Address Program Mode (Using The Keypad) .......16
Overview -- Keypad Programming Modes..................................17
Unlocking The Fire Keypad .........................................................17
Function Menu -- Fire Keypad .....................................................18
Function Menu -- Burglary Keypad.............................................21
GEMC-FK1 Keypad Configuration Mode ....................................24
GEMC-BK1 Keypad Configuration Mode....................................25
Easy Menu Driven Program Mode..........................................27-37
Easy Menu Programming Worksheets ..................................38-50
Direct Address Program Mode ....................................................51
Address Mode Displays ..........................................................51
Programming Conventions Used In This Manual..................54
System Delays & Timeouts......................................................55
Keypad System Codes.............................................................56
CS Receiver Format Options...................................................57
CS Receiver Telephone Numbers........................................... 58
Download / Callback Options.................................................. 58
CS Subscriber ID Numbers ..................................................... 59
Telco Options and Timeouts................................................... 61
CS Area & System Reporting Options ................................... 61
CS Zone Reporting Codes....................................................... 62
CS User Reporting Codes ....................................................... 64
Volume 2
Direct Address Program Mode (cont'd)...................................... 72
Overview ................................................................................... 72
Address Mode Displays .......................................................... 72
Programming Conventions Used In This Manual ................. 75
Global System Trouble Reporting Options............................ 76
Area System Trouble Reporting Options............................... 77
Zone Options .......................................................................79-91
System Options........................................................................ 92
NAC System Options ............................................................... 92
Alarm / Trouble Reporting Codes........................................... 93
Zone Types ............................................................................... 94
SLC/RF Receivers -- Number, Type and Location................. 94
Number of Relay Board Modules............................................ 95
Onboard NAC / Relay Type...................................................... 95
Relay Board Type..................................................................... 95
Fire Reporting Events .............................................................. 96
Burg Area Event Reporting Options....................................... 97
Keypad Options........................................................................ 98
ACM Zone Options................................................................... 99
ACM Global Flags..................................................................... 99
ACM Timeouts .......................................................................... 99
ACM Door Area Options ........................................................ 100
ACM Scheduled Free Access................................................ 100
Emergency Free Access........................................................ 100
System Options...................................................................... 101
User Area Options...........................................................102-103
EZM Group Options ........................................................104-105
EZM PGM Terminal Control................................................... 105
Priority Area Arming Options................................................ 106
Area Output Control Options ................................................ 107
RF Receivers & Supervision Timer Options ........................ 108
System Reset Options ........................................................... 109
Alphabetical Index.................................................................. 110
Address Number Index.......................................................... 115
Limited Warranty.................................................................... 120

NAPCO Security Group
NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
Page 72 Programming Instructions, Volume 2
DIRECT ADDRESS OVERVIEW
Direct Address Programming allows you to go directly to the address locations (up to 8179) and change the data entries
manually in order to customize your control panel options. Whereas the Easy Menu Program Mode guides you through
limited selections to get you started, Direct Address Program Mode allows you to change all options directly. It con-
sists of up to 8179 address locations each with data entry locations as shown in the following diagram (below left). The
data entry location accepts data in one of three formats: Binary, Decimal and Hexadecimal (explained below in
"Address Mode Displays"). The following diagram (below right) illustrates a Decimal format data entry location (using
a GEMC-FK1 Fire keypad). Note: PCD-Windows MUST be used to place the Gemini C-Series system into operation.
ADDRESS MODE DISPLAYS
There are three types of address displays when programming in Direct Entry Program Mode, as follows:
A) BINARY (BIT) FORMAT
Settings (such as Zone Features) display and accept data in binary "bit" or "number" format. For example, Zone
Features are turned on by the pressing of keypad buttons 1 through 8, with the activated Zone(s) displaying the cor-
responding decimal digit (replacing deactivated zones which are signified by dashes).
EXAMPLE: With the GEMC-FK1 Fire keypad: Program Zones 2, 4, 5 and 7 as Exit/Entry Follower Zones.
DETERMINE THE DATA ENTRIES
Referring to the ZONE FEATURES page in the programming worksheets that follow, "Exit/Entry Follower" for zones
1 through 8 are located at address 2018.
DATA ENTRY
LOCATION
ADDRESS
LOCATIONS
0000
0000
TO
8179
DATA ENTRY LOCATION:
(One of three formats):
• Binary (Bit)
• Decimal
• Hexadecimal
DIRECT ADDRESS PROGRAM MODE (CONT'D)
GEMC-FK1 Keypad Display Example
0 0 0 0 0 6 0 D
12
= ADDRESS LOCATION
1
2 = DATA ENTRY LOCATION
2018 - - - - - - - - B 2018 - 2 - 4 5 - 7 -B
Address
2018
"Exit/Entry
Follower"
Address
2018
"Exit/Entry
Follower"
DATA ENTRY LOCATION:
Binary (Bit) Format
Press 2 4 5 and 7 in order
to activate Zones 2, 4, 5, and 7. (The "B" on the
right indicates "Binary" format).
DATA ENTRY LOCATION:
Binary (Bit) Format
• No zones yet activated

NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
NAPCO Security Group
Programming Instructions, Volume 2 Page 73
PROGRAM THE DATA ENTRIES
1. Enter the panel's Dealer Security Code, then press R.
2. Answer NO to all questions until "ACTIVATE PROGRAM Y/N" is displayed; then press YES. NOTE: If you pass
"ACTIVATE PROGRAM", scroll backward using A.
3. Press C to enter the Address Program Mode. Address "0000" will display.
4. Press 2018 to access Address 2018. The existing data will display and the cursor will ad-
vance to the data field.
5. Press 2457. The numbers 2, 4, 5 and 7 will appear on the keypad display indicating the
zones activated.
6. Press U to save. Address 2018 is now programmed with "2, 4, 5 and 7".
7. Press R and enter another 4-digit address to continue programming--or--press C to exit and resume
normal keypad operation.
B) DECIMAL FORMAT
Settings such as Entry Delay and Exit Delay display and accept data in "decimal" format, as a 3 digit number. Data
is entered directly, by pressing keys 0 – 9, with the cursor automatically moving to the right upon each key press.
EXAMPLE: Entries with the GEMC-FK1 keypads: Program Abort Delay to be 15 seconds.
DETERMINE THE DATA ENTRIES
Referring to SYSTEM DELAYS & TIMEOUTS in the Programming Worksheets that follow, the Abort Delay is locat-
ed at address 5306:
PROGRAM THE DATA ENTRIES
1. Enter the panel's Dealer Security Code, then press R.
2. Answer NO to all questions until "ACTIVATE PROGRAM Y/N" is displayed; then press YES. NOTE: If you pass
"ACTIVATE PROGRAM", scroll backward using A.
3. Press C to enter the Address Program Mode. Address "0000" will display.
4. Press 5306 to access Address 5306. The existing data will display and the cursor will ad-
vance to the data field.
5. Press 015. The numbers 015 will appear on the keypad display indicating the number of
seconds entered.
5306 - - - D 5306 015 D
ZONES 1 → 8 ZONES 9 → 16
ZONE FEATURES ADDR Z1 Z2 Z3 Z4 Z5 Z6 Z7 Z8 ADDR Z9 Z10 Z11 Z12 Z13 Z14 Z15 Z16
1234567812345678
Exit/Entry Follower 2018 6 7 8 2118
DATA ENTRY LOCATION:
Decimal Format
• No time yet entered
Address
5306
"Abort
Delay"
DATA ENTRY LOCATION:
Decimal Format
Press 015 in order to set the
"Abort Delay" to 15 seconds. The "D" on the
right indicates "Decimal" format.
ADDRESS 5306
ABORT
DELAY
(sec.)
[Default = 000]
Address
5306
"Abort
Delay"

NAPCO Security Group
NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
Page 74 Programming Instructions, Volume 2
6. Press U to save. Address 5306 is now programmed with a 15-second Abort Delay.
7. Enter another 4-digit address to continue programming or press C to exit and resume normal keypad
operation.
C) HEXADECIMAL FORMAT
Reporting Codes are entered by means of a hexadecimal display. Data is entered directly, by pressing keys 1 – 9,
D0 for zero, and D1 through D5 for hex "B" through "F" (11-15), with the cursor automatical-
ly moving to the right upon each key press. See table below.
3
EXAMPLE: Entries with the GEMC-FK1 keypads: Program an Alarm Trouble Reporting Code (in a central station re-
ceiver format) to be "1B".
DETERMINE THE DATA ENTRIES
Referring to the ALARM TROUBLE REPORTING CODES table in the programming worksheets that follow, the
"Wireless Low Battery" reporting code is located at address 7925; the data entries needed to assign a code of "1B"
are "1" and "D1".
PROGRAM THE DATA ENTRIES
1. Enter the panel's Dealer Security Code, then press R.
2. Answer NO to all questions until "ACTIVATE PROGRAM Y/N" is displayed; then press YES. NOTE: If you pass
HEXADECIMAL ENTRIES
ENTRY
TOTAL PRESS THIS KEY KEYPAD DISPLAYS
ENTRY
TOTAL PRESS THIS KEY KEYPAD DISPLAYS
("blank") 0•888
111999
22210 D 00
33311 D 1B
44412 D 2C
55513 D 3D
66614 D 4E
77715 D 5F
7925 - - H 7925 1 B H
ALARM/TROUBLE
REPORTING CODES LEFTAddress RIGHT
Wireless Low Battery 7925
Wireless Supervision 7926
Wireless Tamper
7927
[Default = blank (•) from address 7925-7927]
Address
7925
"Wireless
Low
Battery"
Address
7925
"Wireless
Low
Battery"
DATA ENTRY LOCATION:
Hex Format
• No data yet entered
DATA ENTRY LOCATION:
Hex Format
Press 1D1 in order to set
"Ambush" Reporting code to "1B". The "H"
on the right indicates "Hexadecimal" format.

NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
NAPCO Security Group
Programming Instructions, Volume 2 Page 75
"ACTIVATE PROGRAM", scroll backward using A.
3. Press C to enter the Address Program Mode. Address "0000" will display.
4. Press 7925 to access Address 7925. The existing data will display and the cursor will advance
to the data field.
5. Since you wish the reporting code to be "1B", press 1 to enter a "1" in the display, and press G1
to enter a "B" in the display. NOTE: The right address is reported first, therefore, in the address table, the
right digit is the 1st digit of the reporting code ("1" in this example). The left digit is the first digit and right digit
is the second digit in a two digit CS receiver format.
6. Press U to save. Address 7925 is now programmed with a "Wireless Low Battery" reporting code of "1B".
7. Press R and enter another 4-digit address to continue programming--or--press C to exit and resume
normal keypad operation.
PROGRAMMING CONVENTIONS USED IN THIS MANUAL
The keypad programming worksheets that follow are provided as an address-programming reference to help the in-
staller modify (via the keypad) their custom default program or to make minor field alterations to an existing control
panel program. The panel MUST be uploaded to NAPCO's PCD-Windows software following any keypad program-
ming; the PCD-Windows's error-check feature must be utilized to reduce the possibility of programming omissions or
conflicts. Keep the Keypad Programming Worksheets on file for future reference.
General Programming Steps
1. Contact the central station to ascertain receiver format, data format, event codes, subscriber numbers and tele-
phone number(s).
2. Select the desired features by writing in (pencil recommended) the respective "address boxes". Refer to the Pro-
gramming Options and Worksheets for guidance in selecting the "data" to be entered into those boxes.
3. Program the data entered in the boxes on the worksheets into the respective addresses. See the programming
examples on the previous pages.
The displays will appear after a brief delay.
• Use the R button to toggle the cursor between the 4-digit address field and the data entry locations.
• The contents of the address will be read automatically, along with the feature name and programming infor-
mation. The cursor will advance to the data field. Enter the required data directly using the number buttons.
 IMPORTANT: Press U to save the contents of each address.
EXIT DIRECT ADDRESS PROGRAM MODE: When done, press C to exit and resume normal keypad operation.

NAPCO Security Group
NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
Page 76 Programming Instructions, Volume 2
SYSTEM RESPONSE
ACTIVATED BY GLOBAL
EVENT/TROUBLE
ADDR
GLOBAL SYSTEM EVENT/TROUBLE
TEST
TIMER
ALARM
SUPERV.
COMM. BUS
1
MEMORY
FAILURE
LOW
BATTERY AC FAIL EZM TAMPER
SENSOR
WATCH
12345678
Burglary Alarm Output 1850
Pulsed Burg. Bell 1851
Burg PGM2 1852
Burg Relay 1853
Burg PGM1 1854
Report Event Telco 1 1855
Report Restore Telco 1 1856
Report Event Telco 3 1859
Report Restore Telco 3 1860
[Default = blank (•) from address 1850-1860].
 1. Select the desired option entering the option number (1-8) for each digit.
 2. Enter corresponding option number in address location.
NOTE: Dark shaded data value box shows option not available. Press U to save.
SYSTEM RESPONSE
ACTIVATED BY GLOBAL
EVENT/TROUBLE
ADDR
GLOBAL SYSTEM EVENT/TROUBLE
TELCO 1
FAIL
TELCO 2
FAIL
Telemetry
Trouble
Telemetry
Failure GF RSRVD. ACM Low
Battery
ACM Power
Fail
12345678
Burglary Alarm Output 1862
Pulsed Burg. Bell 1863
Burg PGM2 1864
Burg Relay 1865
Burg PGM1 1866
Report Event Telco 1 1867
Report Restore Telco 1 1868
Report Event Telco 3 1871
Report Restore Telco 3 1872
[Default = blank (•) from address 1862-1872]
SYSTEM RESPONSE
ACTIVATED BY GLOBAL
EVENT/TROUBLE
ADDR
GLOBAL SYSTEM EVENT/TROUBLE
DIGITAL
DIALER TEST
GUARD
TOUR FAIL RSRVD. SERVICE MESSAGE
PROGRAM
CHANGE RSRVD. RSRVD. RSRVD.
12345678
Burglary Alarm Output 1874
Pulsed Burg. Bell 1875
Burg PGM2 1876
Burg Relay 1877
Burg PGM1 1878
Report Event Telco 1 1879
Report Restore Telco 1 1880
Report Event Telco 3 1883
Report Restore Telco 3 1884
[Default = blank (•) blank (•) from address 1874-1884]
GLOBAL SYSTEM TROUBLE REPORTING OPTIONS (ADDRESS 1850-1884)

NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
NAPCO Security Group
Programming Instructions, Volume 2 Page 77
AREA SYST EM TROUBLE REPORTING OPTIONS (A DDRESS 1890 -1927)
 1. Select the desired option entering the option number (1-8) for each digit.
 2. Enter corresponding option number in address location.
NOTE: Dark shaded data value box shows option not available.
 3. Press U to save.
SYSTEM RESPONSE
ACTIVATED BY AREA 2
EVENT/TROUBLE
AREA 2 SYSTEM EVENT/TROUBLE
ADDR AMBUSH KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.*
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE RSRVD.
12345678
Pulsed Burg. Bell 1900
Burglary Bell 1901Default ON Default ON
Burg PGM2 1902
Burg Relay 1903
Burg PGM1 1904
Report Alarm Telco 1 1905Default ON Default ON
Report Alarm Telco 3 1907
[Defaults as noted from address 1900-1907] * NOTE: Keypad Aux. is not to be selected for UL Installations.
SYSTEM RESPONSE
ACTIVATED BY AREA 3
EVENT/TROUBLE
AREA 3 SYSTEM EVENT/TROUBLE
ADDR AMBUSH KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.*
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE RSRVD.
12345678
Pulsed Burg. Bell 1910
Burglary Bell 1911
Burg PGM2 1912
Burg Relay 1913
Burg PGM1 1914
Report Alarm Telco 1 1915
Report Alarm Telco 3 1917
[Default = blank (•) blank (•) from address 1910-1917] * NOTE: Keypad Aux. is not to be selected for UL Installations.
SYSTEM RESPONSE
ACTIVATED BY AREA 4
EVENT/TROUBLE
AREA 4 SYSTEM EVENT/TROUBLE
ADDR AMBUSH KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.*
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE RSRVD.
12345678
Pulsed Burg. Bell 1920
Burglary Bell 1921
Burg PGM2 1922
Burg Relay 1923
Burg PGM1 1924
Report Alarm Telco 1 1925
Report Alarm Telco 3 1927
[Default = blank (•) blank (•) from address 1920-1927] * NOTE: Keypad Aux. is not to be selected for UL Installations.

NAPCO Security Group
NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
Page 78 Programming Instructions, Volume 2
AREA SYST EM TROUBLE REPORTING OPTIONS (A DDRESS 1930 -1967)
SYSTEM RESPONSE
ACTIVATED BY AREA 8
EVENT/TROUBLE
AREA 8 SYSTEM EVENT/TROUBLE
ADDR AMBUSH KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.*
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE RSRVD.
12345678
Pulsed Burg. Bell 1960
Burglary Bell 1961
Burg PGM2 1962
Burg Relay 1963
Burg PGM1 1964
Report Alarm Telco 1 1965
Report Alarm Telco 3 1967
[Default = blank (•) blank (•) from address 1960-1967] * NOTE: Keypad Aux. is not to be selected for UL Installations.
SYSTEM RESPONSE
ACTIVATED BY AREA 5
EVENT/TROUBLE
ADDR
AREA 5 SYSTEM EVENT/TROUBLE
AMBUSH KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.*
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE RSRVD.
12345678
Pulsed Burg. Bell 1930
Burglary Bell 1931
Burg PGM2 1932
Burg Relay 1933
Burg PGM1 1934
Report Alarm Telco 1 1935
Report Alarm Telco 3 1937
[Default = blank (•) blank (•) from address 1930-1937] * NOTE: Keypad Aux. is not to be selected for UL Installations.
SYSTEM RESPONSE
ACTIVATED BY AREA 6
EVENT/TROUBLE
ADDR
AREA 6 SYSTEM EVENT/TROUBLE
AMBUSH KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.*
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE RSRVD.
12345678
Pulsed Burg. Bell 1940
Burglary Bell 1941
Burg PGM2 1942
Burg Relay 1943
Burg PGM1 1944
Report Alarm Telco 1 1945
Report Alarm Telco 3 1947
[Default = blank (•) blank (•) from address 1940-1947] * NOTE: Keypad Aux. is not to be selected for UL Installations.
SYSTEM RESPONSE
ACTIVATED BY AREA 7
EVENT/TROUBLE
AREA 7 SYSTEM EVENT/TROUBLE
ADDR AMBUSH KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.*
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE RSRVD.
12345678
Pulsed Burg. Bell 1950
Burglary Bell 1951
Burg PGM2 1952
Burg Relay 1953
Burg PGM1 1954
Report Alarm Telco 1 1955
Report Alarm Telco 3 1957
[Default = blank (•) blank (•) from address 1950-1957] * NOTE: Keypad Aux. is not to be selected for UL Installations.
 1. Select the desired option entering the option number (1-8) for each digit.
 2. Enter corresponding option number in address location.
NOTE: Dark shaded data value box shows option not available.
 3. Press U to save.

NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
NAPCO Security Group
Programming Instructions, Volume 2 Page 79
ZONE OPTIONS / ZONES 1-8 (ADDRESS 2002-2088)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 1 ► 8
Z1 Z2 Z3 Z4 Z5 Z6 Z7 Z8
12345678
Zone Area 1 (Fire) 2044
Zone Area 2 2045
Zone Area 3 2046
Zone Area 4 2047
Zone Area 5 2048
Zone Area 6 2049
Zone Area 7 2050
Zone Area 8 2051
Reserved 2052
Reserved 2053
Zone Anding Group 1 2054
Zone Anding Group 2 2055
Zone Anding Group 3 2056
Zone Anding Group 4 2057
Zone Anding Group 5 2058
Zone Anding Group 6 2059
Zone Anding Group 7 2060
Zone Anding Group 8 2061
Interior 1 Bypass 2062
Interior 2 Bypass 2063
Keypad Sounder on Alarm 2064
Ext Fire Output 1 2065
Ext Fire Output 2 2066
Ext Fire Output 3 2067
Ext Fire Output 4 2068
Ext Fire Output 5 2069
Ext Fire Output 6 2070
Ext Fire Output 7 2071
Ext Fire Output 8 2072
Reserved 2073
Reserved 2074
Carbon Monoxide 2075
Verification (Fire) 2076
Waterflow (Fire) 2077
Supervisory 2078
Monitor Zone 2079
NAC A 2080
NAC B 2081
NAC C 2082
NAC D 2083
Reserved 2084
Reserved 2085
Chime 2 2086
Delayed Trip 1 2087
Delayed Trip 2 2088
ZONE OPTIONS ADDR
ZONES 1 ► 8
Z1 Z2 Z3 Z4 Z5 Z6 Z7 Z8
12345678
Priority Zone 2002
Priority / Bypass 2003
AutoBypass 2004
Selective Bypass 2005
Keyswitch Arming 2006
AutoBypass Re-entry 2007
Pre-Alarm Warning 2008
Never Arm 2009
24-Hour Protection 2010
Burg Bell 2011
Pulse Burg Bell 2012
Burg PGM2 2013
Burg Relay 2014
Burg PGM1 2015
Exit/Entry #1 2016
Exit/Entry #2 2017
Exit/Entry Follower 2018
Auto Reset 2019
Swinger Shutdown 2020
Chime Zone 2021
Abort Delay 2022
Power-Up Delay 2023
Day Zone/Trouble Open 2024
Day Zone/Trouble Short 2025
Alarm on Day Zone/Trouble 2026
Report Alarm Tel1 2027
Rpt Alm Restore Tel1 2028
Report Trouble Tel1 2029
Rpt Tbl Restore Tel1 2030
Reserved 2031
Reserved 2032
Reserved 2033
Reserved 2034
Report Alarm Tel3 2035
Rpt Alm Restore Tel3 2036
Report Trouble Tel3 2037
Rpt Tbl Restore Tel3 2038
No EOL Resistor 2039
Sensor Watch 2040
Trouble on Open 2041
Trouble on Short 2042
Trouble on Night Open 2043
FOOTNOTES AND SYMBOLS FOR TABLES
A2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
BIf Fire Alarm Verification is selected, then Fire must also be
selected.
CWhen the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
DDisable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.

NAPCO Security Group
NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
Page 80 Programming Instructions, Volume 2
ZONE OPTIONS / ZONES 9-16 (ADDRESS 2102-2188)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 9 ► 16
Z9 Z10 Z11 Z12 Z13 Z14 Z15 Z16
12345678
Zone Area 1 (Fire) 2144
Zone Area 2 2145
Zone Area 3 2146
Zone Area 4 2147
Zone Area 5 2148
Zone Area 6 2149
Zone Area 7 2150
Zone Area 8 2151
Reserved 2152
Reserved 2153
Zone Anding Group 1 2154
Zone Anding Group 2 2155
Zone Anding Group 3 2156
Zone Anding Group 4 2157
Zone Anding Group 5 2158
Zone Anding Group 6 2159
Zone Anding Group 7 2160
Zone Anding Group 8 2161
Interior 1 Bypass 2162
Interior 2 Bypass 2163
Keypad Sounder on Alarm 2164
Ext Fire Output 1 2165
Ext Fire Output 2 2166
Ext Fire Output 3 2167
Ext Fire Output 4 2168
Ext Fire Output 5 2169
Ext Fire Output 6 2170
Ext Fire Output 7 2171
Ext Fire Output 8 2172
Reserved 2173
Reserved 2174
Carbon Monoxide 2175
Verification (Fire) 2176
Waterflow (Fire) 2177
Supervisory 2178
Monitor Zone 2179
NAC A 2180
NAC B 2181
NAC C 2182
NAC D 2183
Reserved 2184
Reserved 2185
Chime 2 2186
Delayed Trip 1 2187
Delayed Trip 2 2188
ZONE OPTIONS ADDR
ZONES 9 ► 16
Z9 Z10 Z11 Z12 Z13 Z14 Z15 Z16
12345678
Priority Zone 2102
Priority / Bypass 2103
AutoBypass 2104
Selective Bypass 2105
Keyswitch Arming 2106
AutoBypass Re-entry 2107
Pre-Alarm Warning 2108
Never Arm 2109
24-Hour Protection 2110
Burg Bell 2111
Pulse Burg Bell 2112
Burg PGM2 2113
Burg Relay 2114
Burg PGM1 2115
Exit/Entry #1 2116
Exit/Entry #2 2117
Exit/Entry Follower 2118
Auto Reset 2119
Swinger Shutdown 2120
Chime Zone 2121
Abort Delay 2122
Power-Up Delay 2123
Day Zone/Trouble Open 2124
Day Zone/Trouble Short 2125
Alarm on Day Zone/Trouble 2126
Report Alarm Tel1 2127
Rpt Alm Restore Tel1 2128
Report Trouble Tel1 2129
Rpt Tbl Restore Tel1 2130
Reserved 2131
Reserved 2132
Reserved 2133
Reserved 2134
Report Alarm Tel3 2135
Rpt Alm Restore Tel3 2136
Report Trouble Tel3 2137
Rpt Tbl Restore Tel3 2138
No EOL Resistor 2139
Sensor Watch 2140
Trouble on Open 2141
Trouble on Short 2142
Trouble on Night Open 2143
FOOTNOTES AND SYMBOLS FOR TABLES
A2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
BIf Fire Alarm Verification is selected, then Fire must also be
selected.
CWhen the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
DDisable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.

NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
NAPCO Security Group
Programming Instructions, Volume 2 Page 81
ZONE OPTIONS / ZONES 17-24 (ADDRESS 2202-2288)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 17 ► 24
Z17 Z18 Z19 Z20 Z21 Z22 Z23 Z24
12345678
Zone Area 1 (Fire) 2244
Zone Area 2 2245
Zone Area 3 2246
Zone Area 4 2247
Zone Area 5 2248
Zone Area 6 2249
Zone Area 7 2250
Zone Area 8 2251
Reserved 2252
Reserved 2253
Zone Anding Group 1 2254
Zone Anding Group 2 2255
Zone Anding Group 3 2256
Zone Anding Group 4 2257
Zone Anding Group 5 2258
Zone Anding Group 6 2259
Zone Anding Group 7 2260
Zone Anding Group 8 2261
Interior 1 Bypass 2262
Interior 2 Bypass 2263
Keypad Sounder on Alarm 2264
Ext Fire Output 1 2265
Ext Fire Output 2 2266
Ext Fire Output 3 2267
Ext Fire Output 4 2268
Ext Fire Output 5 2269
Ext Fire Output 6 2270
Ext Fire Output 7 2271
Ext Fire Output 8 2272
Reserved 2273
Reserved 2274
Carbon Monoxide 2275
Verification (Fire) 2276
Waterflow (Fire) 2277
Supervisory 2278
Monitor Zone 2279
NAC A 2280
NAC B 2281
NAC C 2282
NAC D 2283
Reserved 2284
Reserved 2285
Chime 2 2286
Delayed Trip 1 2287
Delayed Trip 2 2288
ZONE OPTIONS ADDR
ZONES 17 ► 24
Z17 Z18 Z19 Z20 Z21 Z22 Z23 Z24
12345678
Priority Zone 2202
Priority / Bypass 2203
AutoBypass 2204
Selective Bypass 2205
Keyswitch Arming 2206
AutoBypass Re-entry 2207
Pre-Alarm Warning 2208
Never Arm 2209
24-Hour Protection 2210
Burg Bell 2211
Pulse Burg Bell 2212
Burg PGM2 2213
Burg Relay 2214
Burg PGM1 2215
Exit/Entry #1 2216
Exit/Entry #2 2217
Exit/Entry Follower 2218
Auto Reset 2219
Swinger Shutdown 2220
Chime Zone 2221
Abort Delay 2222
Power-Up Delay 2223
Day Zone/Trouble Open 2224
Day Zone/Trouble Short 2225
Alarm on Day Zone/Trouble 2226
Report Alarm Tel1 2227
Rpt Alm Restore Tel1 2228
Report Trouble Tel1 2229
Rpt Tbl Restore Tel1 2230
Reserved 2231
Reserved 2232
Reserved 2233
Reserved 2234
Report Alarm Tel3 2235
Rpt Alm Restore Tel3 2236
Report Trouble Tel3 2237
Rpt Tbl Restore Tel3 2238
No EOL Resistor 2239
Sensor Watch 2240
Trouble on Open 2241
Trouble on Short 2242
Trouble on Night Open 2243
FOOTNOTES AND SYMBOLS FOR TABLES
A2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
BIf Fire Alarm Verification is selected, then Fire must also be
selected.
CWhen the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
DDisable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.

NAPCO Security Group
NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
Page 82 Programming Instructions, Volume 2
ZONE OPTIONS / ZONES 25-32 (ADDRESS 2302-2388)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 25 ► 32
Z25 Z26 Z27 Z28 Z29 Z30 Z31 Z32
12345678
Zone Area 1 (Fire) 2344
Zone Area 2 2345
Zone Area 3 2346
Zone Area 4 2347
Zone Area 5 2348
Zone Area 6 2349
Zone Area 7 2350
Zone Area 8 2351
Reserved 2352
Reserved 2353
Zone Anding Group 1 2354
Zone Anding Group 2 2355
Zone Anding Group 3 2356
Zone Anding Group 4 2357
Zone Anding Group 5 2358
Zone Anding Group 6 2359
Zone Anding Group 7 2360
Zone Anding Group 8 2361
Interior 1 Bypass 2362
Interior 2 Bypass 2363
Keypad Sounder on Alarm 2364
Ext Fire Output 1 2365
Ext Fire Output 2 2366
Ext Fire Output 3 2367
Ext Fire Output 4 2368
Ext Fire Output 5 2369
Ext Fire Output 6 2370
Ext Fire Output 7 2371
Ext Fire Output 8 2372
Reserved 2373
Reserved 2374
Carbon Monoxide 2375
Verification (Fire) 2376
Waterflow (Fire) 2377
Supervisory 2378
Monitor Zone 2379
NAC A 2380
NAC B 2381
NAC C 2382
NAC D 2383
Reserved 2384
Reserved 2385
Chime 2 2386
Delayed Trip 1 2387
Delayed Trip 2 2388
ZONE OPTIONS ADDR
ZONES 25 ► 32
Z25 Z26 Z27 Z28 Z29 Z30 Z31 Z32
12345678
Priority Zone 2302
Priority / Bypass 2303
AutoBypass 2304
Selective Bypass 2305
Keyswitch Arming 2306
AutoBypass Re-entry 2307
Pre-Alarm Warning 2308
Never Arm 2309
24-Hour Protection 2310
Burg Bell 2311
Pulse Burg Bell 2312
Burg PGM2 2313
Burg Relay 2314
Burg PGM1 2315
Exit/Entry #1 2316
Exit/Entry #2 2317
Exit/Entry Follower 2318
Auto Reset 2319
Swinger Shutdown 2320
Chime Zone 2321
Abort Delay 2322
Power-Up Delay 2323
Day Zone/Trouble Open 2324
Day Zone/Trouble Short 2325
Alarm on Day Zone/Trouble 2326
Report Alarm Tel1 2327
Rpt Alm Restore Tel1 2328
Report Trouble Tel1 2329
Rpt Tbl Restore Tel1 2330
Reserved 2331
Reserved 2332
Reserved 2333
Reserved 2334
Report Alarm Tel3 2335
Rpt Alm Restore Tel3 2336
Report Trouble Tel3 2337
Rpt Tbl Restore Tel3 2338
No EOL Resistor 2339
Sensor Watch 2340
Trouble on Open 2341
Trouble on Short 2342
Trouble on Night Open 2343
FOOTNOTES AND SYMBOLS FOR TABLES
A2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
BIf Fire Alarm Verification is selected, then Fire must also be
selected.
CWhen the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
DDisable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.

NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
NAPCO Security Group
Programming Instructions, Volume 2 Page 83
ZONE OPTIONS / ZONES 33-40 (ADDRESS 2402-2488)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 33 ► 40
Z33 Z34 Z35 Z36 Z37 Z38 Z39 Z40
12345678
Zone Area 1 (Fire) 2444
Zone Area 2 2445
Zone Area 3 2446
Zone Area 4 2447
Zone Area 5 2448
Zone Area 6 2449
Zone Area 7 2450
Zone Area 8 2451
Reserved 2452
Reserved 2453
Zone Anding Group 1 2454
Zone Anding Group 2 2455
Zone Anding Group 3 2456
Zone Anding Group 4 2457
Zone Anding Group 5 2458
Zone Anding Group 6 2459
Zone Anding Group 7 2460
Zone Anding Group 8 2461
Interior 1 Bypass 2462
Interior 2 Bypass 2463
Keypad Sounder on Alarm 2464
Ext Fire Output 1 2465
Ext Fire Output 2 2466
Ext Fire Output 3 2467
Ext Fire Output 4 2468
Ext Fire Output 5 2469
Ext Fire Output 6 2470
Ext Fire Output 7 2471
Ext Fire Output 8 2472
Reserved 2473
Reserved 2474
Carbon Monoxide 2475
Verification (Fire) 2476
Waterflow (Fire) 2477
Supervisory 2478
Monitor Zone 2479
NAC A 2480
NAC B 2481
NAC C 2482
NAC D 2483
Reserved 2484
Reserved 2485
Chime 2 2486
Delayed Trip 1 2487
Delayed Trip 2 2488
ZONE OPTIONS ADDR
ZONES 33 ► 40
Z33 Z34 Z35 Z36 Z37 Z38 Z39 Z40
12345678
Priority Zone 2402
Priority / Bypass 2403
AutoBypass 2404
Selective Bypass 2405
Keyswitch Arming 2406
AutoBypass Re-entry 2407
Pre-Alarm Warning 2408
Never Arm 2409
24-Hour Protection 2410
Burg Bell 2411
Pulse Burg Bell 2412
Burg PGM2 2413
Burg Relay 2414
Burg PGM1 2415
Exit/Entry #1 2416
Exit/Entry #2 2417
Exit/Entry Follower 2418
Auto Reset 2419
Swinger Shutdown 2420
Chime Zone 2421
Abort Delay 2422
Power-Up Delay 2423
Day Zone/Trouble Open 2424
Day Zone/Trouble Short 2425
Alarm on Day Zone/Trouble 2426
Report Alarm Tel1 2427
Rpt Alm Restore Tel1 2428
Report Trouble Tel1 2429
Rpt Tbl Restore Tel1 2430
Reserved 2431
Reserved 2432
Reserved 2433
Reserved 2434
Report Alarm Tel3 2435
Rpt Alm Restore Tel3 2436
Report Trouble Tel3 2437
Rpt Tbl Restore Tel3 2438
No EOL Resistor 2439
Sensor Watch 2440
Trouble on Open 2441
Trouble on Short 2442
Trouble on Night Open 2443
FOOTNOTES AND SYMBOLS FOR TABLES
A2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
BIf Fire Alarm Verification is selected, then Fire must also be
selected.
CWhen the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
DDisable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.

NAPCO Security Group
NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
Page 84 Programming Instructions, Volume 2
ZONE OPTIONS / ZONES 41-48 (ADDRESS 2502-2588)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 41 ► 48
Z41 Z42 Z43 Z44 Z45 Z46 Z47 Z48
12345678
Zone Area 1 (Fire) 2544
Zone Area 2 2545
Zone Area 3 2546
Zone Area 4 2547
Zone Area 5 2548
Zone Area 6 2549
Zone Area 7 2550
Zone Area 8 2551
Reserved 2552
Reserved 2553
Zone Anding Group 1 2554
Zone Anding Group 2 2555
Zone Anding Group 3 2556
Zone Anding Group 4 2557
Zone Anding Group 5 2558
Zone Anding Group 6 2559
Zone Anding Group 7 2560
Zone Anding Group 8 2561
Interior 1 Bypass 2562
Interior 2 Bypass 2563
Keypad Sounder on Alarm 2564
Ext Fire Output 1 2565
Ext Fire Output 2 2566
Ext Fire Output 3 2567
Ext Fire Output 4 2568
Ext Fire Output 5 2569
Ext Fire Output 6 2570
Ext Fire Output 7 2571
Ext Fire Output 8 2572
Reserved 2573
Reserved 2574
Carbon Monoxide 2575
Verification (Fire) 2576
Waterflow (Fire) 2577
Supervisory 2578
Monitor Zone 2579
NAC A 2580
NAC B 2581
NAC C 2582
NAC D 2583
Reserved 2584
Reserved 2585
Chime 2 2586
Delayed Trip 1 2587
Delayed Trip 2 2588
ZONE OPTIONS ADDR
ZONES 41 ► 48
Z41 Z42 Z43 Z44 Z45 Z46 Z47 Z48
12345678
Priority Zone 2502
Priority / Bypass 2503
AutoBypass 2504
Selective Bypass 2505
Keyswitch Arming 2506
AutoBypass Re-entry 2507
Pre-Alarm Warning 2508
Never Arm 2509
24-Hour Protection 2510
Burg Bell 2511
Pulse Burg Bell 2512
Burg PGM2 2513
Burg Relay 2514
Burg PGM1 2515
Exit/Entry #1 2516
Exit/Entry #2 2517
Exit/Entry Follower 2518
Auto Reset 2519
Swinger Shutdown 2520
Chime Zone 2521
Abort Delay 2522
Power-Up Delay 2523
Day Zone/Trouble Open 2524
Day Zone/Trouble Short 2525
Alarm on Day Zone/Trouble 2526
Report Alarm Tel1 2527
Rpt Alm Restore Tel1 2528
Report Trouble Tel1 2529
Rpt Tbl Restore Tel1 2530
Reserved 2531
Reserved 2532
Reserved 2533
Reserved 2534
Report Alarm Tel3 2535
Rpt Alm Restore Tel3 2536
Report Trouble Tel3 2537
Rpt Tbl Restore Tel3 2538
No EOL Resistor 2539
Sensor Watch 2540
Trouble on Open 2541
Trouble on Short 2542
Trouble on Night Open 2543
FOOTNOTES AND SYMBOLS FOR TABLES
A2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
BIf Fire Alarm Verification is selected, then Fire must also be
selected.
CWhen the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
DDisable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.

NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
NAPCO Security Group
Programming Instructions, Volume 2 Page 85
ZONE OPTIONS / ZONES 49-56 (ADDRESS 2602-2688)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 49 ► 56
Z49 Z50 Z51 Z52 Z53 Z54 Z55 Z56
12345678
Zone Area 1 (Fire) 2644
Zone Area 2 2645
Zone Area 3 2646
Zone Area 4 2647
Zone Area 5 2648
Zone Area 6 2649
Zone Area 7 2650
Zone Area 8 2651
Reserved 2652
Reserved 2653
Zone Anding Group 1 2654
Zone Anding Group 2 2655
Zone Anding Group 3 2656
Zone Anding Group 4 2657
Zone Anding Group 5 2658
Zone Anding Group 6 2659
Zone Anding Group 7 2660
Zone Anding Group 8 2661
Interior 1 Bypass 2662
Interior 2 Bypass 2663
Keypad Sounder on Alarm 2664
Ext Fire Output 1 2665
Ext Fire Output 2 2666
Ext Fire Output 3 2667
Ext Fire Output 4 2668
Ext Fire Output 5 2669
Ext Fire Output 6 2670
Ext Fire Output 7 2671
Ext Fire Output 8 2672
Reserved 2673
Reserved 2674
Carbon Monoxide 2675
Verification (Fire) 2676
Waterflow (Fire) 2677
Supervisory 2678
Monitor Zone 2679
NAC A 2680
NAC B 2681
NAC C 2682
NAC D 2683
Reserved 2684
Reserved 2685
Chime 2 2686
Delayed Trip 1 2687
Delayed Trip 2 2688
ZONE OPTIONS ADDR
ZONES 49 ► 56
Z49 Z50 Z51 Z52 Z53 Z54 Z55 Z56
12345678
Priority Zone 2602
Priority / Bypass 2603
AutoBypass 2604
Selective Bypass 2605
Keyswitch Arming 2606
AutoBypass Re-entry 2607
Pre-Alarm Warning 2608
Never Arm 2609
24-Hour Protection 2610
Burg Bell 2611
Pulse Burg Bell 2612
Burg PGM2 2613
Burg Relay 2614
Burg PGM1 2615
Exit/Entry #1 2616
Exit/Entry #2 2617
Exit/Entry Follower 2618
Auto Reset 2619
Swinger Shutdown 2620
Chime Zone 2621
Abort Delay 2622
Power-Up Delay 2623
Day Zone/Trouble Open 2624
Day Zone/Trouble Short 2625
Alarm on Day Zone/Trouble 2626
Report Alarm Tel1 2627
Rpt Alm Restore Tel1 2628
Report Trouble Tel1 2629
Rpt Tbl Restore Tel1 2630
Reserved 2631
Reserved 2632
Reserved 2633
Reserved 2634
Report Alarm Tel3 2635
Rpt Alm Restore Tel3 2636
Report Trouble Tel3 2637
Rpt Tbl Restore Tel3 2638
No EOL Resistor 2639
Sensor Watch 2640
Trouble on Open 2641
Trouble on Short 2642
Trouble on Night Open 2643
FOOTNOTES AND SYMBOLS FOR TABLES
A2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
BIf Fire Alarm Verification is selected, then Fire must also be
selected.
CWhen the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
DDisable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.

NAPCO Security Group
NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
Page 86 Programming Instructions, Volume 2
ZONE OPTIONS / ZONES 57-64 (ADDRESS 2702-2788)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 57 ► 64
Z57 Z58 Z59 Z60 Z61 Z62 Z63 Z64
12345678
Zone Area 1 (Fire) 2744
Zone Area 2 2745
Zone Area 3 2746
Zone Area 4 2747
Zone Area 5 2748
Zone Area 6 2749
Zone Area 7 2750
Zone Area 8 2751
Reserved 2752
Reserved 2753
Zone Anding Group 1 2754
Zone Anding Group 2 2755
Zone Anding Group 3 2756
Zone Anding Group 4 2757
Zone Anding Group 5 2758
Zone Anding Group 6 2759
Zone Anding Group 7 2760
Zone Anding Group 8 2761
Interior 1 Bypass 2762
Interior 2 Bypass 2763
Keypad Sounder on Alarm 2764
Ext Fire Output 1 2765
Ext Fire Output 2 2766
Ext Fire Output 3 2767
Ext Fire Output 4 2768
Ext Fire Output 5 2769
Ext Fire Output 6 2770
Ext Fire Output 7 2771
Ext Fire Output 8 2772
Reserved 2773
Reserved 2774
Carbon Monoxide 2775
Verification (Fire) 2776
Waterflow (Fire) 2777
Supervisory 2778
Monitor Zone 2779
NAC A 2780
NAC B 2781
NAC C 2782
NAC D 2783
Reserved 2784
Reserved 2785
Chime 2 2786
Delayed Trip 1 2787
Delayed Trip 2 2788
ZONE OPTIONS ADDR
ZONES 57 ► 64
Z57 Z58 Z59 Z60 Z61 Z62 Z63 Z64
12345678
Priority Zone 2702
Priority / Bypass 2703
AutoBypass 2704
Selective Bypass 2705
Keyswitch Arming 2706
AutoBypass Re-entry 2707
Pre-Alarm Warning 2708
Never Arm 2709
24-Hour Protection 2710
Burg Bell 2711
Pulse Burg Bell 2712
Burg PGM2 2713
Burg Relay 2714
Burg PGM1 2715
Exit/Entry #1 2716
Exit/Entry #2 2717
Exit/Entry Follower 2718
Auto Reset 2719
Swinger Shutdown 2720
Chime Zone 2721
Abort Delay 2722
Power-Up Delay 2723
Day Zone/Trouble Open 2724
Day Zone/Trouble Short 2725
Alarm on Day Zone/Trouble 2726
Report Alarm Tel1 2727
Rpt Alm Restore Tel1 2728
Report Trouble Tel1 2729
Rpt Tbl Restore Tel1 2730
Reserved 2731
Reserved 2732
Reserved 2733
Reserved 2734
Report Alarm Tel3 2735
Rpt Alm Restore Tel3 2736
Report Trouble Tel3 2737
Rpt Tbl Restore Tel3 2738
No EOL Resistor 2739
Sensor Watch 2740
Trouble on Open 2741
Trouble on Short 2742
Trouble on Night Open 2743
FOOTNOTES AND SYMBOLS FOR TABLES
A2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
BIf Fire Alarm Verification is selected, then Fire must also be
selected.
CWhen the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
DDisable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.

NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
NAPCO Security Group
Programming Instructions, Volume 2 Page 87
ZONE OPTIONS / ZONES 65-72 (ADDRESS 2802-2888)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 65 ► 72
Z65 Z66 Z67 Z68 Z69 Z70 Z71 Z72
12345678
Zone Area 1 (Fire) 2844
Zone Area 2 2845
Zone Area 3 2846
Zone Area 4 2847
Zone Area 5 2848
Zone Area 6 2849
Zone Area 7 2850
Zone Area 8 2851
Reserved 2852
Reserved 2853
Zone Anding Group 1 2854
Zone Anding Group 2 2855
Zone Anding Group 3 2856
Zone Anding Group 4 2857
Zone Anding Group 5 2858
Zone Anding Group 6 2859
Zone Anding Group 7 2860
Zone Anding Group 8 2861
Interior 1 Bypass 2862
Interior 2 Bypass 2863
Keypad Sounder on Alarm 2864
Ext Fire Output 1 2865
Ext Fire Output 2 2866
Ext Fire Output 3 2867
Ext Fire Output 4 2868
Ext Fire Output 5 2869
Ext Fire Output 6 2870
Ext Fire Output 7 2871
Ext Fire Output 8 2872
Reserved 2873
Reserved 2874
Carbon Monoxide 2875
Verification (Fire) 2876
Waterflow (Fire) 2877
Supervisory 2878
Monitor Zone 2879
NAC A 2880
NAC B 2881
NAC C 2882
NAC D 2883
Reserved 2884
Reserved 2885
Chime 2 2886
Delayed Trip 1 2887
Delayed Trip 2 2888
ZONE OPTIONS ADDR
ZONES 65 ► 72
Z65 Z66 Z67 Z68 Z69 Z70 Z71 Z72
12345678
Priority Zone 2802
Priority / Bypass 2803
AutoBypass 2804
Selective Bypass 2805
Keyswitch Arming 2806
AutoBypass Re-entry 2807
Pre-Alarm Warning 2808
Never Arm 2809
24-Hour Protection 2810
Burg Bell 2811
Pulse Burg Bell 2812
Burg PGM2 2813
Burg Relay 2814
Burg PGM1 2815
Exit/Entry #1 2816
Exit/Entry #2 2817
Exit/Entry Follower 2818
Auto Reset 2819
Swinger Shutdown 2820
Chime Zone 2821
Abort Delay 2822
Power-Up Delay 2823
Day Zone/Trouble Open 2824
Day Zone/Trouble Short 2825
Alarm on Day Zone/Trouble 2826
Report Alarm Tel1 2827
Rpt Alm Restore Tel1 2828
Report Trouble Tel1 2829
Rpt Tbl Restore Tel1 2830
Reserved 2831
Reserved 2832
Reserved 2833
Reserved 2834
Report Alarm Tel3 2835
Rpt Alm Restore Tel3 2836
Report Trouble Tel3 2837
Rpt Tbl Restore Tel3 2838
No EOL Resistor 2839
Sensor Watch 2840
Trouble on Open 2841
Trouble on Short 2842
Trouble on Night Open 2843
FOOTNOTES AND SYMBOLS FOR TABLES
A2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
BIf Fire Alarm Verification is selected, then Fire must also be
selected.
CWhen the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
DDisable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.

NAPCO Security Group
NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
Page 88 Programming Instructions, Volume 2
ZONE OPTIONS / ZONES 73-80 (ADDRESS 2902-2988)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 73 ► 80
Z73 Z74 Z75 Z76 Z77 Z78 Z79 Z80
12345678
Zone Area 1 (Fire) 2944
Zone Area 2 2945
Zone Area 3 2946
Zone Area 4 2947
Zone Area 5 2948
Zone Area 6 2949
Zone Area 7 2950
Zone Area 8 2951
Reserved 2952
Reserved 2953
Zone Anding Group 1 2954
Zone Anding Group 2 2955
Zone Anding Group 3 2956
Zone Anding Group 4 2957
Zone Anding Group 5 2958
Zone Anding Group 6 2959
Zone Anding Group 7 2960
Zone Anding Group 8 2961
Interior 1 Bypass 2962
Interior 2 Bypass 2963
Keypad Sounder on Alarm 2964
Ext Fire Output 1 2965
Ext Fire Output 2 2966
Ext Fire Output 3 2967
Ext Fire Output 4 2968
Ext Fire Output 5 2969
Ext Fire Output 6 2970
Ext Fire Output 7 2971
Ext Fire Output 8 2972
Reserved 2973
Reserved 2974
Carbon Monoxide 2975
Verification (Fire) 2976
Waterflow (Fire) 2977
Supervisory 2978
Monitor Zone 2979
NAC A 2980
NAC B 2981
NAC C 2982
NAC D 2983
Reserved 2984
Reserved 2985
Chime 2 2986
Delayed Trip 1 2987
Delayed Trip 2 2988
ZONE OPTIONS ADDR
ZONES 73 ► 80
Z73 Z74 Z75 Z76 Z77 Z78 Z79 Z80
12345678
Priority Zone 2902
Priority / Bypass 2903
AutoBypass 2904
Selective Bypass 2905
Keyswitch Arming 2906
AutoBypass Re-entry 2907
Pre-Alarm Warning 2908
Never Arm 2909
24-Hour Protection 2910
Burg Bell 2911
Pulse Burg Bell 2912
Burg PGM2 2913
Burg Relay 2914
Burg PGM1 2915
Exit/Entry #1 2916
Exit/Entry #2 2917
Exit/Entry Follower 2918
Auto Reset 2919
Swinger Shutdown 2920
Chime Zone 2921
Abort Delay 2922
Power-Up Delay 2923
Day Zone/Trouble Open 2924
Day Zone/Trouble Short 2925
Alarm on Day Zone/Trouble 2926
Report Alarm Tel1 2927
Rpt Alm Restore Tel1 2928
Report Trouble Tel1 2929
Rpt Tbl Restore Tel1 2930
Reserved 2931
Reserved 2932
Reserved 2933
Reserved 2934
Report Alarm Tel3 2935
Rpt Alm Restore Tel3 2936
Report Trouble Tel3 2937
Rpt Tbl Restore Tel3 2938
No EOL Resistor 2939
Sensor Watch 2940
Trouble on Open 2941
Trouble on Short 2942
Trouble on Night Open 2943
FOOTNOTES AND SYMBOLS FOR TABLES
A2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
BIf Fire Alarm Verification is selected, then Fire must also be
selected.
CWhen the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
DDisable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.
