CALIBRATION PROCEDURE
NI 5122/5124
Contents
Conventions ............................................................................................ 2
Introduction............................................................................................. 2
Self-Calibration ........................................................................ 3
External Calibration.................................................................. 3
Calibration Interval................................................................... 3
Software and Documentation Requirements........................................... 3
Software ........................................................................................... 3
Documentation................................................................................. 5
Self-Calibration Procedures .................................................................... 5
MAX ................................................................................................ 6
Scope SFP ........................................................................................ 6
NI-SCOPE ....................................................................................... 6
External Calibration Options .................................................................. 8
Complete Calibration....................................................................... 9
Optional Calibration ........................................................................ 10
External Calibration Requirements......................................................... 12
Test Equipment ................................................................................ 12
Test Conditions ................................................................................ 12
External Calibration Procedures ............................................................. 13
Verifying NI 5122/5124 Specifications........................................... 13
Vertical Offset and Vertical Gain Accuracy............................. 13
Programmable Vertical Offset Accuracy.................................. 20
Timing Accuracy ...................................................................... 22
Bandwidth and Flatness............................................................ 24
Trigger Sensitivity ........................................................................... 29
Adjusting the NI 5122/5124 ............................................................ 31
Calibration Utilities................................................................................. 33
MAX ................................................................................................ 33
NI-SCOPE ....................................................................................... 34
Calibration Function References............................................................. 34
Where to Go for Support......................................................................... 34

NI 5122/5124 Calibration Procedure 2 ni.com
Conventions
The following conventions are used in this manual:
»The »symbol leads you through nested menu items and dialog box options
to a final action. The sequence File»Page Setup»Options directs you to
pull down the File menu, select the Page Setup item, and select Options
from the last dialog box.
♦The ♦symbol indicates that the following text applies only to a specific
product, a specific operating system, or a specific software version.
This icon denotes a note, which alerts you to important information.
This icon denotes a caution, which advises you of precautions to take to
avoid injury, data loss, or a system crash. When this symbol is marked on a
product, refer to the Read Me First: Safety and Radio-Frequency
Interference document for information about precautions to take.
bold Bold text denotes items that you must select or click in the software, such
as menu items and dialog box options. Bold text also denotes parameter
names.
italic Italic text denotes variables, emphasis, a cross reference, or an introduction
to a key concept. This font also denotes text that is a placeholder for a word
or value that you must supply.
monospace Text in this font denotes text or characters that you should enter from the
keyboard, sections of code, programming examples, and syntax examples.
This font is also used for the proper names of disk drives, paths, directories,
programs, subprograms, subroutines, device names, functions, operations,
variables, filenames, and extensions.
monospace italic Italic text in this font denotes text that is a placeholder for a word or value
that you must supply.
Introduction
This document contains instructions for calibrating NI PXI/PCI-5122 and
NI PXI/PCI-5124 digitizers. This calibration procedure is intended for
metrology labs. This document describes specific programming steps for
writing an external calibration procedure for the NI 5122/5124.
The NI 5122/5124 supports two types of calibration: self-calibration (or
internal calibration) and external calibration.

©National Instruments Corporation 3 NI 5122/5124 Calibration Procedure
Self-Calibration
Self-calibration, also known as internal calibration, uses a software
command and requires no external connections. Self-calibration improves
measurement accuracy by compensating for variables such as temperature
that may have changed since the last external calibration. Self-calibration
retains the traceability of the external calibration.
External Calibration
External calibration is generally performed with a high-precision
oscilloscope calibrator at either NI or a metrology lab. This procedure
replaces all calibration constants in the EEPROM and is equivalent to a
factory calibration at NI. Because the external calibration procedure
changes all EEPROM constants, it invalidates the original calibration
certificate. If an external calibration is done with a traceable signal
generator source, a new calibration certificate can be issued.
Calibration Interval
Self-calibration can be performed as necessary to compensate for
environmental changes.
Caution Although you can use self-calibration repeatedly, self-calibrating the
NI 5122/5124 more than a few times a day may cause excessive wear on the relays over
time.
The measurement accuracy requirements of your application determine
how often you should externally calibrate the NI 5122/5124.
NI recommends that you perform a complete external calibration at least
once every two years. You can shorten this interval based on the accuracy
demands of your application. Refer to the External Calibration Options
section for more information.
Software and Documentation Requirements
This section describes the software and documentation required for both
self-calibration and external calibration.
Software
Calibrating the NI 5122/5124 requires installing NI-SCOPE version 2.7 or
later on the calibration system. You can download NI-SCOPE from the
Instrument Driver Network at ni.com/idnet. NI-SCOPE supports
programming the Self-Calibration Procedures in a number of
programming languages. However, only LabVIEW and C are supported
for the External Calibration Procedures.

NI 5122/5124 Calibration Procedure 4 ni.com
NI-SCOPE 2.7 or later includes all the functions and attributes necessary
for calibrating the NI 5122/5124. For LabWindows™/CVI™, the
NI-SCOPE function panel niScopeCal.fp provides further help on the
functions available in CVI. LabVIEW support is installed in
niScopeCal.llb, and all calibration functions appear in the function
palette. Refer to Table 1 for file locations.
Calibration functions are C function calls or LabVIEW VIs in the
NI-SCOPE driver. In this document, the C function call is shown first,
followed by the corresponding LabVIEW VI in parentheses. The C
function calls are valid for any compiler capable of calling a 32-bit DLL.
Many of the functions use constants defined in the niScopeCal.h file.
To use these constants in C, you must include niScopeCal.h in your code
when you write the calibration procedure.
For more information on the calibration functions and VIs, refer to the
NI-SCOPE Function Reference Help or the NI-SCOPE VI Reference Help.
These references can be found in the NI High-Speed Digitizers Help.
To access this help file, go to Start»Programs»National Instruments»
NI-SCOPE»Documentation»NI High-Speed Digitizers Help.
Table 1. Calibration File Locations after Installing NI-SCOPE 2.7 or Later
File Name and Location Description
IVI\Bin\niscope_32.dll NI-SCOPE driver containing the entire
NI-SCOPE API, including calibration functions
IVI\Lib\msc\niscope.lib NI-SCOPE library for Microsoft C containing
the entire NI-SCOPE API, including calibration
functions
LabVIEW ( version )\examples\instr\
niScope
Directory of LabVIEW NI-SCOPE example
VIs, including self-calibration; access the
calibration example from the LabVIEW
function palette
LabVIEW ( version )\instr.lib\niScope
Calibrate\niScopeCal.llb
LabVIEW VI library containing VIs for calling
the NI-SCOPE calibration API; access
calibration functions from the NI-SCOPE
calibration section of the LabVIEW function
palette
IVI\Drivers\niScope\niScopeCal.fp CVI function panel file that includes external
calibration function prototypes and help on
using NI-SCOPE in the CVI environment

©National Instruments Corporation 5 NI 5122/5124 Calibration Procedure
Documentation
You may find the following documentation helpful as you write your
calibration procedure:
• NI High-Speed Digitizers Getting Started Guide
• NI High-Speed Digitizers Help
•NI PXI/PCI-5122 Specifications or NI PXI/PCI-5124 Specifications
•NI-SCOPE Function Reference Help or NI-SCOPE VI Reference Help
These documents are installed with NI-SCOPE. You can also download the
latest versions from the NI Web site at ni.com/manuals.
Self-Calibration Procedures
The NI 5122/5124 includes precise internal circuits and references used
during self-calibration to adjust for time and temperature drift. The
digitizer gain, offset, flatness, and trigger timing are all corrected in
self-calibration. Measuring the accuracy of these internal calibration
circuits with another instrument during external calibration provides
traceability for the verification procedure. Absolute accuracy is ensured by
compensating for any error measured in the internal references.
Note Self-calibrate the digitizer before you perform verification. NI-SCOPE includes
self-calibration example programs for LabVIEW, CVI, and Microsoft Visual C.
You can initiate self-calibration using Measurement & Automation
Explorer (MAX), using the Scope Soft Front Panel (SFP), or
programmatically using NI-SCOPE.
IVI\Include\niScopeCal.h Calibration header file, which you must include
in any C program accessing calibration
functions. This file automatically includes
niScope.h, which defines the rest of the
NI-SCOPE interface
IVI\Drivers\niScope\Examples\ Directory of NI-SCOPE examples for CVI, C,
Visual C++, and Visual Basic
Table 1. Calibration File Locations after Installing NI-SCOPE 2.7 or Later (Continued)
File Name and Location Description

NI 5122/5124 Calibration Procedure 6 ni.com
MAX
To initiate self-calibration from MAX, complete the following steps:
1. Disconnect or disable any AC inputs to the digitizer.
2. Launch MAX.
3. Select My System»Devices and Interfaces»NI-DAQmx Devices.
4. Select the device that you want to calibrate.
5. Initiate self-calibration using one of the following methods:
•ClickSelf-Calibrate in the upper right corner of MAX.
• Right-click the name of the device in the MAX configuration tree
and select Self-Calibrate from the drop-down menu.
Scope SFP
To initiate self-calibration from the Scope SFP, complete the following
steps:
1. Disconnect or disable any AC inputs to the digitizer.
2. Launch the Scope SFP (Start»Programs»National Instruments»
NI-SCOPE»Scope Soft Front Panel).
3. Select the device you want to calibrate using the Device Configuration
dialog box (Edit»Device Configuration).
4. Launch the Calibration dialog box (Utility»Self Calibration).
5. Click OK to begin self-calibration.
NI-SCOPE
To self-calibrate the NI 5122/5124 programmatically using NI-SCOPE,
complete the following steps:
1. Disconnect or disable any AC inputs to the digitizer.
2. Call niScope_init (niScope Initialize VI) to obtain an instrument
session handle. Set the following parameters:
•resourceName: The device name assigned by MAX
•IDQuery: NISCOPE_VAL_VI_FALSE
•resetDevice: NISCOPE_VAL_VI_FALSE
•vi: The returned session handle that you use to identify the
instrument in all subsequent instrument driver function calls
3. Call niScope_calSelfCalibrate (niScope Cal Self Calibrate VI)
with the following parameters:
•sessionHandle: The instrument handle that you obtain from
niScope_init (niScope Initialize VI)

©National Instruments Corporation 7 NI 5122/5124 Calibration Procedure
•channelList: VI_NULL
•option: VI_NULL
Because the session is a standard session rather than an external
calibration session, the new calibration constants are immediately
stored in the EEPROM. Therefore, you can include this procedure in
any application that uses the digitizer.
4. Call niScope_close (niScope Close VI) to close the session handle.
Set the following parameter:
•vi: The instrument handle you obtained from niScope_init

NI 5122/5124 Calibration Procedure 8 ni.com
External Calibration Options
External calibration involves both adjustment and verification. Adjustment
is the process of measuring and compensating for device performance to
improve the measurement accuracy. Performing an adjustment updates the
calibration date, effectively resetting the calibration interval. The device is
guaranteed to meet or exceed its published specifications for the duration
of the calibration interval. Verification is the process of testing the device
to ensure that the measurement accuracy is within certain specifications.
Verification can be used to ensure that the adjustment process was
successful, or to determine if the adjustment process needs to be performed
at all. During verification, you must compare the measurement error to
limits given in Tables 3 through 12.
This document provides two sets of test limits for most verification
stages—the calibration test limits and the published specifications. The
calibration test limits are more restrictive than the published specifications.
If all of the measurement errors determined during verification fall within
the calibration test limits, the device is guaranteed to meet or exceed its
published specifications for a full calibration interval (two years). For this
reason, you must verify against the calibration test limits when performing
verification after adjustment. If all of the measurement errors determined
during verification fall within the published specifications, but not within
the calibration test limits, the device is meeting its published specifications.
However, the device will not necessarily remain within these specifications
for an additional two years. The device will meet published specifications
for the remainder of the current calibration interval. In this case, you can
perform an adjustment if you want to further improve the measurement
accuracy or reset the calibration interval. If some measurement errors
determined during verification do not fall within the published
specifications, you must perform an adjustment to restore the device
operation to its published specifications.
The Complete Calibration section describes the recommended calibration
procedure. The Optional Calibration section describes alternative
procedures that allow you to skip adjustment if the device already meets its
calibration test limits or published specifications.

©National Instruments Corporation 9 NI 5122/5124 Calibration Procedure
Complete Calibration
Performing a complete calibration is the recommended way to guarantee
that the NI 5122/5124 will meet or exceed its published specifications for
a two-year calibration interval. At the end of the complete calibration
procedure, you verify that the measurement error falls within the
calibration test limits. Figure 1 shows the programming flow for complete
calibration.
Figure 1. Complete Calibration Programming Flow
Adjust (Cal Dates and
Temperatures Updated)
Document
Post-Adjustment
Results
Document
Pre-Adjustment
Results
Calibration/
Verification
Complete
Ye s N o
Self-Calibrate
Verify
Verify
Meets
Calibration
Test Limits?
Review Verification/
Adjustment Procedure
or Return Device

NI 5122/5124 Calibration Procedure 10 ni.com
Optional Calibration
You can choose to skip the adjustment steps of the calibration procedure if
the measurement error is within the calibration test limits or the published
specifications during the first verification. If all of the measurement errors
determined during the first verification fall within the calibration test
limits, the device is guaranteed to meet or exceed its published
specifications for a full calibration interval. In this case, you can update the
calibration date, effectively resetting the calibration interval, without
actually performing an adjustment. Refer to the Adjusting the NI 5122/5124
section for more information.
If all of the measurement errors determined during the first verification fall
within the published specifications, but not within the calibration test
limits, adjustment is also optional. However, you cannot update the
calibration date, because the device will not necessarily operate within the
published specifications for an additional two years.
Note Regardless of the results of the first verification, if you choose to perform an
adjustment, you must verify that the measurement error falls within the calibration test
limits at the end of the calibration procedure.
Figure 2 shows the programming flow for the optional calibration.

©National Instruments Corporation 11 NI 5122/5124 Calibration Procedure
Figure 2. Optional Calibration Programming Flow
Self-Calibrate
Verify
Meets
Calibration
Test Limits?
Ye s N o
Meets
Published
Specifications?
Ye s
Results
Within
Published Specs
(Adjustment
Optional)
Update Calibration
Dates and Temperatures
Without Adjusting
No
Adjust (Cal Dates and
Temperatures Updated)
Adjust
Anyway?
No
Calibration/
Verification
Complete
Ye s
Verify
Document
Post-Adjustment
Results
Document
Pre-Adjustment
Results
Meets
Calibration
Test Limits?
Review Verification/
Adjustment Procedure
or Return Device
NoYe s

NI 5122/5124 Calibration Procedure 12 ni.com
External Calibration Requirements
Test Equipment
Table 2 lists the equipment required for externally calibrating the
NI 5122/5124. If you do not have the recommended instruments, use these
specifications to select a substitute calibration standard.
Note The delay times indicated in this procedure apply specifically to the Fluke 9500B
calibrator. If you use a different calibrator, you may need to adjust these delay times.
Test Conditions
Follow these guidelines to optimize the connections and the environment
during calibration:
• Always connect the calibrator test head directly to the input BNC of
the digitizer, or use a short 50 ΩBNC coaxial cable if necessary. Long
cables and wires act as antennae, picking up extra noise that can affect
measurements.
• Keep relative humidity between 10 and 90% non-condensing, or
consult the digitizer hardware documentation for the optimum relative
humidity.
• Maintain an ambient temperature of 23 ±5 °C.
• Allow a warm-up time of at least 15 minutes after the NI-SCOPE
driver is loaded. Unless manually disabled, the NI-SCOPE driver
automatically loads with the operating system and enables the device.
The warm-up time ensures that the measurement circuitry of the
NI 5122/5124 is at a stable operating temperature.
Table 2. Required Equipment Specifications for NI 5122/5124 External Calibration
Required
Equipment
Recommended
Equipment
Parameter
Measured Specification
Signal Generator Fluke 9500B
oscilloscope
calibrator
(Wavetek 9500
with high-stability
reference option)
9510 Test Head
Vertical Gain DC ±(0.025% + 25 µV) into 1 MΩ
or 50 Ω
Bandwidth ±1.5% output amplitude flatness
for leveled sine wave up to
100 MHz relative to 50 kHz into
1MΩor 50 Ω
Timing 2 ppm frequency accuracy
BNC cable — — 50 Ω

©National Instruments Corporation 13 NI 5122/5124 Calibration Procedure
♦For PXI digitizers:
• Ensure that the PXI chassis fan speed is set to HI, that the fan filters are
clean, and that the empty slots contain filler panels.
• Plug the PXI chassis and the calibrator into the same power strip to
avoid ground loops.
♦For PCI digitizers:
• Plug the PC and the calibrator into the same power strip to avoid
ground loops.
External Calibration Procedures
The complete external calibration procedure consists of self-calibrating,
verifying the performance of the digitizer, adjusting the calibration
constants, and verifying again after the adjustments. In some cases, the
complete calibration procedure may not be required. Refer to the External
Calibration Options section for more information.
The external calibration procedure automatically stores the calibration date
to allow traceability.
Verifying NI 5122/5124 Specifications
Note Always self-calibrate the NI 5122/5124 before beginning a verification procedure.
This section describes the program you must write to verify either the
calibration test limits or the published specifications for the NI 5122/5124.
Refer to the External Calibration Options section to determine which limits
to use in these procedures.
All verification procedures described in this section begin with
niScope_init (niScope Initialize VI) with resetDevice set to
NISCOPE_VAL_TRUE, and end with niScope_close (niScope Close VI).
Note If any of these tests fail immediately after you perform an external adjustment, verify
that you have met the required test conditions listed in the External Calibration
Requirements section before you return the digitizer to NI for repair.
Vertical Offset and Vertical Gain Accuracy
Table 3 contains the input parameters for verifying both vertical offset
accuracy and vertical gain accuracy of the NI 5122/5124.
To verify vertical offset accuracy, complete the procedures described in the
Vertical Offset Accuracy section for each of the 39 iterations listed in

NI 5122/5124 Calibration Procedure 14 ni.com
Table 3 for channel 0, then repeat the procedures for channel 1. The
Calibration Test Limits and Published Specifications for vertical accuracy
are shown in Table 4 (NI 5122) and Table 5 (NI 5124).
To verify vertical gain accuracy, complete the procedures described in the
Vertical Gain Accuracy section for each of the 39 iterations listed in
Table 3 for channel 0, then repeat the procedures for channel 1. The
Calibration Test Limits and Published Specifications for vertical gain are
shown in Table 6 (NI 5122) and Table 7 (NI 5124).
Table 3. NI 5122/5124 Input Parameters for Vertical Offset Accuracy
and Vertical Gain Accuracy Verification
Iteration
Input
Impedance
Max Input Frequency (Hz)
RangeNI 5122 NI 5124
150 Ω100,000,000 150,000,000 0.2
250 Ω100,000,000 150,000,000 0.4
350 Ω100,000,000 150,000,000 1
450 Ω100,000,000 150,000,000 2
550 Ω100,000,000 150,000,000 4
650 Ω100,000,000 150,000,000 10
750 Ω35,000,000 60,000,000 0.2
850 Ω35,000,000 60,000,000 0.4
950 Ω35,000,000 60,000,000 1
10 50 Ω35,000,000 60,000,000 2
11 50 Ω35,000,000 60,000,000 4
12 50 Ω35,000,000 60,000,000 10
13 50 Ω20,000,000 20,000,000 0.2
14 50 Ω20,000,000 20,000,000 0.4
15 50 Ω20,000,000 20,000,000 1
16 50 Ω20,000,000 20,000,000 2
17 50 Ω20,000,000 20,000,000 4
18 50 Ω20,000,000 20,000,000 10
19 1MΩ100,000,000 150,000,000 0.2
20 1MΩ100,000,000 150,000,000 0.4

©National Instruments Corporation 15 NI 5122/5124 Calibration Procedure
Vertical Offset Accuracy
To verify vertical offset accuracy, complete steps 1 through 8 for each of
the 39 configuration iterations listed in Table 3.
1. Call niScope_ConfigureChanCharacteristics
(niScope Configure Chan Characteristics VI) with the following
parameters:
•channelList: "0"
21 1MΩ100,000,000 150,000,000 1
22 1MΩ100,000,000 150,000,000 2
23 1MΩ100,000,000 150,000,000 4
24 1MΩ100,000,000 150,000,000 10
25 1MΩ100,000,000 150,000,000 20
26 1MΩ35,000,000 60,000,000 0.2
27 1MΩ35,000,000 60,000,000 0.4
28 1MΩ35,000,000 60,000,000 1
29 1MΩ35,000,000 60,000,000 2
30 1MΩ35,000,000 60,000,000 4
31 1MΩ35,000,000 60,000,000 10
32 1MΩ35,000,000 60,000,000 20
33 1MΩ20,000,000 20,000,000 0.2
34 1MΩ20,000,000 20,000,000 0.4
35 1MΩ20,000,000 20,000,000 1
36 1MΩ20,000,000 20,000,000 2
37 1MΩ20,000,000 20,000,000 4
38 1MΩ20,000,000 20,000,000 10
39 1MΩ20,000,000 20,000,000 20
Table 3. NI 5122/5124 Input Parameters for Vertical Offset Accuracy
and Vertical Gain Accuracy Verification (Continued)
Iteration
Input
Impedance
Max Input Frequency (Hz)
RangeNI 5122 NI 5124

NI 5122/5124 Calibration Procedure 16 ni.com
•inputImpedance: The Input Impedance value for the current
iteration from Table 3
•maxInputFrequency: The Maximum Input Frequency value for
the current iteration from Table 3
2. Call niScope_ConfigureVertical (niScope Configure
Vertical VI) with the following parameters:
•channelList: "0"
•range: The Range value for the current iteration from Table 3
•offset: 0.0
•coupling: NISCOPE_VAL_DC
•probeAttenuation: 1.0
•enabled: NISCOPE_VAL_TRUE
3. Call niScope_ConfigureHorizontalTiming (niScope Configure
Horizontal Timing VI) with the following parameters:
•minSampleRate: 10,000,000
•minNumPts: 100,000
•refPosition: 50.0
•numRecords: 1
•enforceRealtime: NISCOPE_VAL_TRUE
4. Call niScope_Commit (niScope Commit VI) with the following
parameter:
•vi: The instrument handle you obtained from niScope_init
5. Short-circuit the channel 0 input of the digitizer by connecting the
calibrator test head directly to the digitizer and grounding the output of
the calibrator.
6. Wait 500 ms for the impedance matching of the calibrator to settle.
7. Call niScope_InitiateAcquisition. (niScope Initiate
Acquisition VI) with the following parameter:
•vi: The instrument handle you obtained from niScope_init
8. Call niScope_FetchMeasurement (niScope Fetch
Measurement VI) with the following parameters:
•channelList: "0"
•timeout: 1.0
•scalarMeasFunction: NISCOPE_VAL_VOLTAGE_AVERAGE
Compare the resulting average voltage to the value listed in the
Calibration Test Limits column or the Published Specifications column
in Table 4 (NI 5122) or Table 5 (NI 5124) that corresponds to the
vertical range used. The inputImpedance and maxInputFrequency

©National Instruments Corporation 17 NI 5122/5124 Calibration Procedure
do not affect the test limit value. If the result is within the selected test
limit, the device has passed this portion of the verification.
Note 50 Ωinput impedance with 20 V range is not a valid configuration.
9. Move the calibrator test head to the digitizer input channel 1 and repeat
steps 1 through 8 for every configuration in Table 4 (NI 5122) or
Table 5 (NI 5124), replacing "0" with "1" for the channelList
parameter.
You have finished verifying the vertical offset accuracy of the
NI 5122/5124.
Table 4. NI 5122 Vertical Offset Calibration Test Limits and Published Specifications
Range
NI PXI-5122 NI PCI-5122
Calibration Test
Limits (V)
Published
Specifications (V)
Calibration Test
Limits (V)
Published
Specifications (V)
0.2 ±0.00057 ±0.001 ±0.00114 ±0.002
0.4 ±0.00057 ±0.001 ±0.00114 ±0.002
1±0.00057 ±0.001 ±0.00114 ±0.002
2±0.00057 ±0.001 ±0.00114 ±0.002
4±0.0033 ±0.008 ±0.0033 ±0.008
10 ±0.0033 ±0.008 ±0.0033 ±0.008
20 ±0.0039 ±0.01 ±0.0039 ±0.01
Table 5. NI 5124 Vertical Offset Calibration Test Limits and Published Specifications
Range
NI PXI-5124 NI PCI-5124
Calibration Test
Limits (V)
Published
Specifications (V)
Calibration Test
Limits (V)
Published
Specifications (V)
0.2 ±0.00080 ±0.0013 ±0.0013 ±0.0018
0.4 ±0.00080 ±0.0013 ±0.0013 ±0.0018
1±0.00110 ±0.0015 ±0.0016 ±0.0021
2±0.00110 ±0.0015 ±0.0016 ±0.0021
4±0.00575 ±0.010 ±0.005 ±0.010
10 ±0.00575 ±0.010 ±0.005 ±0.010
20 ±0.00575 ±0.01 ±0.005 ±0.010

NI 5122/5124 Calibration Procedure 18 ni.com
Vertical Gain Accuracy
To verify vertical gain accuracy, complete steps 1 through 11 for each of
the 39 configuration iterations in Table 3.
1. Call niScope_ConfigureChanCharacteristics (niScope
Configure Chan Characteristics VI) with the following parameters:
•channelList: "0"
•inputImpedance: The Input Impedance value for the current
iteration from Table 3
•maxInputFrequency: The Maximum Input Frequency value for
the current iteration from Table 3
2. Call niScope_ConfigureVertical (niScope Configure
Vertical VI) with the following parameters:
•channelList: "0"
•range: The Range value for the current iteration from Table 3
•offset: 0.0
•coupling: NISCOPE_VAL_DC
•probeAttenuation: 1.0
•enabled: NISCOPE_VAL_TRUE
3. Call niScope_ConfigureHorizontalTiming (niScope Configure
Horizontal Timing VI) with the following parameters:
•minSampleRate: 10,000,000
•minNumPts: 100,000
•refPosition: 50.0
•numRecords: 1
•enforceRealtime: NISCOPE_VAL_TRUE
4. Call niScope_Commit (niScope Commit VI) with the following
parameter:
•vi: The instrument handle you obtained from niScope_init
5. Connect the calibrator test head directly to the channel 0 input of the
digitizer and output the positive voltage from Table 6 (NI 5122) or
Table 7 (NI 5124) that corresponds to the vertical range used. Be sure
to configure the load impedance of the calibrator to match the input
impedance of the digitizer.
6. Wait 2,500 ms for the impedance matching of the calibrator to settle.
7. Call niScope_InitiateAcquisition (niScope Initiate
Acquisition VI) with the following parameter:
•vi: The instrument handle you obtained from niScope_init

©National Instruments Corporation 19 NI 5122/5124 Calibration Procedure
8. Call niScope_FetchMeasurement (niScope Fetch
Measurement VI) with the following parameters:
•channelList: "0"
•timeout: 1.0
•scalarMeasFunction: NISCOPE_VAL_VOLTAGE_AVERAGE
9. Output the negative voltage listed in Table 6 (NI 5122) or Table 7
(NI 5124) with the calibrator.
10. Wait 750 ms for the output of the calibrator to settle.
11. Call niScope_FetchMeasurement (niScope Fetch
Measurement VI) with the following parameters:
•channelList: "0"
•timeout: 1.0
•scalarMeasFunction: NISCOPE_VAL_VOLTAGE_AVERAGE
12. Compute the error in the vertical gain as a percentage of input using
the formula:
error = (((a– b) / (c– d)) – 1) * 100
where ais the measured positive voltage, bis the measured negative
voltage, cis the applied positive voltage, and dis the applied negative
voltage.
Compare the resulting percent error to the Calibration Test Limits or
the Published Specifications listed in Table 6 (NI 5122) or Table 7
(NI 5124). If the result is within the selected test limit, the device has
passed this portion of the verification.
Table 6. NI 5122 Vertical Gain Stimuli, Calibration Test Limits,
and Published Specifications
Range
(V)
Positive
Input (V)
Negative
Input (V)
Calibration
Test Limits
Published
Specifications
0.2 0.09 –0.09 ±0.37% ±0.65%
0.4 0.18 –0.18 ±0.37% ±0.65%
10.45 –0.45 ±0.37% ±0.65%
20.9 –0.9 ±0.37% ±0.65%
41.8 –1.8 ±0.37% ±0.65%
10 4.5 –4.5 ±0.37% ±0.65%
20 9–9 ±0.37% ±0.65%

NI 5122/5124 Calibration Procedure 20 ni.com
13. Move the calibrator test head to the digitizer input channel 1 and repeat
steps 1 through 12 for every configuration in Table 3, replacing "0"
with "1" for the channelList parameter.
You have finished verifying the vertical gain accuracy of the NI 5122/5124.
Programmable Vertical Offset Accuracy
Complete the following steps to verify the programmable vertical offset
accuracy for each digitizer channel.
1. Call niScope_ConfigureChanCharacteristics (niScope
Configure Chan Characteristics VI) with the following parameters:
•channelList: "0"
•inputImpedance: NISCOPE_VAL_50_OHM
•maxInputFrequency: 100,000,000 (for NI 5122),
150,000 (for NI 5124)
2. Call niScope_ConfigureVertical (niScope Configure
Vertical VI) with the following parameters:
•channelList: "0"
•range: 2.0
•offset: 0.75
•coupling: NISCOPE_VAL_DC
•probeAttenuation: 1.0
•enabled: NISCOPE_VAL_TRUE
Table 7. NI 5124 Vertical Gain Stimuli, Calibration Test Limits,
and Published Specifications
Range
(V)
Positive
Input (V)
Negative
Input (V)
Calibration
Test Limits
Published
Specifications
0.2 0.09 –0.09 ±0.3975% ±0.65%
0.4 0.18 –0.18 ±0.3975% ±0.65%
10.45 –0.45 ±0.3975% ±0.65%
20.9 –0.9 ±0.3975% ±0.65%
41.8 –1.8 ±0.3975% ±0.65%
10 4.5 –4.5 ±0.3975% ±0.65%
20 9–9 ±0.3975% ±0.65%
