Nautilus NT 1810 User manual

TM
NT-1810
Smith Attachment
Revision B

TM 1
NT-1810
Part #
Smith Guide Rod
Smith Guide Rod Holder
Left Smith Slider Assembly
Right Smith Slider Assembly
Smith Bar
Smith Catch Assembly
Bronze Bushing
Rubber Bumper
International Smith Adapter
Hardware And Tools
Button Head Cap Screw - 3/8" x .5"L
Set Screw - 3/8" x .625"L (Pre-Installed)
Set Screw - 5/16" x .5"L (Pre-Installed)
Set Screw - 5/16" x .25"L ????
3/8" Washer
3/16" Allen Wrench
2
2
1
1
1
1
2
2
2
15868
15872
15875
15876
15874
15873
15075
15470
15877
15021
15937
15938
15936
15545
17133
Complete Components List
2
8
1
9
5
7
6
4
1
2
3
4
5
6
7
8
9
9
10
11
12
13
14
4
4
4
2
4
1
3

TM 2
NT-1810
Hardware Size Chart
#9
Qty: 4 #13
Qty: 4
Required Tools:
3/16" (Included with Smith), and 5/32" Allen Wrench (Included with Cage)
A. Compare the Bill of Materials to the box contents to insure that all parts are
 present before installation begins. NOTE: Some hardware may be pre-
 installed.
B. Unpackage parts and place them near the final assembled location to avoid
 moving the gym when fully assembled.
1/2" L

1Smith Guide Rod
Smith Guide Rod Holder
Left Smith Slider Assembly
Right Smith Slider Assembly
Cap Head Screw - 3/8" x .5"L
Set Screw - 5/16" x .5"L
Set Screw - 5/16" x .25"L
3/8" Washer
2
2
1
1
4
2
2
4
2
3
4
9
11
12
13
A. Slide the LEFT SMITH SLIDER ASSEMBLY (3) onto a SMITH
GUIDE ROD (1) in the orientation shown. Place the SMITH
GUIDE ROD (1) in the Left Lower Guide Rod Holder (A).
B. Place a SMITH GUIDE ROD HOLDER (2) on top of the
SMITH GUIDE ROD (1) with the hole for the set screw in the
SMITH GUIDE ROD HOLDER (2) to the rear of the machine.
Attach the SMITH GUIDE ROD HOLDER (2) to the cage
using the hardware shown, and loosley tighten.
TM 3
step
1
Step #1 Materials:
#Description Qty.
NT-1810
D. Repeat Steps A - C for the remaining SMITH GUIDE ROD (1)
and the RIGHT SMITH SLIDER ASSEMBLY (4).
11
2
3
13
9
1
A
A
12
4
C. If there is not a SET SCREW (12) already pre-installed in the
Left Lower Guide Rod Holder (A), loosely thread one in place

4
5
6
10
Smith Bar
Smith Catch Assembly
Bronze Bushing
Set Screw - 3/8" x .625"L
(Set Screws are Pre-Assembled)
1
1
2
4
A. Ensure that the SMITH SLIDER ASSEMBLIES (A) are
both positioned above the saftey spotters on the cage for the
following steps.
B. With the assistance of a helper, sandwich a BRONZE
BUSHING (6), the SMITH CATCH ASSEMBLY (5), and
another BRONZE BUSHING (6), between the 2-SMITH
SLIDER ASSEMBLIES (A). Ensure that when the
SMITH CATCH ASSEMBLY (5) is positioned that the Tab (B)
on the SMITH CATCH ASSEMBLY (5) is positioned above the
TAB (C) on the Smith Slider Assembly. Slide the SMITH BAR
(4) through all of the above mentioned parts, stopping when
the SMITH BAR (4) is centered in the cage.
C. Tighten the pre-installed SET SCREWS (10) into each of the
SMITH SLIDER ASSEMBLIES (A).
TM 4
step
2
Step #2 Materials:
#Description Qty.
NT-1810
C
B
Detail Step B
10
A
5
6
4
A

A. Slide the entire Smith Bar Assembly (A) to the top of the cage,
and engage the safety hooks into the cage, so that it is in the
racked position.
B. Thoroughly tighten the Set Screws (D) in the 2-Guide Rod
Holders (B). Also tighten the 4-Button Head Cap Screws (C)
that hold the 2-Guide Rod Holders (B) in place.
C. Disengage the Smith Bar Assembly (A), and lower it to the
lowest possible resting position. Thoroughly tighten the Set
Screws (F) into each of the two Lower Guide Rod Holders (E)
on the cage, and tighten the 2-SET SCREWS (F).
TM 5
step
3
NT-1810
B
C
D
E
F
A
Step B
Step C

6
step
4
