NEC 78K0R - Save It! User manual

User’s Manual
78K0R - Save It!
Demonstration Kit
Document No. U19663EE1V0UM00
Date Published January 2009
©NEC Electronics (Europe) GmbH

78K0R – Save It!
•The information in this document is current as of June, 2008. The information is subject to change
without notice. For actual design-in, refer to the latest publications of NEC Electronics data
sheets or data books, etc., for the most up-to-date specifications of NEC Electronics products.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
•No part of this document may be copied or reproduced in any form or by any means without the prior
written consent of NEC Electronics. NEC Electronics assumes no responsibility for any errors that may
appear in this document.
•NEC Electronics does not assume any liability for infringement of patents, copyrights or other intellectual
property rights of third parties by or arising from the use of NEC Electronics products listed in this
document or any other liability arising from the use of such products. No license, express, implied or
otherwise, is granted under any patents, copyrights or other intellectual property rights of NEC Electronics
or others.
•Descriptions of circuits, software and other related information in this document are provided for
illustrative purposes in semiconductor product operation and application examples. The incorporation of
these circuits, software and information in the design of a customer's equipment shall be done under the
full responsibility of the customer. NEC Electronics assumes no responsibility for any losses incurred by
customers or third parties arising from the use of these circuits, software and information.
•While NEC Electronics endeavors to enhance the quality, reliability and safety of NEC Electronics
products, customers agree and acknowledge that the possibility of defects thereof cannot be eliminated
entirely. To minimize risks of damage to property or injury (including death) to persons arising from
defects in NEC Electronics products, customers must incorporate sufficient safety measures in their
design, such as redundancy, fire-containment and anti-failure features.
•NEC Electronics products are classified into the following three quality grades: "Standard", "Special" and
"Specific".
The "Specific" quality grade applies only to NEC Electronics products developed based on a customer-
designated "quality assurance program" for a specific application. The recommended applications of an
NEC Electronics product depend on its quality grade, as indicated below. Customers must check the
quality grade of each NEC Electronics product before using it in a particular application.
"Standard": Computers, office equipment, communications equipment, test and measurement
equipment, audio and visual equipment, home electronic appliances, machine tools,
personal electronic equipment and industrial robots.
"Special": Transportation equipment (automobiles, trains, ships, etc.), traffic control systems,
anti-disaster systems, anti-crime systems, safety equipment and medical equipment
(not specifically designed for life support).
"Specific": Aircraft, aerospace equipment, submersible repeaters, nuclear reactor control
systems, life support systems and medical equipment for life support, etc.
The quality grade of NEC Electronics products is "Standard" unless otherwise expressly specified in NEC
Electronics data sheets or data books, etc. If customers wish to use NEC Electronics products in applications
not intended by NEC Electronics, they must contact an NEC Electronics sales representative in advance to
determine NEC Electronics' willingness to support a given application.
(Note)
(1) "NEC Electronics" as used in this statement means NEC Electronics Corporation and also includes its
majority-owned subsidiaries.
(2) "NEC Electronics products" means any product developed or manufactured by or for NEC Electronics (as
defined above).
M8E 02. 11-1
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
2

78K0R – Save It!
For customers in the European Union only
Redemption of Waste Electrical and Electronic Equipment
(WEEE) in accordance with legal regulations applicable in the
European Union only: This equipment (including all
accessories) is not intended for household use. After use the
equipment cannot be disposed of as household waste. NEC
Electronics (Europe) GmbH offers to take back the equipment.
All you need to do is register at http://www.eu.necel.com/weee
CAUTION
This is a Test- and Measurement equipment with possibility to be significantly
altered by user through hardware enhancements/modifications and/or test or
application software. Thus, with respect to Council Directive 89/336/EEC
(Directive on compliance with the EMC protection requirements), this equipment
has no autonomous function. Consequently this equipment is not marked by the
CE-symbol.
EEDT-ST-005-10
CAUTION
This equipment should be handled like a CMOS semiconductor device. The
user must take all precautions to avoid build-up of static electricity while
working with this equipment. All test and measurement tool including the
workbench must be grounded. The user/operator must be grounded using
the wrist strap. The connectors and/or device pins should not be touched
with bare hands.
EEDT-ST-004-10
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
3

78K0R – Save It!
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
4
Regional Information
Some information contained in this document may vary from country to country. Before using any NEC
product in your application, please contact the NEC office in your country to obtain a list of authorized
representatives and distributors. They will verify:
•Device availability
•Ordering information
•Product release schedule
•Availability of related technical literature
•Development environment specifications (for example, specifications for
third-party tools and components, host computers, power plugs, AC supply
voltages, and so forth)
•Network requirements
In addition, trademarks, registered trademarks, export restrictions, and other legal issues may also vary from
country to country.
NEC Electronics Inc. (U.S.)
Santa Clara, California
Tel: [phone]
800-366-9782
Fax: [phone]
800-729-9288
NEC Electronics Hong Kong Ltd.
Hong Kong
Tel: [phone]
Fax: [phone]
NEC Electronics (Europe) GmbH
Duesseldorf, Germany
Tel: [phone]
Fax: [phone]
NEC Electronics Hong Kong Ltd.
Seoul Branch
Seoul, Korea
Tel: [phone]
Fax: [phone]
Sucursal en España
Madrid, Spain
Tel: [phone]
Fax: [phone]
NEC Electronics Singapore Pte. Ltd.
Singapore
Tel: [phone]
Fax: [phone]
Succursale Française
Vélizy-Villacoublay, France
Tel: [phone]
Fax: [phone]
NEC Electronics Taiwan Ltd.
Taipei, Taiwan
Tel: [phone]
Fax: [phone]
Filiale Italiana
Milano, Italy
Tel: [phone]
Fax: [phone]
NEC do Brasil S.A.
Electron Devices Division
Guarulhos, Brasil
Tel: [phone]
Fax: [phone]
Branch The Netherlands
Eindhoven, The Netherlands
Tel: [phone]
Fax: [phone]
Branch Sweden
Taeby, Sweden
Tel: [phone]
Fax: [phone]
United Kingdom Branch
Milton Keynes, UK
Tel: [phone]
Fax: [phone]

78K0R – Save It!
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
5
Revision History
Date Revision Chapter Description
2009-03-16 V1.00 --- First release

78K0R – Save It!
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
6
Table of Contents
1. Introduction............................................................................................................................ 10
1.1 Package contents................................................................................................................................. 10
1.2 Features ................................................................................................................................................ 10
1.3 System requirements........................................................................................................................... 11
1.4 Trademarks........................................................................................................................................... 11
2. 78K0R – Save It! Components.............................................................................................. 12
2.1 Operation mode settings..................................................................................................................... 12
2.2 SW1........................................................................................................................................................ 12
2.3 SW2........................................................................................................................................................ 13
2.4 SW3........................................................................................................................................................ 13
2.5 SW4 (Reset switch).............................................................................................................................. 13
2.6 SW5 (INTP0).......................................................................................................................................... 13
2.7 SW6 (INTP2).......................................................................................................................................... 13
2.8 JP1......................................................................................................................................................... 14
2.9 JP2......................................................................................................................................................... 14
2.10 Q4 (illuminance sensor) .................................................................................................................... 14
2.11 U10, U12 (7 segment LED)................................................................................................................. 14
2.12 LED1 (power LED).............................................................................................................................. 15
2.13 Universal area..................................................................................................................................... 15
2.13.1 Minicube2 connector ......................................................................................................................... 15
3. 78K0R – Save It! system configuration................................................................................ 17
3.1 78K0R – Save It! ................................................................................................................................... 17
3.2 Host computer...................................................................................................................................... 17
3.3 Power supply via USB interface......................................................................................................... 17
4. 78K0R – Save It! installation and operation ........................................................................ 18
4.1 Getting started...................................................................................................................................... 18
4.2 CD-ROM contents ................................................................................................................................ 18
5. Hardware installation............................................................................................................. 19
6. Software installation.............................................................................................................. 20
6.1 TK-78K0RKE3L demonstration program installation....................................................................... 20
6.2 IAR Systems Embedded Workbench for 78K installation ............................................................... 21
6.3 IAR Systems visualSTATE Installation.............................................................................................. 22
6.4 Device file package of 78K0R/Kx3-L for IAR Embedded Workbench installation......................... 22
6.5 WriteEZ4 installation............................................................................................................................ 22
6.6 USB Driver Installation ........................................................................................................................ 22
6.6.1 Installation on Windows 2000 ............................................................................................................. 22
6.6.2 Installation on Windows XP................................................................................................................. 26
6.7 Confirmation of USB Driver Installation............................................................................................ 29

78K0R – Save It!
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
7
7. Demo application using the TK-78K0R/KE3L demonstration program............................ 30
8. Applilet EZ PL......................................................................................................................... 31
8.1 Overview ............................................................................................................................................... 31
8.2 Features ................................................................................................................................................ 31
8.3 Applilet EZ PL demo application........................................................................................................ 32
9. Flash Programmer WriteEZ4................................................................................................. 33
9.1 Device Setup......................................................................................................................................... 33
9.2 Using WriteEZ4..................................................................................................................................... 34
10. Erasing the flash memory (using the WriteEZ4)............................................................... 35
11. IAR Embedded Workbench 78K0R – Save It! sample project ......................................... 36
11.1 Hardware setup.................................................................................................................................. 36
11.2 Loading the Save It! sample project ................................................................................................ 36
11.3 Running the application.................................................................................................................... 41
11.3.1 Count mode....................................................................................................................................... 41
11.3.2 Blink mode......................................................................................................................................... 42
11.3.3 Spinning mode .................................................................................................................................. 42
12. IAR visualSTATE 78K0R – Save It! sample project .......................................................... 43
12.1 Hardware setup.................................................................................................................................. 43
12.2 Functionality of the sample project ................................................................................................. 43
12.3 Running the sample project.............................................................................................................. 44
12.4 Debug the 78K0R – Save It! visualSTATE sample project............................................................. 46
13. Cables................................................................................................................................... 47
13.1 USB interface cable (Mini-B type) .................................................................................................... 47
14. Schematics........................................................................................................................... 48

78K0R – Save It!
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
8
List of Figures
Figure 1: 78K0R – Save It! components .....................................................................................................12
Figure 2: 78K0R – Save It! 7 segment LEDs structure ...............................................................................15
Figure 3: 78K0R – Save It! 7 segment LED port pin connection ................................................................15
Figure 4: 78K0R – Save It! MiniCube2 connector.......................................................................................16
Figure 5: 78K0R – Save It! Minicube2 connection solder bridges ..............................................................16
Figure 6: 78K0R- Save It! system configuration..........................................................................................17
Figure 7: 78K0R – Save It! CD-ROM contents ...........................................................................................18
Figure 8: 78K0R – Save It! CRROM autorun.exe .......................................................................................20
Figure 9: IAR Systems Installation screen ..................................................................................................21
Figure 10: Found New Hardware Wizard (Windows 2000).........................................................................23
Figure 11: Search Method (Windows 2000)................................................................................................23
Figure 12: Driver File Location (Windows 2000) .........................................................................................24
Figure 13: Address Specification 1 (Windows 2000) ..................................................................................24
Figure 14: Address Specification 2 (Windows 2000) ..................................................................................25
Figure 15: Address Specification 3 (Windows 2000) ..................................................................................25
Figure 16: Driver File Search (Windows 2000) ...........................................................................................25
Figure 17: USB Driver Installation Completion (Windows 2000) ................................................................26
Figure 18: Found New Hardware Wizard 1 (Windows XP).........................................................................26
Figure 19: Found New Hardware Wizard 2 (Windows XP).........................................................................27
Figure 20: Search Location Specification 1 (Windows XP).........................................................................27
Figure 21: Search Location Specification 2 (Windows XP).........................................................................28
Figure 22: Windows XP Logo Testing (Windows XP).................................................................................28
Figure 23: USB Driver Installation Completion (Windows XP)....................................................................29
Figure 24: Windows Device Manager .........................................................................................................29
Figure 25: TK-78K0RKE3L demonstration program ...................................................................................30
Figure 26: Applilet EZ PL main window.......................................................................................................31
Figure 27: WriteEZ4 Startup.......................................................................................................................33
Figure 28: WriteEZ4 Device Setup Dialogue ..............................................................................................33
Figure 29: WriteEZ4 Device Menu ..............................................................................................................34
Figure 30: WriteEZ4 open .prm file .............................................................................................................35
Figure 31: WriteEZ4 flash erase successful................................................................................................35
Figure 32: IAR Embedded Workbench Startup window..............................................................................36
Figure 33: IAR Embedded Workbench Main IDE window ..........................................................................37
Figure 34: IAR Embedded Workbench Debugger Options .........................................................................38
Figure 35: Embedded Workbench Linker Configuration .............................................................................39
Figure 36: IAR Embedded Workbench MINICUBE2 settings .....................................................................40
Figure 37: IAR C-SPY debugger .................................................................................................................41
Figure 38: IAR visualSTATE navigator........................................................................................................44
Figure 39: IAR visualSTATE designer.........................................................................................................45
Figure 40: IAR Embedded Workbench visualSTATE sample project .........................................................46
Figure 41: USB interface cable (Mini-B type)..............................................................................................47
Figure 42: TK-78K0RKE3L schematics 1/3 ................................................................................................49
Figure 43: TK-78K0RKE3L schematics 2/3 ................................................................................................50
Figure 44: TK-78K0RKE3L schematics 3/3 ................................................................................................51

78K0R – Save It!
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
9
List of Tables
Table 1: 78K0R – Save It! Switch and Jumper settings ..............................................................................12
Table 2: SW1 modes ...................................................................................................................................13
Table 3: SW2 modes ...................................................................................................................................13
Table 4: SW3 modes ...................................................................................................................................13
Table 5: JP1 settings ...................................................................................................................................14
Table 6: JP2 settings ...................................................................................................................................14
Table 7: 7 segment LED port values ...........................................................................................................15
Table 8: Applilet EZ PL demo Switch settings ............................................................................................32
Table 9: WriteEZ4 action buttons ................................................................................................................34
Table 10: IAR EWB 78K0R – Save It! sample project hardware setup ......................................................36
Table 11: IAR VS 78K0R – Save It! sample project hardware setup..........................................................43

78K0R – Save It!
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
10
1. Introduction
The 78K0R - Save It! demonstration Kit shows the system development possibilities using a NEC low power
consumption microcontroller of the 78K0R/Kx3-L microcontroller family.
A preprogrammed sample project, which is written to work with the TK-78K0R demo PC graphical user
interface, provided on the CD-ROM, shows the current consumption in the different operating modes of the
micro-controller.
Furthermore an IAR Embedded Workbench for 78K, IAR visualSTATE and Applilet EZ PL sample projects
for the 78K0R/Kx3-L can be found on the CD-ROM.
1.1 Package contents
•TK-78K0R/KE3L board
•USB cable
•CD-ROM containing the TK78K0R/KE3L GUI, Applilet EZ PL, an evaluation copy of the IAR
Embedded Workbench for 78K with 4Kbyte code size limitation and IAR visualSTATE
Please verify that you have received all parts listed in the package contents list attached to the 78K0R -
Save It! demonstration kit package. If any part is missing or seems to be damaged, please contact the dealer
from whom you received your 78K0R - Save It!.
1.2 Features
•NEC Electronics µPD78F1009 low power consumption general purpose NEC 16-bit 78K0R MCU
•NEC Electronics µPD78F0730 MCU with on-chip USB interface
•2 latched 7 segment LEDs
•Low current consumption modes demo application with GUI for the Host PC
•Applilet EZ PL graphical based, logic expression design tool, that directly creates the regarding
object code
•On-Board debug function (TK-78K0 debugging)
The 78K0R Save It! supports an On-Board debug function by using the IAR C-SPY debugger
without a need of additional debug hardware. It allows FLASH downloading and standard debug
functions like code execution, single stepping, breakpoints, memory manipulation etc.
•Power supply by USB interface or via external power supply
•The IAR Embedded Workbench for 78K and the IAR C-SPY debugger / simulator are included.
These packages are restricted in such that maximum program code size is limited to 4 Kbyte.
•IAR visualSTATE demo, a package of integrated tools for developing, testing, and implementing
embedded applications based on state chart diagrams.
•Full documentation is included for the NEC 78K078F1009 microcontroller, NEC 78K0 78F0730
microcontroller, IAR Systems Embedded Workbench and IAR Systems C-SPY debugger / simulator.
The 78K0R – Save It! is not intended for code development. NEC does not allow and does not
support in any way any attempt to use 78K0R – Save It! in a commercial or technical product.

78K0R – Save It!
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
11
1.3 System requirements
HOST PC A PC supporting Windows 2000, Windows XP or Windows Vista is required
for the IAR Systems Embedded Workbench demo-version.
A Pentium processor with at least 1 GHz CPU performance, with at least
256 Mbytes of RAM, allowing you to fully utilize and take advantage of the
product features. 500 Mbytes of free disk space and an additional 10
Mbytes of free disk space on the Windows system drive.
A web browser and Adobe Acrobat Reader to be able to access all the
product documentation.
Host interface USB interface that enables communication based on USB (Ver1.1 or later)
Note: Updates of the IAR Embedded Workbench for 78K, documentation and/or utilities for
78K0R SAVE IT!, if available, may be downloaded from the NEC WEB page(s) at
http://www.eu.necel.com/78K0RSAVEIT
1.4 Trademarks
IAR Embedded Workbench, visualSTATE and C-SPY are registered trademarks of IAR Systems AB.
Microsoft and Windows are registered trademarks of Microsoft Corporation. Adobe and Acrobat Reader are
registered trademarks of Adobe Systems Incorporated.
All other product names are trademarks or registered trademarks of their respective owners.

78K0R – Save It!
2. 78K0R – Save It! Components
The TK-78K0R/KE3L board is equipped with USB-connector and with several connectors in order to be
connected to host computers, FLASH programmer, MiniCube2 or any external target hardware.
Figure 1: 78K0R – Save It! components
2.1 Operation mode settings
Caused by the different operating modes the 78K0R –Save It! supports different switches and jumpers are
available on the board.
The table below shows the 3 different modes and the regarding switch / jumper setting for each mode.
Switch / Jumper Demonstration mode Debugging / Writing
mode PC communication mode
SW1 DEMO Debug K0USB
SW2 DEMO EXT K0USB
SW3.1 – SW3.3 OFF ON OFF
SW3.4 – SW3.8 Unused Any Any
JP1 Short Short Short
JP2 1-2 and 3-4 shorted 1-3 shorted 1-3 shorted
Table 1: 78K0R – Save It! Switch and Jumper settings
2.2 SW1
SW1 is a 3 position switch to set following modes.
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
12

78K0R – Save It!
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
13
Position Mode
Left Demo
middle K0USB
Right Debug
Table 2: SW1 modes
2.3 SW2
SW2 is a 3 position switch to set following modes.
Position Mode
Left Demo
middle K0USB
Right EXT
Table 3: SW2 modes
2.4 SW3
SW3 is an 8 position DIP switch with following functions
Bit Mode
1 Mode selection (see Table 1)
2 Mode selection (see Table 1)
3 Mode selection (see Table 1)
4 Connected to microcontroller port pin P33
5 Connected to microcontroller port pin P42
6 Connected to microcontroller port pin P43
7 Connected to microcontroller port pin P77
8 Connected to microcontroller port pin P76
Table 4: SW3 modes
Note: Make sure to set the regarding pull-up resistor option registers (PUx) of the microcontroller if
the Pins P33, P42, P43, P76 and P77. Please refer to the device user’s manual of the
78K0R/Kx3-L for detailed information about the pull-up resistor option register settings.
2.5 SW4 (Reset switch)
SW4 is connected to the external reset pin of the µPD78F1009 microcontroller. External reset can be
triggered by pushing.
2.6 SW5 (INTP0)
SW5 is connected to the "P120/INTP0/EXLVI" pin of the µPD78F1009 microcontroller. It can be used as
external interrupt source.
Note: Make sure to set up the microcontroller internal pull-up resistor option register (PU12)
correctly when using this external switch. Please refer to the device user’s manual of the
78K0R/Kx3-L for detailed information about the pull-up resistor option register settings.
2.7 SW6 (INTP2)

78K0R – Save It!
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
14
SW6 is connected to the "P32/SCK10/SCL10/INTP2" pin of the µPD78F1009 microcontroller. It can be used
as external interrupt source.
Note: Make sure to set up the microcontroller internal pull-up resistor option register (PU12)
correctly when using this external switch. Please refer to the device user’s manual of the
78K0R/Kx3-L for detailed information about the pull-up resistor option register settings.
2.8 JP1
JP1 is a switch jumper to select the power supply.
Position Function
Short USB power supply connected (USB1)
Open Power supply via CN1 or CN2
Table 5: JP1 settings
2.9 JP2
JP2 is a jumper field to establish a current consumption measurement
Jumper settings setting
1-2 and 3-4 short Demonstration mode
1-3 short Debugging/Writing and PC communication mode
any other restricted
Table 6: JP2 settings
2.10 Q4 (illuminance sensor)
The illuminance sensor Q4 is connected to the P80/CMP0P/INTP3/PGAI pin of the µPD78F1009
microcontroller. When lightening up the voltage gains up and when darkening it goes down. So the gain
amplifier function of the microcontroller can be used to read the illuminance. For further information to set up
the registers of the microcontroller to use the gain amplifier functionality please refer to the device user’s
manual.
2.11 U10, U12 (7 segment LED)
U10 and U12 are two 7 segment LEDs. They can be set through the latches U11 and U13. The data
channels of the latch are connected to channel P20 to P27 and the clock pins to P00 (U10) and P01 (U12) of
the of the µPD78F1009 microcontroller.

78K0R – Save It!
Figure 2: 78K0R – Save It! 7 segment LEDs structure
Figure 3: 78K0R – Save It! 7 segment LED port pin connection
In respect to the pin connection the following table shows the port values to be written to show the numbers
from 0 to 9 on the 7 segment LEDs.
Digital number Port value (hex) Digital number Port value (hex)
0 0xC0 5 0x92
1 0xF9 6 0x83
2 0xA4 7 0xF8
3 0xB0 8 0x80
4 0x99 9 0x98
Table 7: 7 segment LED port values
2.12 LED1 (power LED)
LED1 is the power LED, lights up when power is supplied via USB, CN1 or CN2 to the 78K0R – Save It!
2.13 Universal area
The Universal area of the 78K0R – Save It! is a free for the customer to use mounting area. Furthermore
there is the possibility to mount a MiniCube2 connector to the Universal area
2.13.1 Minicube2 connector
If a MiniCube2 shall be connected to the 78K0R – Save It! starter kit a 16-pin connector has to be mounted
to the universal area as shown below.
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
15

78K0R – Save It!
Figure 4: 78K0R – Save It! MiniCube2 connector
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
16
Furthermore some solder bridges have to be shorted to connect the connector to the target device.
Figure 5: 78K0R – Save It! Minicube2 connection solder bridges

78K0R – Save It!
3. 78K0R – Save It! system configuration
The 78K0R – Save It! starter kit system configuration is given in the diagram below
Figure 6: 78K0R- Save It! system configuration
3.1 78K0R – Save It!
The 78K0R – Save It! is a demonstration kit for the 78F1009 16-bit low power consumption microcontroller
of the 78K0R family. The demonstration board is connected to the host system via USB interface cable. The
host system may be used for On-Chip debugging by using the IAR C-SPY debugger and to allow execution
of application programs on 78K0R – Save It! starter kit.
78K0R – Save It! runs the microcontroller at 20 MHz operating speed in normal operation mode.
3.2 Host computer
The USB host interface enables communication to the 78K0R – Save It! board. The μPD78F0730 78K0 8-
Bit microcontroller with on-chip USB interface and the NEC virtual UART driver allows application software to
access the µPD78F1009 device in the same way as it would access a standard RS232 interface.
The NEC virtual UART driver appears to the windows system as an extra Com Port, in addition to any
existing hardware Com Ports.
3.3 Power supply via USB interface
The TK-78F0730 board is powered by the USB interface. Optional the power supply can be applied via a
JACK connector which has to be mounted to CN3.
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
17

78K0R – Save It!
4. 78K0R – Save It! installation and operation
4.1 Getting started
The 78K0R – Save It! is delivered with two PC based user programs. The TK-78K0RKE3L demonstration
program is designed to measure the current consumption, the CPU frequency and the actual illuminance
(measured by an illuminance sensor). The Applilet EZ PL is an easy to use GUI based program to build up
small logical circuits which are automatically converted into an IAR Embedded workbench or NEC PM+
project. They can be compiled and downloaded to the target hardware directly from within the Applilet EZ
PL; therefore it is necessary that the chosen Workbench Suite is correctly installed on the Host PC.
4.2 CD-ROM contents
78K0R - Save It! CD-ROM ROOT
Acrobat - Acrobat Reader for 32Bit Windows OS
Applilet - Applilet EZ PL
Device file package - µPD78F8024 Device file package
Doc - Documentation
dotnet - Microsoft .NET package
Driver - TK-78K0RKE3L driver files
IAR Systems - IAR Embedded Workbench for 78K
- IAR visualSTATE
samples - Example projects for the 78K0R - Save It!
Starter Kit
TK-78K0R_KE3L_Demo - TK-78K0RKE3L current consumption
demonstration program
WriteEZ4 - Flash Programmer WriteEZ4 incl. PRM file
for µPD78F1009
Figure 7: 78K0R – Save It! CD-ROM contents
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
18

78K0R – Save It!
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
19
5. Hardware installation
After unpacking the 78K0R – Save It! demonstration kit,connect the board via connector CN1 to your host
computer using the provided USB interface cable. When TK-78K0R/KE3L board is connected, the USB
driver needs to be installed on the host machine. Please refer to the following USB Driver Installation.

78K0R – Save It!
6. Software installation
The 78K0R – Save It! package comes with the following software packages:
•TK-78K0R/KE3L demonstration program
•IAR Systems Embedded Workbench for 78K 4Kbyte code size limited, including C compiler,
assembler, linker, librarian and IAR C-SPY debugger / simulator
•IAR Systems Visual State time limited demo program
•Device file package of μPD78F1009 for IAR Embedded Workbench for 78K
•WriteEZ4 flash programmer software including the PRM file for μPD78F1009
Figure 8: 78K0R – Save It! CRROM autorun.exe
6.1 TK-78K0RKE3L demonstration program installation
Before the TK-78K0RKE3L demonstration program can be installed on the host PC it is mandatory that
the .NET Framework is installed on the host PC. For further information about installing .NET Framework
please refer to the TK-78K0R_DEMO_GUI.pdf available on the CD delivered with the 78K0R – Save It!
package in the “\Doc” folder.
_______________________________________________________________________________________________
User’s Manual U19663EE1V0UM00
20
