NEC QB-MINI2-EE User manual

Customer Notification
QB-MINI2-EE
Universal Flash Memory Programmer and Serial
On-chip Debugger
Operating Precautions
Target Devices
78K0/Kx2 Series, 78K0/Fx2 Series
78K0/Lx2 Series, 78K0S/Kx1+ Series
µPD78F0731
µPD78F801x
µPD78F802x
V850ES/Kxx Series, V850ES/Jx2 Series
V850ES/Hx2 Series, V850ES/Ix2, V850E/IA3/IA4
V850ES/Sxx Series, V850ES/Fx2-Series
Document No. TPS-LE-OP-TMINI2-2
Date Published: August 2006
NEC Electronics (Europe) GmbH

2Customer Notification
DISCLAIMER
The related documents in this customer notification may include preliminary versions. However,
preliminary versions may not have been marked as such.
The information in this customer notification is current as of its date of publication. The information is
subject to change without notice. For actual design-in, refer to the latest publications of NEC’s data
sheets or data books, etc., for the most up-to-date specifications of NEC PRODUCT(S). Not all
PRODUCT(S) and/or types are available in every country. Please check with an NEC sales
representative for availability and additional information.
No part of this customer notification may be copied or reproduced in any form or by any means without
prior written consent of NEC. NEC assumes no responsibility for any errors that may appear in this
customer notification. NEC does not assume any liability for infringement of patents, copyrights or other
intellectual property rights of third parties by or arising from the use of NEC PRODUCT(S) listed in this
customer notification or any other liability arising from the use of such PRODUCT(S).
No license, express, implied or otherwise, is granted under any patents, copyrights or other intellectual
property rights of NEC or others. Descriptions of circuits, software and other related information in this
customer notification are provided for illustrative purposes of PRODUCT(S) operation and/or application
examples only. The incorporation of these circuits, software and information in the design of customer’s
equipment shall be done under the full responsibility of customer. NEC assumes no responsibility for
any losses incurred by customers or third parties arising from the use of these circuits, software and
information.
While wherever feasible, NEC endeavors to enhance the quality, reliability and safe operation of
PRODUCT(S) the customer agree and acknowledge that the possibility of defects and/or erroneous
thereof cannot be eliminated entirely. To minimize risks of damage to property or injury (including death)
to persons arising from defects and/or errors in PRODUCT(S) the customer must incorporate sufficient
safety measures in their design, such as redundancy, fire-containment and anti-failure features.
The customer agrees to indemnify NEC against and hold NEC harmless from any and all
consequences of any and all claims, suits, actions or demands asserted against NEC made by a third
party for damages caused by one or more of the items listed in the enclosed table of content of this
customer notification for PRODUCT(S) supplied after the date of publication.
Applicable Law:
The law of the Federal Republic of Germany applies to all information provided by NEC to the Customer
under this Operating Precaution document without the possibility of recourse to the Conflicts Law or the
law of 5th July 1989 relating to the UN Convention on Contracts for the International Sale of Goods (the
Vienna CISG agreement).
Düsseldorf is the court of jurisdiction for all legal disputes arising directly or indirectly from this
information. NEC is also entitled to make a claim against the Customer at his general court of
jurisdiction.
If the supplied goods/information are subject to German, European and/or North Americanexport
controls, the Customer shall comply with the relevant export control regulations in the event that the
goods are exported and/or re-exported. If deliveries are exported without payment of duty at the request
of theCustomer, the Customer accepts liability for any subsequent customs administration claims with
respect to NEC.
Notes:(1) “NEC” as used in this statement means NEC Electronics Corporation and also
includes its direct or indirect owned or controlled subsidiaries.
(2) “PRODUCT(S)” means ‘NEC semiconductor products’ (NEC semiconductor
products means any semiconductor product developed or manufactured by or for
NEC) and/or ‘TOOLS’ (TOOLS means ‘hardware and/or software development tools’
for NEC semiconductor products’ developed, manufactured and supplied by ‘NEC’
and/or ‘hardware and/or software development tools’ supplied by NEC but developed
and/or manufactured by independent 3rd Party vendors worldwide as their own product
or on contract from NEC)

Customer Notification 3
Table of Contents
(A) Table of Operating Precautions.....................................................................................4
(B) Description of Operating Precautions............................................................................5
(C) Product Version.............................................................................................................8
(D) Supported Devices.........................................................................................................9
(E) Valid Specification ...................................................................................................... 11
(F) Revision History........................................................................................................... 12

Operating Precautions for QB-MINI2-EE
4Customer Notification
(A) Table of Operating Precautions
QB-MINI2-EE
No.
Target
Device
Debug
/
Progr. Outline Control Code:
Firmware:
A
V3.00 A V4.00
178K0 Debug Invalid internal high-speed RAM area after RESET 77
2V850 Debug Use of watchdog timer 77
3V850 Debug Break during sub-clock operation 77
4V850 Debug Break during flash memory modifications 77
5V850 Debug Reset vector handling 77
6V850 Debug Modifying specific registers 77
7V850 Debug Reset generation 77
878K0S Debug Debugging with operation clock of 6MHz or lower 73
978K0S Debug Downloading when operation clock is 10MHz 77
10 78K0S Debug Display of register values 73
:Not relevant or the target device is not supported
3:Not applicable or corrected
7:applicable

Operating Precautions for QB-Mini2
Customer Notification 5
(B) Description of Operating Precautions
No.1 Invalid internal high-speed RAM area after RESET
Details
If a RESET signal is generated at the RESET-pin or a RESET occurs due to POC during program
execution, below showed internal high-speed RAM areas become invalid:
-5 bytes from FECBh to FECFh (When Permit is selected in Target Power OFF field in the
configuration dialog box)
-10 bytes from FEC9h to FECFh and FEDDh to FEDFh (When Not Permit is selected in
Target Power OFF field in the configuration dialog box)
Workaround
No workaround available
No.2 Use of watchdog timer
Details
The watchdog timer cannot be used, because it’s forcibly stopped by the debug monitor program.
Don’t set the option byte to disable watchdog timer stop.
Workaround
No workaround available
No.3 Break during sub-clock operation
Details
In the configuration dialog box of the debugger it’s possible to define, if the operating clock during a
break is switched from sub-clock to main clock. But if UART is the communication channel
between QB-MINI2-EE and target device, an occurring break during sub-clock operation (while the
main clock has been stopped) will forcibly switch the operation clock to main clock. The device
continues its operation with the main clock after monitor program execution.
Workaround
No workaround available
No.4 Break during flash memory modifications
Details
Abreak may occurs at an unexpected address during flash memory modifications (for example
usage of flash self-programming libraries).
Workaround
Reset the device and repeat program execution.

Operating Precautions for QB-MINI2-EE
6Customer Notification
No.5 Reset vector handling
Details
The reset vector cannot be used.
Workaround
No workaround available
No6 Modifying specific registers
Details
Peripheral I/O registers (except PCC and CKC), that require a specific program sequence for
access, cannot be modified in the I/O register of the debugger.
Workaround
No workaround available
No.7 Reset generation
Details
A break occurs, when an external reset (which isn’t masked in the debugger GUI) or an internal
reset is generated.
Workaround
No workaround available
No.8 Debugging with operation clock of 6MHz or lower
Target Device
78K0S
Details
The debugger does not start when the target device operating frequency is 6MHz or lower
Workaround
No workaround available. This item is corrected from firmware version V4.00 onwards.

Operating Precautions for QB-Mini2
Customer Notification 7
No.9 Downloading when operation clock is 10MHz
Target Device
78K0S
Details
When the target device operating frequency is 10MHz, an error will occur during download of a
program and the downloading cannot be completed.
Workaround
No workaround available
No.10 Display of register values
Target Device
78K0S
Details
Register values may be displayed incorrectly in the debugger during a break.
Workaround
This item is corrected in firmware version V4.00

Operating Precautions for QB-MINI2-EE
8Customer Notification
(C) Product Version
The “Control Code” is an alphabetic code used to identify the hardware of QB-MINI2-EE. It is the second
digit from the left in the 10-digit serial number printed on the sticker attached to the bottom side of QB-MINI2-
EE (if it has not been upgraded).
The “Firmware” (F/W) is a program embedded in the controller device of the QB-MINI2-EE. The F/W version
is shown as Vx.xx.
The control code and firmware version can be checked with the QB-MINI2-EE diagnostic tool:

Operating Precautions for QB-Mini2
Customer Notification 9
(D) Supported Devices
The devices that are supported by Mini2 are listed in the following table:
Information on the supported devices is also available on the following QB-Mini2 webside
URL http://www.necel.com/micro/english/products/sc/allflash/minicube2.html
1. 78K0 microcontrollers
the following table lists the support status for 78K0 microcontrollers. Support for the target device also
differs depending on the version of the development tools.
Version Version
78K0/Lx2 V1.00 V2.93 DF780397 V1.01 V1.00 V1.00 PRM78F0397 V1.02
78K0/Kx2 V1.00 V2.93 DF780547 V2.10 V1.00 V1.00 PRM78F0547 V1.05
78K0/Kx1+ V1.00 V1.00 PRM78F0148H V1.12
UPD78F0731 V1.00 V1.00 PRM78F0731 V1.01
78K0/Fx2 V1.00 V1.00 PRM78F0893 V1.03
78K0/Fx1+ V1.00 V1.00 PRM78F0876 V1.11
UPD78F800xH V1.00 V1.00 PRM78F8006H V1.00
UPD78F801x V1.00 V1.00 PRM78F8016 V1.01
UPD78F802x V1.00 V1.00 PRM78F8020 V1.01
Not supported
Not supported
Not supported
Not supported
Not supported
Not supported
Not supported
Flash Memory Programming
Firmware
Version QBP Version
Device File Package
Parameter File Package
Supported
Devices
On-chip Debugging
Firmware
Version ID78K0-QB Version
2. 78K0S microcontrollers
the following table lists the support status for 78K0S microcontrollers. Support for the target devicealso
differs depending on the version of the development tools. Check the external interrupt pins that can be
used as a communication interface between Minicube2 and the target device.
Version Version
78K0S/KU1+
78K0S/KY1+
78K0S/KA1+
78K0S/KB1+
V2.82 DF789234 V2.11
ID78K0-QB
Version
On-chip Debugging
Supported Serial
Interface
Flash Memory Programming
Firmware
Version QBP Version
Device File Package
Parameter File Package
INTP1
INTP3 V3.00
Supported
Devices Firmware
Version
V3.00 V1.00 PRM78F9234 V1.05

Operating Precautions for QB-MINI2-EE
10 Customer Notification
3. V850 microcontrollers
the following table lists the support status for V850 microcontrollers. Support for the target device also
differs depending on the version of the development tools. Check the serial interface that can be used
as a communication interface between Mini2 and the target device.
Version Version
V850ES/Hx2
UART0 CSIB0
V2.00
Vx.241/
V3.30B
DF703712 V1.10 V2.00 V1.00 PRM70F3712 V1.00
V850ES/IE2 UART0 CSIB0
V2.00
Vx.241/
V3.30B DF703714 V1.00 V2.00 V1.00 PRM70F3714 V1.00
V850ES/Jx2 UART0
CSIB0/CSIB3 V2.00 Vx.241/ V3.30B DF703724 V1.00 V2.00 V1.00 PRM70F3724 V1.00
V850ES/Kx2 UART0 CSIB0
V2.00
Vx.241/
V3.30B DF703734 V1.00 V2.00 V1.00 PRM70F3734 V1.01
V850ES/Kx1
V850ES/Kx1H V2.00 V1.00 PRM70F3218H V1.11
V850ES/Kx1+ V2.00 V1.00 PRM70F3318 V1.11
V850ES/Fx2 V2.00 V1.00 PRM70F3239 V1.12
V850ES/Sx2 V2.00 V1.00 PRM70F3288 V1.11
V850ES/Sx3 V2.00 V1.00 PRM70F3368 V1.00
V850E/IA3 V2.00 V1.00 PRM70F3184 V2.10
V850E/IA4 V2.00 V1.00 PRM70F3186 V2.10
V850ES/IK1 V2.00 V1.00 PRM70F3329 V1.20
Supported
Devices Firmware
Version
GHS eserv /
IAR
Not supported
Not supported
Not supported
Not supported
Not supported
Flash Memory Programming
Firmware
Version
QBP
Version
Device File Package Parameter File Package
On-chip Debugging
Supported
Interfaces
Not supported
Not supported
Not supported
Not supported
Not supported

Operating Precautions for QB-Mini2
Customer Notification 11
(E) Valid Specification
Item Date published Document No. Document Title
1June 2006U17966EEQB-MINI2-EE Setup Manual
2April 2006 ZUD-CD-06-
0018_1_E
QB-MINI2-EE Preliminary User’s Manual

Operating Precautions for QB-MINI2-EE
12 Customer Notification
(F) Revision History
Item Date published Document No. Comment
1June 2006TPS-LE-OP-TMINI2-1Release
August 2006 TPS-LE-OP-TMINI2-2add K0S restrictions
