Nec Neax2400 ics Owner's manual

OCTOBER, 2000

NEC America, Inc.

NDA-24297

ISSUE 1

STOCK # 200775

Feature Programming Manual

LIABILITY DISCLAIMER

The information contained in this document is specific to Dterm Series E only.

Minimum firmware may be required. Contact NEC Engineering for additional

information.

NEC America, Inc. reservesthe right to change the specifications, functions, or

features, at any time, without notice.

NEC America, Inc. has prepared this document for use by its employees and

customers. The information contained herein is the property of NEC America,

Inc. and shall not be reproduced without prior written approval from NEC

America, Inc.

NEAX®and Dterm®are registered trademarks of NEC Corporation.

Cisco®is a registered trademark of Cisco Systems, Inc. Documentation

references to Cisco products refer to networking with Cisco hardware.

NEC America, Inc.

Printed in the U.S.A.

ISSUE 1 ISSUE 2 ISSUE 3 ISSUE 4

DATE OCTOBER, 2000 DATE DATE DATE

ISSUE 5 ISSUE 6 ISSUE 7 ISSUE 8

DATE DATE DATE DATE

NEAX2400 IPX

Feature Programming Manual Revision Sheet 1/15

NDA-24297

PAGE No. ISSUE No.

12345678

i 1
