NEC ELECTRA ELITE IPK II User manual

NOTICE
Note that when converting this document from its original format
to a .pdf file, some minor font and format changes may occur.
When viewing and printing this document, we cannot guarantee
that your specific PC or printer will support all of the fonts or
graphics. Therefore, when you view the document, fonts may be
substituted and your individual printer may not have the
capability to print the document correctly.

Single Line Telephone
User Guide

Table of Contents
General Information .....................................................................1
Quick Reference Guide .................................................................1
Answering Calls ............................................................................2
Ringing Calls ..............................................................................................2
Off-Hook Signaling .....................................................................................2
Placing Calls .................................................................................3
Internal Calls ..............................................................................................3
Outside Calls ..............................................................................................3
Last Co/PBX Number Redial ......................................................................3
Speed Dial - System/Group/Station ...........................................................3
Holding Calls ................................................................................4
Exclusive Hold ............................................................................................4
Transferring Calls .........................................................................4
Conference ....................................................................................5
Call Park .......................................................................................5
To Park a call in a system orbit: .................................................................5
To pick up a parked call: ............................................................................5

Tone Override ............................................................................... 6
To send off-hook signals when calling a busy telephone: ..........................6
To answer Tone Override: ..........................................................................6
Voice Over ..................................................................................... 6
Originate/Answer ........................................................................................6
Call Forwarding ........................................................................... 7
From Your Station ......................................................................................7
Paging ........................................................................................... 8
To make an Internal Page announcement: ................................................8
To Page an external zone: .........................................................................8
Meet-Me Answer ........................................................................................9
Call Pickup .................................................................................... 9
To answer a call ringing another telephone in your Pickup Group: ............9
To answer a call ringing a telephone in another Pickup Group
when you do not know the group number: .................................................9
To answer a call ringing a telephone in another Pickup Group
when you know the group number: ............................................................9
To use Directed Call Pickup to intercept a call to a
co-worker’s extension: ..............................................................................10
Do Not Disturb ............................................................................ 10
Account Code Entry ................................................................... 10
ACD ............................................................................................. 11
Multiple Agent Log In ................................................................................11
Rest Mode ................................................................................................12
Programming Station Speed Dial .............................................. 12

1
GENERAL INFORMATION
The following should be considered when reviewing this User Guide:
H Access to many features is based on system assignments. Some access
codes may vary from those stated in this user guide and not all features
may be available from your telephone.
H The Flash key located on certain models of Single Line Telephones can be
used in place of the hookswitch.
QUICK REFERENCE GUIDE
Outside Calling:
Outside Call Dial 9
 Telephone Number
Last CO/PBX Number Redial Dial #5
Speed Dial Station Speed Dialing Number: #7
 0~9
Group Speed Dialing Number: #4
 xxx
System Speed Dialing Number: #2
 000~999
* No Group buffers assigned at default.
Trunk Queue Receive Trunk Busy Indication
 Dial #
Internal Calling:
Station Call Dial Station Number
Tone Override Reach Busy Station
 Dial *
Voice Over Originate Reach Busy Station  Dial 6
Quick Transfer to Voice Mail Dial Station Number
 8
With A Call In Progress:
Hold Hookswitch
Transfer Hookswitch
 Dial Station Number
Quick Transfer to Voice Mail Hookswitch
 Dial Station Number  8
Conference Hookswitch
 Dial#1  DialParty  Hookswitch
twice
Call Park System Set: Hookswitch
 Dial #6  Dial 01~64
Retrieve: Dial *6
 Dial 01~64
Voice Over Answer Receive Voice Over
 Replace handset 
Lift handset  Converse

2
ANSWERING CALLS
R INGING C ALLS
H Lift handset.
H Converse.
O FF -H OOK S IGNALING
With a call in progress:
H Receive Off-Hook Signaling.
H Replace handset to disconnect the present call.
H Lift handset to converse with second call.
From the Intercom:
Internal Paging Dial 701
 0~9 or 01~64  Page
Dial 0or 00 for All Internal Paging
 Page
External Paging Dial 703
 0or 1~8  Page
Dial 0for All External Paging
 Page
Call Pickup In your Pickup Group: Dial 756
In another Pickup Group when you do not
know the group number: Dial 769
In another Pickup Group when you know the
group number: Dial 768 and the group number
(1~9 or 01~64)
Call Pickup Direct Dial **
 Dial Station Number
Call Forward Set:
For Forward All: Dial 741
 Dial 1  Dial
Destination
ForBusy/NoAnswer:Dial744
 Dial1  Dial
Destination
Cancel:
For Forward All: Dial 741
 Dial 0
For Busy/No Answer: Dial 744
 Dial 0
Programming Speed Dial Dial755
 Dial0~9  D ialTrunkAccessCode 
Dial telephone number

3
PLACING CALLS
I NTERNAL C ALLS
H Lift handset.
H Dial station number or 0 for the attendant.
Note:1 When calling a multiline telephone, dialing 1 after the station number will
change ringing to voice or voice to ringing.
Note:2 To directly access a personal voice mailbox, dial 8 after dialing the station
number.
O UTSIDE C ALLS
H Lift handset.
H Dial trunk access code, i.e. 9.
H Dial telephone number.
H Converse.
L AST C O /PBX N UMBER R EDIAL
H Lift handset.
H Dial Last Number Redial code #5.
H Converse.
S PEED D IAL - S YSTEM /G ROUP / S TATION
H Lift handset.
H Dial Speed Dial code:
J Station Speed Dial #7.
J Group Speed Dial #4.
J System Speed Dial #2.
H Dial Speed Dial Memory location:
J Station Speed Dial 0~9.
J Group Speed Dial xxx (none at default).
J System Speed Dial 000~999.
H Converse.

4
HOLDING CALLS
E XCLUSIVE H OLD
With a call in progress:
H Press Hookswitch.
Note:1 Replacing the handset when a call is on hold will cause the held call to
immediately ring your station.
Note:2 Once a call is placed on hold, the telephone can be used to place another
internal or outside call or access a feature (i.e. Call Pickup). Press Hookswitch
again to return to the original party and place the second party on Hold.
TRANSFERRING CALLS
With a call in progress:
H Press Hookswitch.
H Dial station number.
H Announce call (optional).
H Replace handset.
Note:1 If the called station is busy, replacing handset will initiate a camp-on. An
unanswered camp-on or ring transferred call will recall to your telephone after a
preprogrammed time interval.
Note:2 To return to the original party, press Hookswitch.
Note:3 To transfer a call directly to a personal voice mailbox, dial 8 after dialing the
station number.

5
CONFERENCE
With a call in progress:
H Press Hookswitch and dial #1.
H Dial the party you want to add and wait until they answer.
H Press Hookswitch and repeat the second step to add more parties.
- OR -
H Press Hookswitch twice to set up the Conference.
CALL PARK
T O P ARK A CALL IN A SYSTEM ORBIT :
Note: You can Park Intercom or trunk calls.
H Press Hookswitch.
H Dial #6 and the Park orbit (01~64).
If you hear busy tone, the orbit is busy. To try another orbit, press the
Hookswitch twice and repeat the second step.
H Use Paging to announce call.
H Replace the handset.
If not picked up, the call will recall to you.
T O PICK UP A PARKED CALL :
H Lift the handset.
H Dial *6 and the Park orbit (01~64).

6
TONE OVERRIDE
T O SEND OFF - HOOK SIGNALS WHEN CALLING A BUSY TELEPHONE :
H Dial *.
- OR -
H Dial 709.
You hear Ring Busy Tone.
The called extension hears Call Alert Notification.
Note: By default, your extension will send off-hook signals automatically.
T O ANSWER T ONE O VERRIDE :
H Receive Tone Override.
H Hang up the handset.
H Answer the incoming call and talk with the party.
VOICE OVER
O RIGINATE /A NSWER
Originate Answer
When calling a busy telephone: With a call in progress:
H Dial 6. H Receive Voice Over announcement.
-OR-
H Replace handset; first call is
terminated.
H Dial 690 (if the single digit
access code has been
changed).
H Lift handset when phone rings.
H Converse with Voice Over
originator.
You hear an alert tone.
You can talk to the called
party after the alert tone
ends.

7
CALL FORWARDING
F ROM Y OUR S TATION
To set/cancel Call Forward - Immediate:
To set/cancel Call Forward - Busy/No Answer:
Set Cancel
H Lift the handset. H Lift the handset.
H Dial the Call Forward -
Immediate Service Code
(default: 741).
H Dial the Call Forward -
Immediate Service Code
(default: 741).
H Dial 1(Set). H Dial 0(Cancel).
H Dial the destination extension or
off-premise number.
H Hang up.
H Hang up.
Note: While set, Call Forward - All overrides Call Forward - Busy/No Answer
setting.
Set Cancel
H Lift the handset. H Lift the handset.
H Dial the Call Forward - Busy/No
Answer Service Code (default:
744).
H Dial the Call Forward - Busy/
No Answer Service Code
(default: 744).
H Dial 1(Set). H Dial 0(Cancel).
H Dial the destination extension or
off-premise number.
H Hang up.
H Hang up.
Note: While set, Call Forward - All overrides Call Forward - Busy/No Answer
setting.

8
PAGING
T O MAKE AN I NTERNAL P AGE ANNOUNCEMENT :
H Lift the handset.
H Dial 701 and the Paging Zone number (0~9 or 00~64).
Dialing 0or 00 calls All Call Internal Paging.
- OR -
H Dial *1 and the Combined Paging Group code 1~8 or 0(for Internal/
External All Call).
If the Internal Page Zone is busy or if there are no extensions in a page
group, the page will be announced as an External Page only.
H Make announcement.
H Hang up.
T O P AGE AN EXTERNAL ZONE :
H Lift the handset.
H Dial 703 and the External Paging Zone code (1~8 or 0 for All Call).
- OR -
H Dial *1 and the Combined Paging Group code (1~8 or 0 for Internal/
External All Call).
* If the Internal Page Zone is busy or if there are no extensions in a
page group, the page may be announced as an External Page only.
H Make announcement.
H Hang up.

9
M EET -M E A NSWER
To join a Meet Me Internal Page:
H Lift the handset.
H Dial 763 (if your extension is in the zone called).
- OR -
H Dial 764 and the zone number (if your extension is not in the zone called).
You connect to the other party.
To join a Meet Me External Page:
H Lift the handset.
H Dial 765.
H Dial the announced External Paging Zone (0~8).
You connect to the other party.
CALL PICKUP
T O ANSWER A CALL RINGING ANOTHER TELEPHONE IN YOUR P ICKUP G ROUP :
H Lift the handset.
H Dial 756 or *#.
Service Code *# can pick up any call in the group, plus any Ring Group
calls. Service Code 756 cannot pick up Ring Group calls.
T O ANSWER A CALL RINGING A TELEPHONE IN ANOTHER P ICKUP G ROUP WHEN YOU DO
NOT KNOW THE GROUP NUMBER :
H Lift the handset.
H Dial 769.
T O ANSWER A CALL RINGING A TELEPHONE IN ANOTHER P ICKUP G ROUP WHEN YOU KNOW
THE GROUP NUMBER :
H Lift the handset.
H Dial 768 and the group number (1~9 or 01~64).

10
T O USE D IRECTED C ALL P ICKUP TO INTERCEPT A CALL TO A CO - WORKER ’ S EXTENSION :
H Lift the handset.
H Dial **.
H Dial the number of extension whose call you want to intercept.
If more than one call is coming in, the system sets the priority for which
call it will answer first.
DONOT DISTURB
H Lift the handset.
H Dial 747.
H Dial the DND option code.
0= Cancel DND
1= Incoming Trunk Calls Blocked
2= Incoming Intercom, Call Forwards and Transferred Trunk Calls Blocked
3= All Calls Blocked
4= Call Forwards Blocked
ACCOUNT CODE ENTRY
With an outside call in progress:
H Press Hookswitch.
H Dial Account Code Entry Code ______.
H Dial Account Code (16 digits maximum).
H Press Hookswitch to return to held call.

11
ACD
M ULTIPLE A GENT L OG I N
To Log In:
Note: Follow Steps 1~3 to log in with additional AICs (up to three) at any time.
H Lift the handset and dial the AIC Log In service code (not assigned at
default).
H Dial the log in code (up to 20 digits).
This step is not required if the ID code is disabled in system
programming.
H Dial the first Agent Identity Code (AIC) (up to four digits).
You will hear a confirmation tone when immediately logging in with
additional AICs.
H For second agent log: Dial the second Agent Identity Code (AIC) (up to
four digits).
You will hear a confirmation tone.
H For third agent log: Dial the third Agent Identity Code (AIC) (up to four
digits).
You will hear a confirmation tone.
To Log Out (for single or multiple agent log ins):
Note: All AIC are logged out.
H Lift the handset.
H Dial the AIC Log Out service code (not assigned at default).
- OR -
H To log out of an ACD group without using AIC: Lift the handset.
H Dial the ACD Log Out service code 655 (default).

12
R EST M ODE
To set the manual Rest Mode:
H Lift the handset and dial 658.
A fast busy is heard.
To set Pre-Rest Mode (while on a call), press the hookflash and then
dial 658. Press the Hookflash again to return to the outside party. Rest
Mode will begin once the call is completed.
H Hang up.
To cancel the manual Rest Mode:
H Lift the handset.
A fast busy is heard.
H Dial 659.
H Hang up.
PROGRAMMING STATION SPEED DIAL
To store a Station Speed Dialing number:
H Lift the handset.
H Dial 755.
H Dial the Station Speed Dial buffer number to be programmed (0~9).
1 = Station Speed Dial buffer 1
2 = Station Speed Dial buffer 2
" " " " " "
0 = Station Speed Dial buffer 10
H Dial the Access Code (e.g., 9) - if required.
H Dial telephone number you want to store (up to 24 digits).
Valid entries are 0~9, # and *.
H Hang up.

INT-2001 (IPK II)
© 2006 NEC America, Inc.
The material contained herein is subject
to change without prior notice at the sole
discretion of NEC Unified Solutions, Inc.
Electra Elite is a registered trademark of
NEC America, Inc.
Document Revision 1
For more information contact:
NEC Unified Solutions, Inc.
6555 N State Highway 161
Irving, TX 75039-2402
www.necunified.com
