Nederman N Series User manual

REV.1 0523
N16
N24
N27 N40N29
Installation & Operation Manual
Fans & Pumps
N-Series Fans
16-24-27-29-40

N16/24/27/29/40
1 Preface........................................................................................................................................................................................................................10
2 Safety ...........................................................................................................................................................................................................................10
3 Description .........................................................................................................................................................................................................10
3.3 Technical Data ...................................................................................................................................................................................11
4 Installation ..........................................................................................................................................................................................................11
4.1 Mounting instruction N16/24/27/29/40 ...................................................................................................11
4.2 Electrical installation ..............................................................................................................................................................12
5 Use N16/24/27/29/40 ...............................................................................................................................................................12
5.1 Starting Instructions .................................................................................................................................................................12
5.2 Outdoor Use / Draining ........................................................................................................................................................12
6 Maintenance ....................................................................................................................................................................................................13
6.1 Spare Parts ............................................................................................................................................................................................13
7 Recycling .................................................................................................................................................................................................................13
Figures ................................................................................................................................................................................................................................. 4
Table of Contents
Nederman Customer Service & Technical Support [email protected] [phone]
2
Declaration of Conformity .............................................................................................................................................................. 3
3.2 Pressure Drop/Fan Curves...............................................................................................................................................10
3.1 Dimensions ...........................................................................................................................................................................................10

N16/24/27/29/40
Declaration of Conformity
Declaration of Conformity
We, AB Ph. Nederman & Co., declare under our sole responsibility that the Nederman product:
N16/24/27/29/40 (Part No. **, and stated versions of **) to which this declaration relates, is in
conformity with all the relevant provisions of the following directives and standards:
Directives
2006/42/EC, 2014/30/EU, 2011/65/EU
Standards
EN 60204-1.
The name and signature at the end of this document, is the person responsible for both the
declaration of conformity and the technical file.
Nederman Customer Service & Technical Support [e-mail] [phone]
3
AB Ph. Nederman & Co.
P.O. Box 602
SE-251 06 Helsingborg
Sweden
Anna Cederlund
Product Center Manager
Technical Product Management
2022-10-03

N16/24/27/29/40
19" (482 mm)
22.9" (582 mm)
7.3" (185 mm)
9.8" (250 mm)
19.4" (493 mm)
c/c 9.06" (230 mm)
M8 (x4)
N24, N27 - 13.4" (340 mm)
N16 - 12.6" (320 mm)
18" (457 mm)
7.3"
(185 mm )
c/c 9.06" (230mm)
6.3" (160 mm)
18.8" (478 mm)
M8 (x4)
Figures
11
33
6.3"
(160 mm)
10.8" (275 mm)
18.7"
(475 mm)
5.5" (140 mm)
25" (635 mm)
6.3"
27.2" (690 mm)
14.6" (372 mm)
22
N16
N24
N27
N29
N40 44
ÊÒ½ÏĦ¼ÒÈăÌÄç
¹º½Ä˽ËÅÑîÃÇÍ
৘٫ڝ޼ୂӣ
4
(160 mm)

N16/24/27/29/40
RR
min. 2.75 ft (0.85 m)
5
IP 68
66
77
R
3x
Ø0.2" (5 mm
88
Rotation direction
N40
Recommended protection class
5

N16/24/27/29/40
N16 - 1 PH
m³/h
Pa
N16 - 3 PH
m³/h
Pa
9
6

N16/24/27/29/40
N24 - 1 PH
m³/h
Pa
N24 - 3 PH
m³/h
Pa
10
7

N16/24/27/29/40
N27 - 1 PH
m³/h
Pa
C
D
E
F
N27 - 3 PH
m³/h
Pa
11
8

N16/24/27/29/40
N29 - 3 PH
m³/h
Pa
E
F
G
H
N40 - 3 PH
m³/h
Pa
12
9

N16/24/27/29/40
1
2
Preface
Thank you for choosing Nederman. We are a world class supplier and developer of
products and solutions for the environmental technology sector.
Review all product documentation and the identification plate carefully prior to
installation, use and maintenance of this product. Replace documentation immediately
if lost.
All installation, repair and maintenance must be conducted by qualified personnel
using only Nederman original spare parts. Contact your nearest authorized dealer or
Nederman for advice on technical service or spare parts are needed.
Please contact your carrier and local Nederman representative immediately if there
are missing or damaged parts when delivered.
Nederman reserves the right, without notice, to improve our products and
documentation.
Safety
This document contains hazard information that is presented as a warning, caution or
note as follows:
WARNING! Risk of Personal Injury
Warnings indicate a potential hazard to the health and safety to personnel and
how to avoid that hazard.
CAUTION! Risk of Equipment Damage
Cautions indicate a potential hazard to the product but not to personnel and how to
avoid it.
NOTE! Notes contain information which the user should be aware.
3
3.1
Nederman Customer Service & Technical Support [email protected] [phone]
10
3.2
Description
N-Series are centrifugal fans mainly designed for use with Nederman extraction
products and ideal for welding fumes, steam dust or providing fresh air in confined and
enclosed spaces. These compact fans are easy to use indoors and outdoors
Dimensions
See Figures 1-3 Page 4
Pressure Drop/Fan Curves
See Figures 9-12 Pages 6-9
ATotal pressure
B Static pressure
CTotal pressure (1,1 kW, 1.5 hp)
D Static pressure (1,1 kW, 1.5 hp)
E Total pressure (1,5 kW, 2.0 hp)
F Static pressure (1,5 kW, 2.0 hp)
G Total pressure (2,2 kW, 3.0 hp)
H Static pressure (2,2 kW, 3.0 hp)

N16/24/27/29/40
Motor power See product label
Motor speed See motor label
Votage/Phase See motor label
Frequency See product label
Rated current See motor label
N16 29 lbs (13 kg)
N24 37 lbs (17 kg)
N27 37 lbs (17 kg)
N29 - 3 hp (2.2 kW)71 lbs (32 kg)
N40 - 2 hp (1.5 kW 55 lbs (25 kg)
N40 - 3 hp (2.2 kW 64 lbs (29 kg)
(–22°F to +104°F (–30°C to +40°C)
ÁÊŴÇÏT½ÅȽʹÌÍʽ max+140°F)(+600C)
N16 74-76 dB(A)
N 24 75-79 dB(A)
N27 75-79 dB(A)
N 29 70-80 dB(A)
N 40 60-80 dB(A)
** According to ISO 11203, with duct connected to inlet and outlet.
4
4.1
Installation
Mounting instructions N16/24/27/29/40
WARNING! Risk of explosion.
The fan must not be installed in an environment with danger of explosion or be used
to transport flammable or explosive dust or gases.
WARNING! Risk of personal injuries.
Guard nets must be mounted on the inlet and outlet of the fan, unless the fan is fixed
and/or directly connected to ducting system. See Figure 4 page 4.
WARNING! Risk of personal injuries.
A duct or hose must be fitted on the N40 fan inlet. See Figure 5 page 5.
Ensure the fan has not been damaged during transport. Fans without a stand are
designed to be mounted directly to other Nederman products.
Nederman Customer Service & Technical Support [email protected] [phone]
11
Max Airflow
N16 - 3/4 hp (0.55 kW)750 cfm (1250 m3/hr)
N24 - 1 hp (0.75 kW)900 cfm (1500 m3/hr)
N24 - 1.5 hp (1.1 kW) (230/460V 1030 cfm (1750 m3/hr)
N27 - 1.5 hp (1.1 kW) (110V) 825 cfm (1400 m3/hr)
N27 - 2 hp (1.5 kW) (230/460/575V)1150 cfm (1950 m3/hr)
N29 - 3 hp (2.2 kW) 1765 cfm (3000 m3/hr)
N40 - 2 hp (1.5 kW)1470 cfm (2500 m3/hr)
N40 - 3 hp (2.2 kW)2350 cfm (4000 m3/hr)
3.3 Technical Data
Table 3-1:
Weights:
Noise Level: **
Temperature

N16/24/27/29/40
4.2
5
5.1
5.2
If the fan is fitted to be mounted on a wall or in the ceiling, vibration secured fixing bolts
suitable for the wall or ceiling material are to be used. The bolts must each stand a
torque force of minimum 800 N.
If the fan is to be used indoors and is not mounted on another Nederman product, it is
to be mounted as near the outlet in the room as possible, in order to give under
pressure in the ductwork.
Electrical installation
Check that the mains voltage is the same as on the fan's sign plate. Then connect the
fan according to the wiring diagram in the fan's junction box. It is re-commended to
supply the fan with a lockable safety switch on the mains connection cable. A motor
over-load protector is always to be included in the electrical installation.
Variable speed drive is not an option with 1-phase fans with standard motors.
1 or 3-phase fans, a frequency converter can be used. (max frequency is the rated
frequency).
Use 16/24/27/29/40
Starting Instructions
WARNING! Risk of Personal Injury
The fan must not be used without ductwork connected unless the inlet and outlet are
equipped with approved guard nets.
Ear protectors is to be worn when working near the fan.
Check the cable connections for tightness.
Check the grounding of the electric motor.
Start the fan and check that it operates without any excessive vibration and noise.
On 3-phase fans it is recommended to check that the motor shaft rotates in the right
direction (see rotation arrow on the motor). If the shaft rotates in the wrong direction,
two of the connection cable conductors must be reversed. See Figure6.
Outdoor Use / Draining
Recommended protection. IP 68. See figure 7 Page 5.
If the fan is to be used without any protection outdoors or under other circumstances
where moisture and condensation can be present, it must be verified that the motor
has draining holes. Verify these holes are open and not clogged. In the lowest level in
one of the fan casings, a draining hole must be drilled (approx. 0.2" (5 mm)), see
Figure8. Then treat the hole with an anti-corrosive agent.
If the motor is not provided with draining holes the fan must be protected with a
suitable cover.
Nederman Customer Service & Technical Support [email protected] [phone]
12

N16/24/27/29/40
6 Maintenance
WARNING!Risk of personal injury
• Always disconnect the fan motor from mains with the isolator before starting any
main-tenance or repair work.
• Always use a breathing mask when repairing and servicing the system.
WARNING! Risk of personal injuries.
Always use a respirator when repairing and servicing the system
Installation, repair and maintenance work is to be carried out by qualified personnel
using only original Nederman spare parts. Contact your nearest authorized
distributor or Nederman for advice on technical service.
NOTE! Service intervals are based on the unit being professionally maintained.
Maintenance is recommended at least once a year.
• Listen for noise and touch the fan casings with the hand and notice if the fan
vibrates in an abnormal way. If necessary, disconnect the fan from power,
dismount the fan and clean the impeller (not possible on N29 fan).
(wear a respirator)
• Check the fan’s suction capacity. On 3-phase fans, check that the motor shaft
rotates in the right direction. Check that the ducts are not blocked. Clean if
necessary (wear a respirator).
• Check the electrical installation.
•Check that the power cable is not worn or damaged.
• If the fan has been mounted on a wall or in the ceiling, check the fittings.
• Check and tighten any loose duct connections.
• Check that the guard nets are in position.
6.1 Spare Parts
7 Recycling
The product has been designed for component materials to be recycled. Different
material types must be handled according to relevant local regulations. Contact the
distributor or Nederman if uncertainties arise when scrapping the product at the end of
its service life.
Nederman Customer Service & Technical Support [email protected] [phone]
13
CAUTION! Risk of equipment damage
Use only Nederman original spare parts and accessories.
Contact your nearest authorized distributor or Nederman for advice on technical service
or if you require help with spare parts. See also www.nederman.com.
Ordering Spare Parts
When ordering spare parts always state the following:
• The part number and control number (see the product identification plate).
• Detail number and name of the spare part
(see www.nederman.com/en/service/spare-part-search).
• Quantity of the parts required.

N16/24/27/29/40
Customer Service and Technical Support
Nederman Corporation USA
4404-A Chesapeake Drive
Charlotte, NC 28216
336-821-0800
www.nederman.com
The Nederman Group is one of the World’s leading suppliers of products and solutions within
the environmental technology sector focusing on industrial air filtration and recycling. These
products and solutions reducethe environmental impact of industrial production and create
safe and clean working environments while boosting production efficiency.
The group’s offering covers the design stage through installation, commissioning and servicing
with subsidiaries in 29countries and agents and distributors in over 30countries.
Nederman is ISO 9001 and 14001 certified and develops and produces in its own manufacturing
and assembly facilities in Europe, North America and Asia.
NedermanServiceCapabilities
Nederman has certified service partners trained extensively in servicing our machinery. Make
sure to choose a certified technician to service your Nederman equipment as they have the
correct tools and knowledge to solve any machinery issues and improve its performance. Be
sure to ask if your technician is certified by Nederman.
Our services for extraction and filtratio`n systems are customized to your particular needs. We
work with you to understand your needs, then develop a program to meet your specific
needs. Our services include: (not all services available in all locations)
Bag & Filter Change-outs
Bag Selection Recommendations
Collector Re-builds
Dye Testing for Leakage
Electrical Tests - Current, Voltage
Emergency Call-outs
Filter Media Analysis
Mechanical Survey and Repair
Multi-year Contracts
New Collector Start-upService
On-going Technical Support
Preventative Maintenance Programs
Repair and Replace
Gauges/Timers/Valves
Stack Emission Testing
Training Programs
Troubleshooting / Auditing
Velocity, Pressure and Temperature Tests
Written Service Report
Customer Service and Technical Support
Nederman Corporation USA
4404-A Chesapeake Drive
Charlotte, NC 28216
336-821-0800
www.nederman.com
Nederman Customer Service & Technical Support [e-mail] [phone]
14
