nedis SPBT3600BK User manual

ned.is/spbt3600bk
Bluetooth®
Speaker
with dynamic RGB lights
SPBT3600BK

aQuick start guide 5
cKurzanleitung 9
bGuide de démarrage rapide 14
dSnelstartgids 19
jGuida rapida all’avvio 23
hGuía de inicio rápido 28
iGuia de iniciação rápida 33
eSnabbstartsguide 37
gPika-aloitusopas 42
fHurtigguide 46
2Vejledning til hurtig start 51
kGyors beüzemelési útmutató 55
nPrzewodnik Szybki start 60
xΟδηγός γρήγορης εκκίνησης 65
1Rýchly návod 70
lRychlý návod 74
yGhid rapid de inițiere 79

1
2
3
4
5
6
7
8
q
9
A

4
Specications
Product Bluetooth® Speaker
Article number SPBT3600BK
Maximum battery
play time (at 50%
volume)
LED o: up to 12 hours
LED on: up to 6 hours
Maximum
Charging time
Up to 3 hours
Bluetooth® version V5.1
Bluetooth®
frequency range
2402 - 2480 MHz
Maximum
transmission power
2 dBm
Peak audio output 16 W (2 × 8 W)
RMS audio output 14 W (2 × 7 W)
Driver diameter 45 mm
Impedance 4 Ohm
Protection rating IPX6
RGB LED lights Yes
True Wireless
Stereo (TWS)
Yes
Connections USB Type-C™, AUX, MicroSD
card slot
Battery capacity 1500 mAh
Charging input
power
5.0 VDC ; 1.0 A

5
aQuick start guide
Bluetooth® Speaker SPBT3600BK
For more information see the extended
manual online: ned.is/spbt3600bk
Intended use
This product is intended to stream audio from your
media device via Bluetooth®, an audio cable or from a
MicroSD card.
This product is intended for indoor and outdoor use.
This product is not intended for professional use.
Any modication of the product may have
consequences for safety, warranty and proper
functioning.
Main parts (image A)
1AUX port
2MicroSD card slot
3USB-C charging port
4Mode button
5Volume up / next
track button
6Play/pause button
7Volume down /
previous track
button
8Power button
9Indicator LED
qUSB – USB-C
charging cable
Safety instructions
-
WARNING
• Ensure you have fully read and understood the
instructions in this document before you install or
use the product. Keep the packaging and this
document for future reference.
• Only use the product as described in this
document.
• Do not use the product if a part is damaged or
defective. Replace a damaged or defective product
immediately.

6
• Disconnect the product from the power source
and other equipment if problems occur.
• Do not drop the product and avoid bumping.
• This product may only be serviced by a qualied
technician for maintenance to reduce the risk of
electric shock.
• Do not expose the product to a high pressure of
water or moisture.
• Do not immerse the product in water.
• Do not charge when the product is wet.
• Do not dismantle, open or shred cells or batteries.
• Do not expose cells or batteries to heat or re.
Avoid storage in direct sunlight.
• Do not expose the product to direct sunlight,
naked ames or heat.
• Do not subject cells or batteries to mechanical
shock.
• Disconnect the product from the electrical outlet
and other equipment if problems occur.
• Extended exposure to high volumes can cause
hearing loss.
• Only use the provided USB charging cable.
• Charge the battery for at least 3 hours before using
the product for the rst time.
• Do not short-circuit a cell or a battery.
• Do not store cells or batteries haphazardly in a box
or drawer where they may short-circuit each other
or be short-circuited by other metal objects.
Switching on the product
1. Press and hold the power button A8to switch on
the product.
The product automatically enters Bluetooth pairing
mode.
2. Press and hold the power button A8to switch o
the product.
4The product automatically switches o after 10
minutes of inactivity.

7
Charging the product
4You can charge the product in two ways.
For charging via the power outlet:
1. Plug the USB-C connector of the USB - USB-C
charging cable Aqinto the USB-C charging port
A3.
2. Plug the other end of Aqinto a 5V/1-2A USB
adapter (not provided).
3. Plug the USB adapter into a power outlet.
For charging via the USB charging cable:
1. Plug the USB-C connector of Aqinto A3.
2. Plug the other end of Aqinto a 5/1-2A USB
power source.
A PC is a usable power source for example.
4When the battery is low the speaker emits the
voice alert "Please charge".
Playing music from a Bluetooth®
audio source
1. Switch on the product.
The product automatically enters Bluetooth pairing
mode.
4The indicator LED A9ashes blue quickly to
indicate paring mode is active.
2. Activate Bluetooth on your audio source and
connect with the product (SPBT3600BK).
4A9lights up continuously to indicate pairing is
successful.
3. Play music from a Bluetooth® connected audio
source.
Playing music from an AUX audio
source
1. Switch on the product.
2. Plug a 3.5 mm audio cable (not included) into the
AUX port A1.

8
3. Plug the other end of the 3.5 mm audio cable into
your audio source.
4. Play music from your audio source.
4The indicator LED A9ashes blue slowly while
the product is playing music.
4Bluetooth® is deactivated when you use a dierent
audio source.
4Press the mode button A4to reactivate
Bluetooth® mode.
Switching between modes
Press the mode button A4to switch between
Bluetooth, MicroSD, and AUX mode.
Controlling the music
1. Press and hold the volume up / next track button
A5or the volume down / previous track button
A7to skip between tracks.
2. Press A5or A7to control the volume.
3. Press the play / pause button A6to play or pause
a track.
4You can also control music and volume from your
audio source.
RGB lights
Double press the mode button A4to switch on the
RGB light, to cycle between dierent light modes, or
to switch o the RBG light.
Resetting the product
If the product does not respond. Press and hold the
mode button A4to reset the product.
Press and hold A5and A7simultaneously to reset
the device to factory settings.
Declaration of Conformity
We, Nedis B.V. declare as manufacturer that the

9
product SPBT3600BK from our brand Nedis®,
produced in China, has been tested according to all
relevant CE standards and regulations and that all
tests have been passed successfully. This includes, but
is not limited to the RED 2014/53/EU regulation.
The complete Declaration of Conformity (and the
safety datasheet if applicable) can be found and
downloaded via:
nedis.com/SPBT3600BK#support
cKurzanleitung
Bluetooth®-
Lautsprecher
SPBT3600BK
Weitere Informationen nden Sie in
der erweiterten Anleitung online:
ned.is/spbt3600bk
Bestimmungsgemäße Verwendung
Dieses Produkt dient zum Streamen von
Audiosignalen von Ihrem Mediengerät über
Bluetooth®, per Audiokabel oder von einer
MicroSD-Karte.
Dieses Produkt ist zur Verwendung drinnen und
draußen gedacht.
Dieses Produkt ist nicht für den professionellen Einsatz
gedacht.
Jegliche Modikation des Produkts kann Folgen
für die Sicherheit, Garantie und ordnungsgemäße
Funktionalität haben.
Hauptbestandteile (Abbildung A)
1AUX-Anschluss
2Einschub für Micro-
SD-Karte
3USB-C-
Ladeanschluss
4Modus-Taste

10
5Lautstärke erhöhen /
nächster Titel Taste
6Play/Pause-Taste
7Lautstärke
verringern /
vorheriger Titel Taste
8Ein/Aus-Taste
9Anzeige-LED
qUSB – USB-C
Ladekabel
Sicherheitshinweise
-
WARNUNG
• Vergewissern Sie sich, dass Sie die Anweisungen in
diesem Dokument vollständig gelesen und
verstanden haben, bevor Sie das Produkt
installieren oder verwenden. Heben Sie die
Verpackung und dieses Dokument zum späteren
Nachschlagen auf.
• Verwenden Sie das Produkt nur wie in diesem
Dokument beschrieben.
• Verwenden Sie das Produkt nicht, wenn ein Teil
beschädigt ist oder es einen Mangel aufweist.
Ersetzen Sie ein beschädigtes oder defektes
Produkt unverzüglich.
• Trennen Sie das Produkt von der Stromquelle und
anderer Ausrüstung, falls Probleme auftreten.
• Lassen Sie das Produkt nicht herunterfallen und
vermeiden Sie Kollisionen.
• Dieses Produkt darf nur von einem ausgebildeten
Techniker gewartet werden, um die Gefahr eines
Stromschlags zu reduzieren.
• Setzen Sie das Produkt keinem Wasser oder
Feuchtigkeit mit hohem Druck aus.
• Tauchen Sie das Produkt nicht in Wasser.
• Laden Sie das Gerät nicht auf, wenn es nass ist.
• Batterien oder Akkus dürfen nicht zerlegt, geönet
oder zerstört werden.
• Setzen Sie Akkus oder Batterien keiner Hitze oder
Feuer aus. Vermeiden Sie die Lagerung in direktem
Sonnenlicht.
